PRÜFTECHNIK INCLINEO User manual

INCLINEO handbook
1
INCLINEO
®
Operating handbook

INCLINEO handbook
2

INCLINEO handbook
3
A user’s handbook
Dear Customer,
This handbook sets out to help the instrument user work through the instrument
with the required ease. It is meant to be a quick learning tool that hopefully should
not only make compelling reading but also provide useful guidance when employing
INCLINEO®, the high precision electronic inclinometer.
PRÜFTECHNIK Alignment Systems GmbH
Freisinger Str. 34
85737 Ismaning
Germany
Fax [phone]
Email [email protected]
Edition August 2012
Order number ALI 9.183.G
Firmware version 2.0x
INCLINEO®
INCLINEO®is a registered trademark of PRÜFTECHNIK Dieter Busch AG. PRÜFTECHNIK
products are the subject of patents granted and pending throughout the world.
Contents subject to change without further notice, particularly in the interest of
further technical development. Reproduction, in any form whatsoever, only upon
express written consent of PRÜFTECHNIK Alignment Systems GmbH.
© Copyright 2009 by PRÜFTECHNIK Alignment Systems GmbH

INCLINEO handbook
4
Foreword
INCLINEO®is yet another innovative product introduced to the market by PRÜFTECHNIK.
It combines functions which until now were not available in one compact system
with an elegant design and simplicity of use. Its ergonomic design functionality in
operation together with manufacture from materials that are extremely light but
able to withstand harsh operating environments makes INCLINEO®a highly accurate
and easy to use measurement system. In operation the unit is able to be rotated
through 360° making measurement at any angular position possible. It is operated
using just 3 keys with a functional menu that offers the user all the required options
for measuring profiles and determining levelness and parallelism of surfaces. The
integrated Bluetooth wireless technology is used to transfer data via a flexible modern
common PC software platform for processing and display. INCLINEO®is appropriate
for the following applications:
!Measurement on surfaces with any inclination
!Level, flatness or parallelism of surfaces
!Angularity measurements along edges and borders
!Plumbness of vertical shafts
!Parallelism of sloping surfaces
!Perpendicularity of planes
!Ideal for installation and service
INCLINEO®is a suitable tool for most production industries.
If you have any suggestions for improvement or corrections (not just to this manual,
but also for hardware), please drop us a line. We would be glad to make improve-
ments wherever possible.
We look forward to hearing from you.
PRÜFTECHNIK Alignment Systems
Ismaning, Germany

INCLINEO handbook
5
Contents
A user’s handbook ...............................................................................................................3
Foreword ..............................................................4
INCLINEO packages ......................................................6
INCLINEO standard package ALI 18.000................................................................................6
Other INCLINEO packages.....................................................................................................8
Optional INCLINEO components............................................................................................ 8
Safety notes ............................................................9
Gettingstarted.........................................................11
Getting to know INCLINEO, the high precision inclinometer................................................11
Powering INCLINEO ............................................................................................................13
Understanding menu items.................................................................................................14
Measurementmethods..................................................24
Absolute measurement .......................................................................................................24
Relative measurement.........................................................................................................27
Measuring wide angles .......................................................................................................28
INCLINEO ALIGNMENT CENTER PC software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix to INCLINEO ALIGNMENT CENTER software ........................................................41
INCLINEO technical data .....................................................................................................44
Index.................................................................45
Notes.................................................................47

INCLINEO handbook
6
INCLINEO packages
INCLINEO standard package ALI 18.000
The standard INCLINEO package ALI 18.000 constitutes the listed items:
ALI 18.201 INCLINEO inclinometer assembly without base
ALI 13.620 USB RF dongle
ALI 18.500 Three point mounting base
ALI 18.501-150 INCLINEO grooved mounting base for smooth
surfaces
ALI 18.502-150 INCLINEO prism-shaped mounting base for rolls
and shafts
BATT
INCLINEO®
ENTER
MENU HOLD
+
0
.
00
14
deg-ABS
F
il
te
r
:
m
in
ALI 18.501-150
ALI 18.502-150
ALI 18.200 comprises
ALI 18.201 and
ALI 18.500
ALI 13.620

INCLINEO handbook
7
0 0621 0038 Philips cross screwdriver
0 0739 1056 Allen key (3.0 mm)
90022 (4 no.) Standard AA size batteries
ALI 18.800 INCLINEO standard case
ALI 13.700 CD ALIGNMENT CENTER CD
ALI 9.182.G INCLINEO pocket guide
ALI 9.183.G INCLINEO operating instructions
Baby LR 14 C AM2
No 4014 1,5 V
Nichtins Feuer werfen!
Nichtwiederaufladbar.
Mayexplode in fire! Not rechargeable.
Nepasjeter au feu! non rechargeable.
0 0739 1056
90022
ALI 13.700 CD
ALI 9.182.G
ALI 9.183.G
ALI 18.800
0 0621 0038

