Powtran PR5200 Series User manual

Foreword
Thank you very much for purchasing PR5200(C) soft starter.
This user’s manual provides the users with the instructions on the
installation, parameter setting, error diagnosis, routine maintenance and
necessary precautions. Please read the manual carefully before the installation
of the product in order to ensure that it can be correctly installed and operated.
Please contact Powtran's dealers or directly contact with the company if
you have difficult questions during the use of the soft starter , our professional
staff is willing to serve for you.
Please leave this manual to the end user and keep it in good condition for
the future maintenance and other application occasions . Please fill in the
warranty card then fax to the distributor or fax to Powtran if there is quality
problem during the warranty period.
During this product updating period, some details may be changed
without prior notice. If you want to get the latest information, please visit our
website.
For other products’ information, please visit our homepage:
http://www.powtran.com.
Powtran
September , 2011

Contents
Chapter 1 The introduction of PR5200(C) soft starter...............................................................1
1-1. The feature of the PR5200(C) soft starter ..................................................................1
1-2. The main function of the PR5200(C) soft starter .......................................................1
1-3. The main features of the PR5200(C) soft starter........................................................1
Chapter 2 Product model description and open - package inspection........................................3
2-1. Product model description .........................................................................................3
2-2. The steps of open - package inspection......................................................................3
Chapter 3 The conditions of use and installation requirements..................................................4
3-1. The conditions of use of the soft starter.....................................................................4
3-2. The installation requirements of the soft starter.........................................................4
3-3. The appearance and installation dimension of the soft starter....................................4
Chapter 4 Main circuit and terminal wiring...............................................................................9
4-1. The basic wiring diagram of the soft starter...............................................................9
4-2. Instruction of soft starter terminal wiring.................................................................10
4-3. PR5200C external terminal description ...................................................................12
Chapter 5 Control panel and operation....................................................................................14
5-1 Keyboard operational approach................................................................................14
5-2 Function parameters setting and description.............................................................16
5-3 Programmable relay output functions .......................................................................17
5-4 Operation protection function of power on terminal.................................................17
5-5 Other settings description .........................................................................................18
5-6 Help and instructions................................................................................................18
Chapter 6 Protection and description.......................................................................................19
6-1. Protection functions and their parameters................................................................19
6-2. Protection level setting description..........................................................................19
Chapter 7 Test runing and application.....................................................................................21
7-1. Power test running...................................................................................................21
7-2. PR5200(C) series soft starter starting mode and application....................................22
7-3. PR5200(C) series soft starter's stop mode and application.......................................23
7-4. Special application...................................................................................................24
7-5. Application examples ..............................................................................................24
Chapter 8 RS485 communication............................................................................................26
8-1. Summary of the modbus RTU communication protocol..........................................26
8-2. The soft starter associated settings...........................................................................26
8-3. Exception reponse....................................................................................................27
8-4. Using the matters need attention..............................................................................28
Chapter 9 Fault causes and treatment ......................................................................................29
Chapter 10 Soft-start model specifications and options...........................................................30
Chapter 11 Warranty................................................................................................................31

Precaution
Thanks for selecting intelligent motor soft starter products from Powtran technology Co.,
LTD., we will with excellent performance in return for your attention!
Please pay attention to the following matters during the soft starter installation, operation
and maintenance process
Please be sure to read the operating instructions before installation
Must by professional technicians to install the soft starter
The specifications of the motor must match with the soft starter
Prohibit to connect the capacitors in soft starter output terminal (U, V, W)
The bare terminals must be wrapped by insulating tape after installation
Soft starter or related equipment should be reliable grounding
Input power must be cut off when equipment maintenance
Do not disassemble , modify, maintenance of this product personally.
Only trained people are allowed to operate this device, please read this
manual about the safety, installation, operation, and maintenance section before
use of the items. The safe application of this equipment depends on the correct
transportation, installation,operation and maintenance.

