PowerWalker BP A24R-4x9Ah User manual

User Manual
Battery Pack

1. Important Safety Warnings
Please comply with all warnings and operating instructions in this
instruction strictly. Read carefully the following instructions before installing
the unit. Do not operate this unit before reading through all safety
information and operating instructions carefully.
Do not try to assemble or repair the unit yourself, contact your local
supplier, seek for help of qualified technician
To eliminate any overheating of the battery box, keep all ventilation
openings free from obstruction and do not place any foreign objects on
top of the battery bank. Keep the battery box 20 cm away from the wall.
Make sure the battery box is installed within the proper environment as
specified. (0-40°C and 30-90% non-condensing humidity)
Do not install the battery box under direct sunlight. Your warranty will be
void if the batteries fail due to overheating.
This battery box is not designed for use in dusty, corrosive and salty
environment.
The warranty for this battery bank will be void if water or other liquid is
spilled or poured directly onto the battery box. Similarly we do not
warrant any damage to the battery box if foreign objects are deliberately
or accidentally inserted into the battery box enclosure.
The battery will discharge naturally if the system is unused for a period of
time.
It should be recharged every 2-3 months if unused. If this is not done,
then the warranty will be null and void. During normal operation, the
batteries will be automatically remained in charged condition.
Servicing of batteries should be performed or supervised by trained
personnel with knowledge of batteries and the required precautions.
When replacing batteries, it is necessary to replace ALL batteries with the
same quantity, type & capacity.
CAUTION – Do not dispose of battery or batteries in a fire. The battery
may explode.
CAUTION – Do not open or mutilate the batteries. The electrolyte from
the batteries is toxic and harmful to the skin and eyes.
CAUTION – Risk of Electric Shock –Hazardous voltage may exist between
battery terminals and ground. Test before touching with bare hands.

Storage & Maintenance
The unit contains no user-serviceable parts. If the battery service life
(3~5 years at 25°C ambient temperature) has been exceeded, the
batteries must be replaced. In this case, please contact your dealer.
Storage
Before storing, charge the unit 4 hours. Store the unit covered and
upright in a cool, dry location. During storage, recharge the battery in
accordance with the following table:
Storage Temperature Recharge Frequency Charging Duration
-25°C - 40°C Every 3 months 1-2 hours
40°C - 45°C Every 2 months 1-2 hours
Be sure to deliver the spent battery to a recycling facility or ship
it to your dealer in the replacement battery packing material.
Installation and Setup
NOTE: Before installation, please inspect the unit. Be sure that nothing inside
the package is damaged. Please keep the original package in a safe place for
future use
CAUTION –A battery can present a risk of electrical shock and high short
circuit current. The following precaution should be observed when
working on batteries:
1. Remove watches, rings, or other metal objects.
2. Use tools with insulated handles.
3. Wear rubber gloves and boots.
4. Do not lay tools or metal parts on top of batteries.
5. Disconnect charging source prior to connecting or disconnecting
battery terminals.
Do not plug or unplug the battery connector if UPS works in DC
(discharging) mode.

450MM
450MM 350MM
350MM
Battery assembly A
SOP - How to assemble BP A24R-4x9Ah

2Asbelowshown, lockthebaffleofbatteryonthebase. Screw: 38-000008 -XXG*4;Torque:
8KGF-CM
1Asbelowshown,inserttwobatterypacksblacklineonP5&P10 terminalof
thePCBboard ；Inserttheswitchinsurance shortredlineontheleftsideofthe
batteryredterminal, and thelongredlineontherightsideofthebatteryred
terminal.
插红线
插红线
P10 P5
Battery assembly B
