Precision DS1000D Operation manual

Hopper (Pre Assembled)
Leg Stand (04)
Hopper (Pre Assembled) Side Handles (06)
Top Handle (07)
Side Handle (06)
Hardware Sack
Leg Stand (04)
Leg Stand (04)
Top Handle (07)
Side Handles (06)
Top Handle (07)
Control Cable
DS1000D & DS1000DGY Drop Spreader
INSTRUCTIONS & Parts List
NOTE: Wheel may vary from pictures
Sheet Number: 3860 Rev 8/2005
In order to assure that the assembly of your spreader
goes smoothly, please review all of the steps before
proceeding. TIP: Loosely tighten all bolts until assembly
is complete, then completely tighten.
Note: You may have extra hardware when assembly
is complete.
STEP 1 - BEGIN HERE
Lay out all of the parts shown below. If any are
missing, please turn this sheet over and contact us with
the information provided.
STEP 2 - Attach the Leg Stand
Hand tighten the Leg Stand (04) to the Hopper using
four 1-1/4” Carriage Bolts (10) and 1/4” Wing Nuts (12)
at the four locations shown below.
STEP 3 - Attach the Side Handles
Hand tighten the Side Handles (06) to the Leg Stand
(04) using two 1-3/4” Carriage Bolts (11) and
1/4” Wing Nuts (12) at the two locations shown
below.
STEP 4 - Attach the Top Handle
Hand tighten the Top Handle (07) to the Side Handles
(06) using two 1-3/4” Carriage Bolts (11) and 1/4” Wing
Nuts (12) at the two locations shown below.
STEP - 5 Attach the Control Cable
Attach the Control Cable mechanism to the
Top Handle (07) using a 2-1/4” Carriage Bolt (16)
and a 1/4” Wing Nut (12) at the location shown
below.

01
09
08
05
03
02
04
06
07
REF# PART DESCRIPTION PART # QTY.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
Hopper
Axle (Black)
Axle (Gray)
Flow Bar
Leg Stand (Black)
Leg Stand (Gray)
Agitator Blade Plastic
Side Handle (Black)
Side Handle Gray)
Top Handle (Black)
Top Handle (Black)
Wheel
Control Cable Assembly
1/4” x 1-1/4” Carriage Bolt
1/4” x 1-3/4” Carriage Bolt
1/4” Alan Nut
1/2”Hubcap
1-7/16” Split Spacer
#10 x 1-1/4” Sheet Metal Screw
1/4” x 2-1/4” Carriage Bolt
2420
2421B
2421GY
2674
2449B
2449GY
2403
1107B
1107GY
1108B
1108GY
1917
2442
1407
1408
2828
1040
2679
2405
1868
01
01
01
01
01
02
01
02
01
04
04
09
02
02
02
01
PARTS NOT TO SCALE
Control Lever
Calibration Indicator Button
Open
Close
11
10 12
14
13
15
16
Using Your Spreader
Settings are made by pressing down on the
Calibration Indicator Button and sliding it to the
desired setting. Push the Control Lever to the
button to begin spreading. To stop fertilizer
distribution, pull the Control Lever back
to the “off” position.
MAINTENANCE INSTRUCTIONS
AFTER EACH USE: Wash unit thoroughly let dry.
Lubricate moving parts, including flow bar, axle,
and agitator.
CAUTION:
CARE MUST BE TAKEN WITH ANY WEED
KILLER, PESTICIDE, OR COMBINATION
PRODUCT. ALWAYS FOLLOW ALL DIRECTIONS
PRINTED ON THE MATERIAL PACKAGING.
LIMITED WARRANTY
This unit is warranted against defects in materials and workmanship to
the original purchaser, under normal use and service, for a period of
ninety (90) days from date of sale. During the Warranty Period, we will
repair or replace at our option free of charge to the original purchaser,
any part of the Unit that our examination shows to be defective in
workmanship or materials. This Warranty Does Not apply to damage
caused by misuse, abuse, neglect, accident, normal wear, or alterations
by unauthorized persons.
CUSTOMER SUPPORT
At Precision Products, Inc. Delivering quality, value and
outstanding service is our goal. However, sometimes
parts do become damaged or lost during transport from
our facilities to the store. If you have any problems,
please do not return this merchandise to the store.
Call us and we will take care of any problem you
may have with this unit. When ordering replacement
parts, please have the model number, part description
and part number readily available.
Customer Support: [phone] Ex.204
General Office Number: [phone]
General Fax Number: [phone]
Mail: Precision Products, Inc.
Parts Division
316 Limit Street
Lincoln, IL 62656
Visit us on the web at: www.precisionprodinc.com
PARTS LIST
