PR Lighting XLED 3007 User manual

XLED 3007
PR-8125
This product manual contains important information about the safe installation and use of this product. Please
read and follow these instructions carefully before installing and using the product and keep this manual in a
safe place for future reference.
PR LIGHTING LTD.
http://www.pr-light ing.co m

2/18
INDEX
SAFETY INFORMATION AND WARNINGS ------------------------------------------------------------------------------------ 3
PRODUCT INSTALLATION ----------------------------------------------------------------------------------------------------------- 4
POWER SUPPLY CONNECTION -------------------------------------------------------------------------------------------------- 5
DMX CONTROL CONNECTION ---------------------------------------------------------------------------------------------------- 5
DMX TERMINATOR --------------------------------------------------------------------------------------------------------------------- 6
PRODUCT FUNCTION SETUP ---------------------------------------------------------------------------------------------------- 6
DMX START ADDRESS SETUP ---------------------------------------------------------------------------------------------------- 7
STAND-ALONE MODE ----------------------------------------------------------------------------------------------------------------- 7
MASTER/SLAVE MODE --------------------------------------------------------------------------------------------------------------- 7
SOUND OPERATION---------------------------------------------------------------------------------------------------------------------- 8
OPERATION MENU --------------------------------------------------------------------------------------------------------------------- 8
DMX PROTOCOL ----------------------------------------------------------------------------------------------------------------------- 10
DISPLAY INFORMATION -------------------------------------------------------------------------------------------------------------- 12
MAINTENANCE --------------------------------------------------------------------------------------------------------------------------- 12
PRODUCT CLEANING ----------------------------------------------------------------------------------------------------------------- 13
TROUBLESHOOTING ------------------------------------------------------------------------------------------------------------------ 13
TECHNICAL DATA ----------------------------------------------------------------------------------------------------------------------- 13
COMPONENT ORDER CODES ------------------------------------------------------------------------------------------------------- 15
IRCUIT DIAGRAM ------------------------------------------------------------------------------------------------------------------------- 16
Every ex-company fixture is tested completely and packed properly by the manufacturer. The use explanations and
warnings in this manual must be strictly followed .Any damage caused by improper use will not be covered by the
manufacturer and / or dealer.
If any technical data changes, further notice won’t be offered.
ACCESSORIES
These items are packed together with the product, please check them:
Name Quantity Unit Remark
XLR connector 2 PCS 1 male and 1 female, 5-pin
Safety cord 1 PCS
This manual 1 PCS
G clamp 1 SET Standard
Ω clamp 1 SET Optional
Wireless receiver 1 SET Optional
Frost Panel 1 PCS Optional

3/18
SAFETY INFORMATION AND WARNINGS
After receiving product, please unpack and check if there are any damages caused by transportation. Do not use the fixture if
transportation damages occur and contact the manufacturer or the dealer as soon as possible.
The product is only for indoor use, IP20. Use only in dry locations. Keep this device away from rain and moisture, excessive heat,
humidity and dust. Do not allow its contact with water or any other liquids .
The unit is only intended for installation, operation and maintenance by qualified personnel.
The product must be installed in a location with good ventilation, at least 50cm from adjacent wall surfaces. Be sure that no fans and
ventilation slots are blocked.
Do not project the beam onto inflammable surfaces, minimum distance is 1.3m. 1.3m
Avoid looking into the light from the fixture directly (especially to Epileptic Patients). The light is harmful to the eye.
Do not attempt to dismantle and/or modify the product in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power requirements of the fixture .
It is essential that each fixture is correctly earthed and that electrical installation conforms to all relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the power-cord come into contact with other cables.
If the fixture is not in use or before it being cleaned, please hold the plug and unplug the power cord . Never pull out the plug by
tugging the power-cord.
The fixture should always be installed with a secondary safety fixing. A safety cord is supplied for this; it should be attached as shown
in “installing the unit” section. At the back cover of the base, there is a safety hole for the safety cord, for safety installation, please
run the safety cord supplied with the fixture through the safety hole to support the safe installation.
Shields and lens shall be changed if they have become visibly damaged to such an extent than their effectiveness is impaired, for
example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 45℃, when steady, it achieves 50℃,
There is no user repairable parts inside the fixture, do not open the housing and never operate the unit with the covers removed. Before
the use of the fixture, please check if the covers are fixed well and all screws are fastened.
If any questions, don’t hesitate to consult your dealer or the manufacturer.
Important: Always disconnect from Power Supply, when the device is not in use or before cleaning or
any maintenance work!

