Gossen MetraWatt Kompakt Master Z502H Owner's manual

Supplement
Z502H – Kompakt Akku-Pack Master
Z502O – Akkupack 3-447-108-27
2/10.22
Gossen Metrawatt GmbH 1
Safety Instructions
Observe this documentation, in particular all
included safety information, in order to pro-
tect yourself and others from injury, and to
prevent damage to the device.
• Carefully and completely read and
adhere to the documentation for the
associated test instrument.
The respective documents can be found
at http://www.gossenmetrawatt.com.
Retain these documents for future refer-
ence.
• Observe and comply with all safety regu-
lations which are applicable for your
work environment.
• Use the battery set in undamaged condi-
tion only.
Inspect the battery set before use. Pay
particular attention to damage.
• Do not use the battery set after long peri-
ods of storage under unfavorable condi-
tions (e.g. humidity, dust or extreme
temperature).
• The battery set must not be exposed to
direct sunlight.
• Only use the battery set in compliance
with the specified technical data.
• Batteries may only be charged in
undamaged condition.
Inspect the batteries before use. Pay
particular attention to leaky and dam-
aged batteries.
Intended Use / Use for Intended Purpose
Battery set Kompakt Master Z502H is exclu-
sively used for the power supply of the follow-
ing test instruments: PROFITEST MF Series,
PROFITEST MASTER IQ Series, PROFITEST
MASTER Series, PROFITEST INTRO,
METRISO Series.
Battery set Z502O is exclusively used for the
power supply of the following test instruments:
PROFITEST MF Series, PROFITEST INTRO,
METRISO Series.
Use for Other than Intended Purpose
Use of the product for any purposes other
than those described in this supplement, or
in the operating instructions for the respec-
tive test instrument, is contrary to use for
intended purpose.
Liability and Guarantee
Gossen Metrawatt GmbH assumes no liability
for property damage, personal injury or conse-
quential damage resulting from improper or
incorrect use of the product, in particular due
to failure to observe the product documenta-
tion. Furthermore, all guarantee claims are ren-
dered null and void in such cases.
Opening the Accessory / Repairs
Unauthorized modification or opening of the
accessory is prohibited.

© Gossen Metrawatt GmbH
Prepared in Germany • Subject to change, errors excepted • PDF version available on the Internet
All trademarks, registered trademarks, logos, product names, and company names are the property of
their respective owners.
Gossen Metrawatt GmbH
Südwestpark 15
90449 Nürnberg • Germany
Phone [phone]
Fax [phone]
E-Mail [e-mail]
www.gossenmetrawatt.com
Utilized Symbols
Technical Data
Scope of Delivery
Use
The battery set must be applied and con-
nected as described in the documentation of
the respective test instrument.
The battery set may only be charged with
charger Z502R.
Returns and Environmentally Sound Disposal
This product is subject to directive 2006/66/
EC on batteries and accumulators and
waste batteries and accumulators and its
German national equivalent implemented as
the Battery Act (BattG) on the marketing,
return and environmentally sound disposal of
batteries and accumulators.
The symbol at the left indicates that
batteries and rechargeable batter-
ies must be disposed of in accor-
dance with applicable legal regula-
tions. Batteries and rechargeable batteries
may not be disposed of with household
trash. In order to dispose of the batteries or
rechargeable batteries, remove them from
the instrument and bring them to a desig-
nated collection point.
Segregated disposal and recycling con-
serves resources and protects our health
and the environment.
Current and further information is available
on our website at http://www.gossenme-
trawatt.com under the search terms “WEEE”
and “environmental protection”.
European conformity marking
The test instrument may not be
disposed of with household
trash (see Returns and Environ-
mentally Sound Disposal 2).
NiMH
The battery set must be fed into
the recycling loop for recharge-
able nickel metal hydrid batter-
ies.
Dimensions:
(L × W × H)
Approx.
63 mm × 30 mm × 61 mm
Weight: Approx. 250 g
Terminals: for 9-V block battery clips
Charging
capacity:
- Z502H
- Z502O
2000 mAh
2500 mAh
Voltage: 9.6 V
Overall
resistance: 0.6 Ω (1000 Hz)
Storage
temperature:
+10 °C…+25 °C
(never over 30 °C!)
Relative
atmospheric
humidity: 65 % ± 20 %
1 Battery set Z502H or Z502O
1 Supplement (this document)
