PowerWalker LiFe Battery System 102-37 User manual

LiFe Battery System
102-37
User Manual
Version: 01
Date: 2023-7-10

~ 1 ~

~ 2 ~
Thank you for purchasing the lithium battery —PowerWalker LiFe Battery System
102-37. Please read this manual before you install the battery and follow the
instructions carefully during the installation process.
Symbol Conventions
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages with this symbol to avoid possible injury or
death.
DANGER
DANGER indicates a hazardous situation that, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazard with a medium level of risk which, if not avoided, could result
in serious injury
CAUTION
CAUTION indicates a hazardous situation that, if not avoided, could result in
minor or
moderate injury.
NOTICE
NOTICE is used to address
practices not related to physical injury. The safety alert symbol
shall not be used with this type of safety message.
Table 1 Safety messages
Product Handling Guide
<18 kg
<40 lb
18-32 kg
40-70 lb
32-55 kg
70-120 lb
>55 kg
>120 lb

~ 3 ~
Manual Intended Audience
The operation in this document can only be performed by qualified personnel with the following
skills:
▪Personnel who plan to install or maintain battery equipment and inverter must receive
thorough training, understand all necessary safety precautions, and be able to correctly
perform all operations.
▪Only qualified professionals or trained personnel are allowed to install, operate, maintain
the equipment, remove safety facilities, and inspect the equipment, who are specialists
according to IEC 60 364 or DIN VDE 0105, and qualified based on proven knowledge
of relevant norms, and regulations, accident prevention regulations and operating
conditions and have been authorized by the person responsible for the safety of the
component/system to carry out the necessary work.
▪Personnel who will operate the equipment, including operators, trained personnel, and
professionals, should possess the local and national required qualifications in special
operations such as high-voltage operations, working at heights, and operations of special
equipment.
▪Only professionals or authorized personnel are allowed to replace the equipment or
components (including software).

~ 4 ~
Table of Contents
1 Safety Messages and Precautions .............................................................................................. 6
1.1 Declaration ....................................................................................................................... 6
1.2 General Safety Requirements........................................................................................... 7
2 Product Introduction ................................................................................................................. 10
2.1 Overview........................................................................................................................ 10
2.2 Battery Capacity Description ......................................................................................... 10
2.3 Battery application on the Grid ...................................................................................... 11
2.4 Battery Pack System Description................................................................................... 12
2.4.1 Battery Illustration ............................................................................................ 12
2.4.2 Control Box Description................................................................................... 13
2.4.3 Battery Module Description.............................................................................. 16
2.4.4 Base Introduction.............................................................................................. 17
3 Battery Pack System Installation............................................................................................. 18
3.1 Inspection of package..................................................................................................... 18
3.2 Package Content............................................................................................................. 18
3.3 Required Tools (not included)........................................................................................ 21
3.4 Installation environment................................................................................................. 23
3.5 Determination of the Location and Position................................................................... 24
3.5.1 Installation Angle Requirement ........................................................................ 24
3.5.2 Installation Position Requirements ................................................................... 24
3.5.3 Installation Space Requirements....................................................................... 24
3.6 Installation Process......................................................................................................... 25
3.6.1 Installation Precautions..................................................................................... 25
3.6.2 Installation of battery modules and control box................................................ 27
3.6.3 Crimping the cables .......................................................................................... 32
3.6.4 Installing the cables to the control box .............................................................34
3.6.5 Installing the side cover to the battery module and the control box .................37
3.7 Connecting battery packs in parallel ..............................................................................40
4 Powering the System............................................................................................................. 41
4.1 Preparation before running:............................................................................................ 41
4.2 Run the battery system (test drive):................................................................................ 41
4.3 Powering off the battery system.....................................................................................42
5 Battery Pack Parameters ......................................................................................................... 43

~ 5 ~
5.1 Battery pack specification .............................................................................................. 43
5.2 Modular guide ................................................................................................................ 45
6 Troubleshooting ...................................................................................................................... 47
7 Acronyms and abbreviations................................................................................................... 49

~ 6 ~
1 Safety Messages and Precautions
1.1 Declaration
Please read this manual carefully before installation, operation, and maintenance. Inappropriate
use may lead to injury or even death for the user or third parties. Material damage to the battery
and other equipment can also occur. All operations should be performed by a qualified person.
The manufacturer will not be liable for any consequences of the following circumstances:
• Operation beyond the conditions specified in this document.
• The installation and use environment do not comply with relevant international or national
and regional standards.
• Failure to follow the operation instructions and safety messages on the batteries and in this
document.
• Product damage caused by an unstoppable natural disaster.
• Damage caused during transportation by the customer.
• Damage caused by storage conditions that do not meet the requirements specified in
related documents.
• Damage caused by the device due to negligence, improper operation, or intentional
damage to the device.