4/18
PRODUCT INSTALLATION
WARNING：
Please run the safety cord through
safety hole and make sure that the
cord is property secured.
SAFETY CORD
CLAMP
Take 1 clamp and 1 the safety cord out from the package and mount 1 clamp on the BOTTOM of fixture with 2 retainers attached to
the clamp. Hang the fixture on the steel truss and fasten the retainers attached to the clamp. Always ensure that the location that you are
going to mount the unit is secure and is strong enough to support the weight of the unit (See the WARNING as shown above) To pass
SAFETY CORD through the SAFETY HOLE on the back cover of the base of the fixture for safety! Always ensure that the
unit is firmly anchored to avoid vibration and slipping whilst functioning.
WARNING:
1. The unit MUST be lifted or carried by the HANDLES instead of clamps.
2. For safety the safety cord should bear 10 times of the unit’s weight .

5/18
POWER SUPPLY CONNECTIONS
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Please be advised to notice power supply’s voltage and frequency meet what are described on the nameplate of the product. It is
recommended that each unit be power connected separately so that they may be individually switched on and off.
IMPORTANT
It is essential that each unit(yellow/green twin wire) is correctly earthed and the electrical installation conforms to all relevant
standards.
DMX CONTROL CONNECTION
Connection between controller and unit and between one unit and another must be made with a 2 core-screened cable, with each core
having at least a 0.5mm diameter. Connection to the DMX512 input and output ports of the unit is via 5 pin XLR plugs and
sockets(which are included with the unit). The XLR's plugs and sockets are connected with wires as shown in the figure above. Note:
care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR’s plug and socket must not
be connected with XLR control wire in any way other than shown as above. The fixture accepts digital control signals in protocol
DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the second fixture’s input and connect
the rest fixtures in the same way. Eventually connect the last fixture’s output to a DMX terminator as shown in the figure below.
DMX IN FROM
CONTROLLER
DMX OUT TERMINATOR
MASTER SLAVE SLAVE
DMX IN DMX OUT DMX IN

6/18
DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noise from disturbing and corrupting the DMX512 control signals.
The DMX terminator is simply a Canon connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged
into the output socket on the last fixture in the chain. The connections are illustrated below.
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain.
PIN 3
PIN 2
PRODUCT FUNCTION SETUP
Control panel with wireless function:
Control panel without wireless function:
Fixture’s address and function code configuration can be set conveniently via Touch Key and LCD display. Press button ENTER
more than 3 seconds to unlock panel. LED display shows the fixture’s function menu. Each Option of the main menu has its own
sub-menu. Each menu stands for specified function of the fixture, please see the details in the following:
Press button UP or DOWN if you want to set or browse through the various Setup Options.
1
2
3
4
5
120

7/18
Press button ENTER to save your settings or enter the sub-menus.
Press button UP or DOWN to change the parameters (increase or decrease the numbers)
Press button FUNC, it will return to the upper menu one by one. If the button not pressed, the system will go back to display status
automatically.
DMX START ADDRESS SETUP
If many fixtures are controlled by the controller, each fixture should be set with a start address to receive signals sent by the controller
and respond to it. The fixture have 2 DMX modes. There are standard mode and extended mode, For example standard mode has 18
channels, so set the No. 1 Fixture’s address 001, No. 2 Fixture’s address 019, No. 3 Fixture’s address 037 and so on.
Switch on the Fixture. Press button ENTER more than 3 seconds to unlock panel.
Press either buttons of UP and DOWN, under 1st level menu to locate the menu of DMX ADDRESS, press ENTER to set DMX
address.
Press button UP and DOWN, you can set the address;
Press button ENTER to confirm; when powered on next time, it will show the latest number you saved.
Press button FUNC, it will return to the upper menu one by one.
STAND-ALONE MODE
Operate the fixture without connecting a controller, enable the master mode in the operation panel, the fixture will run in Stand-Alone
mode automatically.
MASTER/SLAVE MODE
If many fixtures are connected under Master/Slave mode, use XLR-XLR control cable to connect the first fixture’s DMX output port
with the second fixture’s DMX input port, then to connect the second fixture’s output port with the third fixture’s input port and so on
until all the fixtures are connected, the last thing is to plug the terminator at the last fixture’s output port. In this case, the first fixture is
the master, others are slaves
Set the master’s address at 001, Master can be set at any mode(STD mode or extended mode) and slave should be set at same mode as
the master’s.
After powered on, the group will run under Master/Slave mode.
DMX IN FROM
CONTROLLER
DMX OUT TERMINATOR
MASTER SLAVE SLAVE
DMX IN DMX OUT DMX IN

