PQ Labs JJ-F67-T User manual

1 Packing List
Main Components
Accessories
HUB ×1
Optional (For Intel NUC Package only)
Stylus Pen ×2
M6 Bolt ×4 M6*15 Screws ×4
NUC Computer Bracket ×1 NUC PC × 1
Touch Display ×1
Remote Control ×1
HDMI Cable ×1
Power Cable ×1
(Remote Control)
Copyright ©2020 PQ Labs.Inc Ver. 1.0.3
(55 Inch) User Manual
Product Model：JJ-F67-T

2.1 Environment
For the best user experience, please place the Holo Board with approx. 2.3 feet/ 0.7m from
your conference table, also keep the middle of the Holo Board aligned to the middle of the
conference table.
≈0.7m
CPU 7th Generation Intel® Core™
i3 Processor or above
7th Generation Intel® Core™
i5 Processor or above
16 GB or above 16 GB or above
RAM
Graphics Intel® HD Graphics Intel® HD Graphics
Video Output 4K (3860 x 2160) 60Hz 4K (3860 x 2160) 60Hz
Minimum Requirements Recommend Requirements
2.2 Hardware requirements for computer
Please follow this part if you are plan to use Intel NUC PC mounting, skip this part for external PC.
CAUTION
a. Please install the NUC computer bracket to back side of the Holo Board as below;
2.3 Install the Intel NUC PC
b. Please install the screws to the NUC and mount the NUC to the bracket.
b1 b2
c. Please attach AC power adapter onto Holo Board as shown.
2.4 Instruction for connecting to your PC
- Please make sure your HDMI cable is HDMI 2.0 compliance.
- Please DO NOT use any USB Hub in this step, connect the 3 USB Cables to your PC.
a. Please connect the 3 USB cables from the Holo Board to your computer directly.
(Light-Field Sensor-1, Light-Field Sensor-2, Holo Board Camera)
CAUTION

Light-Field
Sensor USB -1
Light-Field
Sensor USB -2
Holo Board
Camera
a
Holo Board will start automatically once powered on.
CAUTION
Please DO NOT connect the USB cable at step 2.4 (a) to the HUB
CAUTION
b. Please connect the touch sensor USB cable to the USB HUB below, and connect the USB
HUB to your computer, you can also connect your keyboard/mouse/usb storage device
to the HUB.
c. Please connect the HDMI cable to the HDMI 1 port of your Holo Board and your computer.
b
3 Start to use Holo Board
1. Holo Board with a Built-in PC.
2. Holo Board with your own PC.
a) Press the button of your remote controller to power the Holo Board, the system will
start automatically, if the Holo Board displays a “no signal”message with a blue screen,
please press the power button once and it will light on.
b) You can press the power button at the left side of the Holo Board.
a) Please use the button from the remote controller to start the Holo Board display.
b) Start the computer manually.
Please be aware that you need to start the Holo Board and PC separately.
CAUTION
Touch Sensor
USB
HUB
a. Wall mount: Please use your own wall mount bracket ( support up to 35 kg )
Please install the M6 Bolt to the VESA screw hole before install your wall mount bracket.
CAUTION
Please make sure your wall
could support the up to 35 kg
weight before the installation.
CAUTION
Holo Board can be installed as wall mount or floor stand. Please choose accordingly based on
your preference.
2.5 Mounting Holo Board
b. Floor stand: sold separately, please refer to the installation guide of the floor stand.
Wall