1
第
十
章
Chapter 1 The introduction of PR5200(C) soft
starter
1-1. The feature of the PR5200(C) soft starter
PR5200(C) series intelligent motor soft starter incorporates the latest motor control theory and
proprietary motor protection technology and advanced software technology of new equipment, it is
an ideal replacement of startup products which early used start method of “Star to Triangle
conversion”, “autoformer step-down voltage” and “magnetic control step-down voltage” ; at
present market ,Its performance is more superior than other ordinary soft starter without using
intelligent control technology.
1-2. The main function of the PR5200(C) soft starter
To reduce the motor starting current and reduce power distribution capacity, avoid
investment of expansion of power capacity.
To reduce the starting stress of the motor and the load of the equipment ; extend lifespan of
the motor and related equipments.
Its soft stop function can effectively solve the problem of parking vibration of the inertial
system,which is unable to realize by traditional starting equipment.
To have six unique start-up modes adapts to the complex conditions of motor and load, to
perfect start effect.
Has the perfect and reliable protection function; effectively protect the motor and the related
production equipment use safety.
Motor soft starter intelligence, and network technology application makes motor control
technology to adapt to the rapid development of the electric power automation technology in
higher requirements.
1-3. The main features of the PR5200(C) soft starter
●Perfect human nature design:
Beautiful shape and reasonable structure
Perfect function and easy operation
Sturdy and reliable and compact structure
Industrial product excellence in the design of art.
●Reliable quality assurance:
Using the computer simulation design.
SMT placement production process.
Excellent electromagnetism compatibility.
The whole machine of aging, vibration test in high temperature before they leave the
factory
●Perfect and reliable protection function:
Voltage lose, lower voltage and over-voltage protection.
Soft starter motor overheating, lower load, too long starting time protection.
Input phase lose, output phase lose, three-phase unbalance protection.
Startup current, overload, short circuit protection.

Chapter 1 The introduction of PR5200(C) soft starter
2
●Proprietary intellectual property products:
Appearance design patent.
Independent software copyright.
Proprietary motor starting and protection technology.
Unique testing debugging equipment and process.
●Swift thoughtful after-sales service:
Reliable performance and quality lay the foundation of excellent service.
Provide excellent perfect supporting design scheme.
Timely and thoughtful use consultation.
Continuously improve product performance according to user opinion

3
第
十
章
Chapter 2 Product model description and open -
package inspection
2-1. Product model description
2-1-1. Instructions on nameplate
POWER
INPUT
OUTPUT
DALIAN POWTRAN TECHNOLOGY CO.,LTD.
MODEL
18.5kW
AC 3PH 380V 50Hz/60Hz ±10%
AC 0 37A 50Hz/60Hz3PH 380V
PR5200+ 018G3
ZPB1A0100001
Figure 2.1
2-1-2. Model designation
PR 520 0 + 018 G 3
Soft starter
Model specification
Class code:
0:normal configuration
1:special 1 configuration
2:special 2 configuration
Machine code:
a:General(omit)
C:Integrative machine
+:Function enhanced
Rated Power:
Example：400:400kW
018:18.5KW
Function code
G：Gerneral
Input Voltage Level
2:Three-phase 220V±10%
3:Three-phase 380V±10%
4:Three-phase 460V±10%
Output configuration
0：General configuration（omit）
Figure 2.2
(Note: The function enhanced- software algorithm to optimize, the standard RS485 built-in )
2-2. The steps of open - package inspection
Each PR5200(C) series soft starter is under strict inspection and testing before they leave the
factory. Users received the products and unpacked, please follow the inspection steps , if found
problem, please contact the supplier promptly.
Confirm the soft starter without any damage in transport process (machine body damage or
gap).
Check with the machine, the instruction manual,the warranty card
Check the product of the specifications of the enclosure panels, ensure that the received goods
match with you ordered products

4
第
十
章
Chapter 3 The conditions of use and installation
requirements
PR5200(C) series soft starter should comply with the following conditions of use and
installation requirements; otherwise, the performance will not guarantee, it can shorten life of soft
starter even damage.
3-1. The conditions of use of the soft starter
3-1-1. Power supplies: The utility, self-power station, diesel generating sets three-phaseAC
380 V plus or minus 10%, frequency 50 Hz or 60 Hz, the power supply capacity must meet soft
starter motor starting to the requirement
3-1-2. Applicable motor: Mouse cage type three-phase asynchronous motor, ac motor rated
power should be matching with soft starter rated power .
3-1-3. Starting times:Less than 10 times / hour.Cooling way: Air cooling.
3-1-4. The protective level: IP20.
3-1-5. Environmental conditions: Below elevation 3000 meters, the environmenttemperature
between -25 ℃~ + 40 ℃, relative humidity below 90% RH, no dewing, no inflammable, no
explosive, no corrosive gas easily, have noelectrical conductivity dust, indoor and ventilated good,
vibration is less than 0.5 G place.
We can offer under special conditions of use products, such as the explosion proof type, low
temperature, high pressure type type soft starter, its use conditions will need further instructions.
3-2. The installation requirements of the soft starter
Installation direction and distance: In order to ensure that the soft starter in use with good
ventilation and cooling conditions, soft starter should be installed vertically, and in the equipment
with sufficient heat dissipation space all round, as shown in Figure 3.2 and Figure 3.1, in the photo,
to allow the minimum distance.
When the soft starter is installed in the cabinet, in addition to the above requirements, the
upper and lower well ventilated cabinet is selected.
OUT
OUT
IN IN
AIR
50mm 50mm
150mm 150mm
Figure 3.1 Figure 3.2
PR5200(C) series integrative machine,wall-mounted(without cabinet installation) and cabinet
choose wall-mounted or landed installation,require surroundings ventilated,without dust and other
suspended solids.
3-3. The appearance and installation dimension of the soft starter
3-3-1. PR5200 + series 5.5kw-115kw soft starter shape and installation size as shown in

