PR XRLED 700-WBWS User manual

1
XRLED 700-W BWS
PR-8173
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1.
SAFETYAND WARNINGS…………………………………………………………………………………………
3
2.
INSTRUCTIONS……………………………………………………………………………………………………
4
3.
APPEARANCE…………………………………………………………………………………………………
……
5
4.
INSTALLATION……………………………………………………………………………………………………
5
5.
SETUPAND CONFIGURATION……………………………………………………………………………………
8
6.
OPERATION MENU………………………………………………………………………………………………
10
7.
DMX PROTOCOL…………………………………………………………………………………………………
15
8.
ERROR MESSAGES……………………………………………………………………………………………
21
9.
TECHNICALDATA…………………………………………………………………………………………………
22
10.
CIRCUIT
DIAGRAM………………………………………………………………………………………………
25
11.
COMPONENT ORDER
CODES……………………………………………………………………………………
27
ACCESSORIES
The following items are supplied with the projector and please check:
Name
Quantity
Unit
Remark
G clamps
2
Pcs
XLR connector
1
Set
Male and female
Safety cord
1
Pc
User manual
0
Pc
QR Code
Ω clamps
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of the manual we reserve the right
to change specifications in the course of product improvement. The publishers cannot be held responsible for the
accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or
the unit are in good condition before installation and use. Should there be any damage caused by transportation,
consult your dealer and do not use the unit. Any damage caused by improper use will not be assumed by the
manufacturer and / or dealer.

3
Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the
delivery date but the light source is not within the warranty.
1. SAFETYAND WARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
The following safety signs are used in the user manual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
●When unpacking , check if there is transportation damage before using the projector. Should there be any
damage caused by transportation, consult your dealer and do not use it.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projector as he/she likes.
●Please be noted that the damage caused by changing the projector at will is not warranted.
●Do not hesitate to contact the dealeror the manufacturer if any questions or advice.
●The projector is for indoor use only, IP20.
●Use only in dry locations. Keep this unit away from rain and moisture, excessive heat, humidity and dust. Do not
allow contact with water or any other liquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
being operated.
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operation must strictly follow the procedures in the manual.
●No repairable parts in the projector and do not open covers for maintenance by yourself.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned..
●Do not connect this device to any type of dimmer pack.
●lens and other optical parts shall be replaced immediately if they have deformed or been damaged, otherwise the
light output will be compromised.
●For the location of a lighting fixture, it shouldn’t be seen in the distance of less than 4 meters.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector while covers(housing)are off .
●Keep the lamp clean and do not touch it with bare hands.
●While operating it, wear protective items.

4
●Any electrical connection must be carried out by a qualified person .
●Before installation, please confirm the voltage supplied matches what is required for the projector.
●Each projector must be properly earthed and installed as per related electrical standards.
●Do not use power cord with its insulator damaged and connect the power cord with other cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully or
by pulling the power cable.
●All power cords must conform to related safety and regulations.
●While being operated, the projector should not be under rains or in humidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electrical parts’ life will be shortened .
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord
supplied through the safety cord holes for safety support.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from
power mains.
●.After stable operation under normal ambient temperature ,the temperature of the external surface of the housing
of the LED lighting fixture (the surface of the heat sink) is 75℃after the stable running.
●While the LED is lit for the first time, there will be smoke and strange smell. It’s normal and does not mean the
projector has some defects.
●While projector running, do not touch the metal housing with bare hand, otherwise get burned.
●Under normal ambient conditions, the housing’s temperature should be less than 75℃.
●Do not mount the projector directly on inflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector
and illuminated items is 10m.
●A projector should be installed with good ventilation and the minimum distance between the projector and walls
is 50cm.At the same time, please ensure the fans and air inlets and outlets are workable.
●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature
internally causing damages to the projector. Before power-off, please use Tilt channel to move the head and
make it facing downward.
●The product meets The General Technical Requirements and Standards for Recycle and Use Of
ExpiredAppliance and Electronic Products.
●When the product meets disposal standards and needs to be disposed, a client needs to dispose and recycle it.
2. INSTRUCTIONS
●CLEANINGAND MAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved, restart
the projector.
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very necessary to
ensure a reliable use of it. Cooling fans need to be cleaned every 15days. Internal lens, reflector and hot mirror need to be cleaned
periodically to optimize light output.
Cleaning frequency is to be decided by operations and its environment. Use soft cloth and normal detergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean
and do not touch optical parts with bare hands.
●Before any maintenance and cleaning, please ensure the project is off the power.
●Only qualified person is allowed to do maintenance.
●During maintenance and before maintenance, the projector must be off power.

