Pream-I-Air HM68801RC User manual
TWO POSITION HEPA AIR PURIFIER
WITH REMOTE CONTORL
MODEL HM68801RC
THANK YOU FOR CHOOSING THIS EHS
PRODUCT. BEFORE OPERATING PLEASE
READ THIS INSTRUCTION MANUAL
Impor an Safe y Ins ruc ions
WARNING - This appliance is in ended for use in a domes ic &
commercial environmen only. Any o her use is no recommended by
he manufac urer and may cause fire, elec rical shocks or o her injury o
person or proper y.
When using elec rical appliances, basic safe y
precau ions should always be followed:
1. Always operate the product from a power source of the same
voltage, frequency and rating as indicated on the product
identification plate.
2. Close supervision is necessary when any product is used by or
near children. Do not allow children to use it as a toy.
3. Do not operate any product with a damaged cord or plug, or after
the product malfunctions, is dropped or appears damaged in any
way. eturn the complete product to the place of purchase for
inspection, repair or replacement.
4. To reduce the risk of electrical shocks, do not expose the unit or
flexible cord to moisture of any sort.
5. Switch off and unplug from the power socket when not in use,
before assembling or changing filters and before cleaning.
6. Do not place objects on the product or allow objects to obstruct the
inlet or outlet openings, or operate in close proximity to walls or
curtains, etc.
7. The use of attachments or accessories not recommended or sold
by the product distributor should not be used.
8. This product is intended for normal domestic/household use only.
9. Do not attempt to disassemble the unit other than to replace filters
or scent cartridge.
10. Do not place the unit on a metal surface.
11. Ensure the unit is placed on a firm level surface before operating.
12. Do not use the unit in artificially hot or humid conditions or use in
any hazardous environment.
13. Do not clean the machine with organic solvent.
14. Place the unit 90cm above floor level for best performance. The unit
should never be used at floor level if the room is carpeted.
15. Set in "high speed" to clean room air rapidly and then turn to lower
speed half an hour later. When used at night, set the speed at lower
grade to keep the air fresh and clean.
16. Do not wash the filter cartridge (HEPA). The cartridge is not
washable and doing so will cause damage.
BS Plug Wiring
Wiring Ins ruc ions: Should i be necessary o change he plug please
no e he wires in he mains lead are coloured in accordance wi h he
following code :
BLUE - NEUTRAL
BROWN - LIVE
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your plug,
proceed as follows:
1. The BLUE wire is the NEUTRAL and must be connected to the terminal
which is marked with the letter N or coloured BLACK.
2. The BROWN wire is the LIVE and must be connected to the terminal
which is marked with the letter L or coloured RED.
3. NEITHE WI E must be connected to the terminal which is marked
with the letter E, the earth symbol , coloured G EEN O
G EEN/YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 3A (BS 1362)
fuse. If in doubt consult a qualified electrician.
Wiring for a 13 Amp Plug (BS1363)
Fea ures
Three func ions in one: It can be used as air purifier, ionizer and air
fragrance to improve the air quality in office or home.
*Efficien ly cleans he air: Using negative ion and multi-layer HEPA
filters to collect dust, it can reduce indoor air pollution caused by pollen,
suspended particles, hairs, germs, harmful gases (formaldehyde),
smoke, other odours and transportation of pollution.
*Three-speed se ings: set in high speed ‘H’ to clean room air rapidly,
then turn to medium speed half an hour later to keep the air fresh and
clean. Use extra quiet low speed at night.
*Safe: It is safe and reliable with an auto shut off function. There are 3
time setting modes and related indicator lights
Func ion Guide
Each of the unit’s function can be fully controlled via wireless remote control.
The function keys include:
1) Power
2) Ioniser on/off (“ION”)
3) Low speed
4) Medium speed
5) High speed
6) 8 Hour time setting
7) 4 Hour time setting
8) 2 Hour time setting
emote control required (2) AAA 1.5V batteries (not included).
Note: Batteries contain materials, which are hazardous to the environment;
they must be removed from the appliance at the end of their life and
disposed of safely.
