powersoft DigiMod 1000 User manual

®
Via Enrico Conti, 5
50018 Scandicci (FI)
www.powersoft-audio.com
Technical Support
Should you encounter any difculties in operating this amplier
module, please do not hesitate to contact our technical support.
We will be glad to be of assistance.
suppor[email protected]
Powersoft
Via Enrico Conti, 13/15
50018 Scandicci - Firenze
Italy
Tel/fax: [phone]
DigiMod 1000
DigiMod 1000 is a class-D amplier module delivering up to
1000W, and capable of driving an additional 2-channel output stage
(DigiMod 1000NPS) to cover a wide range of applications, from
small/medium subwoofers to 2-way monitors, as well as 3-way
systems.
Specically designed DSP boards with advanced processing, remote
control and networking capabilities are available for DigiMod 1000,
to perfectly t with the amplier and providing a complete solution
in a compact package.
Quick Guide DigiMod 1000
Specications
AC Mains Power
Operating voltage
AC 195V – 250V @ 50/60Hz,
I*
nom = 1.6 ARMS
AC 95V – 125V @ 50/60Hz,
I*
nom = 3.2 ARMS
*1/8 max output power
Efciency > 85% (typical )
Power consumption
I/8 of max power @ 8 � bridged 178 VA
Max aux supply current draw 200 mA
Construction
Dimensions 216 mm x 122 mm x 53 mm
(8.5” x 4.8” x 2”)
Weight 1.05 kg (2.3 lb)

OUT 1
OUT 2
AC MAINSGROUND
Place jumper to set
operating voltage to
115 VAC
Phoenix
pitch: 5.08
SIGN. GROUND 1
BAL. INPUT 1 +
BAL. INPUT 1 –
BY11
BY21
SIGN. GROUND 2
AUX SUPPLY GND
MUTE
+12 VDC OUT
–12 VDC OUT
BAL. INPUT 2 +
BAL. INPUT 2 –
BY12
BY22
EARECT1
PROTECT1
TEMP
MUTE
+12VDC OUT
GND
PROTECT2
EARECT2
Remove jumper
to enable DSP
Remove jumper to
insert external circuit
Remove jumper to
insert external circuit
Remove jumper
to enable DSP
jumper not in place
jumper in place
DEFAULT SETTINGS
CN16
CN16
CN17
CN17 CN3
CN11
CN18
CN18
CN7
CN15 CN12
CN14
pin 1
Via Enrico Conti, 5
50018 Scandicci (FI)
www.powersoft-audio.com
CN16
1EARECT2
2PROTECT2
3GND
4+12VDC OUT
5MUTE
6TEMP
7PROTECT1
8EARECT1
CN12
1SIGN. GND 2
2 BAL. INPUT 2 +
3 BAL . INPUT 2 –
4BY12
5BY22
CN11
1SIGN. GND 1
2 BAL. INPUT 1 +
3 BAL . INPUT 1 –
4BY12
5BY22
CN17
1BY31
2BY 21
3BY 21
4BY11
CN18
1BY12
2 BY22
3 BY22
4BY32
CN14
1AUX SUP. GND
2MUTE
3+12VDV
4–12V DC
DigiMod 1000