5
●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high
temperature internally causing damages to the projector. Before power-off, please use Tilt channel to
move the head and make it facing downward.
●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
●Do not use any solvent with chemical elements to clean color filters or hot mirror.
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’bearings and 2 sliding bars for zoom and focus lens
be lubricated every 2 months. High quality and high temperature lubricant/grease is advised..
●TROUBLESHOOTING
PROBLEM
ACTION
The projector can’t be switched on
Check if the fuse is burned
Check if the power cord is connected well
Check if the switching power supply is bad or not connected well. A
professional technician is required for the repair
Check if the control board is connected well. .A professional technician
is required for the repair
The projector can be switched on , but the LED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technician is required for the repair
The projector can be switched on normally, but
not controlled by the DMX controller
Make sure that the fixture’s start address is right
Replace or repair the XLR signal cable.
The beam is not bright and its brightness
decreases sharply
Make sure the fans are working well orfans and their shields are not blocked
by dust.
Makesure that theinternal opticsis clean.
The project image appears to have a halo
Carefully clean the LED lamp, optical lenses and other components.
Heavily Defective Beam
Check if lens are in good condition(not cracked)
Clean dust or grease on the lens.
3. APPEARANCE
4. INSTALLATION
●RIGGING
Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a
projector with power while it is locked.
Head
Arm
Base

6
Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to
each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside
of the base as shown above) To pass the SAFETY CORD through the HOLES for safety! Always ensure that the projector is
firmly anchored to avoid vibration and slipping whilst functioning.Always ensure that the structure that you are going to mount the
projector to is secure and strong enough to support the weight of a projector.
WARNING:
●The projector MUST be lifted or carried by the HANDLES instead of clamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●POWER CONNECTION
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector be connected with power separately so that they may be individually switched on and off.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in accordance with
the standards concerned.
●If any questions about the electrical installation, do not continue but consult a qualified electrician.
Note:
1. the distance between the foot of the base and
the front lens cover(the head facing downward)
2. the distance between mounting truss and the
front lens cover( the head facing downward)
3. The maximum diameter of the rotating head
( minimum spacing between fixtures)
Warning
Please run the safety
cord through its 2 holes for
safety

7
●DMX CONTROLCONNECTION:
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each
wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector)
or 5 pin XLR plugs and sockets. The XLR's are connected as shown in the figure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The XR330BWS accepts digital control signals in protocol
DMX512 (1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second fixture’s
DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX terminator as
shown in the figure below.
●DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged into
the output socket on the last projector in the chain. The connections are illustrated below.
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain.
PIN 3
PIN 2
●GOBO REPLACEMENT

