Precor Spinner Chrono User manual

Service Manual
SBK800-16 INDOOR CYCLES
SPINNER®CHRONO™ POWER
SPINNER®CLIMB™

Contents
Introduction 1
About This Document 1
Service manual contents 2
Additional Service Documentation and Videos 2
Product Literature & Videos 3
Service & Maintenance Documentation 3
Precor Websites 3
Service Videos 4
Safety Guidelines 6
Safety guideline you need to know and follow: 6
General Information 7
Orientation Convention 7
Tools 7
Specification Summary 8
Bolt Grade Identification 8
Bolt Grade Markings Chart 9
Parts 9
Optional AC Power Adapter 10
Lubrication 11
Cleaning 12
Approved Cleaning Products 12
Cleaning Procedure 12
Equipment Spacing Requirements 13
Operation Verification 14
About 14
Operation Verification Checklist 14
Adjustment Procedures 17
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page ii

About 17
Available Adjustment Procedures 17
AutoCal 18
AutoCal Release 1 (AutoCal R1) 19
AutoCal Release 2 (AutoCal R2) 20
Brake Pad Adjustment 23
Procedure 23
Drive Belt Tension and Tracking Adjustment 27
About 27
Procedure 27
Generator Belt Tension Adjustment 35
About 35
Specifications 35
Procedure 35
Bike Leveling Adjustment 39
Replacement Procedures 41
Replacement Procedures 41
Battery Replacement 43
About 43
Specifications 43
Determining the battery condition 43
Battery Fuse 44
Procedure 44
Belt Guard Cover Replacement 47
About 47
Procedure 47
Brake Pad Replacement 52
About 52
Specialized Tools 53
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page iii

Procedure 54
Brake Caliper Assembly Replacement 57
About 57
Strain gauge cable routing 57
Specialized Tools 58
Parts 59
Procedure 59
Replacement Procedures 59
Replacement Procedure - (Spinner® Chrono™ Power models only) 59
Replacement Procedure - (Spinner® Climb™ models only) 69
Data COMM Cable Replacement 72
About 72
Specialized Tools 73
Parts 73
Procedure 73
Drive Belt, Generator Belt, and Flywheel Replacement 85
About 85
Specifications 85
Procedure 86
Generator Assembly Replacement 98
About 98
Procedure 98
Handlebar Assembly Replacement 100
About 100
Procedure 100
Handlebar Adjustment Knob Replacement 104
About 104
Procedure 104
Handlebar Post Removal 106
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page iv

About 106
Procedure - (Spinner® Chrono™ Power models only) 106
Procedure - (Spinner® Climb™ models only) 109
LPCA board Replacement 112
About 112
LPCA Interface Cable Connections 113
LPCA Status LEDs 114
Procedure 114
Pedal Replacement 121
About 121
Specifications 121
Specialized Tools 121
Procedure 121
Crank Arm Replacement 126
About 126
Specialized Tools 126
Procedure 126
Resistance Knob Replacement 129
About 129
Procedure 129
Seat Assembly Replacement 134
About 134
Procedure 134
Stabilizer Replacement 136
About 136
Front Stabilizer Replacement 137
Rear Stabilizer Replacement 140
Troubleshooting 143
About 143
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page v

Introduction To Troubleshooting 143
Basic Steps 143
Service and Diagnostic Menus 146
About 146
Service/Setup Mode Access 146
Menu Navigation 147
Service and Settings Menus 148
Error Log 151
Active Status Light (ASL) 152
About 152
ASL Overview 152
ASL States 153
ASL Setup and Test 153
Resetting the ASL state and Maintenance Counter 154
Clearing a Pulsing Yellow and/or Steady Yellow ASLstate 154
Error Log 156
About 156
Accessing the Error Log 156
Clearing the Error Log 156
Exporting the Error Log 157
System Troubleshooting Procedures 158
About 158
Available procedures 158
Belt Drive Issues 159
Resistance Issues 160
Erratic Power (WATTS) Measurements 162
Bike Missing From Group Leader Board 164
Bottom Bracket Inspection 166
Preventive Maintenance (PM) 168
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page vi

