Powr-Flite Rigel Pro User manual

Rigel Pro/Rigel Deluxe™
Operating Instructions
PV100-W14-U/PV130-W14-U

CONTENTS
Getting Started
Introduction ................................................................................................................................................3
Warranty ......................................................................................................................................................3
Grounding Instructions.......................................................................................................................... 4
Important Safety Instructions ..............................................................................................................5
Technical Specifications.........................................................................................................................7
Common Replacement Parts ...............................................................................................................7
Parts Identification .................................................................................................................................. 9
Operation
Before Using Your Unit ........................................................................................................................10
Unwinding the Power Cord.................................................................................................................. 11
Connect the Power Cord ...................................................................................................................... 11
On / Off Switch ...................................................................................................................................... 12
Vacuuming Carpet.................................................................................................................................. 13
Vacuuming Hard Surfaces .................................................................................................................. 13
Carpet Height Adjustment .................................................................................................................. 13
Vacuuming Under Furniture ...............................................................................................................14
Carrying the Vacuum ............................................................................................................................ 15
Attachment Cleaning
Wand Cleaning.........................................................................................................................................16
Fast Task™ Cleaning Tools .................................................................................................................. 17
Adjusting the Suction Power..............................................................................................................18
When to Change the Vacuum Bag ..................................................................................................19
Maintenance and Care
Replacing the Vacuum Bag ...............................................................................................................20
When to Change the Filters................................................................................................................ 21
Replacing the Hepa Post Filter.......................................................................................................... 21
Replacing the Secondary Filter........................................................................................................ 22
Removing and Reinstalling Bottom Plate .................................................................................... 23
Replacing the Agitator Belt ...............................................................................................................24
Edge Cleaning .........................................................................................................................................26
Problem Solving Guide
Unclogging Nozzle and Hose............................................................................................................ 27
Thermal Motor Protection ..................................................................................................................28
Trouble Shooting ...................................................................................................................................29
For Best Performance..........................................................................................................................29
Record of Purchase...............................................................................................................................30

3
INTRODUCTION
Warranty
Please visit https://www.powr-flite.com/warranty-registration
to learn more about your warranty and confirm your information.
Warning Labels
Prior to operating the unit, read and understand completely this
owner’s manual paying special attention to warning labels. These
labels indicate a potentially hazardous situation that could result
in death or serious injury if not avoided. Use only as described in
this manual.
Important
There are no owner serviceable parts inside this machine.
Removal of screws and accessing internal components will
void all warranty claims.
Your new Powr-Flite unit is a high quality, precision-made product. All parts used in
the manufacturing of this unit have passed rigid quality control standards prior to
assembly. Please safeguard the original receipt/invoice given at the time of purchase.
If you experience any problems with your unit during the warranty period, the original
receipt/invoice will act as proof of purchase.
Upon receipt, inspect outer box for exterior damage. Unpack all internal parts,
ensure all items are present according to the owner’s manual, and review
components for damage.
Each unit is tested and thoroughly inspected prior to shipping. If damage is
discovered, immediately notify the transportation company that delivered your
machine and request an inspection. As a manufacturer, we are unable to act upon
any claim for concealed damage and you must originate the claim. Be sure to keep
the carton, packing inserts, and carrier’s receipt until the inspector has verified
your claim.

4
WARNING!
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service person if you are in doubt
as to whether the outlet is properly grounded. DO NOT modify the plug provided
with the vacuum. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This vacuum cleaner must be grounded. If it should malfunction or break down,
grounding provides a path of least resistance for electric current to reduce the risk
electric shock. This vacuum cleaner is equipped with a cord having an equipment-
grounding conductor and grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
This vacuum cleaner is for use on a nominal 115-volt circuit and has a ground plug
(see illustration). Make sure that the vacuum is connected to an outlet having the
same configuration as the plug. No adapter should be used with this vacuum.
GROUNDING INSTRUCTIONS
GROUNDING
PIN
GROUNDING
OUTLET
GROUNDING
OUTLET BOX