8/18
SOUND OPERATION
To select different level(0-100) of sound sensitivity based on different operating environment under sound operation under
Operation Mode. There are several different(0-6) sound effects for different operating environment under Sound
Operation.
Note: If several fixtures in series under Master/Slave mode, Only Master responds to external sound.
OPERATION MENU
Level 1 Level 2 Level 3 Level 4
DMX Address
Standard 1~495
Extended 1~470
Reset Are You Sure
Config Settings
DMX ChannelMode
（Default is：STd）
Standard 18
Extended 43
Pan Tilt Swap
（Default is OFF）
OFF
ON
Pan & Tilt Invert
（Default is OFF）
OFF
ON
Pan Angle Range
（Default is 360）
360
720
DMX Mode *
（Default：XLR First）
XLR First
XLR Only
Wireless Only
Wireless First
Wireless To XLR
Unlink Wireless * YES
MasterSlaveMode
Default：Slave）
Slave
Master
Sound Level 0～100
Factory Settings YES
PRM Transmit YES
Display Options
Language
English
Chinese
Display Mode
On Always
Off After Delay

9/18
Display Reverse
OFF
ON
Display Contrast
( Default: 9 ) 0~18
Display
Dimming
(
Default:
10
)
0～10
Information
Power On Hours Hour:XXX
Software Version 1.0.1
Test Mode
Self Test YES
Manual Test
Lamp
OFF
Red
Green
Blue
White
Red & Green
Green & Blue
Red & Blue
Red &Green &Blue
ON
Zoom 0-255
Pan Location 0-255
Pan
0-127: Stop
128-191: Pan Speeds in CW
from slow to fast
192-255 :Pan Speeds in CCW
from slow to fast
Tilt Location 0-255
Tilt
0
-
127: Stop
128-191: Tilt Speeds in CW
from slow to fast
192-255 :Tilt Speeds in CCW
from slow to fast
Pan&Tilt Speed 0-255
Operation Mode
DMX Operation YES
Sound Operation 0~8 0: All Audio effect
1～8: Single Audio effect
Preset Memory YES
User Memory YES
Memory Edit Static Scene 1～16
Strobe
000 (NO Strobe)
001-129(Plus Strobe)
130-255(Strobe)
Red 0-255
Green 0-255

10/18
Blue 0-255
White 0-255
Zoom 0-255
Pan
Location 0-255
Pan 0-255
Tilt
Location 0-255
Tilt 0-255
P&T
Speed 0-255
Keep Time
0.1s~25s
Note:
1. There is only one projector to be set as a Master in a signal cable if Master’s functions used, Please disable DMX control
signal.
2. When multiple projectors’ work together in synchronous control state, Parameters can be transmitted from the master
projector to the slave projector such as DMX channel mode, Display setting status ( Contrast setting exclude ) and
operation mode ( User memory data is include ) . Before parameters transmitted, the projector which will send
parameters should be set as a Master and others be as Slaves.
3. Mark “ * ” content applies only to the wireless receiving function effective use.
DMX PROTOCOL
Standard Extended Functions DMX Descriptions
1 1 Strobe
000 No Strobe
001-129 Pulse from slow to fast
130-255 Strobe from slow to fast
2 2 Dimmer 000-255 Linear Dimming from dark to bright
3 Dimming in 16 bit 000-255 Dimming in 16 bit precision
3 4 Color Temp 000 No
001-255 Linear color Temp adjustment from high to low
4 5 Animation 000 No
001-255 Animation effect
5 6 Color Macro
000 No
001-031 Red
032-063 Green
064-095 Blue
096-127 Red & Green
128-159 Green &Blue
160-191 Red& Blue
192-223 Red &Green& Blue
224-255 Rainbow effects (Speed from slow to fast between 224 and 255
in DMX value
6 7 Area 1 Red 000-255 Linear adjustment in Red from light to dark of Area 1

