PowerPac PPDF872 User manual

Model: PPDF872
200705-24

Your compact Deep Fryer includes many features to enable safe and successful frying.
The cool-to-touch exterior has been designed for additional safety. The variable
thermostat allows the temperature to be adjusted and controlled to ensure that food
is fried to the exact degree of crispness required.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Fry Basket
Variable Thermostat
Power Pilot Light
Temperature Pilot Light
Fry Bowl
Viewing Window
Filter System
Read Cable Shell
Housing
PARTS & DESCRIPTION
1

ATTENTION :
Read this booklet carefully it contains important instructions for a safe installation, use
and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
This appliance is NOT suitable to be used in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air).
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
Place and use the appliance on a horizontal, stable and heat-resistant surface.
Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
Any accessories NOT recommended by the manufacturer may cause injuries to
persons.
During use and storage, the appliance must be kept at a safe distance from heat
sources (open flame, heaters, stoves, etc.) or any flammable and/or potentially
explosive substances.
WARNINGS
2

13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
If you are using the appliance for the first time, you should:
a. Open the lid and clean the fry basket & fry bowl thoroughly with hot water &
detergent with a non-abrasive sponge.
Notice: you can use a dishwasher to clean the fry basket & fry bowl;
b. Clean the inside and outside of the appliance with a wet cloth.
c. Use only metal utensils with insulated handles in hot oil
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
• switch the power on when there is no oil in the fry bowl;
• cover the appliance during functioning
• obstruct totally nor partially the filter system;
• insert objects or body parts inside the protection cover of the appliance;
• use the appliance near curtains or textiles;
• leave the appliance unsupervised during operation.
Plug and unplug the power cable with dry hands and hold it firmly. Always unplug
the power cable to avoid overheating and avoid stretching it (DO NOT pull it, tug it
or use it to drag the appliance to which is connected). Before unplugging the
appliance, switch it off, using the proper command on the control panel.
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
DO NOT soak the appliance in water or other liquids, wash it under the tap, or let
any liquid flow into the internal casing of the appliance to prevent electric shock. In
case of accidental fall in water, DO NOT try to take it out, but first of all unplug
immediately the power cable from the socket.
Place the appliance at a proper distance from the objects or surrounding walls
making sure that its functioning will not cause accidental damages. There should
be at least 10 cm of free space from the back, left & right sides, and the top of the
deep fryer. Never put things on top of the deep fryer, for this will prevent air flow
and reduce the effect of hot air heating.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily.
Always remember to unplug the power cable of the appliance if it is NOT used for a
long period, before storing, cleaning or performing any maintenance operation.
Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
The appliance shall NOT be placed on a surface or in the vicinity of objects which
can be damaged by heat, such as carpets or plastics. When using the deep fryer, the
surface that the deep fryer is placed upon may become very hot.
3

23.
24.
25.
26.
27.
28.
29.
30.
During the period of frying, high temperature steam may be emitted from the filter
system. One’s hands and face should be angled away from the steam as well as the
filter system.
DO NOT touch the inside of the deep fryer while it is operating. This is to prevent
scalding. The bottom of the fryer becomes exceedingly hot as the deep fryer
operates.
If smoke is observed coming out of the deep fryer, unplug the power cable
immediately. Remove the frying pan away from the deep fryer after it has stopped
smoking.
Before cleaning or storing the appliance, remove the fry basket from the deep fryer
(Caution: The fry bowl is very hot at this time!) and leave to cool for at least
30 minutes.
The deep fryer is limited to normal domestic usage. It should NOT be used in the
dining rooms of shops, office, farms or other working environments. And it should
not be used by customers in hotels, motels, guest houses or breakfast rooms, or
other accommodation environments without the use of a functioning kitchen.
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cord out of reach of children less than 8 years.
Save these instructions.
4

The deep fryer can be used to cook many types of food. The additional food making
manual will assist you to understand this product.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
Insert the plug into the grounded socket.
Use good quality solid fat or frying oil and pour into the fry bowl, between the
minimum & maximum marks as indicated on the fry bowl. You can use corn oil or
peanut oil, but avoid margarine, olive oil or butter. These are not recommended as
they have a lower smoking temperature.
When using solid fat, place less than 1 kg into the bowl to melt on the lowest
temperature setting.
Put the fry basket into the fry bowl (containing oil or fat) and close the lid.
Switch on the power and set the temperature taking into account the food to be
cooked. As a general guide, foods that have been pre-cooked in some way need a
higher temperature than raw food, i.e. potato croquettes made from pre-cooked
potato need higher temperature than raw bread dough.
Use only metal utensils with insulated handles in hot oil.
Care should be taken to cook foods thoroughly as the exterior may show signs of
turning golden brown before the interior is cooked.
When frying battered food, drain off excess batter, carefully place into the oil with
the basket already in the oil. Close lid and fry for the requested duration.
If you want to add more food during the frying, please ensure that the surface of
the food is dry. All foodstuffs, particularly potatoes and frozen food, have significant
moisture content which turns into steam and escapes through the filter lid.
Opening the lid fully in one swift movement will disperse the steam and prevent
burning.
Note: Always use old potatoes to make chips. Cut the potatoes into even-sized
chips, ensure that they are evenly cooked, rinse the potato chips and dry
thoroughly before adding into the deep fryer.
When cooking is complete, lift the fry basket from the oil and shake the basket over
the oil if necessary. Remove the basket and turn the contents onto absorbent paper
towels before serving (to absorb excess grease and retain crispness).
After completing the cooking of one batch of food, the deep fryer is ready to cook
another batch of food.
Switch off the power and remove the plug from the mains after your finish frying.
Remember that oil retains its temperature for a long while after use.
Note: If you wish to remove oil from the fry bowl, it is recommended that the
pouring lip be used to reduce spillage
To get the maximum out of your fryer, you can retain the cooled and strained oil
inside the fry bowl ready for the next frying session with the lid acting as a dust
cover.
USING YOUR APPLIANCE
5

