PPI LabCon User manual

LabCon Map + Printer User Manual
User Manual
Multi-Purpose Temperature Controller
Recording + 4 Channel Mapping + Printer Interface
6/01/16
10:40:06
42.542.5
Temp High SP
°C
LabCon

LabCon Map + Printer User Manual
CONTENTS
1. FRONT PANEL LAYOUT 1
2. BASIC OPERATION 2
3. OPERATOR PARAMETERS 5
4. SUPERVISORY PARAMETERS 7
5. FACTORY PARAMETER 14
6. PANEL MOUNTING AND ELECTRICAL CONNECTIONS 25
APPENDIX-A : DC LINEAR SIGNAL INTERFACE 29

1
LabCon Map + Printer User Manual
GRAPHIC READOUT
The Graphic Readout is a 160 X 80 Pixel Monochrome LCD Display. In Normal operation mode the Readout shows measured
Temperature Value, Set Temperature Value, Alarm / Process Status, Elapsed Soak Time (if enabled & running) & Date/Time.
Other process information like Mapping Channels PVs / Alarm Status, Process Status & Stored Records can be viewed using
screen scroll feature.
In Set-up Mode, the Readout displays parameter names and values that can be edited using front keys.
KEYS
There are six tactile keys provided on the front panel for configuring the controller and setting-up the parameter values.
The Table 1.1 below lists each key (identified by the front panel symbol) and the associated function.
Section 1
The Controller front panel comprises of Graphic Readout and Membrane Keys as shown in Figure 1.1 below.
FRONT PANEL LAYOUT
Table 1.1
Figure 1.1
LabCon
PPI
Graphic
Readout
Keys
°C
6/01/16 10:40:06
25.0
25.0
Temp High SP
Micro PLC
Symbol
Key Function
DOWN
UP
ENTER
SET-UP Press to enter or exit set-up mode.
Press to store the set parameter value and to scroll to the next
parameter.
Press to increase the parameter value. Pressing once
increases the value by one count; keeping pressed speeds up
the change.
Press to decrease the parameter value. Pressing once
decreases the value by one count; keeping pressed speeds up
the change.
Press to scroll through various Process Information Screens in
Normal Operation Mode.
Scroll
Press to acknowledge and mute (if active) alarm output.
Alarm
Acknowledge

2
LabCon Map + Printer User Manual
POWER-UP DISPLAY
BASIC OPERATIONS
Section 2
Upon power-up the controller display shows screen depicted in Figure 2.1(a) for 2 Seconds. The controller runs through a self-
test sequence for checking its Real Time Clock, SD Memory Card, internal Communication Link and Parameter Storage
Memory (EEPROM). The and symbols indicate whether a check is passed or failed, respectively. In case any one or
more checks fail, the controller starts executing its normal operation but ‘Self Checking’ screen is halted until front panel
“Acknowledge” key is pressed. This is followed by screen depicted in Figure 2.1(b) for next 2 Seconds. This screen shows the
controller model name, Hardware Version and Firmware Version.
RUN MODE
After the Power-up display sequence the controller enters into RUN Mode. This is the normal operation mode wherein the
controller starts PV measurements, Alarm monitoring and Control Loop execution. The Display comprises of several screens
described below. The screens appear one-after-the-other upon pressing (Scroll) Key while in RUN Mode.
Main Screen
Figure 2.2 (a)
Figure 2.1 (a)
LabCon
H/W Version
F/W Version
02.02
01.01
Figure 2.1 (b)
Self Checking...
SD MEMORY CARD
COMM. LINK
REAL TIME CLOCK
EEPROM
°C
6/01/16 10:40:06
25.0
25.0
Temp High SP
Calendar Date
(Date/Month/Year)
Clock Time
(Hours:Minutes:Seconds)
Measured Temperature
Alarm / Process Status Set Temperature
°C
6/01/16 10:40:06
25.0
25.0
0:10:00 SP
Temp High
Calendar Date
(Date/Month/Year)
Clock Time
(Hours:Minutes:Seconds)
Set Temperature
Measured Temperature
Alarm / Process Status
Elapsed Soak Time
Figure 2.2 (b)