~ 7 ~
1.2 General Safety Requirements
DANGER
• Ensure the housing of the battery packs is properly grounded before operation.
• Do not dispose of batteries in a fire or hash chemicals. The batteries may explode.
• The disassembly of batteries may generate internal short circuits, which may cause
firing or other problems.
• Do not open or mutilate batteries. Released electrolyte is harmful to the skin and
eyes. It may be toxic.
• Batteries theoretically do not have flowing electrolytes
, but in the event of any
leakage and contact with skin, eyes, or other parts of the body, flush the electrolyte
with water immediately and seek medical attention.
•
The battery may be damaged due to impact or other reasons during transportation
or assembly. If the battery is found to have any abnormal characteristics, such as
the housing being damaged, the electrolyte gas, the electrolyte leak, etc. The battery
shall not be used. Contact the dealer or installer to replace it.
• Do not expose the cable externally which may cause a short-circuit to the battery
or electric shock to humans.
• Do not touch the output terminals of the battery pack while it is working. The DC
cables connected to an inverter may be live. Touching live DC cables may result in
death or serious injury due to electric shock.
• When performing high-voltage operations, use dedicated insulation tools.

~ 8 ~
WARNING
• Wear suitable personal protective equipment for all work on the battery system.
•
Before installation, be sure to cut off the power grid and ensure that the battery is
in shutdown mode.
• For the equipment that
needs to be grounded, install the protective earthing (PE)
cable first when installing the equipment and remove the PE cable last when
removing the equipment. Do not operate the equipment in the absence of a properly
installed grounded conductor.
• Remove metal objects from your body while operating, such as watches, necklaces,
and rings.
• Connect all cables according to the instructions and ensure no reverse connection
for positive and negative poles. No external short circuit.
• Do not connect the battery to the utility grid or AC source directly.
• Do not mix and match this battery with other batteries.
• If a fire occurs ABC, or carbon dioxide extinguisher can be used.
NOTICE
• Inspect the package contents upon receipt. Notify the dealer if there is any damage.
•
Do not operate this battery pack in direct sunlight, in contact with fluids, or where
there is excessive dust or high humidity.
• Do not lay tools or metal parts on top of the battery.
• Do not place inflammable items around the equipment.
•
Wear ESD gloves when handling the equipment. Do not wear clothes prone to static
electricity.
• The battery modules cannot be stored at high temperatures (greater than 60 °C)
•
The battery system must only be used as stationary equipment. If the battery system
needs to be moved or repaired, the power must be cut off and the battery has to be
completely shut down.

~ 9 ~
1.3 Disclaimer
The manufacturer shall not be liable for equipment function abnormality, component damage,
personal health or safety, property loss, or other damage caused by the following reasons:
1) The batteries are not charged as required during storage, resulting in capacity loss
or irreversible damage to the batteries.
2) The battery is damaged, falls, or leaks due to improper operations or incorrect
connection.
3) Battery parameters are incorrectly set.
4) After being installed and connected to the system, the batteries are not powered on
in time, which causes damage to the batteries due to over-discharge.
5) The batteries are overloaded or used with other batteries, including but not limited
to batteries of other brands or batteries of different rated capacities.
6) The batteries are damaged because the operation is outside the recommended
environment or external power parameters do not meet the stated technical
specifications.
7) Batteries are frequently deep-discharged or have not been fully charged for a long
time.
8) The warranty period of batteries has expired.

