Premio VIO-100/PC100 Series User manual

USER’S
MANUAL
VIO-100/PC100 Series
VIO-200/PC100 Series
Industrial Panel PCs

VIO-100(200)/PC100 | User’s Manual
Table of Contents
Prefaces …………………………………………………….……………………………………………. 05
Revision …………………………………………………………………………………………..……………….……….. 05
Disclaimer ………………………………………………………..…….…….………………………….……………….. 05
Copyright Notice …………………………………….…………………….…………………………………………… 05
Trademarks Acknowledgment …………..………………………………………………………...................05
Environmental Protection Announcement …………………………….………………….……………….. 05
Safety Precautions ………………………………………….……………………………….…………….………….. 06
Technical Support and Assistance …………………………………….…………….…………….…………….07
Conventions Used in this Manual ………………………………………………………………….….………..07
Package Contents …………………………………………………………………………………………….…………08
Ordering Information …………………………………….……………………………………….……….………… 09
Optional Accessory …………...……………………………………..................................................... 12
Chapter 1 Product Introductions ………………………………………………………..… 13
1.1 Overview ……………………….………………………………..………….…………………………..14
1.1.1 Key Feature ………….……………………………………………….…..……………....... 14
1.2 Hardware Specification ….………………………….....…………...…………..……………… 15
1.2.1 VIO-110R(C)/PC100 | VIO-110R(C)/PC110 …….….…………………………… 15
1.2.2 VIO-112R(C)/PC100 | VIO-112R(C)/PC110 ……….………….………………... 16
1.2.3 VIO-212R(C)/PC100 | VIO-212R(C)/PC110 …………….…….………………... 17
1.2.4 VIO-115R(C)/PC100 | VIO-115R(C)/PC110 ..…………………………………... 18
1.2.5 VIO-215R(C)/PC100 | VIO-215R(C)/PC110 ..…………...……………………... 19
1.2.6 VIO-W115R(C)/PC100 | VIO-W115R(C)/PC110 ..…....……………………... 20
1.2.7 VIO-W215R(C)/PC100 | VIO-W215R(C)/PC110 ..…....……………………... 21
1.2.8 VIO-117R(C)/PC100 | VIO-117R(C)/PC110 ..………...………………………... 22
1.2.9 VIO-217R(C)/PC100 | VIO-217R(C)/PC110 ..…....……..………………..…... 23
1.2.10 VIO-119R(C)/PC100 | VIO-119R(C)/PC110 ..………...……………………... 24
1.2.11 VIO-219R(C)/PC100 | VIO-219R(C)/PC110 ..…....……..………………..... 25
1.2.12 VIO-W121R(C)/PC100 | VIO-W121R(C)/PC110 ..…..…………………..... 26
1.2.13 VIO-W221R(C)/PC100 | VIO-W221R(C)/PC110 ..…....…………………... 27
1.3 System I/O ……………………………..……………………..……….……………………………… 28
1.3.1 Front ……………………………………......................….……………………………… 28
1.3.2 Rear ………….……………….…………………………………..………………..…………... 28
1.3.3 Side (Left) ……………………..……………..…………………..….…….………………... 29
1.3.4 Side (Right) ……………………………..…………..……………..……...………………... 29
1.3.5 Top ………….……………….……………………………..…………..…………..…………... 30
1.4 Mechanical Dimension …………………………..……………………..…..………….………. 31
1.4.1 VIO-110R(C)/PC100 …….……..……............…………………..………………….… 31
1.4.2 VIO-110R(C)/PC110 ……………………………..……………….…………………….... 31
1.4.3 VIO-112R(C)/PC100 ……………..….…...............…………..…………………….… 32
1.4.4 VIO-112R(C)/PC110 …………………….….…..................……………………….… 32
1.4.5 VIO-212R(C)/PC100 ………………….……...........………………………..……….… 33
1.4.6 VIO-212R(C)/PC110 …………………….………................……………………….… 33
1.4.7 VIO-115R(C)/PC100 ………………….…........................……………………….… 34
1.4.8 VIO-115R(C)/PC110 ………………….…........................……………………….… 34
1.4.9 VIO-215R(C)/PC100 ………………….…........................……………………….… 35
1.4.10 VIO-215R(C)/PC110 ………………….…................……………….…………….… 35
2

