PremierOne MUV7-200QR Installation and operating instructions

The following parts are included:
• Power Supply
• Four (4) Germicidal Twin H Lamps
(packed in lamp boxes)
•Twenty (20) Sheet Metal Screws
When installing and using this electrical equipment, basic safety precautions
should always be followed including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Always be sure the unit is unplugged during installation or service procedures.
3. The ultraviolet light produced by the UV lamp is harmful to your eyes. Do not look directly at
the lamp. Should it become necessary to view the lamp, use UV-protected safety goggles.
Lors de l’installation et de l’utilisation de cet équipement, des précautions devront être suivies.
1- Lire et suivre les étapes attentivement.
2- Assurez vous de toujours débrancher avant l installation ou le service.
3-Ne pas regarder la lampe directement avec les yeux. Si nécessaire de le faire,
veuillez porter les lunettes de soleil contre les rayons U.V.
IMPORTANT: SAFETY INSTRUCTIONS
Important: Instructions de securité
• Four (8) Caution Labels
• Strain Relief Connector
• Alcohol Pad for Cleaning Lamps
• Installation & Maintenance Instructions
MUV7-200QR
MultiVoltage UVC System
Installation & Maintenance Instructions
UNPACKING THE UNIT
Each unit is shipped with the germicidal lamps placed in a box with
protective packaging. When handling lamps take care to not touch
the glass portion of the lamp with bare hands. Oils from the hands
can cause “hot spots” which reduce lamp life. Handle by the end
caps or use a soft cloth. If you accidentally touch a lamp, use the
alcohol pad included or clean it using a soft cloth dampened with
rubbing alcohol. The lamp is fragile and proper care must be taken
when removing from packaging.

INSTALLATION:
• Do not locate the germicidal lamps in direct sight of plastic material that will be exposed to the UV light, such as
wiring, return-side humidier or certain types of air lters. Check with the lter manufacturer to see if their material
is UV resistant. Over time, UV light may degrade plastic.
• Do not touch the glass portion of the lamps with bare hands because oils from the hands can cause “hot spots”
which reduce lamp life. Handle either by the end caps or use a soft cloth. If you accidentally touch a lamp, wipe it
off, using the included alcohol cleaning pad or a soft cloth dampened with rubbing alcohol.
INSTALLING THE GERMICIDAL UNIT
MOUNTING GERMICIDAL LAMP AND POWER SUPPLY (supply or return side plenum)
1. Unplug mid-cord connector by pressing the lock release (marked “PRESS” on the connector.) (see photo B)
Remove two thumb nuts holding moisture resistant lamp socket to mounting plate and remove from the plate.
2. Using the lamp mounting plate as a template, draw the hole pattern on the air duct in a suitable location.
Do not install the UVC lamps where there is a straight line of sight of the lamps through a vent.
When choosing a location to mount the lamps, make certain no UV light is visible to the consumer.
3. Using a 1 1/4 inch Vari-Bit®, make two holes side by side. Clean off excess metal between the two
holes with tin snips. Alternately cut a 2” hole.
4. Peel off the gasket backing from lamp mounting plate and center over hole. Secure using four
self-tapping sheet metal screws provided. Repeat steps 1-4 for the second lamp.
5. Find a suitable location to mount the power supply making sure supply cord to ballast will reach 120 or
240 volt power supply. Mount the power supply using four self-tapping sheet metal screws provided.
6. Taking care not to touch the glass, hold the lamp by the end cap and insert fully into the base plate.
7. Insert the moisture resistant lamp socket over the plastic lamp end tting over the mounting studs,
secure using the two thumb nuts. (Photo B)
8. Route cord back to the moisture resistant lamp socket and reconnect mid-cord connector. Be sure to line up
arrows on the connector. (Photo A) Repeat steps 6-8 for the second lamp.
9. Adhere included UV Warning Label next to the access point in ductwork for servicing the lamps.
Photo B
Photo A

Recommended for airows up to 8000 cfm
According to Westinghouse
®
this is the minimum
duct length to achieve a 70-85% kill/deactivation
of microorganisms in a forced air system at
2000CFM using one 16” lamp.
All parameters based off end-of-life output
(110 µW/cm2)
 Airow Ductlengthneeded
500 FPM 36”
250 FPM 22”
For best results, lamps need to be mounted on the same plain in order to get the combined
microwatts to be sufcient for the air volume. Lamps should be mounted with as much
distance upstream and downstream as possible. Example: in a ten (10) foot duct, lamps should be
mounted at ve (5) feet allowing ve feet on each side of the lamps. A three (3) foot duct would
be centrally mounted leaving a 1.5 feet on each side of the lamp. This should be considered the
minimum distance.
Do not install the UVC lamps where there is a straight line of sight of the lamps through a vent.
When choosing a location to mount the lamps, make certain no UV light is visible to the consumer.