3
LabCon Map + Printer User Manual
The Alarm / Process Status space on the screen may show one or more of the several messages listed in Table 2.2 depending
upon the existence of active alarms or process events. In case of co-existence of multiple active alarms or process events, the
messages are scrolled one after the other with an approximate time interval of 3 seconds. Also if there is no active alarm or
process event, the message space is blank.
Mapping Status Screen
This is the default Run Mode screen that shows easured Temperature Value, et Temperature Value, Calendar Date, Clock M S
Time and Alarm / Process Status as illustrated in Figure 2.2 (a) above.
If Soak Timer function is enabled, the un ode screen also shows the elapsed time as R M illustrated in Figure 2.2 (b) above.
In case of measured value errors, the messages listed in Table 2.1 flash in place of process value as illustrated in Figure 2.3.
Message Error Type Cause
Sensor Open
Under-range
Over-range
Sensor (RTD Pt100) Broken / Open
Temperature above Max. Specified Range
Temperature below Min. Specified Range
OPN
Table 2.1
OVR
UNR
Figure 2.3
°C
6/01/16 10:40:06
OPN
25.0
Temp High SP
Figure 2.4
The Mapping Status Screen is shown upon pressing (Scroll) key from
Main Screen.
The Controller provides up to 4 mapping channels. The Mapping Status
Screen is available only if the controller is configured for at least one
mapping channel. The mapping status screen for 4 mapping channels is
shown in the figure 2.4. In case lesser mapping channels are configured,
the skipped channels are not shown on the screen.
Message String Alarm / Process Status
The Controller is Self Tuning.
The measured temperature at Mapping Channel
‘x’ (x = 1, 2, 3 or 4) is in Process High Alarm State.
Temp High
Temp Low
Map-x High
Map-x Low
Tuning
Mains Fail
The measured temperature at Control Channel is
in Process High Alarm State.
The measured temperature at Control Channel is
in Process Low Alarm State.
The measured temperature at Mapping Channel
‘x’ (x = 1, 2, 3 or 4) is in Process Low Alarm State.
The Controller is operating on Standby Power
Source like battery or inverter.
Table 2.2
Door Open The Equipment / Chamber door is open for a time
longer than the set ‘DOOR ALRM DLY’ time.
MAPPING STATUS
MAP PV °C ALARM
125.1 Normal
224.4 Low
325.0 Normal
425.4 High

4
LabCon Map + Printer User Manual
The Controller provides programmable Low & High deviation
limits around the temperature control setpoint to monitor Alarm
conditions. The screen shows either NORMAL or LOW or
HIGH Status, as shown in Figure 2.5 (a) depending upon the
deviation of measured temperature value from the control
setpoint and set limits.
The Controller provides a Digital Input for interfacing Door
switch that senses the door position, Open or Close. The
screen indicates the door status as shown in Figure 2.5 (b).
DOOR
OPEN
DOOR
CLOSE
Door Status
Figure 2.5 (b)
°C
NORMAL
Temperature Alarm Status
Within
Limits
Below
Low Limit
Above
High Limit
°C
LOW
°C
HIGH
Figure 2.5 (a)
Process Status Screen
The Process Status Screen is shown upon pressing (Scroll) key from Main Screen or upon acknowledging a new Alarm by
pressing (Acknowledge) key. As depicted in Figure 2.5; the screen shows Temperature Alarm Status, Door Open / Close
Status, the Heater Output (Heating) in % & Compressor ON / OFF Status.
°C
PROCESS STATUS
High
Door
Close
Compressor
OFF
Heating
0.0%
Heating Control
Output Power
Compressor
Output Status
Temperature
Alarm Status Door Status
Figure 2.5
Record View Screen
The Record View Screen is shown upon pressing (Scroll) key from Process Status Screen. This screen facilitates
viewing of up to most recent 1000 stored records. The records can be scrolled for viewing using (UP) & (DOWN) keys.
As depicted in Figure 2.7; the record view screen comprises Date & Time stamps, PV, SP & Alarm Status for Control Channel.
If Mapping Channels are configured, the recorded Process Values & Alarm Status for configured mapping channels are also
shown. The Record Number format shows both, the sequential number for the selected record & the total numbers of records
available for viewing (for example; 1/21 means the sequential record number is 1 & the total available records are 21).
Figure 2.7
RECORD VIEW
RECORD NO :
6/01/16 10:37:28
1/21
CTRL
M-1
25.1
25.1
PV SP ALARM
M-2 24.4
M-3 25.0
25.0
(This Record No. /
Total Records)
Time StampDate Stamp
M-4 25.4