VIO-100(200)/PC100 | User’s Manual
1.4.11 VIO-W115R(C)/PC100 ………..………..….…...............……………………….… 36
1.4.12 VIO-W115R(C)/PC110 ……….……………….…............……………………….… 36
1.4.13 VIO-W215R(C)/PC100 ………..…..….…....................……………………….… 37
1.4.14 VIO-W215R(C)/PC110 …………….……….…...............……………………….… 37
1.4.15 VIO-117R(C)/PC100 ……..………….….......................……………………….… 38
1.4.16 VIO-117R(C)/PC110 ………….…………….…................……………………….… 38
1.4.17 VIO-217R(C)/PC100 …..…………….….......................……………………….… 39
1.4.18 VIO-217R(C)/PC110 ………….…………….…................……………………….… 38
1.4.19 VIO-119R(C)/PC100 ………..……….….......................……………………….… 40
1.4.20 VIO-119R(C)/PC110 ……..………………….…...............……………………….… 40
1.4.21 VIO-219R(C)/PC100 ………………...….......................……………………….… 41
1.4.22 VIO-219R(C)/PC110 …………..……..…….…….............……………………….… 41
1.4.23 VIO-W121R(C)/PC100 ………..……….………..............……………………….… 42
1.4.24 VIO-W121R(C)/PC110 ……….…………….…...............……………………….… 42
1.4.25 VIO-W221R(C)/PC100 …………..…….…….................……………………….… 43
1.4.26 VIO-W221R(C)/PC110 ………….………….…...............……………………….… 43
Chapter 2 Jumpers and Connectors ………………………………………………………. 44
2.1 Switch and connector Locations ………………………………………..…….……………....45
2.1.1 Top View ………………………………………………………………………..……………… 45
2.1.2 Bottom View ………………………………………………………………………..………..45
2.2 Connector / Switch Definition ……………………………….……….…….……….............46
2.3 Switch Definitions ………….……………...............................................................47
2.4 Connector Definitions ………………………….......................................................49
Chapter 3 Front Panel Controls ……………………..……………………………………… 60
3.1 Users Controls ……...………………………………………………………………..………..……...61
3.1.1 Power Button …………………………………….…………………………..………………61
3.1.2 LED ……………………………………………….………………………………..………………61
3.1.3 MENU / Enter Button ……………………………………………………..………………61
3.1.4 Increase Button ……………………………………………………………..……………… 61
3.1.5 Decrease Button ………………..…………………………………………..………………61
3.1.6 AUTO / Exit Button ………………………………………………….……..………………61
3.2 OSD Operation ……...……………………………………………….……………..………..……... 62
3.2.1 Luminance ……………………………………………………………………..………………62
3.2.2 Picture ………………………………….………………………………………..………………63
3.2.3 Color ………………………………….…………………………………………..………………63
3.2.4 OSD Settings …………………………………………………………………..………………63
3.2.5 Setup ……………………………………………………………………………..……………… 64
Chapter 4 System Setup …………………………..…………………………………………… 65
4.1 Set torque force to 3.5 kgf-cm to execute all the screwing and
unscrewing …………………………………………………………………….……………………….. 66
4.2 Installing SODIMM ………………….………………….………………………..…….…………... 66
4.3 Installing mini PCIe card / mSATA …….…………..………...…..….……………….…….. 67
4.4 Installing HDD on removable SATA HDD bay ………..………………………………….. 68
4.5 Installing CFast card …………….…………………………………...……..…………………….. 70
4.6 Installing SIM card …………….……………………………………………………..…………….. 71
4.7 Removing chassis bottom cover …………………………………….…………............... 73
4.8 Installing antenna …………………………………..…………..…………..……..………..….... 74
4.9 Assemble chassis top cover ….…………..…………….……………………..………..….... 77
4.10 Connecting PC module with VIO display module ………………......………..….... 79
3

