Powr-Flite PF6 User manual

Commercial Canister Vacuum
Powr-Flite• A Tacony Company
3101 Wichita Court • Fort Worth, TX 76140 • 800.880.2913 X8782
Model PF6/PF6H and PF9/PF9H
OWNERS MANUAL
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

To reduce risk of fire, electric shock, or
injury:
● Do not use outdoors or on wet surfaces.
● Do not leave vacuum cleaner
unattended when plugged in. Turn off
the switch and unplug the electrical cord
when not in use and before servicing.
● Do not allow to be used as a toy.
Close attention is necessary when used
by or near children.
●Use only as described in this manual.
The use of accessories which have not
been approved or supplied by the
manufacturer may be dangerous.
● Do not use with damaged cord or plug.
If vacuum cleaner is not working as it
should, has been dropped, damaged,
left outdoors, or dropped into water,
return it to a service center before using.
● Do not pull or carry by cord, use cord as
ahandle, close a door on cord, or pull a
cord around sharp edges or corners.
Do not run vacuum cleaner over cord.
Keep cord away from heated surfaces.
● Do not use extension cords or outlets
with inadequate current carrying
capacity.
●Turn off all controls before unplugging.
● Do not handle plug or vacuum cleaner
with wet hands.
● Do not put any objects into openings.
● Do not use with any opening blocked,
keep free of dust, lint, hair, and anything
that may reduce airflow.
●This vacuum cleaner creates suction.
Keep hair, loose clothing, fingers, and all
parts of body away from openings.
● Do not pick up anything that is burning
or smoking, such as cigarettes, matches
or hot ashes. Do not use without dust
bag in place. Use extra care when
cleaning on stairs. Do not use to pick up
flammable or combustible liquids such
as gasoline, or use in areas where they
may be present.
●Store your cleaner indoors in a cool, dry
area.
● Do not unplug by pulling on cord. To
unplug, grasp the plug,
NOT THE CORD.
THIS MODEL IS GROUNDED,
CONNECT TOA PROPERLY
GROUNDED OUTLET ONLY
SEE GROUNDING INSTRUCTIONS.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it
should malfunction or breakdown, ground-
ing provides a path of least resistance for
electric current to reduce the risk of shock.
This appliance is equipped with a cord hav-
ing an equipment-grounding conductor and
grounding plug. The plug must be inserted
into an appropriate outlet that is properly
installed and grounded in accordance with
all local codes and ordinances.
WARNING -Improper connection of the
equipment-grounding conductor can result
in a risk of electric shock. Check with a
qualified electrician or service person if you
are in doubt as to whether the outlet is
properly grounded. Do not modify the plug
provided with the appliance - if will not fit
the outlet, have a proper outlet installed by
aqualified electrician.
Note: In Canada, the use of a temporary
adapter is not permitted by the Canadian
Electrical Code.
WARNING
IMPORTANT
READ THESE INSTRUCTIONS AND RETAIN FOR FUTURE REFERENCE
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

●Do not vacuum water or liquids.
●Do not vacuum up hard or sharp objects,
as they may damage the hose, vacuum
bag or the vacuum motor.
●Do not drop the vacuum on the floor.
●Do not operate the vacuum while it is
standing on high-pile carpet. It is
essential that the exhaust airflow is
not restricted.
●Do not wash or launder the cloth
vacuum bag. It would destroy the
filtration capacity of the fabric.
●Do not kink or twist the power cord.
●Do not attempt to service the vacuum
yourself. Repair by anyone other than
an authorized repair service may void
the warranty.
Carefully check carton to signs of damage.
Report damages at once to carrier.
Unpack the machine and check machine
for completeness. Check the cord plug
installed corresponds to your wall outlet.
1. Pass the power cord through the power
cord pull reliever. (see photo below)
2. Insert the hose into the machine
Note: this machine is suitable for voltages
from 110-120 AC/60 Hz.
2. Plug the power cord into a receptacle.
This vacuum is equipped with an on/off
switch with a light indicator.The switch
should light after it receives mains
voltage. If this does not happen, check
the power cord, or change the main
power cord.
3. Turn on the on/offswitch. The vacuum
motor will start.
4. Clean the carpet without pressing down;
the vacuum cleaner will work best if
excessive pressure is not applied to
the carpet.
1. Take the hose out of the hose
connection.
2. Open the vacuum cleaner by releasing
the latch mechanism.
3. Vacuum bags are self-sealing to prevent
dust from escaping into the air. Pull the
dust release tab on the bag to the full
top position to close the vacuum bag.
4. Fold the ends of the vacuum bag
together and carefully remove the bag
from the holder.
5. Place the full bag in the trash.
6. Replace a new bag immediately.
1. Place a new dust bag as far inside the
holder as possible on the inlet opening
of the tank inlet. Push down the upper
edge of the bag so that it does not get
caught in the latching arrangement.
The bag should be place around the
outside of the housing to allow room for
the filter and motor. (Bags cannot be
placed in the holder upside down. If the
bag does not fit properly,turn it over
and insert it again.)
BAG REPLACEMENT
BAG REMOVAL
OPERATION
ASSEMBLY
SAFETY PRECAUTIONS
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