About 168
PM Guides and Videos 168
Product PM Guides 168
PM Service Videos 170
Parts 172
About 172
Exploded View Diagram 173
Parts List 174
Consoles 176
About 176
Spinner® Chrono™ Console 177
About 177
Console Power 178
Installation and Removal 179
Service/Setup Menu Access 179
Menu Navigation 179
Menus and Settings 180
Error Log Information 182
Spinning® Studio Console 185
About 185
Cadence (RPM) sensor installation 186
Heart Rate Belt Bluetooth Pairing 186
Service and Maintenance 186
Appendix A : Edition Information i
Edition i
Additional Documentation i
Copyright i
Appendix B : Notices and Safety ii
Trademarks ii
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page vii

Intellectual Property ii
Warranty ii
Safety Notices iii
Service Safety Guidelines iii
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page viii

Introduction
About This Document
Only Precor certified technicians are authorized to service Precor equipment. If you are not
a Precor certified servicer, you must not attempt to service any Precor product. Call your
dealer for service information
WARNING: This service documentation is for use by Precor certified servicer pro-
viders only. Personal injury can result from electrical shock and/or mechanical mov-
ing parts.
This service manual applies to the SBK800 series model Spinner®Chrono1™ Power and
Spinner®Climb™ indoor cycles. This document contains information required to service,
repair, troubleshoot, and maintain the machines.
Indoor Cycle Model Feature Summary
Spinner® Chrono™ Power SBK869 Magnetic braking, Self-
powered, Direct
PowerMeasurements
(Watts), ASL2, & Spin-
1Spinner® Chrono™ Power bike.
2Active Status Light: Service and maintenance status light.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 1
1 Introduction
About This Document

Indoor Cycle Model Feature Summary
ner® Chrono™ console
Spinner® Climb™ SBK867 Magnetic braking &
Spinning® Studio™
console
Service manual contents
The service manual contains information to service, repair, troubleshoot, and maintain the
machine base.
This manual does not include console service and repair information, for console service
and repair information, refer to the console service manual.
However, the service manual does include information about how to use the console stand-
ard service menus, diagnostic tests and error code log to help troubleshoot and repair
machine issues.
Additional Service Documentation and Videos
There are additional literature and video resources available that can help you to use, ser-
vice, troubleshoot, and repair the machine. Refer to Product Literature & Videos topic:
l"Product Literature & Videos" on the facing page
.
See Also
"General Information" on page7
"Safety Guidelines" on page6
"Operation Verification" on page14
"Adjustment Procedures" on page17
"Replacement Procedures" on page41
"Troubleshooting" on page143
"Preventive Maintenance (PM)" on page168
"Parts" on page172
"Consoles" on page176
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 2
1 Introduction
Service manual contents

Product Literature & Videos
Additional product literature and videos that will help you to service and maintain the equip-
ment.
l"Service & Maintenance Documentation" below
l"Precor Websites" below
l"Service Videos" on the next page
Service & Maintenance Documentation
Document Link
SBK800-16 Spinner®Chrono1™ Power &
Climb™ Indoor Cycle (online version)
Service Manual
Preventative Maintenance Guides "Preventive Maintenance
(PM)" on page168
Precor Websites
Precor Websites Link
Precor.com product home page.
Available information:
•Product Specifications
•Assembly Guides
•Preventative Maintenance Guides
•Console Install & PM Guides
Precor.com
Precor Connect servicer home page*.
Available Product information:
•Part Numbers
•Exploded View Diagrams
•Service Bulletins
•Software Updates
•Service Videos
Connect Login
Precor Technician Certification Training Service & Install Training
Precor E-Learning Center E-Learning System
1Spinner® Chrono™ Power bike.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 3
1 Introduction
Product Literature & Videos