5
LabCon Map + Printer User Manual
OPERATOR PARAMETERS
The Operator Parameters are accessible under PASSWORD 0. The list includes parameters for adjusting Control Setpoint,
Alarm Setpoints & Zero-offset for Control & Mapping Channels. If Soak Timer is enabled then Time Interval value & Timer Start
/ Abort commands are also available.
The Figure 3.1 shows how to access Operator Parameters. The Example illustrates changing the Low Deviation alarm value
from 2.0 to 5.0 for control channel. (The Example is shown with Soak Timer disabled).
Section 3
Parameter Description Settings
(Default Value)
Table 3.1
The Table 3.1 below described the Operator Parameters in detail.
Figure 3.1
or
Next Parameter
CTRL HI DEVIATION >>
2.0
CTRL LO DEVIATION >>
2.0
Desired Parameter
CTRL LO DEVIATION >>
5.0
Desired Value
Press UP/DOWN Keys
to adjust Parameter Value
Press ENTER Key
to store the New Value
& to move to Next Parameter
ENTER PASSWORD >>
0
CTRL SET VALUE >>
25.0
RUN Mode
Main Screen
Default Password
for Operator Parameters
First Parameter
Press SET-UP Key
for Password Entry
Press ENTER Key
To open Operator
Parameter List
Press & Release
ENTER Key until Desired
Parameter appears
°C
6/01/16 10:40:06
25.0
25.0
Temp High SP
(This command is available only if Printer Function is
enabled and Printer is powered and connected)
None
Skip Printing.
Print (New)
Prints all the available records since previous ‘Print (New)’
command.
Re-Print (Old)
Re-Prints the records that were printed upon issuing previous
‘Print (New)’ command.
Print Info Page
Prints a single page information showing the details of
abbreviations used to indicate different Events (like Door Open,
Power Fail, etc.)
SELECT PRNT OPTION>>
None
Print (New)
Re-Print (Old)
Print Info Page
(Default : None)

6
LabCon Map + Printer User Manual
(Available only if Soak Timer is Enabled)
These two commands are mutually exclusive.
Set to Yes to start Soak Timer, if not already started.
Set to Yes to abort a running timer.
TIME START COMMAND >>
TIME ABORT COMMAND >>
Parameter Description Settings
(Default Value)
CTRL SET VALUE >>
This parameter sets the value at which the controller attempts to
maintain the measured temperature value.
CTRL LO DEVIATION >>
This Parameter sets a negative deviation (offset) limit with respect
to the ‘Control Set-point’. The Alarm is activated if the measured
temperature value falls below this limit.
CTRL HI DEVIATION >>
This Parameter sets a negative deviation (offset) limit with respect
to the ‘Control Set-point’. The Alarm is activated if the measured
temperature value exceeds this limit.
CHANGE PASSWORD >>
The Controller is shipped from the factory with a default password
(0) for accessing the parameters reserved for Operator. However,
if required the password can be changed by setting the new value
for this parameter.
(The new password replaces the old password. That is, the old
password is no longer valid. it is user’s responsibility to memorize
the password.)
1 to 100
(Default : )0
0.00 to 500.00
(HH:MM)
(Default : 0.10)
TIME INTERVAL (H:M) >>
(Available only if Soak Timer is Enabled)
The set time value for the soak timer in Hours : Minutes.
Yes
No
(Default : No)
Setpoint LO limit to
Setpoint HI limit
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)
(Default : 25.0)
For RTD & DC Linear : 0.2 to 99.9
For Thermocouple : 2 to 99
(Default : 2.0)
For RTD & DC Linear : 0.2 to 99.9
For Thermocouple : 2 to 99
(Default : 2.0)

7
LabCon Map + Printer User Manual
SUPERVISORY PARAMETERS
Section 4
Accessing Group & Parameters
The Figure 4.1 below illustrates how to access the group and parameters. The example shows changing the value for the
parameter ‘Setpoint High Limit’ from 600.0 to 100.0 that is located under group ‘Control’.
Table 4.1
The various parameters have been assembled in different groups under the default factory password 123.
Refer Table 4.1 below for a quick summary of parameters under different groups. Each parameter has been described in
subsequent sections.
Figure 4.1
ENTER PASSWORD >>
0
RUN Mode
Main Screen
Default Password
for Operator Parameters
Press SET-UP Key
for Password Entry
Press UP/DOWN Keys
To adjust Password
Value
Press & Release
ENTER Key for the
First Group
ENTER PASSWORD >>
123
or
Password for
Supervisory Parameters
°C
6/01/16 10:40:06
25.0
25.0
Temp High SP
SELECT GROUP>>
SENSOR INPUT
First Group
or
Desired Group
Press UP/DOWN
Keys to Select
Desired Group
Press ENTER Key
to Access Parameters
First Parameter in
selected Group
SELECT GROUP>>
CONTROL
TUNE >>
NO
Parameters
Group
Recording
Record Interval (Min), Alarm Toggle Record,
Delete Print Records, Delete Display Records, RTC Time,
RTC Date, RTC Month, RTC Year
Control
Tune, Setpoint Low Limit, Setpoint High Limit, Compressor Setpoint
Compressor Hysteresis, Heat Control Action, Heat Hysteresis,
CZ Proportional Band, CZ Integral Time, CZ Derivative Time,
HZ Proportional Band, HZ Integral Time, HZ Derivative Time, Cycle Time
Exit Set-up Mode Yes/No
Print Event
Password Change Password
Printer Setting Line Per Page, Top Margin, Bottom Margin, Header & Footer, Enable
Exit
Alarm Toggle, RTC Modify, Interval Modify, Power-up,
Door Open, Mains Fail, Setpoint Modify
Sensor Input Control Zero Offset, Mapping 1 Zero Offset, Mapping 2 Zero Offset,
Mapping 3 Zero Offset, Mapping 4 Zero Offset