VIO-100(200)/PC100 | User’s Manual
Chapter 5 BIOS Setup ……………………..…………………………………………………….81
5.1 BIOS Introduction …….……….……………………………………..….…….…..….………….. 82
5.2 Main Setup ……..……….………………….…………………………..…….….………………..... 83
5.2.1 System Date …….……………………………………………..……..……………………... 83
5.2.2 System Time ………..…………………………………………..……….…………………... 83
5.3 Advanced Setup ……………………………………………………..……………………………….. 84
5.3.1 Trusted Computing (Optional) ……………………………………………………..… 84
5.3.2 ACPI Settings ……..…………………………………………………………..……………….85
5.3.3 Super IO Configuration …………………………….………..…………………..……... 85
5.3.4 Hardware Monitor ………………………………………….………………………..…....89
5.3.5 Serial Port Console Redirection …………………………………....……..…….....90
5.3.6 CPU Configuration ……………………………..……………….………….….…….….... 90
5.3.7 SATA Configuration ..……………………………..…………..………..... 91
5.3.8 OS Configuration ……..………………………………..…………………………....... 91
5.3.9 CSM Configuration …………………………………………………………..………….... 92
5.3.10 USB Configuration ………………………………………………………………….……. 93
5.3.11 Intel® I210 Gigabit Network Connection- XX:XX:XX:XX:XX:XX………. 94
5.4 Chipset …………...……….………………….…..….…..………………………………………..…....95
5.4.1 North Bridge ………….…………………………………………………..………………….. 95
5.4.2 South Bridge ………….………………………………………………..…………………….. 97
5.5 Security …………...……….………………….…..….…..………………………………..…………...99
5.5.1 Administrators Password …….…………………………………..…………………….. 99
5.5.2 Users Password …….……………………………….………………..…………………….. 99
5.6 Boot …………...……….….………………….…..…………………………..…………..……………...100
5.6.1 Setup Prompt Timeout ………………………..…………..……………………………..100
5.6.2 Bootup NumLock State ……………………………………………….…….…………… 100
5.6.3 Full Screen Logo Show ………………………….…………………………..…...……….100
5.6.4 Boot Option Priorities …………………………..………………………..……………... 100
5.7 Save & Exit …...……….….………………….…..….…..…………………………..…….……...... 101
5.7.1 Save Changes and Reset ……………..………………………………..……..……......101
5.7.2 Discard Changes and Reset …………………………………............……………….101
5.7.3 Restore Defaults ……………………………………………………………..……………...101
Appendix WDT & GPIO …………………………………………………………………………… 102
WDT Sample Code …….……………………….……………….……………..….…….…….…………... 103
GPIO Sample Code ………………………………………………………..…………………………………. 104
4

VIO-100(200)/PC100 | User’s Manual
5
Revision
Disclaimer
All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio
Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The
information in this document is subject to change without notice and does not represent a commitment on
the part of Premio Inc.
Premio Inc. disclaims all warranties, express or implied, including, without limitation, those of
merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must
take full responsibility for the application of the product.
Copyright Notice
All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,
without the prior written permission of Premio Inc. Copyright © Premio Inc.
Trademarks Acknowledgment
Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.
Windows® is registered trademark of Microsoft Corporation.
AMI is trademark of American Megatrend Inc.
IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution
and ensure environment protection.
Prefaces
Revision
Description
Date
1.0
Manual Released
2018/12/27
Preface