Precor Websites Link
SalesForce Login SalesForce Login
* Always log in to Precor connect using your Precor Connect account login information.
Service Videos
Service Video Link
Preventative Maintenance Videos
Preventative Maintenance Videos for all products:
•Login to Precor Connect*.
•select SERVICE VIDEOS
•Navigate to the product equipment PM videos
available on Precor Con-
nect
Connect Login
SBK800-16 Spinner®Chrono™ Power™ &
Climb™ indoor cycle service videos
Belt Guard Cover Removal Belt Cover Removal
Pedal Replacement Pedal Replacement
Chrono Bottom Bracket Verification Check Chrono Bottom Bracket
Check
SBK800-16 Spinner®Rally™, Shift™, and
Ride™ indoor cycle service videos
Belt/Chain Guard Cover Removal Belt/Chain Cover Removal
Pedal Replacement Pedal Replacement
Belt Tension Adjustment Belt Tension Adjustment
Belt Replacement Belt Replacement
Chain Tension Adjustment Chain Tension Adjustment
* Always log in to your Precor connect servicer account. Guest login users do not have
access to all features.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 4
1 Introduction
Product Literature & Videos

Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 5
1 Introduction
Product Literature & Videos

Safety Guidelines
Safety guideline you need to know and follow:
lRead and follow all Warning notices to protect yourself from personal injury.
lRead and follow all Caution notices to prevent damage to the equipment.
lRead the owner’s manual and follow all operating instructions.
lOperate the equipment on a solid, level surface.
lVisually check the equipment before beginning service or maintenance operations. If
it is not completely assembled or is damaged in anyway, do not attempt to operate the
equipment.
lNever place liquids on any part of the equipment while performing service.
lTo prevent electrical shock, keep all electrical components away from water and
other liquids.
lDo not use accessory attachments that are not recommended by the manufacturer-
such attachments can cause injury.
lDo not stand or climb on the handlebars, display enclosure or cover.
When servicing the equipment:
lDuring service operations you will be very close to moving machinery and voltage
bearing components:
oRemove jewelry (especially from ears and neck),
oTie up long hair,
oRemove neck ties, and
oDo not wear loose clothing
See Also
"Notices and Safety" on pageii
"Safety Notices" on pageiii
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 6
1 Introduction
Safety Guidelines

General Information
The following information provides general equipment and service information that will help
you to use this manual to properly repair and maintain the bike.
Orientation Convention
The equipment orientation (front, right, left, back) is referenced to an exerciser sitting on the
seat facing the handlebars.
Tools
Required service and repair tools:
lMetric Hex Key set (2.5 - 6mm)[4] lSpinner Bike Tool Kit
(PPPFT0000007308000)[2]
lTorque1wrench 40 ft-lbs (54 N•m lMagneticGap Fixture kit
(PPP000000058248101)[3]
[4]
lMetric wrench set (10 - 21mm)[4] lCrank Extractor (X-Tools
Crank Extractor)[1][4]
lScrew driver set lBelt Tension Gauge
1Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 7
2 General Information
Orientation Convention

(recommended Kent-
Moore BT-33-73-F)
lAC1/DC2Power Adapter (PPP000000058020102)5
Notes:
[1] Required for pedal removal.
[2] The bike tool kit contains most of the specialized tools to repair the bike. (Does not
include the magnetic gap fixture tool.)
[3] Required for magnetic brake pad adjustment.
[4] (Included in the Spinner Bike Tool Kit (PPPFT0000007308000).
[5] Required to do a manual AutoCal for bikes that have the updated implementation
(second version) of the AutoCal, see "AutoCal " on page1.
Specification Summary
This table provides a summary of system component specifications.
System Component Specification
Pedal Torque 33 ft-lb (45 N•m)
Drive Belt Tension 70 - 76 lbs (31.8 - 34.5 kgs)
Generator Belt Tension 1/2 in (1.3 cm) up/dwn travel
Stabilizer fastener Torque 15.6 ft-lbs (21 N•m)
Axle Nut Torque 29.5 ft-lbs (40 Nm)
Bolt Grade Identification
Bolt grade markings are used to categorize bolts according to the bolt material, man-
ufacturing process, and mechanical properties. The grade of the bolt is stamped on the
head of the bolt.
US SAE bolts: The bolt grade markings are determined by the number of the lines stamped
on the head of the bolt. The number of lines is always two less than the grade of the bolt.
Count the lines, add two, and you can determine the grade of the bolt.
1Alternating Current: electric current which periodically reverses direction between positive
and negative polarity.
2Direct Current: electrical current that only flows in one direction.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 8
2 General Information
Specification Summary