INCLINEO handbook
8
Other INCLINEO packages
Other INCLINEO packages are listed below and details of their composition may be
obtained from your local PRÜFTECHNIK Alignment Systems representative.
INCLINEO package with grooved mounting base (150 mm) ALI 18.001
INCLINEO package with prism-shaped mounting base (150 mm) ALI 18.002
INCLINEO package with three-point mounting base ALI 18.003
Optional INCLINEO components
ALI 18.290 INCLINEO calibration certificate
ALI 18.400 INCLINEO USB converter
ALI 18.500-M INCLINEO magnetic foot
ALI 3.581-2 Receiver cable
ALI 3.581-2
ALI 18.400
ALI 18.500-M

INCLINEO handbook
9
Safety notes
Intended use
INCLINEO is a package designed to be used in industrial environments only for
measuring inclination and angularity on surfaces, rolls and shafts. Care must be taken
to ensure that the system is not subjected to mechanical knocks. INCLINEO must
be operated only by properly trained personnel. No liability will be assumed when
components or operating procedures as described in this manual are altered without
permission of the manufacturer.
Safety symbols
The following symbols are used in this manual in order to draw the reader’s attention
to especially important text, such as that regarding possible sources of danger or
useful operating tips.
This symbol denotes general information and tips regarding operation of
INCLINEO.
This symbol denotes information which must be followed in order to avoid
damage to equipment.
This symbol denotes information which must be followed in order to avoid
personal injury.
The number within the red circle corresponds to the instruction with the same
number and must be followed exactly.
CE compliance and EMC
All INCLINEO components fulfil the EC Guidelines for electric devices and those
relating to electromagnetic compatibility (2004/108/EC).
IP classification
INCLINEO and related components are water and dust resistant (IP65). (dust-tight and
protected against immersion).
!Note
"
CAUTION
#
WARNING
T
his symbol denotes general in
f
ormation and tips regarding operation o
f
I
NCLINEO
.
T
his symbol denotes in
f
ormation which must be
f
ollowed in order to avoid
dama
g
e to equipment
.
T
his s
y
mbol denotes in
f
ormation which must be
f
ollowed in order to avoid
persona
l
injury
.
Th
e num
b
er wit
h
in t
h
e re
d
circ
l
e correspon
d
s to t
h
e instruction wit
h
t
h
e same
n
umber and must be followed exactl
y.
7

INCLINEO handbook
10
Storage
When not in use, store INCLINEO in such a manner that the display lies in parallel
with the red handle and the mounting base. Also ensure that the display axis remains
horizontal within +/- 5°. INCLINEO should be stored at temperatures between 15°
and 30° C. These measures should prevent against premature damage of the high
precision electronic inclinometer.
Note regarding data storage
With any data processing software, data may be lost or altered under certain
circumstances. PRÜFTECHNIK strongly recommends that you keep a backup or
printed records of all important data.
PRÜFTECHNIK assumes no responsibility for data lost or altered as a result of
improper use, repairs, defects, battery replacement/failures or any other cause.
PRÜFTECHNIK assumes no responsibility, directly or indirectly, for financial losses
or claims from third parties resulting from the use of this product and any of its
functions, such as loss or alteration of stored data.
Service and care
Although INCLINEO is essentially maintenance free, the calibration accuracy of the
system should be checked every six months as indicated by the calibration label (see
below) located on the back of the rotatable inclinometer assembly.
Component labelling
The labels shown below are to be found on INCLINEO.
Note regarding data storage
W
ith any data processing so
f
tware, data may be lost or altered under certain
circumstances. PRÜFTECHNIK strongly recommends that you keep a backup or
printed records o
f
all important data.
PRÜFTECHNIK assumes no responsibility for data lost or altered as a result of
improper use, repairs, defects, batter
y
replacement/failures or an
y
other cause.
PRÜFTECHNIK assumes no responsibilit
y
, directl
y
or indirectl
y
, for financial losses
o
r claims
f
rom third parties resulting
f
rom the use o
f
this product and any o
f
its
f
unctions, such as loss or alteration o
f
stored data
.
!
Note
The calibration label is affixed
on the back of INCLINEO and
shows the date of the next
scheduled calibration.
The above label is affixed on the
back of INCLINEO and shows
the part and serial number of
the system and the hardware
version.
