Powerline APLG User manual

INSTRUCTION MANUAL
APLG Green Pipe Laser

2

3
Please read this instruction manual before operating this product.
Please store this instruction manual in the carry case for future reference.
CAUTION: Class 3 Laser Product
Do not stare directly into the laser beam from apertures.
Do not disassemble the instrument or attempt to perform any internal servicing
as this will void your warranty. No user serviceable parts included.
Only approved and authorised service technicians can carry out warranty repairs.
SAFETY

4
Powerline APLG
Please ensure the following items are included with your laser.
If anything is missing please contact your retailer.
ITEM CHECKLIST
Rechargeable
battery pack
Alkaline
battery pack
Car charger Charger
Carry case
4x Sets of
interchangeable feet
2x Adjustable
laser targets
Remote control
Target
6
in
8
150
mm
200
10 250
Target
16
20 500
in
400
mm
Pipe Laser Remote

5
Laser port
4x Interchangeable feet
LCD Display
Battery pack
PRODUCT OVERVIEW
Control panel

6
SET ENT
CONTROL PANEL
Negative grade adjustment
Positive grade adjustment
Enter
Dot right
Dot left
Power
LCD Display
LCD backlight
Grade mode

7
Pipe Laser Remote
REMOTE CONTROL PANEL
LCD backlight
Dot right
LED light
Power
Dot left
Speaker

8
USING YOUR LASER
Power Supply
‣The Powerline APL pipe laser is supplied with a rechargeable Ni-MH battery
pack that is located in the base of the unit. An alkaline battery pack is also
supplied with four D batteries.
‣It is recommended that the battery pack be completely charged before use.
‣Charging time is approximately 5 hours.
‣Use of the unit over time and changes in temperature may cause increases
or decreases in charging and operation time.
‣The power indicator light will flash when the battery is low. The unit should
be re-charged as soon as possible. Alternatively, the alkaline batteries should
be replaced.
‣To charge the unit insert the charger into the port on the battery pack.
Progress will be shown by the power indicator display on the charger as below:
Red (constant) = Battery is charging.
Green (constant) = Battery is charged.

9
Setting Up
‣Select a place as close as practical to the work site.
Ensure the location is clear of traffic.
‣Place the laser onto a level surface. Use the bubble vial on
the LCD screen to level the unit.
Operation
‣To turn the unit on press the power switch.
‣Press and hold the dot left and dot right buttons simultaneously
to centre the laser beam.
‣Use the dot left and dot right buttons to adjust the beam as required.
The LCD screen will indicate the position of the beam. See diagram below:
Laser dot is in the far left position
Laser dot is in the left position
Laser dot is centred
Laser dot is in the right position
Laser dot is in the far right position

10
Tilt Alarm
The unit may be levelled by using the bubble vial displayed on the
LCD screen. See diagram below:
Flashing arrow indicates the left side of the laser
is beyond the levelling range.
Laser is tilted left.
Laser is level.
Laser is tilted right.
Flashing arrow indicates the right side of the laser
is beyond the levelling range.