Illus ra ion of air cleaning procedure
1. Side grid: unfiltered air comes in through inlet.
2. Pre-fil er: collects large-sized dust particles in air.
3. HEPA fil er (white): stops small particles coming through with
high-efficiency sterilizing and dust collection function.
4. Ac iva ed carbon fil er (black): absorbs smoke and odours.
5. Tio2 coa ed pho oca alys fil er (grey): kill germs, bacteria and
virus.
6. Scen cover: scent comes from the outlet.
7. Upper cover: emits clean air from outlet.
Note: HEPA means ‘High Efficiency Par icula e Air’. Two Posi ion
HEPA Air Purifier
You can use your Air Purifier upright as shown in diagram or lying down
on its back, whichever suits your chosen location.
Opera ion Guide
1. emove cover (1) eplace pre-filter and cover. Your filters will need
replacing every 6-12 months, depending on the environment and
frequency of use. On the filter there is a space for you to write the
date you inserted into the unit. The HEPA filter will go from white to
a dark grey when it will need changing.
2. Connect to power outlet and press Power button. The default speed
setting will be medium. Manually select high or low if required.
3. Manually select ‘ION’ button if ioniser is required.
4. Press Timer to select required run duration.
5. Press Power button to turn on or turn off.
Please no e your air purifier can be opera ed lying down or uprigh
depending on your chosen loca ion.
Scen Car ridge Fi ing
Press he scen cover (6) and inser
he car ridge (af er removing pull
cover). Press again o close. The
uni can be used wi hou scen if
preferred. Please no e ha for he
small number of as hma ics who are
sensi ive o perfumes e c. hey may
have a similar reac ion wi h he scen
car ridge. These people should use
he scen car ridge wi h cau ion.
Technical Da a
1. Concentration of anion: 1.5 x ≥10
6
ions/cc or above
2. Air cleaning rate: ≥90%
3. Air flow: H: 3m/s, M: 2m/s, L: 1m/s
4. Input voltage: 220-240V~/ 50Hz
5. ated power: 40W
6. Working Environment: Temperature –10-+55°C; 95% H
7. Dimension: 300 x 300 x 175 (mm)
8. Net Weight: 2.55kg
9. Gross Weight: 3.2kg
10. Effective area: 15m²
Main enance
CAUTION: DISCONNECT FROM POWER SUPPLY BEFORE
CLEANING
1. emove the dust from the ion outlet with dry brush as required.
2. Clean the pre filter with water every 2 months to remove dirt and
odour, replace with it is completely dry.
Replacemen Fil ers
• eplacement filters are available from our Help Desk on 0870 742
5021
• eplacement scent cartridges are available from our Help Desk on
0870 742 5021
Produc Disposal Informa ion
Do no mix produc s bearing he crossed ou bin symbol (below)
wi h your general household was e. For he correc collec ion
and rea men of hese produc s ake hem o he collec ion poin s
designa ed by your local au hori y. Al erna ively con ac he
re ailer who sold you he produc .
Service & Warran y
• Do not operate any product with a damaged cord or plug, or after the
product malfunctions, or is dropped or appears damaged in any way.
eturn the complete product to the place of purchase for inspection,
repair or replacement.
• For your convenience, record the complete Model/Type Number
(located on the Product Identification Plate) and the date you received
the product below, and attach your purchase receipt docket as proof of
purchase.
•
To ensure your product is covered by warranty, the complete faulty
product together with your purchase receipt, should be returned to your
retailer.
ONE (1) YEAR LIMITED WARRANTY
SAVE THIS WARRANTY INFORMATION
EHS (In erna ional) L d. guarantees this product free from defects in
materials and workmanship for a period of one (1) year.
Should this unit be operated under conditions other than those
recommended or at voltages other than the voltage indicated on the
unit, or any attempts made to service or modify the unit, this will render
WARRANTY VOID. The product you buy may sometimes differ slightly
from illustration. This warranty is in addition to, and does not affect,
your statutory rights.
Should you have a problem with this product, please write to our
Service Desk, Tel: 0870 7425021.
This product has been manufactured to comply with EEC Directives 73/23/EEC and
89/336/EEC
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
EHS, Manches er, M17 1RN
EHS10/06