8
Open the head cover after locking the Tilt and loosening 6 fast-fit screws of the cover and the structures as illustrated by the above figures
will be seen.
For the rotating gobos: Take out the rotators by hand and remove the spring and gobo. Place a new gobo into the rotator and put back the
spring. Ensure the spring is in the narrower side of the rotator, i.e. inner circle of the rotator, and flatten it. At last, use proper tool to
compress the spring and with the help of the other hand place the rotator back to its original place in the wheel.
Note: Do not touch the color filter and gobos by hand. Clean and soft paper or cloth must be between hands and gobos or color filters.
Tighten the 6 fast-fit screws after the head cover is on. Unlock the Tilt.
DANGER!
Before replacement of gobos, the projector must be off the power.
5. SETUPAND CONFIGURATION
●FRONT PANELOPERATION
The projector configuration can be set conveniently via push buttons and color touch screen.
To browse through or change the projector ’s settings, touch the white area of the touch screen or press ENTER button for more than
3s(Only powered by the battery, pressing the ENTER button) to unlock the screen , then press ENTER key to enter the projector ’s
function menus. Each main menu has its sub-menus. And each menu stands for special function. For the details, please see the
following 6th point ”Operation Menu”.:
1. At the page to set the fixture’s functions, press FUNC, ENTER,▲,▼ keys or their respective icons to select the functions
desired.
2. While at 2nd,3rd and 4th level of menus, the FUNC key is for ESCAPE, but ENTER key won’t work, and ENTER key is used for
ENTER. Press ENTER key to save the changes or enter into the sub menus. Press ▲or ▼keys to change the
numbers(minus or plus). Or touch the option needed for change.
Push the left key or X on the top right to go back to the upper level menu. Otherwise, the system will go back to initial status.
Shortcut keys: After the Function Menu is entered into, there are all options for the functions on the top of the screen. On the right
there are 4 shortcut keys like ←,→ Lamp Control and English/Chinese.

9
●DMX STARTADDRESS
Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3 DMX modes. There are standard mode ,short mode and extended mode. For example standard mode has
30 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 031, No. 3 projector’s address 061,No. 4 projector’s
address 091, and so on.
Switch on the Projector . Press ENTER key more than 3 seconds to unlock panel, then press ENTER key to enter into the fixture’s
operation menus.
Select DMXAddress icon and press ENTER key or touch the icon directly on the display and select DMX address at the 2nd level menu
for the address setting.
Press▲or ▼keys or touch<、>displayed for the DMX address desired.
Press ENTER key to confirm.
Press the FUNC key to go back to the upper level menu.
.
●DMX WIRELESS CONTROL（Optional）
The projector has wireless control function with wireless receiver module and antenna for remote control.
The setup of it is below:
1. Press ▲ and ▼keys to enter into the operation menu and select “Config Settings”.
2. Select “Wireless First” or “Wireless Only” from the menu of “Signal Select”.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press
“Enter” for the menu of Un-link Wireless under the upper level menu of Config Settigns , then the fixture is unlinked with the
wireless transmitter.
●FAN SPEED MODES
It has standard and theater modes. Theater mode is quiet mode.
Its setups are as follows:
1. Hold the “ENTER”button for more than 3s to unlock the control panel and then push▲、▼button to enter into the menus
and select “Option Settings”.
2. Select either of Standard and theater modes after the menu of Fan Settings.
●STAND-ALONE MODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVE MODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the last
fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation mode can
be set accordingly.
After Powered on, the group will run in Master/Slave Mode

10
6. OPERATION MENU
1st
LEVEL
2nd LEVEL
3rd LEVEL
4th LEVEL
5th LEVEL
Address
DMX Address
1-488（short mode）
1-483（STD mode）
1-478（Extended mode）
IP Address
Default IPAddress
2.X.X.X /10.X.X.X
Custom IPAddress
X.X.X.X
SubNet Mask
X.X.X.X
ArtNet Universe
0-255
sACN Universe
1-63999
Reset
Total Reset
Really Reset?
Confirm or Cancel
Pan&Tilt Reset
Really Reset?
Confirm or Cancel
Colour System Reset
Really Reset?
Confirm or Cancel
Gobo Reset
Really Reset?
Confirm or Cancel
Fo. Zo. Fr. Pr. Reset
Really Reset?
Confirm or Cancel
Other Reset
Really Reset?
Confirm or Cancel
DMX Channel Mode
Short Mode 25CH
Standard Mode 30CH
Extended Mode 35CH
View Selected Mode
. Ch.01 Strobe
Ch.02 Dimmer
…
Ch.XX Control Function
Signal Select
(Wireless control only
XLR Only