Chapter 3 The conditions of use and installation requirements
5
Figure 3.3, PR5200 + series 132kw-400kw soft starter shape and installation size as shown in
Figure 3.4. The factory standard is three to six.
Rated power and rated current refer to the maximum rated value of soft starter. In general, the
corresponding parameters of the adaptive motor should not exceed this value.
W
φd
a
b
L
H1
H
L1
Figure 3.3
H1
H
W
φd
a
b
L
L1
Figure 3. 4
G2 series
Model
Rated
Power
(kw)
Rated
current
(A)
Base
No.
Dimension(mm)
Installation(mm)
Net
(kg)
L1
L
W
H1
H
A
B
D
PR5200+ 7R5G2
7.5
30
5R1
303
288
146
159
105
270
115
Ø8
<4.8
PR5200+ 011G2
11
45
PR5200+ 015G2
15
60

Chapter 3 The conditions of use and installation requirements
6
PR5200+ 018G2
18.5
75
PR5200+ 022G2
22
90
PR5200+ 030G2
30
110
PR5200+ 037G2
37
150
5R2
371.5
350
206
210
156
330
160
Ø9
<10
PR5200+ 045G2
45
180
PR5200+ 055G2
55
230
PR5200+ 075G2
75
260
5R3
529
390
280
264
210
450
230
Ø9
<21
PR5200+ 090G2
90
320
PR5200+ 115G2
115
370
PR5200+ 132G2
132
420
PR5200+ 160G2
160
560
5R4
528
505
326
256
200
476
260
Ø9
<26
PR5200+ 185G2
185
600
PR5200+ 200G2
200
660
G3 series
Model
Rated
Power
(kw)
Rated
current
(A)
Base
No.
Dimension(mm)
Installation(mm)
Net
(kg)
L1
L
W
H1
H
A
B
D
PR5200+
5R5G3
5.5
11
5R1
303
288
146
159
105
270
115
Ø8
<4.8
PR5200+
7R5G3
7.5
15
PR5200+ 011G3
11
23
PR5200+ 015G3
15
30
PR5200+ 018G3
18.5
37
PR5200+ 022G3
22
45
PR5200+ 030G3
30
60
PR5200+ 037G3
37
75
PR5200+ 045G3
45
90
PR5200+ 055G3
55
110
PR5200+ 075G3
75
150
5R2
371.5
350
206
210
156
330
160
Ø9
<10
PR5200+ 090G3
90
180
PR5200+ 115G3
115
230
PR5200+ 132G3
132
260
5R3
529
390
280
264
210
450
230
Ø9
<21
PR5200+ 160G3
160
320
PR5200+ 185G3
185
370
PR5200+ 200G3
200
400
PR5200+ 250G3
250
500
PR5200+ 280G3
280
560
5R4
528
505
326
256
200
476
260
Ø9
<26
PR5200+ 320G3
320
630
PR5200+ 400G3
400
800
G4 series
Model
Rated
Power
(kw)
Rated
current
(A)
Base
No.
Dimension(mm)
Installation(mm)
Net
(kg)
L1
L
W
H1
H
A
B
D
PR5200+
5R5G4
5.5
11
5R1
303
288
146
159
105
270
115
Ø8
<4.8
PR5200+
7R5G4
7.5
15
PR5200+ 011G4
11
23
PR5200+ 015G4
15
30