5
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating.
Safety is a combination of common sense,staying alert, and knowing how your
unit works. Use this unit only as described in this manual. Use only manufacturer’s
recommended attachments. To reduce the risk of personal injury or damage to your
unit use only recommended accessories.
WARNING To avoid fire, DO NOT use with a flammable or combustible liquid
or floor cleaner.
WARNING To avoid electric shock, DO NOT expose to rain. Store Indoors.
When using this unit, basic precautions should always be followed, including the
following:
• DO NOT leave unit when plugged in. Unplug from outlet when not in use and
before servicing.
• DO NOT allow unit to be used as a toy. Close attention is necessary when used
around or near children.
• Use only as described in this manual. Use only manufacturer’s recommended
attachments.
• DO NOT use with damaged cord or plug. If unit is not working properly because
it has been dropped, dropped into water, left outdoors, or damaged in any way,
contact a service center
• DO NOT handle plug or appliance with wet hands.
• DO NOT put any objects into openings.
• DO NOT use with any opening blocked: keep free of dust, lint, hair, or anything that
may reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts.
• DO NOT pick up anything that is smoking or burning such as cigarettes, matches,
or hot ashes.
• DO NOT use to pick up hazardous chemicals.
• Turn off all controls before unplugging.
• Turn unit off immediately if foam or liquid comes from machine exhaust. .
• DO NOT use to pick up flammable or combustible liquids such as gasoline or use in
areas where they may be present.
• DO NOT use where oxygen or anesthetics are used.
• Replace damaged or worn parts immediately with genuine original equipment parts
to maintain safety.
• This unit must be connected to a properly grounded outlet only.
See grounding instructions.
• DO NOT use equipment out of doors or in the rain.
• DO NOT use equipment near or around flammable or explosive materials, fuels,
or solvents.
• DO NOT allow the unit to freeze.
• Anyone designated to operate this equipment must, without fail, read and
thoroughly understand all instructions and precautions prior to use.
• Do not operate in standing water.
• Do not operate equipment under any unsafe condition.
SAVE THESE INSTRUCTIONS

6
IMPORTANT SAFETY INSTRUCTIONS
Flammability Warning
NEVER fill unit with flammable chemicals. Do NOT use
in an area where flammable fumes are present.
State of California Proposition 65 Warnings
WARNING: This product contains one or more chemicals
known to the state of California to cause cancer.
WARNING: This product contains one or more
chemicals known to the state of California to cause
birth defects or other reproductive harm.
Intended Use
Do NOT modify this unit in any way or adapt it for any use.
Modification of this unit in any way will void all warranties
and could create safety hazards.

7
TECHNICAL SPECIFICATIONS
COMMON REPLACEMENT PARTS
Model PV100-W14-U PV130-W14-U
Voltage/Frequency 115VAC/60 Hz 115VAC/60 Hz
Vacuum
Motor Rating
1200W/10A 1200W/10A
Bag Capacity -Dry 3.8 Qt/3.6l 3.8 Qt/3.6l
Airflow 50cfm/24 l/sec 50cfm/24 l/sec
Water Lift 70”/1778 mm 70”/1778 mm
Filtration
HEPA
([email protected] micron)
HEPA
([email protected] micron)
Brush Width 12”/305 mm 12”/305 mm
Power Cord Pigtail w/Extension
Cord 40’/12 M
Pigtail w/Extension
Cord 40’/12 M
Weight w/o Cord 16.6 lbs./7.5 kg. 16.8 lbs./7.6 kg.
Weight w/Cord 19.48 lbs./8.8 kg. 19.48 lbs./8.8 kg.
Noise Level* 71 dB(A) 65.6 low - 71 high dB(A)
Construction Class I I
Protection IP20 IP20
Certification ULus/CSA ULus/CSA
PV100-W14-U/PV130-W14-U
X1999 HEPA Media Bags (Qty 25)
B014-0714 Belt
B222-0700 HEPA Post Filter
B222-0500 Secondary Filter
CM-CLOTH Reusable Cloth Bag w/Clamp
*Sound Pressure level tested in accordance with ISO Standard 11202:2010