Illustration #1 Ballast 1 & 2,
(2 lamps per ballast)
For Technical Support Call [phone] www.premieroneproducts.com ©2020
WIRING/FUSE
The multivoltage ballast is self-adjusting and operates with voltages from 120 - 240 VAC. For 120V wiring
connect the black wire to L1, white wire to neutral, green wire to ground. For 240V wiring install 5 amp inline
fuses to both legs of power, then connect the black wire to L1, white wire to L2, green wire to ground. Be sure
power cord is secured with included strain relief connector.
It is recommended you interlock with the system blower or install a blower door safety switch so the
unit powers off when the system is serviced. Connect in accordance with local wiring codes.
CORRECT WIRING FOR FOUR LAMP OPERATION.

1. Using the lamp mount as a template, draw the hole pattern on the air duct in a suitable location.
2. Using a 1 1/4 inch Vari Bit, make two holes side by side. Clean off excess metal between the two holes with tin snips.
3. Peel off the adhesive backing of the gasket on backside of mounting plate.
4. Center mounting plate on hole.
5. Use four self tapping screws provided to secure mounting plate on the air duct.
Power Supply Dimensions:
Size (L x W x D)
10.625h x 5.75w x 1.75 d
Lamp Socket Dimensions:
Size (L x W x D)
3.5” x 2.75” x 1.625”
3099107
TROUBLESHOOTING
With the selector switch in the ON position, the LED should light when power is supplied to the unit.
If the LED does not light with switch in the On position:
1. Check to be sure there is power to the unit.
2. Be sure lamp connectors are fastened securely.
3. If the LED still does not light, replace lamp(s).
4. If still not operating, replace ballast.
Note: Standard off-the-shelf lamps are not compatible with this unit. Use of improper lamps will void warranty.
WARRANTY RETURNS
All electronic components carry a lifetime warranty to the original homeowner. In addition there is a four-year
warranty from the date of installation for any subsequent owner. The original lamp is warranted for a period of
two years. This warranty does not cover broken lamps due to shipping, installation or handling. Please see the
complete warranty statement on the back page of this booklet.
All returns are routed through your wholesaler and must be approved and accompanied by an RGA number.
Please call PremierOne Products, Inc. at 800-982-1840 and we will guide you through the return procedure.
This warranty gives you specic legal rights and you may also have other rights which vary from state to state.

MAINTENANCE
This maintenance schedule is only a guideline, determined by average conditions. Actual conditions will dictate
the frequency of cleaning and/or replacement of lamps. Do not touch the glass portion of the lamps with bare
hands because oils from the hands can cause “hot spots” which reduce lamp life. Handle either by the end caps or
use a soft cloth. If you accidentally touch a lamp, clean it using a soft cloth dampened with rubbing alcohol.
CLEANING THE GERMICIDAL LAMP - Recommended interval: 12 months
1. Disconnect power to the unit.
2. Unplug mid-cord connectors by pressing the lock release (marked “PRESS” on the connector.)
Remove two thumb nuts holding moisture resistant lamp socket to mounting plate and carefully remove the
lamp socket with lamp from the mounting plate. Repeat this step for the other three lamps.
3. Use a soft cloth moistened with rubbing alcohol to wipe down each lamp. If there is a large build-up of dust
particles, you may wish to use a can of air rst. Do not touch the glass portion of the lamps with bare hands.
4. Carefully slide the moisture lamp socket with lamp through the mounting plate into duct tting over the
mounting studs and secure using the two thumb nuts. (Photo A)
5. Reconnect the mid-cord connector. Be sure to line up arrows on the connector. (Photo B)
Repeat this step for the other three lamps.
6. Supply power to the unit.
REPLACING THE LAMP - Recommended interval: 24 months
Replacement lamps are available through your HVAC contractor.
Follow above procedure except #3 where you replace the lamps instead of cleaning them.
(Note: standard off-the-shelf lamps are not compatible with this unit. Use of improper lamps will void warranty.)
LSK200-16 LSK200-12
LAMP KITS FOR MUV7-200QR
#LSK200-16 UVC lamp service kit with two (4) 16” UV lamps - 36-Watt each.
#LSK200-12 UVC lamp service kit with two (4) 12” UV lamps - 24-Watt each.
For Technical Support Call [phone] www.premieroneproducts.com ©2020