8
LabCon Map + Printer User Manual
This value is algebraically added to the measured Temperature
Value at control channel to derive the final value that is displayed
and compared for alarm / control. Use this value to nullify any
known constant error.
Final Value = Measured Value + Offset
CTRL ZERO OFFSET >>
MAP-1 ZERO OFFSET >>
Same as Control Zero Offset but applied to Mapping Channels 1 to
4, respectively.
MAP-2 ZERO OFFSET >>
MAP-3 ZERO OFFSET >>
MAP-4 ZERO OFFSET >>
-50 to 50
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)
(Default : )0.0
-50 to 50
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)
(Default : )0.0
Notes
1. The Last Parameter in the selected Group rolls back to the ‘SELECT GROUP’ screen again to avoid re-entering the password in case
multiple parameters need to be set under the selected Group.
2. Select group ‘EXIT’ & set parameter ‘EXIT SET-UP MODE’ to ‘YES’ for returning to Main Display Mode. Alternately use Setup Key for
instant revert to Main Display Mode.
Desired Parameter
SETPOINT HI LIMIT >>
600.0
or or
Press UP/DOWN
Keys to adjust
Parameter Value
Next Parameter
Press UP/DOWN
Keys to Select
Desired Parameter
Press ENTER Key
to store the Value
and move to Next
Parameter
HEAT CTRL ACTION >>
PID
Desired Parameter
Value
SETPOINT HI LIMIT >>
100.0
SUPERVISORY SENSOR INPUT
Parameter Description Settings
(Default Value)
Parameter Descriptions
The various Supervisory Parameters have been described with their respective group & sub-group.

9
LabCon Map + Printer User Manual
SUPERVISORY RECORDING
The Controller generates and stores periodic records at the
interval set by this parameter. The time units are in Minutes.
Setting this parameter value to 0 disables normal recording.
REC. INTERVAL (MIN) >>
If this parameter is set to ‘Enable’, the Controller generates and
stores a record each time either the temperature or %RH alarm
toggles the status (On-to-Off or Off-to-On).
ALRM TOGGLE RECORD >> ENABLE
DISABLE
(Default : ENABLE)
(Default : )5 Min
0 to 250 Min
Parameter Description Settings
(Default Value)
0 to 23 for Hour
0 to 59 for Min
(Default : NA)
RTC TIME >>
Set current clock time in Hrs:Min (24 Hours format).
1 to 31
(Default : NA)
RTC DATE >>
Set current calendar date.
1 to 12
(Default : NA)
RTC MONTH >>
Set current calendar month.
2000 to 2099
(Default : NA)
RTC YEAR >>
Set current calendar year.
1 to 127
(Default : 1)
DEVICE ID >>
(Applicable for Serial Communication)
Unique numeric code assigned to the indicator for identification by
the remote PC. Set the value as required by the remote PC.
DEL PC RECORDS >>
This parameter is a command that allows the user to delete all the
records from the controller memory that are meant for uploading
to remote PC. Set the parameter to “YES” to carry out delete
operation.
YES
NO
(Default : NO)
DEL DISPLAY RECORD >>
This parameter is a command that allows the user to delete all the
records from the controller memory that are meant for displaying
on the controller screen using ‘Record View’. Set the parameter to
“YES” to carry out delete operation.
YES
NO
(Default : NO)
1 to 128
(Default : 1)
GSM MACHINE ID >>
(Available only if the controller is supplied with GSM Module
Version)
This parameter can be used to assigned a unique ID to the
machine (chamber) to identify the source of SMS alert.

