Powerline S5BLG User manual

INSTRUCTION MANUAL
S5BLG Green Dot Laser

3
Please read this instruction manual before operating this product.
Please store this instruction manual in the carry case for future reference.
CAUTION: Class 3 Laser Product
Do not stare directly into the laser beam from apertures.
Do not disassemble the instrument or attempt to perform any internal servicing
as this will void your warranty. No user serviceable parts included.
Only approved and authorised service technicians can carry out warranty repairs.
SAFETY

4
Carry case
Laser glasses
Batteries
Indoor tripodLaser target
Magnetic base
Powerline S5BLG
Please ensure the following items are included with your laser.
If anything is missing please contact your retailer.
ITEM CHECKLIST
INCHES CM
1
1
2
3
4
5
6
7
2
3

5
PRODUCT OVERVIEW
Dot laser ports (x5)
Battery indicator
Lock indicator
Power / locking switch

6
USING YOUR LASER
Setting Up
Power Supply
Operation
‣Select a place as close as practical to the work site.
Ensure the location is clear of traffic.
‣Place the laser on a level surface such as a bench or mount.
The S5BLG is powered by three AA alkaline batteries.
‣To turn the unit on turn the power switch to “on” position.
Self levelling will commence and the 5 laser dots will appear.
‣If the unit is outside the self levelling range the unit will not
level causing the speaker to beep and the laser beam to turn off.

7
CARE AND MAINTENANCE
‣This is a precision instrument and should always be transported
within the carry case provided.
‣Always turn the on/off lock to “off” when transporting the unit.
‣Whenever possible, store the instrument in a dry, shady location.
‣The S5BLG should be calibrated every 6 months, if ongoing
accurate levelling is required or an impact has occurred.
‣The operator should check the S5BLG for accuracy before
precision levelling is attempted.
‣Clean the instrument with a dry, soft cloth after use in
dusty, damp or wet conditions before storing.
‣Smudges and fingerprints may be removed with a damp tissue
or a soft, lint-free cloth.

8
WARRANTY
The Powerline S5BLG comes with a 3 year manufacturers warranty.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
Separate to the above Australia Consumer Law, Spot-on oers a global warranty.

9
SERVICE AND SUPPORT
Customer Support
To assist you with any queries or technical questions please contact the
customer support line: 1300 658 338
Operates 5 days a week: 8am - 5pm (EST)
30 Day Free Service
If your laser is out of calibration within the rst 30 days of purchase you
are entitled to a free calibration adjustment. For more information please
contact your retailer or Spot-on.

10
SPECIFICATIONS
Specications Powerline S5BLG
Product code 50073
Warranty 3 Years
Accuracy ±2mm at 10m
Range 20m
Levelling range ±4°
Laser class 3 Green
Battery life 10 hours
Battery type 3x AA
Dots 5
IP rating 54
Weight (kg) 0.60
Dimensions (mm) 112x113x63

www.spoton.com.au