11
Config
Settings
for the projector with
wireless receiver)
XLR First
Wireless Only
Wireless First
Wireless In/XLR Out
ARTNETOnly
ARTNETIn/XLR Out
sACN Only
sACN In /XLR Out
Loss of DMX
Normal time out
Hold Last Value
Display Config
Display Mode
Off After Delay
OnAlways
Display Invert
Invert OFF
Invert ON
InvertAuto
Language Setting
English\Chinese
Touch Calibration
Temperature Unit
Celsius Degree
Fahrenheit Degree
Un-LinkWireless
(Wireless control only
for the projector with
wireless receiver)
Really Un-Link?
Confirm or Cancel
Factory Defaults
Restore Defaults?
Confirm or Cancel
Option
Settings
Pan/Tilt Settings
Pan DMX Invert
OFF/ ON
Tilt DMX Invert
OFF/ ON
Pan Tilt Swap
OFF/ ON
XYFeedback
OFF/ ON

12
Pan/Tilt mode
Speed/Time
1. "Speed Mode" means Pan
and Tilt will move from
Point A to Point B at their
respective maximum
speeds."Time Mode"
means both Pan and Tilt
will arrive at designated
point at the same time. It's
advised Time Mode be
used if the projector runs
circles or in oblique lines.
Dimmer Settings
Gamma Curve
2.0/2.2/2.4/2.6
LED Refresh rate
1200/2400/4800/10000/12000/15000/2
0000/25000Hz
Dimmer speed
Fast/Medium/Slow
Fan Settings
Standard/Theatre
Invert Settings
Iris Invert
ON/OFF
Zoom Invert
ON/OFF
CYM Invert
ON/OFF
CTO Invert
ON/OFF
Defaults
Information
View DMX Values
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CYM Macro XXX
Cyan XXX
Yellow XXX
Magenta XXX
CTO XXX
Color Wheel XXX
Color Wheel Fine XXX
Iris XXX
Iris Macro XXX
Fix. Gobo Wheel XXX
Rot. Gobo Wheel XXX
Rot. Gobo Rotation XXX
Rot. Gobo Rotation F. XXX
Prism XXX
Prism Rotation XXX
Frost XXX
Effect wheel XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Pan XXX
Pan Fine XXX
Tilt XXX
Tilt Fine XXX
Pan /Tilt speed & time XXX
Power/Special Fun. XXX
Lamp Hours
Lamp Hours＝XXX H
Reset Lamp Hours
Total Hours
Total Hours＝XXX H

13
Temperature
Display Board=×××C
Pan &Tilt Board=×××C
Driver Board1=×××C
Driver Board2=×××C
LED Sensor =XXXC
Software Version
PCB Sys Boot
Display Board xxx xxx
Pan & Tilt board xxx xxx
Driver Board1 xxx xxx
Driver Board 2 xxx xxx
Electronic SN
XXXXXX
RDM Device Label
XXXXXXX
ANSI E1.20 RDM
Fan Status
Fan Speed Status
Base Fan1 xxx on/off
Base Fan2 xxx on/off
LED Fan1 xxx on/off
LED Fan2 xxx on/off
LED Fan3 xxx on/off
Service
Manual Effect Control
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CYM Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Iris XXX
Iris Fine XXX
Iris Macro XXX
Fix. Gobo Wheel XXX
Rot. Gobo Wheel XXX
Rot. Gobo Rotation XXX
Rot. Gobo Rotation F. XXX
Prism XXX
Prism Rotation XXX
Frost XXX
Effect wheel XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Pan XXX
Pan Fine XXX
Tilt XXX
Tilt Fine XXX
Pan /Tilt speed & time XXX
Power/Special Fun XXX
Factory Mode
XXX
…
DMX Mode
Change Operation Mode?
Confirm or Cancel
Master Mode
Preset Memory
Change Operation Mode?
Confirm or Cancel