Chapter 3 The conditions of use and installation requirements
7
PR5200+ 018G4
18.5
37
PR5200+ 022G4
22
45
PR5200+ 030G4
30
60
PR5200+ 037G4
37
75
PR5200+ 045G4
45
90
PR5200+ 055G4
55
110
PR5200+ 075G4
75
150
5R2
371.5
350
206
210
156
330
160
Ø9
<10
PR5200+ 090G4
90
180
PR5200+ 115G4
115
230
PR5200+ 132G4
132
260
5R3
529
390
280
264
210
450
230
Ø9
<21
PR5200+ 160G4
160
320
PR5200+ 185G4
185
370
PR5200+ 200G4
200
400
PR5200+ 250G4
250
500
PR5200+ 280G4
280
560
5R4
528
505
326
256
200
476
260
Ø9
<26
PR5200+ 320G4
320
630
PR5200+ 400G4
400
800
3-3-2. PR5200C series integrative machine appearance and installation dimensions, the
standard factory configuration is three input and three out.
Wall-mounted size chart(6R1-6R3).
b
a
H
W
L
φd
Figure 3.5
Size table
Model
Rated
power(kw)
Rated
current(A)
Base
No.
Dimension(mm)
Installation(mm)
L
W
H
A
B
D
PR5200C+ 015G3
15
30
6R1
620
400
220
600
250
Ø10
PR5200C+ 018G3
18.5
37
PR5200C+ 022G3
22
45
PR5200C+ 030G3
30
60
PR5200C+ 037G3
37
75
PR5200C+ 045G3
45
90
PR5200C+ 055G3
55
110
PR5200C+ 075G3
75
150
6R2
980
534
278
852
275
Ø12
PR5200C+ 090G3
93
180
PR5200C+ 115G3
115
230

Chapter 3 The conditions of use and installation requirements
8
PR5200C+ 132G3
132
260
PR5200C+ 160G3
160
320
6R3
1000
590
300
939
370
Ø12
PR5200C+ 185G3
185
370
PR5200C+ 200G3
200
400
Cabinet size chart
WH
L
b
a
φd
Figure 3.6
Size table
Model
Rated
power(kw)
Rated
current(A)
Base
No.
Dimension(mm
)
Installation(mm)
L
W
H
A
B
D
PR5200C+ 250G3
250
500
GGD
Cabinet
1800
800
600
550
640
Ø1
6
PR5200C+ 280G3
280
560
PR5200C+ 320G3
320
630
PR5200C+ 400G3
400
800
PR5200C+ 450G3
450
900
PR5200C+ 500G3
500
1000
PR5200C+ 560G3
560
1120
PR5200C+ 630G3
630
1260

9
第
十
章
Chapter 4 Main circuit and terminal wiring
PR5200(C) series soft starter has two kinds of wiring:
The main circuit wiring:Tthree phase power input and output to the motor wiring and coil in
line circuit breaker, bypass contactor wiring.
External terminal wiring: By 14 small terminals derivation, including input, output control
lines and analog output signal lines.
4-1. The basic wiring diagram of the soft starter
Figure 4.1
3phase power input
Soft Starter
PR5200 Series
Connector(KM)
M
3phase asynchronous mouse cage motor
Braker(QF)
Note:six copper bar, R,S,T is connected to three-phase power supply,
U,V,W is connected to motor.
Keyboard
control