10
LabCon Map + Printer User Manual
ON-OFF
PID
(Default : PID)
HEAT CTRL ACTION >>
(Available for ‘Heat Only’ & ‘Heat+Cool’ Control Strategy)
On-Off
The control algorithm tends to maintain the PV at SP by either
switching the output (say, Heater) fully OFF or fully ON. The On
and Off switching is differentiated by the user settable ‘Hysteresis
Band’.
PID
The control algorithm uses a 2nd order equation to compute the
‘% Output Power’ required to maintain the PV at SP. The constants
P, I, D are automatically set by the controller.
0.1 to 99.9
(Default : 0.2)
HEAT HYST >>
(Available for ‘ON-OFF’ Heat Control Action)
Sets a differential (dead) band between the ON and OFF states.
Keep it large enough to avoid frequent switching of the load
without losing the desired control accuracy.
COMPRESSOR HYST >>
(Available for ‘Cool Only’ & ‘Heat + Cool’ Control with
Compressor PV based Strategy)
Differential (dead) band between the compressor ON and OFF
states.
0.1 to 99.9
(Default : 2.0)
SUPERVISORY CONTROL
(Available for Heat Only / Heat+Cool Control Strategy)
Set ‘Yes’ to activate and ‘No’ to abort the Tuning operation.
TUNE >>
This parameter sets the minimum limit on the Control Setpoint
value.
SETPOINT LO LIMIT >>
(Default : )No
Yes
No
Parameter Description Settings
(Default Value)
SETPOINT HI LIMIT >>
This parameter sets the maximum limit on the Control Setpoint
value.
COMPRESSOR SETPOINT >>
(Available for ‘Heat + Cool’ Control with Compressor PV
based Strategy)
This Setpoint Value is compared with the Process Value to switch
the compressor On/Off with the set compressor hysteresis.
0 to 100
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)
(Default : 45.0)
(Default : 0.0)
Min Range for the Selected
Input Type to Setpoint HI Limit
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)
(Default : 600.0)
Setpoint LO Limit to
Max Range for the Selected
Input Type
(Resolution 0.1°C for RTD /
DC Linear & 1°C for Thermocouple)

11
LabCon Map + Printer User Manual
HZ INTEGRAL TIME >>
0 to 3600 sec
(Default : 100 sec)
Integral Time for
Heat Pre-dominant zone
HZ DERIVATIVE TIME >>
0 to 600 sec
(Default : 16 sec)
Derivative Time for
Heat Pre-dominant zone
CYCLE TIME >>
0.5 to 100.0 sec
(Default : 10.0 sec)
OVERSHOOT INHIBIT >>
Enable
Disable
(Default : Disable)
CUTOFF FACTOR >>
1.0 to 2.0 sec
(Default : 1.2 sec)
OVERSHOOT INHIBIT >>
Enable
Disable
(Default : Disable)
CUTOFF FACTOR >>
1.0 to 2.0 sec
(Default : 1.2 sec)
OVERSHOOT INHIBIT >>
Enable
Disable
(Default : Disable)
CUTOFF FACTOR >>
1.0 to 2.0 sec
(Default : 1.2 sec)
0.1 to 999.9
(Default : 50.0)
HZ PROP BAND >>
Proportional Band for
Heat Pre-dominant zone
CYCLE TIME >>
0.5 to 100.0 sec
(Default : 10.0 sec)
CYCLE TIME >>
0.5 to 100.0 sec
(Default : 10.0 sec)
PROPORTIONAL BAND >>
0.1 to 999.9
(Default : 50.0)
INTEGRAL TIME >>
0 to 3600 sec
(Default : 100 sec)
DERIVATIVE TIME >>
0 to 600 sec
(Default : 16 sec)
PROPORTIONAL BAND >>
0.1 to 999.9
(Default : 50.0)
INTEGRAL TIME >>
DERIVATIVE TIME >>
0 to 3600 sec
(Default : 100 sec)
0 to 600 sec
(Default : 16 sec)
CZ PROP BAND >>
0.1 to 999.9
(Default : 50.0)
Proportional Band for
Cool Pre-dominant zone
CZ INTEGRAL TIME >>
0 to 3600 sec
(Default : 100 sec)
Integral Time for
Cool Pre-dominant zone
CZ DERIVATIVE TIME >>
0 to 600 sec
(Default : 16 sec)
Derivative Time for
Cool Pre-dominant zone
Heat Only Control Heat + Cool
Control Zone : Single
Heat + Cool
Control Zone : Dual