~ 10 ~
2 Product Introduction
2.1 Overview
The Lithium-Ion Battery Pack System is a high-power DC battery system for use with inverters.
It contains two parts, one is the battery module, and the other is the control box.
It can store and release electric energy based on the requirements of the inverter. It has a built-in
intelligent battery management system (BMS), which can manage and monitor the battery voltage,
temperature, current and other information. The battery pack system can be used individually or
in parallel, and the capacity and power can be expanded according to different requirements.
2.2 Battery Capacity Description
The battery supports power and capacity expansion. One power control box supports a maximum
of five battery expansion modules. The capacity of each module is 3.8 kWh.
Figure 1 Modules in series for power and capacity expansion

~ 11 ~
Figure 2 Battery in parallel for capacity expansion
Note: Two batteries in parallel only support capacity expansion, power expansion is not suggested.
The Module quantity of each string of battery should be the same.
2.3 Battery application on the Grid
The battery can be used in the grid-tied systems of residential rooftop PV plants.
Figure 2 Grid Application

~ 12 ~
2.4 Battery Pack System Description
2.4.1Battery Illustration
This topic describes the battery's illustration.
Figure 3 Battery Illustration
(1) Logo and cold start switch
(2) Control Box
(3) Battery modules
(4) Base

~ 13 ~
2.4.2 Control Box Description
Figure 4 Control Box Front Panel
No Item Description
1 Symbol Logo
2 Power button with status
LED
A power button with dual-color LEDs, for
switching the battery on / off and displaying
working status.
For starting up and shutting down the battery pack:
Pressing the button for 3 seconds to shut down the
battery pack when it is in active status.
Pressing the button for 3 seconds to wake up the
battery pack when it is in shut down status.
For displaying the working status of the battery
pack:
When the LED is steady green, that means the
battery pack is running normally.
When the LED is blinking red, that means the
battery pack has a minor fault that is recoverable.
When the LED is steady red, that means the
battery pack has a major fault that is
unrecoverable.

~ 14 ~
Figure 5 Control Box Side Panel
No Item Description
3 Communication port
Four 8 pins RJ45 ports for communication.
RS485 + I/O port：
Every single pin of the two RJ45 ports is
connected in parallel internally. Connect this
port to another control box or system.
CAN + 12V port：
Every single pin of the two RJ45 ports is
connected in parallel internally. Connect this
port to another control box or system.
Detailed PIN assignment on page 37

~ 15 ~
4 DC Breaker
This breaker controls the power supply for the
battery pack.
Left: OFF
Right: ON
5 Protective earthing port To protect people from electric shocks in the
event of a fault
6 Battery power ports
“+” is battery power positive port.
“-” is battery power negative port.
Figure 6 Control Box Bottom Panel
No Item Description
7 Bottom Connector Control box bottom connector that connects to
module top connector.
Table 2 Control box description

~ 16 ~
2.4.3 Battery Module Description
The standard capacity of a battery expansion module is 3.8 kWh.
Figure 7 Battery Module Bottom Panel
No Item Description
1 Bottom Connector Module bottom connector that connects to
module top connector.
Figure 8 Battery Module Top Panel
No Item Description
2 Top Connector Module top connector that connects to module
or control box bottom connector.
Table 3 Battery module description

~ 17 ~
2.4.4 Base Introduction
Figure 9 Base Top Panel
No Item Description
1 Top Connector The base top connector connects to the
module bottom connector.
Table 4 Base description

~ 18 ~
3 Battery Pack System Installation
3.1 Inspection of package
When unpacking the package, please check the appearance ahead of installation. If the main body of the
product is damaged, please consult the dealer, and do not install the product.
After unpacking the battery, check that the deliverables are intact and complete, and free from any obvious
damage. If any item is missing or damaged, please contact your dealer.
3.2 Package Content
Item Name Quantity Figure
Battery
module
package
Battery Modules 2/3/4/5
Dimensions (W x D x H):
625 mm x 250 mm x 315 mm
Weight: Approx 45.0Kg
Side Covers 4/6/8/10
Dimensions (W x D x H):
314.5 mm x 214.5 mm x 15.0 mm

~ 19 ~
Connection
mounting pieces 4/6/8/10
Dimensions (W x D x H):
81 mm x 50 mm x 2.0 mm
Control box
package
Control Box 1
Dimensions (W x D x H) :
625 mm x 250 mm x 150 mm
Weight: Approx 12.5Kg
Wall mounting
piece 1
Dimensions (W x D x H) :
60 mm x 45 mm x 32 mm
Base 1
Dimensions (W x D x H) :
625 mm x 250 mm x 50 mm
Weight: Approx 4.5Kg