VIO-100(200)/PC100 | User’s Manual
6
Safety Precautions
Before installing and using the equipment, please read the following precautions:
Put this equipment on a reliable surface during installation. Dropping it or letting it fall could
cause damage.
The power outlet shall be installed near the equipment and shall be easily accessible.
Turn off the system power and disconnect the power cord from its source before making any
installation. Be sure both the system and the external devices are turned OFF. Sudden surge
of power could ruin sensitive components. Make sure the equipment is properly grounded.
When the power is connected, never open the equipment. The equipment should be opened
only by qualified service personnel.
Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
Avoid the dusty, humidity and temperature extremes.
Do not place heavy objects on the equipment.
If the equipment is not used for long time, disconnect it from the power to avoid being
damaged by transient over-voltage.
The storage temperature shall be above -20°C and below 70°C.
The computer is provided with a battery-powered real-time clock circuit. There is a danger of
explosion if incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer.
If one of the following situation arises, get the equipment checked be service personnel:
•The power cord or plug is damaged.
•Liquid has penetrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well or it cannot work according the user’s manual.
•The equipment has been dropped and damaged.
•The equipment has obvious signs of breakage.
Preface

VIO-100(200)/PC100 | User’s Manual
7
Technical Support and Assistance
1. Visit the Premio Inc website at www.premioinc.com where you can find the latest information about
the product.
2. Contact your distributor, our technical support team or sales representative for technical support if
you need additional assistance. Please have following information ready before you call:
Model name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual
Preface
This indication alerts operators to an operation that, if not strictly observed,
may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly observed,
may result in safety hazards to personnel or damage to equipment.
CAUTION
This indication provides additional information to complete a task easily.
NOTE

VIO-100(200)/PC100 | User’s Manual
8
Package Contents
Before installation, please ensure all the items listed in the following table are included in the package.
VIO
-110/PC100 | VIO-110/PC110
Item Description Q’ty
1
VIO
-110/PC100 Series Panel PC 1
2
Panel Mount Kit
6
3
Utility DVD Driver
1
4
Screw Pack
1
Preface
VIO
-112/PC100 | VIO-112/PC110
Item Description Q’ty
1
VIO
-112/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-115/PC100 | VIO-115/PC110
Item Description Q’ty
1
VIO
-115/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-W115/PC100 | VIO-W115/PC110
Item Description Q’ty
1
VIO
-W115/PC100 Series Panel PC 1
2
Panel Mount Kit
8
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-119/PC100 | VIO-119/PC110
Item Description Q’ty
1
VIO
-119/PC100 Series Panel PC 1
2
Panel Mount Kit
14
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-W121/PC100 | VIO-W121/PC110
Item Description Q’ty
1VIO-W121/PC100 Series Panel PC 1
2
Panel Mount Kit
12
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-117/PC100 | VIO-117/PC110
Item Description Q’ty
1
VIO
-117/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-212/PC100 | VIO-212/PC110
Item Description Q’ty
1
VIO
-212/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1

VIO-100(200)/PC100 | User’s Manual
9
Preface
VIO
-215/PC100 | VIO-215/PC110
Item Description Q’ty
1
VIO
-215/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-W215/PC100 | VIO-W215/PC110
Item Description Q’ty
1VIO-W215/PC100 Series Panel PC 1
2
Panel Mount Kit
8
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-219/PC100 | VIO-219/PC110
Item Description Q’ty
1
VIO
-219/PC100 Series Panel PC 1
2
Panel Mount Kit
14
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-W221/PC100 | VIO-W221/PC110
Item Description Q’ty
1VIO-W221/PC100 Series Panel PC 1
2
Panel Mount Kit
12
3
Utility DVD Driver
1
4
Screw Pack
1
VIO
-217/PC100 | VIO-217/PC110
Item Description Q’ty
1
VIO
-217/PC100 Series Panel PC 1
2
Panel Mount Kit
10
3
Utility DVD Driver
1
4
Screw Pack
1
Ordering Information
Model No. Product Description
VIO-110R/PC100-J1900 10.4" SVGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-110C/PC100-J1900 10.4" SVGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-110R/PC110-J1900 10.4" SVGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-110C/PC110-J1900 10.4" SVGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-112R/PC100-J1900 12.1" XGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-112C/PC100-J1900 12.1" XGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM

VIO-100(200)/PC100 | User’s Manual
10
Preface
Model No. Product Description
VIO-112R/PC110-J1900 12.1" XGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-112C/PC110-J1900 12.1" XGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-212R/PC100-J1900 12.1" XGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-212C/PC100-J1900 12.1" XGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-212R/PC110-J1900 12.1" XGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-212C/PC110-J1900 12.1" XGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-115R/PC100-J1900 15" XGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-115C/PC100-J1900 15" XGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-115R/PC110-J1900 15" XGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-115C/PC110-J1900 15" XGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-215R/PC100-J1900 15" XGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-215C/PC100-J1900 15" XGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-215R/PC110-J1900 15" XGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-215C/PC110-J1900 15" XGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-W115R/PC100-J1900 15.6" 16:9 Full HD Resistive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-W115C/PC100-J1900 15.6" 16:9 Full HD Capacitive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-W115R/PC110-J1900 15.6" 16:9 Full HD Resistive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-W115C/PC110-J1900 15.6" 16:9 Full HD Capacitive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-W215R/PC100-J1900 15.6" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM
VIO-W215C/PC100-J1900 15.6" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM
VIO-W215R/PC110-J1900 15.6" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM, 2x Universal I/O Bracket
VIO-W215C/PC110-J1900 15.6" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM, 2x Universal I/O Bracket

VIO-100(200)/PC100 | User’s Manual
11
Preface
Model No. Product Description
VIO-117R/PC100-J1900 17" SXGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-117C/PC100-J1900 17" SXGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-117R/PC110-J1900 17" SXGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-117C/PC110-J1900 17" SXGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-217R/PC100-J1900 17" SXGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-217C/PC100-J1900 17" SXGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-217R/PC110-J1900 17" SXGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-217C/PC110-J1900 17" SXGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-119R/PC100-J1900 19" SXGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-119C/PC100-J1900 19" SXGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM
VIO-119R/PC110-J1900 19" SXGA Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-119C/PC110-J1900 19" SXGA Capacitive Touch Panel PC with Intel® Celeron® Processor J1900, 4x COM,
2x Universal I/O Bracket
VIO-219R/PC100-J1900 19" SXGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-219C/PC100-J1900 19" SXGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-219R/PC110-J1900 19" SXGA Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-219C/PC110-J1900 19" SXGA Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-W121R/PC100-J1900 21.5" 16:9 Full HD Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x
COM
VIO-W121C/PC100-J1900 21.5" 16:9 Full HD Capacitive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM
VIO-W121R/PC110-J1900
21.5" 16:9 Full HD Resistive Touch Panel PC with Intel® Celeron® Processor J1900, 4x
COM,
2x Universal I/O Bracket
VIO-W121C/PC110-J1900 21.5" 16:9 Full HD Capacitive Touch Panel PC with Intel® Celeron® Processor J1900,
4x COM, 2x Universal I/O Bracket
VIO-W221R/PC100-J1900 21.5" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM
VIO-W221C/PC100-J1900 21.5" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM
VIO-W221R/PC110-J1900 21.5" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM, 2x Universal I/O Bracket
VIO-W221C/PC110-J1900 21.5" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Celeron® Processor
J1900, 4x COM, 2x Universal I/O Bracket

VIO-100(200)/PC100 | User’s Manual
12
Preface
Optional Accessories
Model No. Product Description
1
-E09A06007
Adapter AC/DC 12V 5A 60W with 3pin Terminal Block Plug 5.0mm Pitch
SFICBL022
Power Cord, 3
-pin US Type, 180cm
1
-TPCD00002
Power Cord, European Type, 180cm
1
-TPCD00001
Power Cord, 3
-pin UK Type, 180cm