12
LabCon Map + Printer User Manual
SUPERVISORY PRINTER SETTING
This parameter sets the page length in terms of total print lines
including the top and bottom margins.
LINE PER PAGE >>
This parameter sets the blank space in terms of numbers of lines
from the top edge of the print page.
TOP MARGINE >> 1 to 5
(Default : 2)
(Default : )65
25 to 100
Parameter Description Settings
(Default Value)
BOTTOM MARGINE >>
This parameter sets the blank space in terms of numbers of lines
above the bottom edge of the print page.
No
Header / Footer never printed.
On First Page
Header / Footer is printed on the first page only.
Every Page
Header / Footer is printed on every page.
HEADER & FOOTER >>
No
On First Page
Every Page
(Default : No)
ENABLE >>
No
Disables Printer function and suppresses all print related
commands / parameters.
Yes
Enables Printer function.
YES
NO
(Default : NO)
1 to 5
(Default : 2)
PROPORTIONAL BAND
Sets proportional gain (% power per unit error). Defined in same units and resolution as that for PV.
INTEGRAL TIME
Sets integral time constant in Seconds. Setting the value to 0, cuts-off the integral action.
DERIVATIVE TIME
Sets derivative time constant in seconds. Setting the value to 0, cuts-off the derivative action.
CYCLE TIME
Sets the total ‘On + Off’ time in seconds for time proportional power output through Relay / SSR for OP1.
OVERSHOOT INHIBIT
Set this parameter to ‘Enable’ if the process exhibits unacceptable overshoot upon start-up or a step change in SP. If enabled,
the controller controls the rate of change of PV to minimize overshoot while approaching the target SP.
CUTOFF FACTOR
This parameter adjusts the effectiveness of the Overshoot Inhibit feature. Increase the value if the overshoot is curbed but the
PV takes longer to reach the SP. Decreases the value if the overshoot persists.

13
LabCon Map + Printer User Manual
SUPERVISORY PASSWORD
Parameter Description Settings
(Default Value)
CHANGE PASSWORD >>
The Controller is shipped from the factory with a default password
(123) for accessing the parameters reserved for the equipment
manufacturer. However, if required the password can be changed
by setting the new value for this parameter.
(The new password replaces the old password. That is, the old
password is no longer valid. it is user’s responsibility to memorize
the password.)
(Default : )123
1000 to 1999
ALARM TOGGLE >>
RTC MODIFY >>
Parameter Description Settings
(Default Value)
INTERVAL MODIFY >>
POWER UP >>
DOOR OPEN >>
YES
NO
(Default : YES)
MAINS FAIL >>
SETPOINT MODIFY >>
SUPERVISORY EXIT
Parameter Description Settings
(Default Value)
EXIT SETUP MODE >>
Select ‘Yes’ to quit Setup mode and return to Main Display mode.
YES
NO
(Default : NO)
The controller generates instantaneous records of several Events such as Alarm Toggle, Power-up, Door Open, etc. These
records are in addition to the records generated at regular user set time interval. The printouts of event generated records are
marked with specific abbreviations for differentiation. The user, however, has an option to individually suppress these records
for printing by setting the related parameters to “NO”.
The Table lists the parameters associated with the Events that can be selected (set to “Yes”) or suppressed (set to “No”) for
printing.
SUPERVISORY PRINT EVENT