Chapter 4 Main circuit and terminal wiring
10
4-2. Instruction of soft starter terminal wiring.
Output terminal like Figure 4.2 illustration:
12345678910 11 12
-+
Bypass
output
Programming
output
Fault
output 7.Instantaneous
stop start public Analog output
13 14
Communication
terminal
485+
485-
Figure 4.2
4-2-1.Terminal 1, 2 is bypass output which is used to control bypass contactor. Normally
open terminalwill close.The terminal capacity is AC 250V/5A.
4-2-2.Terminal 3, 4 is programable relay output, output model and function set by
“PE”parameter. This terminal is normally open passsive pot. Capacity is AC 250V/5A.
4-2-3.Terminal 5, 6 is error output: Which will colse when soft starter error or power lose.
Capacity is AC250V/5A.
4-2-4.Terminal 7 is transient stop input. This terminal must connect with terminal 10 when
soft starter normally work. If Terminal 7 disconnect with terminal 10, softstart will transient stop
and show error. This terminal can be controled by normal close output terminal of outside
protection device, set PA to 0 (primary protection),this terminal funtion is prohibited.
4-2-5.Terminal 8, 9, 10 is for wiring of outside control start,stop button. There are two type
wiring way(3 lines and 2 lines) to choose proper way according to demand.As Figure 4.3.
78910
Transient
stop
stop start common
3lines way
78910
Transient
stop
stop start common
2lines way:close K start
open K stop
K
Figure 4.3
4-2-6.Terminal 11, 12 is 0~20ma, 4~20ma DC anolog output. Which is used to inspect the
motor current. The max 20ma indicates motor current is 4 times of soft starter rated current. Which
can be viewed by extra 0~20ma, 4~20ma current meter. The max resistor of output load is 300Ω.
Remark: The machine defaults to 4 ~ 20ma output, if need 0 ~ 20ma output please explain in order.
4-2-7.Terminal 13, 14 for the RS485 communication terminal, 13 for the communication
terminal“485-”, 14 for the communication terminal “485+”.
4-2-8.The outside terminal should be correct connection, otherwise which will damage this
softstarter.
4-2-9.PR5200series soft starter main circuit diagram.

Chapter 4 Main circuit and terminal wiring
11
RST
13 5
braker
（QF）
RST
135
L1 L2 L3
135
KH
bypass
electromagnetic
contactor
246
UVW
246
07 08 09 10 10 11 12 G
01 02 03 04 05 06
M
A
-+
anolog output
(DC 0～20mA）
KH/transient
stop stop start common
KM
N or L1
A1 A2
bypass
output
PR5200+ series soft starter
delay
output error
output
FU
(KM)
13 14
BA
Communication
terminal
Figure 4.4

Chapter 4 Main circuit and terminal wiring
12
Motor
R
Three-phase 380V AC
ST
U V W
Figure 4.5
4-3.PR5200C external terminal description
4-4-1. Terminal 3,4 is programmable relay,output and function set by the setting item PE, as
normally open dry contact.Contact capacity is:AC 250V/5A.
4-4-2. Terminal 5, 6 as fault output,when the soft starter failure or loss of power closed, when
the soft starter normal open, contact capacity is:AC 250V/5A
4-4-3. Terminal 11, 12 as 0 to 20ma, 4 to 20ma DC analog output, use for real-time
monitoring current,when the full scale is 20ma,the instruction motor current is four times as the
soft starter nominal rated current,you can external 0 to 20ma, 4 to 20ma DC ammeterto observate,
the output load resistance max value is 300 ohm. Remark: The machine defaults to 4 ~ 20ma
output, if need 0 ~ 20ma output please explain in order.
4-4-4. PR5200C series main circuit wiring schematic diagram.

Chapter 4 Main circuit and terminal wiring
13
start control panel
temperature
controlled
switch
delay
output
fault output
RH/ instant
stop
start
analog output
(0～20mA 、4～20mA )
operation
keyboard
breaker
380V soft starter circuit diagram
Figure 4.6

14
第
十
章
Chapter 5 Control panel and operation
★PR5200(C)series soft starter has five kinds working state: Ready, running, error, start and
stop. Ready, running, error has corresponding state light.Startup indicatesxxxx, softstop indicates
—XXX ,and xxxxxindicates motor current.
5-1 Keyboard operational approach
JP3E5200 keyboard diagram
Ampere
Percentage
Second
Error light
Bypass
light
Colon
blank
Ready light
Three digitals
Two position
function code
Parameter Alternation
Key (acc/reduction key)
parameter
setting/shift
key
Rapid select/confirm
parameter setting
Running Key Stop/reset key
Figure 5.1
JP3E5200D keyboard diagram
Ampere
Percentage
Second
Error light
Bypass
light
Colon
blank
Ready light
Three digitals
Two position
function code
Parameter Alternation
Key (acc/reduction key)
parameter
setting/shift
key
Rapid select/confirm
parameter setting
Running Key
Stop/reset key
Figure 5.2