1.
2.
3.
4.
5.
6.
7.
Your deep fryer has a filter system comprising of deflectors, which collect drops of
oil from the steam as it passes through. After several cooking sessions the filter lid
should be removed from the fryer, plunged into hot sudsy water and left to soak for
5-10 minutes. It should then be rinsed thoroughly and dried.
To remove lid, lift to vertical position and remove with a straight pull upward.
Reverse the above sequence to replace.
As with any cooking vessel your fryer should be cleaned after every use.
After the oil has cooled, remove the fry bowl and pour out the oil. The oil should be
filtered through fine muslin or absorbent paper placed in a suitable funnel
(excessive discolor oil should be discarded).
The fry bowl should be wiped with absorbent paper, then with a damp cloth with
some detergent and finally with a dry cloth. Stubborn deposits can be removed by
using non-abrasive cleaners with a soft pad.
The strained oil may be stored either in the fryer or in an airtight container in a dark
cupboard. It is recommended that you discard the oil after about 10 times of use.
The outside and lid should be wiped with a damp cloth a dried thoroughly. In order
to keep your fry basket in good working order, it is recommended that it be
thoroughly cleaned in hot sudsy water after every.
CLEANING
6

Frying Time and temperature Chart
Conversion Table
The temperature control of your Deep Fryer is calibrated in degrees C.
However, to enable you to cook recipes marked in degrees F, the following
approximately table is provide.
Fresh Chips maximum basket Capacity 400 g
Fry for 180°C for 9 – 11 minutes, then 190°C
for 1 – 2 minutes until golden brown
Frozen Chips See the manufacturers Recommendations
Fish Scampi frozen in crumbs (just enough to loosely cover
the base of basket)
Fry for 170°C for 3 – 5 minutes
Fresh Whitebait just enough to cover base of basket
Fry for 190°C for 1 – 2 minutes
Fresh Cod or Haddock or
batter
Fry for 160°C for 5 – 10 minutes
(depends on thickness of fish)
Frozen Cod or Haddock or
portions in crumbs or batter
Fry for 190°C for 10 – 15 minutes
(depends on thickness of fish)
Frozen Plaice Fry for 190°C for 5 – 6 minutes
Frozen Hamburgers 2 oz / 50 g
Fry for 150°C for 3 – 5 minutes
Chicken portions in crumbs Fry for 160°C for 10 – 12 minutes
(1 – 3 cm size)
Fry for 160°C for 15 – 30 minutes
(3 – 7 cm size)
Frozen Veal Escalope Fry for 170°C for 3 – 8 minutes
(depends on thickness)
Fresh Chicken Drum Stick in
crumbs
Fry for 170°C for 15 minutes
°C °F
90 195
110 230
130 265
°C °F
150 300
170 340
190 375
7

•
•
•
•
•
•
normal wear and tear
if the steps (as laid out in the section regarding Warnings) have not been observed
e.g. overloading of the appliance, use of non-approved accessories
if the appliance has not been properly maintained, if force has been used against it
or if it has been damaged in any other way
damage caused by non-observance of the user manual or non-compliance with the
installation instructions
errors or faults owing to defects in the distribution system
if the appliance has been repaired or modified or changed in any way or by any
person not properly authorised
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discharge the
appliance at your local recycling center.
DISPOSAL: Do not dispose this product as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
ENVIRONMENTAL TIP
The manufacturer provides warranty in accordance with the legislation of the
customer’s own country of residence, with a minimum of 1 year, starting from the date
on which the appliance is sold to the end user.
The warranty covers defects in material and workmanship.
The repairs under warranty may only be carried out by an authorised service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date clearly indicated) must be submitted.
The warranty will not apply in cases of:
WARRANTY
8

PPDF872
MODEL
220-240V ~ 50/60Hz
VOLTAGE
850~950W
WATTS(W)
SPECIFICATION
9