8
12
3
5
6
7
8
914
13
12
16
410
11
17 15

9
PARTS IDENTIFICATION
1 Ergonomic handle
2 Main on/off power switch
3 On the PV100-W14-U this is an On indicator light below.
On the PV130-W14-U this is a quiet mode switch instead of an indicator. When
in a noise sensitive area, press the quiet mode switch forward. The power will
decrease to approximately 70%, thereby reducing the noise of the unit. After you
have left the noise sensitive area, press the quiet mode switch backwards to return
the unit to full power.
NOTE: The unit remains in the quiet mode until the full power mode is selected.
4Power Cord
5 Carrying handle
6Bag compartment cover (to replace vacuum bag)
7Vacuum nozzle
8Furniture guard
9Carpet / Floor selector (for model PV130-W14-U only)
10 Quick release cord hook
11 Fast Task™ tools
12 Suction control dial
13 Combination dusting / upholstery brush
14 Crevice tool
15 Thermal reset button
16 Full bag indicator
17 Handle release pedal
NOTE: The PV130-W14-U comes with (2) plastic extension wands as well as a
re-usable cloth bag w/clamp. The re-usable cloth bag can be ordered as an
optional item for the PV100-W14-U.

10
OPERATION
Before Using Your Unit
For The First Time
Attaching the handle to the vacuum.
The vacuum cleaner and the handle are
packed separately.
1. After first removing the handle
screw, position the handle behind the
vacuum cleaner and level with the
top of the unit. Hold the power cord
down and away from the vacuum
while the handle is being attached.
Make sure that the switch on the
handle is positioned toward the front
of the vacuum cleaner.
2. On the bottom of the handle are two
“T-shaped” rails that slide forward
onto two guides located on the top
of the vacuum cleaner. Line up the
handle so that the “T” rails will slide
into the guides and push the handle
forward.
3. Insert the handle screw and tighten
securely.
4. Turn the upper cord storage hook
to the upright position and wind the
power cord around the cord storage
hooks when storing the vacuum
cleaner.

11
Unwinding The Power Cord
The upper cord hook rotates to allow for
quick access to the power cord.
OPERATION
Connect The Power Cord
Attach the extension cord (provided) to
the pigtail on the vacuum. Ensure all cord
connections are made using the cord lock
system that comes with the vacuum.

12
OPERATION
On / Off Switch PV100-W14-U
1. To start the vacuum cleaner, flip the
“on / off” switch located on the handle
to the “on” position.
2. To stop the vacuum cleaner, flip the
“on / off” switch to the “off” position
3. Turn the vacuum cleaner off before
unplugging from electrical outlet.
On / Off Switch PV130-W14-U
1. To start the vacuum cleaner, flip the
“on / off” switch located on the handle
to the “on” position.
2. To stop the vacuum cleaner, flip the
“on / off” switch to the “off” position.
3. Turn the vacuum cleaner off before
unplugging from electrical outlet.
OFF
ON
There is a quiet mode switch instead of an
indicator. When in a noise sensitive area,
press the quiet mode switch forward. The
power will decrease to approximately 70%,
thereby reducing the noise of the unit.
After you have left the noise sensitive area,
press the quiet mode switch backwards to
return the unit to full power.
NOTE: The unit remains in the quiet mode
until the full power mode is selected.

13
OPERATION
Vacuuming Carpet
PV130-W14-U
For carpet cleaning, slide the
carpet / floor selector toward the back
of the nozzle so that it reads “Carpet”.
Vacuuming Hard Surfaces
and Using Tools
PV130-W14-U
To prevent brushroll from spinning when
cleaning bare floors or using tools, slide
the carpet / floor selector toward the
front of the nozzle so that it reads “Floor
& Tools”.
Carpet Height Adjustment
Your Powr-Flite upright vacuum cleaner is
designed with an automatic self-adjusting
rug nozzle. No manual adjustments are
required. The height of the rug nozzle
is instantly and automatically adjusted
to carpet pile height. This self-adjusting
feature allows the rug nozzle to float
evenly over all carpet pile surfaces.
Floor & Tools Carpet

14
OPERATION
Vacuuming Under Furniture
Your unit will lay flat on the floor for
effective cleaning under beds and
tables.
1. Press the foot pedal release once for
normal vacuum cleaning.
2. Press the foot pedal release a
second time to enable the vacuum
to lay flat on the floor.