14
LabCon Map + Printer User Manual
Figure 5.1
FACTORY PARAMETERS
Section 5
Table 5.1
The various parameters have been assembled in various group under the default factory password 321.
Refer Table 5.1 below for a quick summary of parameters under different groups. Each parameter has been described in
subsequent sections.
Accessing Group & Parameters
The Figure 5.1 below illustrates how to access the group and parameters. The example shows changing the value for the
parameter ‘Hysteresis’ that is located under group ‘Alarm’ from 0.2°C to 0.5°C.
HYSTERESIS >>
0.2
SELECT GROUP>>
CTRL SENSOR INPUT
First Group
or
First Parameter in
selected group
Desired Group
Press UP/DOWN
Keys to Select
Desired Group
Press ENTER Key
to Access
Desired Parameters
ENTER PASSWORD >>
0
RUN Mode
Main Screen
Default Password
for Operator Parameters
Press SET-UP Key
for Password Entry
Press UP/DOWN Keys
To adjust Password
Value
Press & Release
ENTER Key for the
First Group
ENTER PASSWORD >>
321
or
Desired Password
SELECT GROUP>>
ALARM
°C
6/01/16 10:40:06
25.0
25.0
Temp High SP
or
Press UP/DOWN
Keys to Adjust
parameter Value
HYSTERESIS >>
0.5
Desired Parameter
Value
Press ENTER Key
to Store the New Value
& Move to Next Parameters
INHIBIT >>
YES
Next Parameter in
selected group
Alarm Hysteresis, Inhibit
Door Open Enable/Disable, Switch Logic, Door Alarm Delay
Mains Failure Enable/Disable, Switch Logic
Factory Default Set to Default Yes/No
Exit Exit Set-up Mode Yes/No
Parameters
Group
Control Sensor Input Input Type, Signal Low, Signal High, Range low, Range High
Heat Cool Select Control Strategy, Compressor Strategy, Boundary Set Value,
Control Zones, Time Delay (Sec)
Mapping Mapping Points, Input Type, Signal Low, Signal High,
Range low, Range High
Soak Timer Enable, Start Band, Holdback Strategy, Hold Band,
Heat Off, Cool Off, Power Recovery
Password Change Password

15
LabCon Map + Printer User Manual
Notes
1. The Last Parameter in the selected Group rolls back to the ‘SELECT GROUP’ screen again to avoid re-entering the password in case
multiple parameters need to be set under different Group.
2. Select group ‘EXIT’ & set parameter ‘EXIT SET-UP MODE’ to ‘YES’ for returning to Main Display Mode. Alternately use Set-up Key for
instant revert to Main Display Mode.
Parameter Descriptions
The various Factory Parameters have been described with their respective group & sub-group.
Parameter Description Settings
(Default Value)
Select Input type in accordance with the type of Temperature
sensor / transmitter connected for measurement.
INPUT TYPE >>
(Available for DC linear V & mA Inputs only)
The transmitter output signal value corresponding to Range Low
process value. Refer Appendix-A : DC Linear Signal Interface for
details.
SIGNAL LO >>
(Available for DC linear V & mA Inputs only)
The transmitter output signal value corresponding to Range High
process value. Refer Appendix-A : DC Linear Signal Interface for
details.
SIGNAL HI >>
(Available for DC linear V & mA Inputs only)
The process value corresponding to the Signal Low value from the
transmitter. Refer Appendix-A : DC Linear Signal Interface for
details.
RANGE LO >>
(Default : 0.0)
-199.9 to RANGE HI
(Available for DC linear V & mA Inputs only)
The process value corresponding to the Signal High value from
the transmitter. Refer Appendix-A : DC Linear Signal Interface for
details.
RANGE HI >>
Input Type Settings Default
0 to 20 mA 0.00 to Signal High 0.00
4 to 20 mA
0 to 5 V
0 to 10 V
1 to 5 V
4.00 to Signal High
0.000 to Signal High
0.00 to Signal High
1.000 to Signal High
4.00
0.000
0.00
1.000
Input Type Settings Default
0 to 20 mA
4 to 20 mA
0 to 5 V
0 to 10 V
1 to 5 V
Signal Low to 20.00 20.00
20.00
5.000
10.00
5.000
Signal Low to 20.00
Signal Low to 5.000
Signal Low to 10.00
Signal Low to 5.000
(Default : 100.0)
RANGE LO to 999.9
(Default : Pt100)RTD
Refer Table 5.2
FACTORY CONTROL SENSOR INPUT

16
LabCon Map + Printer User Manual
FACTORY
Parameter Description Settings
(Default Value)
Select Input type in accordance with the type of Temperature
sensor / transmitters connected for mapping. Note that all inputs
must have the same sensor or transmitter type.
INPUT TYPE >>
The transmitter output signal value corresponding to Range Low
process value. Refer Appendix-A : DC Linear Signal Interface for
details.
SIGNAL LO >>
The transmitter output signal value corresponding to Range High
process value. Refer Appendix-A : DC Linear Signal Interface for
details.
SIGNAL HI >>
The process value corresponding to the Signal Low value from the
transmitter. Refer Appendix-A : DC Linear Signal Interface for
details.
RANGE LO >>
(Default : 0.0)
-199.9 to RANGE HI
The process value corresponding to the Signal High value from
the transmitter. Refer Appendix-A : DC Linear Signal Interface for
details.
RANGE HI >>
Input Type Settings Default
0 to 20 mA 0.00 to Signal High 0.00
4 to 20 mA
0 to 5 V
0 to 10 V
1 to 5 V
4.00 to Signal High
0.000 to Signal High
0.00 to Signal High
1.000 to Signal High
4.00
0.000
0.00
1.000
Input Type Settings Default
0 to 20 mA
4 to 20 mA
0 to 5 V
0 to 10 V
1 to 5 V
Signal Low to 20.00 20.00
20.00
5.000
10.00
5.000
Signal Low to 20.00
Signal Low to 5.000
Signal Low to 10.00
Signal Low to 5.000
(Default : 100.0)
RANGE LO to 999.9
The Controller supports up to 3 or 4 sensor inputs (depending on
version supplied) for Mapping. This parameter allows the user to
select the desired numbers for Mapping. Selecting 0 disables any
mapping.
MAPPING POINTS >>
(Default : )0
0 to 4
MAPPING PARAMETERS
(Default : Pt100)RTD
Refer Table 5.2

