Premium PRN10050MW User manual

PRN10050MW
PRN10060MS

I . Product Specifications
1, Introduction
- Structure: upper refrigeration compartment; lower freezing compartment
- Total - frost free
- Reversible door
- DOE platform
1、Specifications
Model PRN10050MW, PRN10060MS
Voltage / frequency 115V~/60Hz
Input power (W) 120W
current (A) 1.4
Energy
consumption(kwh/24h)
0.9
Energy consumption
level DOE
Refrigerant R600a/42g
Freezer compartment
effective capacity(L) 75
Refrigeration
compartment effective
capacity (L)
205
Total effective
capacity (L) 280
Net weight (lb) 119.1

Gross weight (lb) 132.3
II. Safety precautions
115V-60 HZ AC

III. Disassembly
1. The internal structure:
1、Thermostat
2、Temperature control panel
3、Refrigerator shelf
4、Crisper(The crisper contains ice tray and manual)
5、Adjustable foot
6、Freezer shelf
7、Freezer tray
8、lamp switch
9、Refrigerator tray

OPERATION
HMI and keys operation
The keys in HMI and display layout are referred in the following figure：
1.1Key
A.SET position set key
1.2Display screen
①Shift 1
②Shift 2
③Shift 3
④Shift 4
⑤Shift 5
1.3Display
◆Once initially powered on，the display screen is on full display for 3s，and then operates
as the displayed middle shift.
◆Normal operation display
In case of a failure，the appropriate LED light show in combination the failure code (in recycling display)；
In case of no failures，the actual operation position of refrigerator will be on display.
1.4Shift setting
Each time the shift setting key A is pressed once，the shift position changes one time. After the shift setting
has been completed, the refrigerator will operate according to the set value in 5mins.
The shift regulation is：
1.5Fault indication
Display
Malfunction
The LED1 and LED2 lit
Refrigerator temperature sensor circuit
The LED1 and LED3 lit
Freezer defrost sensor
The LED1 and LED4 lit
Ambient temperature sensor
Shift 1
Shift 2
Shift 3
Shift 4
Shift 5
A ①②③④⑤

Temperature Control
When using the refrigerator-freezer for the
first time or after defrosting, turn the
temperature control to set “MAX” for at least
two hours before introducing the food to be
Repalcing Your Light Bulb
Note：
All parts removed must be saved to do the replacement of the light bulb.
Before removing the light bulb, either turn off the appliance or disconnect
the electricity leading into the appliance at the main power supply. Failure
to do so could result in electrical shock or personal injury.
Unplug the AC power cord from the wall.
Pull down to remove the lamp cover.
Unscrew the bulb.
Repace with a 15-watt bulb that is the same shape and size.
REQUESTING ASSISTANCE OR SERVICE
If the problem is not due to one of the items listed in Troubleshooting, Contact
the dealer or authorized Service Company.

IV. Product disassembly display

V. user manual
1. product Installation
RECOMMENDATIONS：
1) WARNING –Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
2) WARNING –Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
3) WARNING –Do not damage the refrigerant circuit.
4) WARNING –Do not use electrical appliances inside the food storage compartments
of the appliance, unless they are of the type recommended by the manufacturer.
5) The appliance has to be unplugged after use and before carrying out user
maintenance on the appliance.
6) This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
7) Children should be supervised to ensure that they do not play with the appliance.
8) If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.

9) Please abandon the refrigerator-freezer according to local regulators for it use
flammable blowing gas and refrigerant.
10）Please according to local regulations regarding disposal of the appliance for its
flammable refrigerant and blowing gas. Before you scrap the appliance, please take off
the doors to prevent children trapped.
VI. Tools required for maintenance
name
usage
electronic leak detector
Leakage or not
cross-screwdriver
Unscrew the screw
31 pieces of tool assembly

冷凝器
防露管 干
燥
过
滤
器
回
气
换
热
管
毛
细
管
冷冻室蒸发器
压
缩
机
Condenser
Anti dew tube
Compressor
Freezer Evaporator
Dry and
Filtering
device
Capillary tube
Heat exchange tube
VIII. drawing diagram
VIIII. System diagram
ELECTRIC DIAGRAM
TH Sensor
Power Plug
PTC
Compressor
Protector
Lamp Switch
R Lamp
Defrost
Sensor
R Sensor
Control Board
Fan Motor
Defrost
Fuse
Defrost
Heater
N
L
60Hz
115V~
C