1. Limited Warranty. Except as set forth herein, PremierOne Products,
Inc. (“PremierOne”) warrants MUV7-200QR-16, MUV7-200QR-12,
(the “Product”) to be free from defects in manufacturing, materials,
and workmanship for the life of the Product; provided, however,
that such warranty shall only apply to the customer who original-
ly purchased the Product (the “Limited Warranty”). With respect
to a party, who is not the original purchaser of the Product, Pre-
mierOne’s Limited Warranty shall extend to said party for, only,
a period of four (4) years from the date of the Product’s original
purchase by the original customer.
2. Remedy. In the event of a Product failure as the result of a defect
in manufacturing, materials, or workmanship. PremierOne, at its
option, will: (a) provide to the customer the appropriate replace-
ment for the defective Product; or (b) repair the Product found
to be defective. In the event that PremierOne elects to repair or
replace the Product, such repaired or replaced Product shall be
warranted, as set forth in this Limited Warranty, for the lifetime of
such repaired or replaced Product.
3. Warranty Exclusions. This Limited Warranty is the only express
warranty (written or oral), applicable to the Product and no individual
or entity is authorized to modify or expand this Limited Warranty.
While warranty claims must be processed through, and approved
by, a PremierOne wholesaler/reseller and accompanied by a “RGA
Number,” customers are encouraged to call PremierOne at (800)
982-1840 for assistance and guidance through the claim procedure.
ALL IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, IMPLIED WARRANTIES FOR MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY
DISCLAIMED. PREMIERONE EXPRESSLY DISCLAIMS ALL
WARRANTIES NOT STATED IN THIS LIMITED WARRANTY.
ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW
ARE LIMITED IN DURATION TO THE TERMS OF THIS LIMITED
WARRANTY. IN NO EVENT WILL PREMIERONE BE LIABLE TO
A CUSTOMER, OR ANY THIRD PARTY, FOR ANY DAMAGES
IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT
ALLEGED TO BE DEFECTIVE. IN ADDITION, PREMIERONE
SHALL IN NO EVENT BE LIABLE TO A CUSTOMER, OR ANY
THIRD PARTY, FOR ANY DIRECT OR INDIRECT DAMAGES
OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CON-
SEQUENTIAL DAMAGES ARISING OUT OF THE FAILURE OF
THE PRODUCT TO COMPLY WITH THIS LIMITED WARRAN-
TY, INCLUDING, BUT NOT LIMITED TO, DAMAGE OR LOSS
OF OTHER PROPERTY OR EQUIPMENT. THE REMEDIES OF
CUSTOMER SET FORTH IN THIS LIMITED WARRANTY ARE
EXCLUSIVE. NOTWITHSTANDING ANYTHING CONTAINED
HEREIN TO THE CONTRARY, PREMIERONE’S LIABILITY
WITH RESPECT TO THE PRODUCT, IN ALL INSTANCES,
SHALL BE LIMITED TO THE REPAIR OR REPLACEMENT OF
THE PRODUCT ALLEGED TO BE DEFECTIVE.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitation of the duration of an implied
warranty, so the above limitations or exclusions may not apply to
the customer. This Limited Warranty gives the customer specic
legal rights, and the customer may also have other rights which
may vary from jurisdiction to jurisdiction.
4. Additional Warranty Exclusions. In addition to the exclusions
set forth above, this Limited Warranty does not cover Product de-
fects, including lamps, caused, in whole or in part, by any one or
more of the following circumstances or conditions: (a) adjustments
or corrections to Product due to improper Product installation; (b)
improper assembly or improper Product installation; (c) Product
failure due to the application or installation of non-PremierOne
approved accessories, pieces, hardware, and additions includ-
ing, but not limited to, installation and use of other than a genuine
PremierOne lamp designed specically for the Product; (d) failure
to properly install related Product accessories, pieces, hardware,
and additions including, but not limited to, customer’s failure to
replace the Product’s lamp(s) every two (2)years; (e) Product ex-
posure to conditions outside of the scope of PremierOne’s Product
performance specications; (f) improper maintenance and care of
the Product, before, during, or after installation including, speci-
cally, breakage of Product lamps during shipping and installation
or caused by improper handling; (g) modication or refabrication,
partial or otherwise, of the Product; and (h) accidents.
This Limited Warranty does not cover any labor, including labor
related to the removal, replacement, installation, or disposal of a
defective Product.
PremierOne warrants that, subject to the exceptions set forth in
Section 4, above, genuine PremierOne lamps shall function as
intended for a period of two (2) years from date of Product installa-
tion or, as the case may be, from the date of customer’s purchase
of a genuine PremierOne replacement lamp.
5. Miscellaneous. The rights and obligations of the parties hereun-
der shall be interpreted and governed in accordance with the laws
of the State of Wisconsin. Any claim, dispute, controversy, or ac-
tion arising out of or related to the enforcement of this Limited War-
ranty, regardless of the existence and nature of any purchase and
sale documents related to the Product, shall be led or brought
in the Brown County Circuit Court, Green Bay, Wisconsin, or in
the United States Federal District Court for the Eastern District of
Wisconsin, Green Bay, Wisconsin. If any provision of this Limited
Warranty is deemed or held to be illegal, invalid, or unenforceable,
under any present or future laws of any applicable jurisdiction, this
Limited Warranty shall be considered divisible and inoperative as
to such provision to the extent it is deemed to be illegal, invalid,
or unenforceable, and in all other respects, this Limited Warranty
shall remain in full force and effect.
LIMITED WARRANTY
For Technical Support Call [phone] www.premieroneproducts.com ©2020