17
LabCon Map + Printer User Manual
Table 5.2
FACTORY ALARM PARAMETERS
Parameter Description Settings
(Default Value)
This parameter sets a differential (dead) band between the ON
and OFF Alarm status change. Keep it large enough to avoid
frequent switching of the Alarm Status/Relay.
HYSTERESIS >>
(Default : )0.2
0.1 to 99.9
Yes
The Alarm activation is suppressed until the Temperature value is
within Alarm limits from the time the controller is switched ON. This
allows suppressing the Alarm during the start-up Alarm
conditions.
No
The Alarm is not suppressed during the start-up Alarm conditions.
INHIBIT >>
(Default : )YES
YES
NO
Resolution
Range (Min. to Max.)
Fixed
1°C
0 to +1300°C
0 to +1825°C
0 to +1765°C
0 to +1770°C
-200 to +385°C
-200 to +1376°C
0 to +960°C
Fixed
0.1°C
Fixed
0.1 unit
-199.9 to 600.0°C
-199.9 to 999.9 units
What it means
Type J Thermocouple
Type K Thermocouple
Type T Thermocouple
Type R Thermocouple
Type N Thermocouple
Type B Thermocouple
Type S Thermocouple
0 to 20mA DC current
4 to 20mA DC current
0 to 5.0V DC voltage
0 to 10.0V DC voltage
1 to 5.0V DC voltage
3-wire, RTD Pt100
Reserve
Reserved for customer specific Thermocouple type
not listed above. The type shall be specified in
accordance with the ordered (optional on request)
Thermocouple type.

18
LabCon Map + Printer User Manual
FACTORY
The PPI “Multi-Purpuse Temperature Controller” provides control outputs for driving, both, heating & cooling sources. The
user can enable any one or both outputs depending upon the test equipment type and application. If both outputs are enabled
(by setting the parameter ‘Control Strategy’ to Heat + Cool) and if the cooling source is compressor then the controller offers
various strategies for switching the compressor as described below.
Compressor Switching Strategies
1. Compressor Off
The compressor is kept Off. This strategy is usually selected for temperature values significantly above the ambient
temperature.
2. Compressor On
The compressor is kept On regardless of the measured or set temperature value. This strategy is usually selected for
temperature values significantly below the ambient temperature.
3. SP Based Strategy
In this strategy, the chamber temperature range is split in two zones by setting the parameter 'Boundary Set-point' (BSP).
Refer Figure 5.2.
HEAT COOL SELECT
Figure 5.2
70°C
0°C
45°C
30°C
50°C
Temp. Control SP in
Cool Pre-dominant Zone
Temp. Control SP in
Heat Pre-dominant Zone
Compressor Status
Boundary Set-point
ON
OFF
The zone at and above the boundary SP ( ) is referred as Heat Pre-dominant zone and that below the boundary SP ( )
is referred as Cool Pre-dominant zone. The controller automatically switches between the two zones depending upon the
Temperature SP. If the Temperature SP is below boundary SP, Cool Pre-dominant zone is active and the compressor is kept
ON. If the Temperature SP is at or above boundary SP, Heat Pre-dominant zone is active and the compressor is kept OFF. This
strategy eliminates the need for the user to manually switch the compressor ON or OFF.
If the parameter Control Zones is set to “Dual”; separate tuning can be performed in the Cool and Heat Pre-dominant zones for
accurate control in each zone. The controller maintains separate sets of Proportional Band, Integral Time & Derivative Time
constants for each zone that are automatically selected and used by the controller depending upon the active zone.
However, if the parameter Control Zones is set to “Single”; the controller uses a single set of Proportional Band, Integral Time
& Derivative Time constants for both zones.