14
Operation
Mode
User Memory 1
Change Operation Mode?
Confirm or Cancel
User Memory 2
Change Operation Mode?
Confirm or Cancel
Stand-Alone Mode
Preset Memory
Change Operation Mode?
Confirm or Cancel
User Memory 1
Change Operation Mode?
Confirm or Cancel
User Memory 2
Change Operation Mode?
Confirm or Cancel
Static Scene
Change Operation Mode?
Confirm or Cancel
DiffFrost
User
Memories
Edit User Memory
Edit User Memory 1
/
Edit User Memory 2
Scene XX
(1~200Scenes）
Paste?
Confirm/Cancel
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CYM Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Iris XXX
Iris Fine XXX
Iris Macro XXX
Fix Gobo Wheel XXX
Rot. Gobo Wheel XXX
Rot. Gobo Rotation XXX
Rot. Gobo Rotation F. XXX
Prism XXX
Prism Rotation XXX
Frost XXX
Effect wheel XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Pan XXX
Pan Fine XXX
Tilt XXX
Tilt Fine XXX
Pan /Tilt speed & time XXX
Power/Special Fun XXX
FadeTime XXX
HoldTime XXX
Delay Unit ms/s/min
Link to Step XXX

15
Edit Static Scene
Paste?
Confirm/Cancel
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CYM Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Iris XXX
Iris Fine XXX
Iris Macro XXX
Fix Gobo Wheel XXX
Rot. Gobo Wheel XXX
Rot. Gobo Rotation XXX
Rot. Gobo Rotation F. XXX
Prism XXX
Prism Rotation XXX
Frost XXX
Effect wheel XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Pan XXX
Pan Fine XXX
Tilt XXX
Tilt Fine XXX
Pan /Tilt speed & time XXX
Power/Special Fun XXX
FadeTime XXX
Hold Time XXX
Delay Unit ms/s/min
Link to Step XXX
Init User Memory
Reset User Memory 1
Reset User Memory?
Confirm or Cancel
Reset User Memory 2
Reset User Memory?
Confirm or Cancel
Reset Static Scene
Reset Static Scene?
Confirm or Cancel
7. DMX PROTOCOL
Short
mode
Standard
mode
Extended
Mode
FUNCTION
DMX
DESCRIPTION
1
1
1
Strobe
000
Close
001-127
Pulse strobe speed from slow to fast
128-255
Strobe from slow to fast
2
2
2
Dimmer
000-255
Linear dimming（0-100%）
3
3
Dimmer Fine
000-255
Dimmer in 16 bit
3
4
4
CYM Macro
0-7
Open
8-9
Color Temperature 2700K
10-11
Color Temperature 3000K
12-13
Color Temperature 3500K
14-15
Color Temperature 4000K

16
16-17
Color Temperature 4500K
18-19
Color Temperature 5000K
20-21
Color Temperature 5700K
22-23
Color Macro 1
24-25
Color Macro 2
26-27
Color Macro 3
28-29
Color Macro 4
30-31
Color Macro 5
32-33
Color Macro 6
34-35
Color Macro 7
36-37
Color Macro 8
38-39
Color Macro 9
40-41
Color Macro 10
42-43
Color Macro 11
44-45
Color Macro 12
46-47
Color Macro 13
48-49
Color Macro 14
50-51
Color Macro 15
52-53
Color Macro 16
54-55
Color Macro 17
56-57
Color Macro 18
58-59
Color Macro 19
60-61
Color Macro 20
62-63
Color Macro 21
64-65
Color Macro 22
66-67
Color Macro 23
68-69
LEE 4 (Medium Bastard Amber)
70-71
LEE 10 (Medium Yellow)
72-73
LEE 19 (Fire)
74-75
LEE 26 (Bright Red)
76-77
LEE 58 (Lavender)
78-79
LEE 68 (Sky Blue)
80-81
LEE 71 (Tokyo Blue)
82-83
LEE 79 (Just Blue)
84-85
LEE 88 (Lime Green)
86-87
LEE 90 (Dark Yellow Green)
88-89
LEE 100 (Spring Yellow)
90-91
LEE 101 (Yellow)
92-93
LEE 102 (Light Amber)
94-95
LEE 103 (Straw)
96-97
Lee 104 (Deep Amber)
98-99
LEE 105 (Orange)
100-101
LEE 106 (Primary Red)
102-103
LEE 111 (Dark Pink)