11/18
8 Area 2 Red 000-255 Linear adjustment in Red from light to dark of Area 2
9 Area 3 Red 000-255 Linear adjustment in Red from light to dark of Area 3
10 Area 4 Red 000-255 Linear adjustment in Red from light to dark of Area 4
11 Area 5 Red 000-255 Linear adjustment in Red from light to dark of Area 5
12 Area 6 Red 000-255 Linear adjustment in Red from light to dark of Area 6
13 Area 7 Red 000-255 Linear adjustment in Red from light to dark of Area 7
7
14 Area 1 Green 000-255 Linear adjustment in Green from light to dark of Area 1
15 Area 2 Green 000-255 Linear adjustment in Green from light to dark of Area 2
16 Area 3 Green 000-255 Linear adjustment in Green from light to dark of Area 3
17 Area 4 Green 000-255 Linear adjustment in Green from light to dark of Area 4
18 Area 5 Green 000-255 Linear adjustment in Green from light to dark of Area 5
19 Area 6 Green 000-255 Linear adjustment in Green from light to dark of Area 6
20 Area 7 Green 000-255 Linear adjustment in Green from light to dark of Area 7
8
21 Area 1 Blue 000-255 Linear adjustment in Blue from light to dark of Area 1
22 Area 2 Blue 000-255 Linear adjustment in Blue from light to dark of Area 2
23 Area 3 Blue 000-255 Linear adjustment in Blue from light to dark of Area 3
24 Area 4 Blue 000-255 Linear adjustment in Blue from light to dark of Area 4
25 Area 5 Blue 000-255 Linear adjustment in Blue from light to dark of Area 5
26 Area 6 Blue 000-255 Linear adjustment in Blue from light to dark of Area 6
27 Area 7 Blue 000-255 Linear adjustment in Blue from light to dark of Area 7
9
28 Area 1 White 000-255 Linear adjustment in White from light to dark of Area 1
29 Area 2 White 000-255 Linear adjustment in White from light to dark of Area 2
30 Area 3 White 000-255 Linear adjustment in White from light to dark of Area 3
31 Area 4 White 000-255 Linear adjustment in White from light to dark of Area 4
32 Area 5 White 000-255 Linear adjustment in White from light to dark of Area 5
33 Area 6 White 000-255 Linear adjustment in White from light to dark of Area 6
34 Area 7 White 000-255 Linear adjustment in White from light to dark of Area 7
10 35 Zoom 000-255 Linear adjustment in Field Angle
11 36 Pan Location 000-255 Pan (0~360°)
12 37 Pan Location in 16 bit 000-255 Pan in 16 bit precision
13 38 Pan
000-127 Pan Stop
128-191 Pan Speeds in CW from slow to fast
192-255 Pan Speeds in CCW from slow to fast
14 39 Tilt Location 000-255 Tilt(0~270°)
15 40 Tilt Location in 16 bit 000-255 Tilt in 16 bit precision
16 41 Tilt
000-127 Tilt Stop
128-191 Tilt Speeds in CW from slow to fast
192-255 Tilt Speeds in CCW from slow to fast
17 42 Pan & Tilt Speeds 000-255 Pan & Tilt Speeds from fast to slow
18 43 Control function 000-049 Reserved
050-255 Reset
Remarks:
1. DMX Priority sequence from high to low: Macro, Animation, CT, single color dimming of RGBW, Pan Continuous rotation,
Tilt continuous rotation
2. Regional distribution are as follows (Base on the Reset Status of Sample product’s）

12/18
Area1
Area3
Area5
Area4
Area6
Area7
Area2
DISPLAY INFORMATION
LED Indications：
DMX Indication ON DMX Signal OK
OFF NO DMX Signal
W-DMX Indication
ON Wireless DMX Signal available
OFF Not linked to any transmitter
Flash Lose link with a transmitter or being linked with one
SOUND Indication ON Sound Operation on
OFF Sound Operation off
Explanations for logo on top-right of the LCD display：
S
Slave
M
Master
D
DMX512 Mode
I Preset Memory
V Sound Operation
U
User’s Memory
T
Test Memory
Lock Logo
Buttons are Locked, buttons are
unlocked and lock logo disappears after “Enter” button
pressed more than 3 seconds
MAINTENANCE
If the Fixture does not function, check if the fuses on the power socket of the unit is broken or not, if broken, they should only be
replaced by fuses of the same specification. Should there be damaged call a qualified technician before replacement. The fixture has
thermal protection device that will switch off the unit in case of overheating. Should any case like this happen, check if the fans work
well or fans and fan screens are blocked, restart the fixture before the problems have been found and resolved.
Any maintenance work should only be carried out by qualified technicians.