Chapter 1
Product Introductions

VIO-100(200)/PC100 | User’s Manual
14
1.1.1 Key Features
10.4”~ 21.5” Multi-functional All-in-One Panel PCs
Intel® Celeron® processor J1900, 2.0 GHz
1x 204-pin DDR3L SODIMM. Max up to 8GB
1x 2.5” SATA HDD bay, 1x mSATA, 1x Cfast, 2x SIM socket
2x Full-size mini PCIe for communication or expansion modules
2x LAN
1x VGA, 1x DisplayPort
4x External RS-232/422/485, 2x Internal RS-232/422/485
1x USB 3.0, 3x USB 2.0
1x Line-out, 1x Mic-in
8x Isolated Digital Input, 8x Isolated Digital Output
9 to 50VDC wide range power input
Designed with Aluminum Die-Casting Front Frame
IP65 Compliant Front Panel
2x 2W Internal Speakers Built-in (VIO-110/ VIO-212 Series Only)
2x 5W Internal Speakers Built-in (VIO-112 Series Only)
2x 10W Internal Speakers Built-in
Multi-language OSD Built-in
1.1 Overview
The VIO-100/PC100 and VIO-200/PC100 series Panel PC is based on Intel®Celeron®J1900 Quad
Core Processor. Designed with flat surface, IP 65 dust/waterproof front panel, and aluminum die-
casting front frame with rugged body structure, it is a versatile I/O connections, and rugged reliability
industrial panel PC.
The VIO-100/PC100 and VIO-200/PC100 series Panel PC supports Multi-Mode Display Module (MDM)
technology which makes it more flexible in system maintaining and upgrading. It offers modularize
expansion I/O, rich connectivity interfaces, wide range (9~50V) DC power input, and high reliability
even operating in temperature extremes.
Featuring with completely high functional, VIO-100/PC100 and VIO-200/PC100 series Panel PC are
ruggedized display systems that can operate in harsh environments and easy to install and maintain. A
build in over voltage protection (OVP), over current protection (OCP), reverse protection, and wide
range DC power input makes VIO-100/PC100 and VIO-200/PC100 series Panel PC are safety system for
all industrial applications.
Chapter 1: Product Introductions

VIO-100(200)/PC100 | User’s Manual
15
1.2 Hardware Specification
1.2.1 VIO-110R(C)/PC100 | VIO-110R(C)/PC110
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 10.4” (4:3)
•Max. Resolution: 800 x 600 (SVGA)
•Brightness (cd/m2): 400
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.264 (H) x 0.264 (V)
•Viewing Angle (H-V): 160 / 130
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-110R/PC100 and VIO-110R/PC110
Only
•Projected Capacitive: VIO-110C/PC100 and VIO-
110C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•1x External 2.5” SATA HDD Bay
•1x mSATA (Shared by 1x Mini PCIe)
•1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-110/PC110 Series Only)
Other Features
•Internal Speaker: AMP 2W + 2W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
-4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows 10
•Windows 7
•WES7
•Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-110R(C)/PC100
- Dimension: 300 (W) x 238.5 (D) x 64.7 (H)mm
- Weight: 4.31 ~ 4.36 kg
•VIO-110R(C)/PC110
- Dimension: 300 (W) x 238.5 (D) x 86.7(H)mm
- Weight: 4.39 ~4.41 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm

VIO-100(200)/PC100 | User’s Manual
16
1.2.2 VIO-112R(C)/PC100 | VIO-112R(C)/PC110
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 12.1” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 500
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.24 (H) x 0.24 (V)
•Viewing Angle (H-V): 160 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-112R/PC100 and VIO-112R/PC110
Only
•Projected Capacitive: VIO-112C/PC100 and VIO-
112C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•SSD/HDD: 1x External 2.5” SATA HDD Bay
•mSATA: 1x mSATA (Shared by 1x Mini PCIe)
•CFast: 1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•SIM Socket: 2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-112/PC110 Series Only)
Other Features
•Internal Speaker: AMP 5W + 5W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
- 4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows: Windows 10, Windows 8.1, Windows 7, WES7
•Linux: Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-112R(C)/PC100
- Dimension: 338 (W) x 262 (D) x 61.7 (H)mm
- Weight: 4.82 ~ 4.88 kg
•VIO-112R(C)/PC110
- Dimension: 338 (W) x 262 (D) x 83.7 (H)mm
- Weight: 4.89 ~ 4.92 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm

VIO-100(200)/PC100 | User’s Manual
17
1.2.3 VIO-212R(C)/PC100 | VIO-212R(C)/PC110
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 12.1” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 500
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.24 (H) x 0.24 (V)
•Viewing Angle (H-V): 160 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-212R/PC100 and VIO-212R/PC110
Only
•Projected Capacitive: VIO-212C/PC100 and VIO-
212C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•SSD/HDD: 1x External 2.5” SATA HDD Bay
•mSATA: 1x mSATA (Shared by 1x Mini PCIe)
•CFast: 1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•SIM Socket: 2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-212/PC110 Series Only)
Other Features
•Internal Speaker: AMP 2W + 2W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
- 4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows: Windows 10, Windows 8.1, Windows 7, WES7
•Linux: Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-212R(C)/PC100
- Dimension: 319 (W) x 257 (D) x 61.7 (H)mm
- Weight: 3.88 ~ 3.92 kg
•VIO-212R(C)/PC110
- Dimension: 319 (W) x 257 (D) x 83.7 (H)mm
- Weight: 4.28 ~ 4.37 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm

VIO-100(200)/PC100 | User’s Manual
18
1.2.4 VIO-115R(C)/PC100 | VIO-115R(C)/PC110
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 15” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 350
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.297 (H) x 0.297 (V)
•Viewing Angle (H-V): 170 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-115R/PC100 and VIO-115R/PC110
Only
•Projected Capacitive: VIO-115C/PC100 and VIO-
115C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•SSD/HDD: 1x External 2.5” SATA HDD Bay
•mSATA: 1x mSATA (Shared by 1x Mini PCIe)
•CFast: 1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•SIM Socket: 2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-115/PC110 Series Only)
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
- 4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows: Windows 10, Windows 8.1, Windows 7, WES7
•Linux: Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 65°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-115R(C)/PC100
- Dimension: 397 (W) x 306 (D) x 64.7 (H)mm
- Weight: 5.69 ~ 5.72 kg
•VIO-115R(C)/PC110
- Dimension: 397 (W) x 306 (D) x 86.7 (H)mm
- Weight: 5.81 ~ 5.86 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm

VIO-100(200)/PC100 | User’s Manual
19
Chapter 1: Product Introductions
1.2.5 VIO-215R(C)/PC100 | VIO-215R(C)/PC100
Hardware Specification
Display
•LCD Size: 15” (4:3)
•Max. Resolution: 1024 x 768 (XGA)
•Brightness (cd/m2): 350
•Contrast Ratio: 700 : 1
•LCD Color: 16.2M
•Pixel Pitch (mm): 0.297 (H) x 0.297 (V)
•Viewing Angle (H-V): 170 / 160
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-215R/PC100 and VIO-215R/PC110
Only
•Projected Capacitive: VIO-215C/PC100 and VIO-
215C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•SSD/HDD: 1x External 2.5” SATA HDD Bay
•mSATA: 1x mSATA (Shared by 1x Mini PCIe)
•CFast: 1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•SIM Socket: 2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-215/PC110 Series Only)
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
- 4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows: Windows 10, Windows 8.1, Windows 7, WES7
•Linux: Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 60°C
•Storage Temp.: -20°C to 65°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-215R(C)/PC100
- Dimension: 377 (W) x 301 (D) x 64.7 (H)mm
- Weight: 5.12 ~ 5.16 kg
•VIO-215R(C)/PC110
- Dimension: 377 (W) x 301 (D) x 86.7 (H)mm
- Weight: 5.24 ~ 5.32 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm

VIO-100(200)/PC100 | User’s Manual
20
1.2.6 VIO-W115R(C)/PC100 | VIO-W115R(C)/PC110
Chapter 1: Product Introductions
Hardware Specification
Display
•LCD Size: 15.6” (16:9)
•Max. Resolution: 1920 x 1080 (Full HD)
•Brightness (cd/m2): 400
•Contrast Ratio: 700 : 1
•LCD Color: 16.7M
•Pixel Pitch (mm): 0.17925 (H) x 0.17925 (V)
•Viewing Angle (H-V): 160 / 140
•Backlight MTBF: 50000 hrs (LED Backlight)
Touch
•Resistive 5-Wire: VIO-W115R/PC100 and VIO-
W115R/PC110 Only
•Projected Capacitive: VIO-W115C/PC100 and VIO-
W115C/PC110 Only
System
•Processor: Intel® Celeron® Processor J1900, Quad Core,
2MB Cache, 2.0 GHz
•System Chipset: SOC integrated
•LAN Chipset: GbE1 & GbE2: Intel® I210-AT (Support Wake-
on-LAN and PXE)
•Audio Codec: Realtek ALC888S
•System Memory: 1x 204-Pin DDR3L 1066/1333MHz
SODIMM. Max. up to 8GB
•BIOS: AMI 64Mbit SPI BIOS
•Watchdog: Software Programmable Supports 1~255 sec.
System Reset
Storage
•SSD/HDD: 1x External 2.5” SATA HDD Bay
•mSATA: 1x mSATA (Shared by 1x Mini PCIe)
•CFast: 1x CFast (Shared by 1x mSATA & 1x Mini PCIe)
•SIM Socket: 2x External SIM socket
Expansion
•Mini PCI Express: 2x Full-size Mini PCIe
- 1x Full-size Mini PCIe socket with USIM socket
(PCIe+USB+SATA)
- 1x Full-size Mini PCIe socket with USIM socket (PCIe+USB)
•2x Universal I/O Bracket (VIO-W115/PC110 Series Only)
Other Features
•Internal Speaker: AMP 10W + 10W
•OSD: LCD On/Off, Auto, Menu, Up and Down Multi-
language
I/O
•VGA: 1x VGA
•DisplayPort: 1x 1x DisplayPort
•COM
- 4x RS-232/422/485
- 2x RS-232/422/485 (internal)
•USB: 1x USB 3.0, 3x USB 2.0
•LAN: 2x RJ45
•Audio: 1x Mic-in, 1x Line-out
•DIO: 8 in / 8 out (Isolated)
•Others:
- 3x WiFi Antenna Holes
- 1x Power Switch, 1x AT/ATX Switch,1x Remote Power
On/Off
Operating System
•Windows: Windows 10, Windows 8.1, Windows 7, WES7
•Linux: Linux kernel 3.X
Power
•Power Mode: AT, ATX
•Power Supply Voltage: 9-50VDC
•Power Ignition Sensing: Power Ignition Management
•Power Connector: 3-pin Terminal Block
•Power Adaptor: Optional AC/DC 12V/5A, 60W
•Power Protection
- OVP (Over Voltage Protection)
- OCP (Over Current Protection)
- Reverse Protection
Environment
•Operating Temp.: -10°C to 70°C
•Storage Temp.: -20°C to 70°C
•Relative Humidity: 10%~80% (non-condensing)
•IP Level: IP 65 Compliant Front Panel
•Standards / Certification: CE, FCC Class A
Physical
•Front Panel Construction: Die-cast Flat Surface
•VIO-W115R(C)/PC100
- Dimension: 432 (W) x 261 (D) x 70.7 (H)mm
- Weight: 6.22 kg
•VIO-W115R(C)/PC110
- Dimension: 432 (W) x 261 (D) x 92.5 (H)mm
- Weight: 6.42 kg
•Mounting: VESA Mounting Holes 75 x 75mm, 100 x
100mm
This manual suits for next models