17
104-105
LEE 115 (Peacock Blue)
106-107
LEE 116 (Medium Blue-Green)
108-109
LEE 117 (Steel Blue)
110-111
LEE 118 (Light Blue)
112-113
LEE 119(Deep Blue)
114-115
LEE 120 (Dark Blue)
116-117
LEE 121 (LEE Green)
118-119
LEE 128 (Bright Pink)
120-121
LEE 131 (Marine Blue)
122-123
LEE 132 (Medium Blue)
124-125
LEE 134 (Golden Amber)
126-127
LEE 135 (Deep Golden Amber)
128-129
LEE 136 (Pale Lavender)
130-131
LEE 137 (Special Lavender)
132-133
LEE 138 (Pale Green)
134-135
LEE 139 (Primary Green)
136-137
LEE 141 (Bright Blue)
138-139
LEE 147 (Apricot)
140-141
LEE 148 (Bright Rose)
142-143
LEE 152 (Pale Gold)
144-145
LEE 154 (Pale Rose)
146-147
LEE 157 (Pink)
148-149
LEE 158 (Deep Orange)
150-151
LEE 162 (Bastard Amber)
152-153
LEE 164 (Flame Red)
154-155
LEE 165 (Daylight Blue)
156-157
LEE 169 (Lilac Tint)
158-159
LEE 170 (Deep Lavender)
160-161
LEE 172 (Lagoon Blue)
162-163
LEE 179 (Chrome Orange)
164-165
LEE 180 (Dark Lavender)
166-167
LEE 181 (Congo Blue)
168-169
LEE 197 (Alice Blue)
170-171
LEE 201 (Full C.T. Blue)
172-173
LEE 202 (Half C.T. Blue)
174-175
LEE 203 (Quarter C.T. Blue)
176-177
LEE 204 (Full C.T. Orange)
178-179
LEE 205 (Half C.T. Orange)
180-181
LEE 206 (Quarter C.T. Orange)
182-183
LEE 247 (LEE Minus Green)
184-185
LEE 248 (Half Minus Green)
186-187
LEE 281 (Three Quarter C.T. Blue)
188-189
LEE 285 (Three Quarter C.T. Orange)
190-191
LEE 352 (Glacier Blue)

18
192-193
LEE 353 (Lighter Blue)
194-195
LEE 715 (Cabana Blue)
196-197
LEE 778 (Millennium Gold)
198-199
LEE 793 (Vanity Fair)
200-255
CYM 混色变换效果速度由慢到快
4
5
5
Cyan
000-255
Cyan (linear 0~100%)
6
Cyan Fine
000-255
Cyan in 16 Bit
5
6
7
Yellow
000-255
Yellow (linear 0~100%)
8
Yellow Fine
000-255
Yellow in 16 Bit
6
7
9
Magenta
000-255
Magenta (linear 0~100%)
10
Magenta Fine
000-255
Magenta in 16 Bit
7
8
11
CTO
000-255
CTO(linear 0~100%)
12
CTO Fine
000-255
CTO in 16 bit
8
9
13
Color Wheel
000-063
Indexing(0-360degrees)
064-087
Open
088-091
Open / (Red)
092-095
Red
096-099
Red /Light Green
100-103
Light Green
104-107
Light Green / Blue
108-111
Blue
112-115
Blue / Cyan
116-119
Cyan
120-123
Cyan / Yellow
124-127
Yellow
128-131
Yellow /Magenta
132-135
Magenta
136-139
Magenta /Orange
140-143
Orange
144-147
Orange /Green
148-151
Green
152-155
Green /Dark Blue
156-159
Dark Blue
160-163
Dark Blue /UV
164-167
UV
168-171
UV /Light Yellow
172-175
Light Yellow
176-179
Light Yellow /DarkYellow
180-183
DarkYellow
184-187
DarkYellow/Open
188-191
Open
192-223
Rotation ,Clockwise from slow to fast
224-255
Rotation,Anti-clockwise from fast to slow
10
14
Color Wheel Fine
0000-255
Color Wheel in 16 Bit