15
OPERATION
Carrying The Vacuum
To safely transport your vacuum,
especially when carrying the vacuum
up and down stairs, use the carry
handle.

16
ATTACHMENT CLEANING
Wand Cleaning
With the on-board cleaning tools and
vacuum wand, your unit becomes a
comprehensive cleaning system.
The models equipped with on-board
tools include an upholstery tool, dusting
brush, crevice tool, extension wand and
stretch hose. The PV130-W-14-U also
comes with (2) extra plastic extension
wands that can be added to the
telescopic wand to extend the reach for
cleaning higher up.
1. Remove the telescopic wand from the
body of the vacuum.
2. Extend the wand by pushing the
button forward and pulling the
smaller wand out of the larger wand.
3. Attach any of the on-board tools
to the end of the wand or if you do
not need the wand, any tool can be
connected directly onto the hose.

17
ATTACHMENT CLEANING
Fast Task™ Cleaning Tools
Your vacuum is equipped with a dusting
brush, upholstery brush and crevice
tool. Other tools are available at your
authorized retailer.
Remove the cleaning wand from the
vacuum (PV130-W14-U only, turn the
carpet / floor selector to the “Floor &
Tools” position, see page 12).
Insert any of the tools onto the end of
the wand.
Dusting Brush
Ideal for table tops, shelves, blinds or hard
surface floors.
Upholstery Tool
Ideal for soft surfaces like chairs and
couches. Remove the dusting brush clip
for upholstery cleaning.
Crevice Tool
Ideal for tight places like between seat
cushions or corners.
Wand with Dusting Brush
Dusting/Upholstery Tool
Crevice Tool

18
ATTACHMENT CLEANING
Adjusting The Suction
Power For Tool Cleaning
On the back of the vacuum, locate
the suction control dial and turn it
to the desired position. This reduces
the suction power coming through
the hose. Close the suction control
dial when finished to restore full
suction power.
WARNING: PV100-W14-U
There is no way to turn the brushroll off.
Therefore, when using the cleaning tools
it is important to keep your vacuum from
running in the same spot for a period of
time, as carpet or flooring damage could
result. If you need to keep the vacuum in
the same spot for a period of time, such
as at the base of the stairs when cleaning
the stairs, place something, like a flattened
cardboard box, under the vacuum to
prevent damage to the floor.

19
ATTACHMENT CLEANING
When to Change the Vacuum
Bag/Full Bag Indicator Light
The full bag indicator light is designed to
show when the bag is full or when there is
a clog in the vacuum.
The system measures airflow and alerts
the user when airflow is significantly
reduced – most commonly from full bags
and clogs.
The light could also come on when
vacuuming fine powders such as flour or
drywall dust. These materials can quickly
block the bag pores, significantly reducing
airflow before the bag appears to be full.
The vacuum bag should still be changed.
The light could also come on during
attachment cleaning.
NOTE: The vacuum bags are disposable
and intended to only be used once. Do not
attempt to reuse as suction and filtration
performance would be greatly reduced.
PV130-W14-U
A re-usable shake out bag is included with
this model. When the bag is full, the bag
full indicator light is illuminated. Remove
the bag and slide the clamp off and
dispose of dirt in trash receptacle. Before
replacing clamp, tap the bag to loosen
and remove any dirt still remaining. You
can also use the dusting brush to brush
the inside of the re-usable cloth bag,
removing as much dust as possible.
When using the re-usable cloth bag it
should be replaced at least every six
months.

20
MAINTENANCE AND CARE
Replacing The Vacuum Bag
1. Open the bag compartment lid.
2. Remove vacuum bag by pulling
bag collar off the bag holder.
3. Attach the new vacuum bag onto
the bag holder.
4. Tuck the bag corners into the
vacuum before replacing the bag
compartment lid.
5. Replace lid and press onto vacuum
until it snaps into place.