Metric bolts: On metric bolts, the bolt grade is identified by a bolt grade number stamped
on the head of the bolt.
CAUTION:Always replace bolts with the same grade bolt. If you don’t know the
grade of the replacement bolt – DO NOT USE THE BOLT.
Bolt Grade Markings Chart
Example bolt grades used on Precor equipment (may not represent all bolt grades). Always
match the replacement bolt grade marking to the removed bolt grade marking.
Parts
IMPORTANT: Always purchase OEM replacement parts and hardware from Pre-
cor. If you use parts not approved by Precor, you could void the Precor Limited War-
ranty. Use of parts not approved by Precor may cause injury.
Major Assembly and Parts Location
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 9
2 General Information
Parts

Exploded View Diagram and Parts List
There is a copy of the parts Exploded View Diagram and Parts Identification List included in
the "Parts" on page172 chapter that you can use as a quick reference. It is recommended
that you go to the servicer partners Precor Connect website to view the most current
parts information including the Exploded View Diagram and Parts Identification List.
lPrecor Connect Partner Website
Optional AC Power Adapter
Part Number: PPP000000058020102 "UNIVERSAL AC POWER ADAPTER with
POWER CORD."
Note: This is the same power supply that is used on AMT1products.
1Adaptive Motion Trainer
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 10
2 General Information
Optional AC Power Adapter

The optional AC Power Adapter is an 18 Vdc 3 Amp power supply that provides two dif-
ferent functions depending on whether the bike has the initial first release or the updated
second release of the AutoCal software.
1. Powersupply: On bikes with the initial first release of the AutoCal, LPCA1SW ver-
sion 303713-101 or 102, the AC Power Adapter is used as an alternative method to
power the LPCA board and console. Very helpful when you need to use the console
for extended periods of time, such as when configuring settings or updating software.
2. To enable a manual AutoCal: On bikes with updated second release of the
AutoCal, LPCA SW version 303713-103 and later, the AC Power Adapter is also used
to enable manual AutoCal calibrations, see "AutoCal " on page18.
IMPORTANT: On bikes with the updated AutoCal release 2, do not leave the AC
Power Adapter plugged in during normal operation. Plugging in the AC Power
Adapter will enable the manual AutoCal function, if the pedals are spun above 55
rpm the bike will do an AutoCal when the pedals stop.
Installation: The ACPower Adapter plugs into the LPCA Power Adapter input port located
on the bottom edge of the card (orientation as installed).
Lubrication
Lubricants
Only use products from the following list of approved lubricants:
1Lower Printed Circuit Assembly board; also refered to as the Lower PCA or simply as the
lower board. On treadmills, it is the console to base function interface and the motor con-
troller unit (MCU). On self-powered units, it is the lower PCA console to base function inter-
face.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 11
2 General Information
Lubrication

Lubricant Description
Grease Use only NLGI class 2 PTFE synthetic grade grease. Use of unapproved
lubricants may void the product warranty.
Recommended brands (or equivalent):
• Mobil 1®synthetic grease
• Super Lube®with Teflon
CAUTION: Do not use petroleum based lubricants on mechanical components
such as the lift, as this may result in degradation of nylon gearing mechanisms.
Use only synthetic lubricants such as "Super Lube with Teflon" or "Mobile One
Synthetic" grease (RED).
Cleaning
Cleaning
Only use the following approved cleaning products and procedures to safely clean and pre-
vent damage to the machine surfaces.
Approved Cleaning Products
Approved equipment and console cleaning products:
lGeneral Equipment Surfaces:
o1 part mild soap to 30 parts water (recommend Simple Green®cleaner or equi-
valent).
oAthletic equipment cleaner, 9x7 pre-saturated wipes (ATHLETIX PRODUCTS).
oEnivir O Safe oxygen enhanced cleaner or Enviro Safe glass and multitask
cleaner concentrate.
lConsoles and PVS1displays: a diluted solution of one part 91% Isopropyl alcohol
to one part water.
Cleaning Procedure
Generic cleaning procedure applicable to all Precor equipment:
TIP: There are many product specific PREVENTATIVE MAINTENANCE cleaning
videos available on the Precor Connect SERVICE VIDEOS web page. Log in to
your Precor Connect servicer account and select SERVICE VIDEOS, see
SERVICE VIDEOS.
1Personal Viewing System display.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 12
2 General Information
Cleaning