19
9
11
15
Iris
000-255
Linear Iris from small to big 0-100%
16
Iris Fine
000-255
Iris in 16 bit precision
10
12
17
Iris Macro
000-010
Iris Macro disabled
011-074
Iris Macro1: from big to small with speed from
slow to fast
075-138
Iris Macro2: from small to big with speed from
slow to fast
139-202
Iris Macro3: Iris contracts from slow to fast
203-210
Iris Macro4(Macro1 at random) with speed from
slow to fast
211-218
Iris Macro5(Macro2 at random) with speed from
slow to fast
219-229
Iris Macro6(Macro3 at random) with speed from
slow to fast
230-255
Open
11
13
18
Fixed Gobo
Wheel
000-015
White
016-031
Gobo1
032-047
Gobo2
048-063
Gobo3
064-079
Gobo4
080-095
Gobo5
096-111
Gobo6
112-127
Gobo7
128-156
Clockwise rotation from slow to fast
157-185
Anti Clockwise rotation from slow to fast
186-195
Shake effect 1 from slow to fast
196-205
Shake effect 2 from slow to fast
206-215
Shake effect 3 from slow to fast
216-225
Shake effect 4 from slow to fast
226-235
Shake effect 5 from slow to fast
236-245
Shake effect 6 from slow to fast
246-255
Shake effect 7 from slow to fast
12
14
19
Rotating Gobo
Wheel
000-015
White
016-031
Gobo1
032-047
Gobo 2
048-063
Gobo 3
064-079
Gobo 4
080-095
Gobo 5
096-111
Gobo 6
112-127
Gobo 7
128-156
Rotation （clockwise From slow to Fast）
157-185
Reverse Rotation（anti-clockwise From slow
to Fast）
186-195
Shake of Gobo 1 from slow to fast

20
196-205
Shake of Gobo 2 from slow to fast
206-215
Shake of Gobo 3 from slow to fast
216-225
Shake of Gobo 4 from slow to fast
226-235
Shake of Gobo 5 from slow to fast
236-245
Shake of Gobo 6 from slow to fast
246-255
Shake of Gobo 7 from slow to fast
13
15
20
Gobo Rotation
000-128
Gobo Indexing(0~360 degrees)
129-188
Rotation （Clockwise From slow to Fast）
189-195
Stop
196-255
Rotation （Anti-ClockwiseFromslowtoFast）
16
21
Gobo Rotation
Fine
000-255
Gobo Rotation in 16 Bit
14
17
22
Prism
000-016
Open
128-255
Prism
15
18
23
Prism Rotation
000-127
Prism Indexing
128
Stop
129-191
Rotation(Clockwise from slow to fast)
192
Stop
193-255
Rotation(Anti- Clockwise from slow to fast)
16
19
24
Frost
000-09
No
010-255
Frost In
17
20
25
Effect Wheel
000-010
No
011-020
Effect wheel in
21-255
Effect wheel rotation from slow to fast
18
21
26
Focus
000-255
Linear Focus
22
27
Focus Fine
000-255
Focus in 16 bit precision
19
23
28
Zoom
000-255
Linear Zoom
24
29
Zoom Fine
000-255
Zoom in 16 bit precision
20
25
30
Pan
000-255
Pan(0°~540°)
21
26
31
Pan Fine
000-255
Pan in 16 bit
22
27
32
Tilt
000-255
Tilt(0°~270°)
23
28
33
Tilt Fine
000-255
Tilt in 16 bit
24
29
34
Pan & Tilt Speeds
000-255
Pan & Tilt Speed from Fast to Slow
25
30
35
Control
000-019
Reserved
Keep in the DMX range for more than 5S to activate the following
functions. If power-off, the following are invalid.
020-024
Graphic Display On
025-029
Graphic Display Off
030-046
Reserved
047-048
Fan standard mode
049-050
Fan theater mode
051-052
Reserved
053-054
Fast dimmer
055-056
Medium dimmer