2. Close the latch and make sure the
catch closes properly.
1. Turn latch to allow removal of the filter
cartridge.
2. Take the filter cartridge out of the
vacuum cleaner. (see photo below)
3. Remove the filter by opening the
cartridge.
4. Check the filter, replacing if necessary.
Do not attempt to clean the filter.
5. Put the new filter in the holder and
replace it in the machine.
6. Turn the latch to make sure the filter
cartridge is firmly in place.
WARNING: Do not knock the
filter against hard surfaces.
Note: filter should be changed very 50
paper bags.
1. Slide the filter from the motor housing
to remove.
2. Place the
new filter in place and push
down, securing the filter in place.
WARNING: Do not use the machine
if no filter has been installed.
Note: filter should be changed very 10-20
paper bags.
Authorized personnel should always per-
form maintenance. The machine must be
inspected each year in accordance with
locally applicable safety standards.
WARNING: Voltage is dangerous.
Electrical shocks can be fatal. Remove the
plug from the plug socket when you carry
out maintenance activities on the machine.
Weekly
1. Check the vacuum bag to see if it is full.
Replace as necessary.
2. Clean the outer surface of the machine
with a dust cloth. A damp cloth may be
used with a gentle-action cleanser.
Monthly
1. Check and clean the filter in the inlet
opening of the suction motor.
Annually
1. Check carbon brushes in the vacuum
motor and the brush motor for war.
Replace as necessary.
The temperature of the vacuum motor is
measured constantly. If the temperature
becomes too high, the sensor will switch
off the suction motor. Check whether the
suction system is blocked. The sensor will
automatically be switched on again after
the sensor and the motor have cooled
down sufficiently. The machine may be
restarted at that time.
The machine must be stored in a dry
place. Make sure that the hose is not
pinched or squeezed.
STORING THE MACHINE
OVERHEATING
ROUTINE MAINTENANCE
REPLACING THE MOTOR FILTER
REPLACING THE OUTLET FILTER
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

ref# part # description
1CABLE
1CORD CONNECTOR 3-POLE
2 TERMINAL POWER CONN.
12 POLE
5MOTOR VAC
6SUPRESSOR RFI
25 CARRY HANDLE
26 CM3 SWITCH 4-P. LIGHT
27 CM4 SWITCH PA
28 RECEPT INLET 2 POLE
32 CABLE HOOK BLACK
33 CM5 FILTER CASSETTE
ASSEMBLY
34 TOPCOVER
35 BLOCK/CLIP FILTER
CASSETTE
36 WAND LOCKER
40 MOTOR COVER
41 MOTOR GASKET COMP
BOTTOM\LARGE
41 MOTOR GASKET COMP
TOP /SMALL
42 CM6 GASKET ROUND 08MM
FOR COVER
43 BUMPER EPDM 60/5 SHORE
AGREY
44 CABLE RESTRAIN ASSEMBLY
47 GASKET ROUND 06MM FOR
MOTOR
49 MOTOR HOUSING BLACK
52 CM7 CARTRIDGE FILTER
53 PAPER BAG HOLDER BLACK
54 CAN/TUB
55 CLIP ASSEMBLY
56 STORAGE CLIP/FIXTURE
BLACK
56 STORAGE CLIP/FIXT LEFT
57 SHIM RING 0 26
60 CM8 REAR CASTER BEARING
BLACK
ref# part # description
61 CM9 REAR CASTER BLACK
62 CM10 SOCKETS DOUBLE CASTER
63 CM11E CASTER DOUBLE 50MM
RUBBER/B\NY
64 GASKET HOSE CONN COMP
EPDM CEL
70 PAPER BAG INLET
CONNECTOR BLACK
71a HOSE CONN COMP
71b CAN CONNECTOR BLACK
72 CM12 HOSE ASSEMBLY
80 CM13 WAND
81 CM14 FLOOR TOOL
82 CM15 CREVICE TOOL
85 CM2 PAPER BAG
87 30 DEGREE BEND
89 MANUAL
100 SCREW PT WN1412KB60X20
COMP.
101 SCREW 5x14
101 WARNING STICKER
102 STICKER CARD
102 SCREW M5 X 12
103 NUT M5 NYLON
105 SCREW /PARKER 2.9x16
106 SCREW 4 X 16
110 CM16 GASKET FILTER CASSETTE
111 CM17 FELT TOP
112 CM18 FELT MOTORBASE 0
ROUND X -Y
113 CM19 FOAM SIDE FORM.
114 CM20 FELT MOTOR HOUSING X-Y
ED WIRE BROWN 1 MM 2 220 MM
ED WIRE BLACK 0,75 MM2 310
MM OEP
ED WIRE BLUE 160 S/S
ED WIRE BROWN 1 MM2
150 M F/F/
CANISTER VAC PARTS LIST
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

PF6/PF6H EXPPLODED VIEW
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

PF9/PF9H EXPPLODED VIEW
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

Powr-Flite• A Tacony Company
3101 Wichita Court • Fort Worth, TX 76140 • 800.880.2913
Model PF6/PF6H and PF9/PF9H
OWNERS MANUAL
The Powr-Flite Limited Warranty
The manufacturer warrants to the original purchaser that products manufac-
tured are free from defects, provided such goods are installed, operated and
maintained in accordance with written manuals or other instructions for a
period of 1 year from date of purchase on workmanship, motor, and parts.