13/18
PRODUCT CLEANING
To ensure the reliability of the fixture it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The
lens should also be regularly cleaned to maintain an optimum light output. Do NOT use any type of solvent containing chemical
elements.
Cleaning intervals depends on the environment in which the fixture operates and use frequency. A soft cloth and typical glass
cleaning products should be used in cleaning the fixtures. It is recommended to clean the external optical system at least once every 20
days.
Do not use any organic solvent, e.g. alcohol, to clean the housing of the apparatus to avoid damages
TROUBLE SHOOTING
PROBLEM ACTION
The fixture can not start
 Check if the fuse on the power socket is broken or not .
 Check the status of the fuse
The lamp works normal but the fixture doesn’t
respond to the controller
 Check if the fixture’s start address is set properly
 Check if XLR signal cable is broken or not
The fixture only functions intermittently
 Make sure the fans work normally and if dirt blocks fans and fan
screens.
The beam appears dim and brightness decreases
apparently
 Check if the lamps reach the end of their lives
 Check if external and internal optical systems are clean or not.
TECHNICAL DATA
VOLTAGES:
100V~240V AC,50/60Hz
LIGHT SOURCE:
TYPE: LED LZ4-04MDCA
QUANTITY: 7 Pcs
LIFE SPAN: 50,000 Hrs
POWER CONSUMPTION:
200W@220V
HEAD MOVEMENT:
Pan: 720°,360°or Endless, Tilt : 270°or Endless
Pan Tilt Swap and Invert Function ; Auto-position correction and magnet positioning function
COLOR SYSTEM:
RGBW linear color mixing with macro

14/18
DIMMER
0-100% linearly adjustable
COLOR TEMPERATURE CORRECTION:
Linear color temperature correction from 10000K to2700K.
STROBE:
Electronic strobe, 0-25 F.P.S
LENS ANGLE:
Beam Angle(1/2 Maximum) : 7°~42°
Field Angle(1/10 Maximum): 17°~60°
CONTROL:
DMX512, 5 pin interfaces
18channels in standard mode, and 43 channels in extended mode.
Master/slave mode
Stand-alone mode, Preset mode, Self test mode, Single Scene mode
OTHER FUNCTIONS:
Single LED control
Sound operation
Wireless control (optional)
Over temperature protection
HOUSING:
High temperature engineering-plastic, IP20
WEIGHT:
5.7 Kg
SIZES:
348
274
305
187

15/18
LIGHT OUTPUT :
DISTANCE（M） 0 2 4 6 8 10 12
17°LUX（lx） 019739 4935 2193 1234 790 548
17°DIAMETER （M） 0 0.3 0.6 0.9 1.2 1.5 1.8
0 1309 327 145 82 52 36
0 0.27 0.53 0.8 1.06 1.33 1.6
60°LUX（lx）
60°DIAMETER （M）
COMPONENT ORDER CODES
NO NAME PART NO. QUANTITY REMARK
1 POWER SUPPLY
19201018
4
1 PCS
2 20W LED ASSAMBLY
230060
361
1 PCS
3 LENS 1 071100058 7 PCS
4 LENS 2 071100059 7 PCS
5 FUSE
270041037
1 PCS
6 TILT/ PAN BELT
290151413
2 PCS
7 8025FAN
0300600
99
1 PCS
8 4010 FAN
030060093
1 PCS
9 STEP MOTOR( PAN/TILT )
030040
239
2 PCS
10 STEP MOTOR ( ZOOM ) 030040235 3 PCS
11 PAN/TILT MOTOR DRIVE BOARD
230060
352
1 PCS
12 LED DRIVER PCB
230060
351
1 PCS
13 DISPLAY PCB
230060
353
1 PCS
14 WIRELESS ANTENNA W006512 1 PCS
(optional)
15 WIRELEES RECEIVER W006511 1 PCS
(optional)

16/18
IRCUIT DIAGRAM

17/18

18/18
PR LIGHTING LTD.
1582 Xingye Avenue, Nancun Panyu
Guangzhou, 511442 China
TEL: [phone]
FAX: [phone]
P/N: 320020266
Version: 20141013