Chapter 5 Control panel and operation
15
5-1-1.Startup state: When the indication ready light display 5200 or ,then
softstater can start. The displaying 5200 means POWTRAN 5200 series softstarter. And
means ready to start.
5-1-2.Delay state: Ready or error state indication light flash means interval, display dexxx and
count down means startup delay.
5-1-3.Start and stop key:In the process of soft startup,the screen display XXXX to indicates
motor current, and only Stop key is valid, and can not enter menu to set parameter, and
ready,running,error lights black out.In the process of soft stop, the screen displayxxxx to indicates
motor current,and only RUN key is valid, and can not enter menu to set parameter, and ready,
running, error lights black out, meanwhile the stop key has reset function.
5-1-4.PRG key , in the non-help mode, press the PRG key to enter the setup menu,display PX:
XXX,then press PRG key again, colon flashes, that means can modify the parameters after
colon.Press the Set key when the colon flashes, if the data has been modified, it will display good
and twice ring, indicating that new data has been saved, and then exit. If you do not want to save
the new data, press the PRG key, colon will stop flashing and restoring the original data, then press
Set key or Stop key to exit.
5-1-5.Set key, in the non-setting state, press the set key to enter the help menu, display HX:
XXX, press the Set key or stop key to exit. In setting state, press the set key to save the new setting
of data and to exit the setting state.
5-1-6.Acceleration,deceleration key, in the setting menu, when the colon does not flash ,press
the acceleration or deceleration key to change the function number; when colon flashes, press the
acceleration or deceleration key to change the data, press on the acceleration or deceleration key
for more than 1 second, the data will be increased or decreased continuously and quickly .In the
help menu, press the acceleration or deceleration key to change the function number and the
corresponding message.When the indicator light of bypass operation is on, and did not enter the
setting and help menu, display AXXXX, that means the motor running current, then press the
acceleration or deceleration key to select display PXXXX or HXXXX. PXXXX indicates motor
apparent power;HXXXX indicates motor overloaded heat balance coefficient. When indication
value of HXXXX is more than 100%,soft starter will be overload protection and display Err08.
5-1-7.When the data is more than 999, the last decimal point is bright, indicates the mantissa +
0. 5-1-8.If the key operating is effective,there will be a voice tip, or this key does not work in
this state.
5-1-9.When the external control terminal connected to a 3-wire mode, the external control
start button and stop button have the equivalent function with start and stop keys on the control
panel.
5-1-10.The control panel with super anti-jamming design,and the outside connection distance
is allow to be more than 3 m.
5-1-11.Keyboard digital display illustration
Display letter
Relative
letter
Display
letter
Relative
letter
Display
letter
Relative
letter
0
1
2
3
4
5
6
7
8
9 or g
Aor R
B
C
D or D
E
F
H
J
L
N
U or V

Chapter 5 Control panel and operation
16
O
P
R
Y
RUN
Ver
READY
Good
Err
M
N
5-2 Function parameters setting and description
Function parameters code in the following table
Code Setting Description
Code
Name
Range of
set value
Factory
setting
Explanation
P0
Starting voltage
30-70%
30%
Voltage slope model is effective, the starting
voltage of current mode is 40%.
P1
Soft starting time
2-60S
16S
Limiting current mode does not work.
P2
Soft stop time
0-60S
0S
Setting 0 means free stopping, please set 0 for
one with two onnections .
P3
Start interval delay
0-999S
0S
The minimum time between two successive
start, the function of protecting thyristor.
P4
Language selection
0 or 1
0
0 for Chinese display, 1 for the English
display.
P5
Starting current limit
50-400%
280%
The current limiting mode is effective; the
maximum flow value of the voltage slope
mode is 400%.
P6
Load regulation rate
50-200%
100%
Relative to the value of the rated current PP.
P7
Under voltage
protection
40-90%
80%
Protection below the set value.
P8
Overvoltage protection
100-140%
120%
Protection is higher than the set value.
P9
Starting mode
0-6
1
0 limit current; 1 voltage; 2 jump; limit
current; 3 jump + voltage; 4 current ramp; 5
double closed loop; 6 monitoring.
PA
Protection level
0-4
4
0 primary; 1 light load; 2 standard; 3 heavy
load; 4 advanced.
PB
Control mode
0-6
1
0 keyboard; 1 keyboard + external control; 2
external control; 3 external control +
communication; 4 keyboard + external control
+ communication; 5 keyboard +
communication; 6 communication.
PC
Parameter
modification allowed
0-3
1
See 5.5 other setup instructions.
PD
Correspondence
address
0-64
0
For MODBUS native slave address setting.
PE
Programming output
0-19
7
See 5.3 programmable relay output functions.
PF
Soft stop current
20-100%
80%
See 7.3.1 soft stop mode.
PP
Motor rated current
11-998A
Rated
value
Nominal rated current for input motor.
