Premium PRN18055KW User manual

PRN18055KW
PRN18055KW
REFRIGERADOR DE 18 cu.ft
18 cu.ft REFRIGERATOR

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY!
Please read these instructions carefully before the
first use of this product and save this manual for your
future reference.
IMPORTANT SAFETY INSTRUCTIONS
W hen using an electrical appliance, basic precautions should always be
followed, including the following:
1. This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
2. Do not use if supply cord is damaged. If damaged, it must be
replaced by the manufacturer or a similarly qualified person in
order to avoid hazard.
3. In order to save power consumption,keep the air circulation
around the appliance and dispose of food packages before placing
them in the appliance as soon as possible.
-01-
4. Ensure the refrigerator is unpluggedbefore cleaning or if the
product is not in use.
5. To clean the appliance use only mild detergents or glass cleaning
products. Never use harsh detergents or solvents.
6. It is not recommended to use this refrigerator with an extension
cord or power board. Please ensure that the appliance is plugged
directly into the electrical outlet.
7. Do not place hot food or drink into the refrigerator before it
cools down to room temperature.
8. Close the door immediately after putting in any items so
the inside temperature will not rise dramatically.

9. Keep appliance away from any heat source or direct sunlight.
10. To fix stably, the appliance must be placed on a flat and solid
surface. It should not be laid on any soft material.
11. Do not place any other appliance on top of the refrigerator, and do
not wet it.
12. Do not store something like ether, methanol, gasoline etc.,
which is easy to evaporate burn or explode.
13. To avoid injury or death from electrical shock do not operate the
appliance with wet hands, while standing on a wet surface or while
standing in water.
14. Do not use outdoors or in wet conditions.
15. Never pull the cord to disconnect it from the outlet. Grasp the
plug and pull it from the outlet.
16. Keep the cord away from heated surfaces.
17. Do not move the appliance when it is well filled of foods to
avoid any tipping over.
18. Check that the voltage of the power supply in your home is the
same as the voltage shown on the rating label of this product.
19. Connect your refrigerator to an independent electrical socket
and use a safe ground wire.
20. When the frost in freezer is removed, or when there is no electricity
or when refrigerator ceases to be used, it should be cleaned in order to
prevent it from smelling.
21. Defrost the freezer at least once a month because too much frost
may affect refrigeration.
22. Do not touch the appliance with wet hands or with naked feet on a wet
floor.
23. Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
24. Turn on electricity only 5 minutes later after electricity goes off.
Otherwise, the compressor may be damaged.
-02-

26. The appliance is not intended to be operated by means of an
external timer or a separate remote –control system.
27. This appliance has been incorporated with a grounded plug.
Please ensure the wall outlet in your house is well earthed.
28. It is recommended to check regularly the supply cord for
any sign of possible deterioration, and the appliance should not be
used if the cable is damaged.
29. WARNING: Keep ventilation opening, in the appliance
enclosure or in the built-in structure, clear of obstruction.
30. WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by
the manufacturer.
31. WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
32. WARNING: Do not damage the refrigerant circuit.
33. This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
25. Children should be supervised to ensure that they do not play
with the appliance.
34. Regarding the information for replacing of the lamps of the
appliance, thanks to refer to the below paragraph of the manual.
35. Regarding the information pertaining to the installation, handing,
maintenance, servicing and disposal of the appliance, thanks to refer to
the below paragraph of the manual.
-03-

A: Freezer compartment
1. Freezer lamp
2. Removable ice box
3. Freezer door tray
4. Freezer glass shelves
5. Freezer drawer cover
6. Freezer drawer
B: Fridge compartment
7. Fridge lamp
8. Fridge door tray I
9. Fridge door tray II
10. Water tank
11. Fridge glass shelves
12. Fridge drawer cover
13. Fridge drawer
5
4
STRUCTURE ILLUSTRATION
B
1
2
3
6
7
8
9
10
11
12
13
A
-04-

During transportation, hold the base and lift the refrigerator carefully
with an angle inferior at 45 degree. Never hold the door handle as
support. Never place it upside down nor horizontally. Push
refrigerator on its basis and place it according to its roller feet.
To fix stably, the appliance must be placed on a flat and solid
surface. It should not be laid on any soft material.
Choose a location where there is no heat source. Keep the
refrigerator away from direct sunlight or other appliance producing
heat. Choose a dry and well-ventilated place where there is no
corrosive air.
In order to improve efficiency of the cooling system and save
energy, it is necessary to maintain good ventilation around
the appliance for the dissipation of heat. For this reason,
sufficient clear space should be available around the
refrigerator. Suggest: It is advisable for there to be at least
75mm of space from the back to the wall, at least 100mm
from its top. The sides please refer to below diagram. A clear
space is in front to allow the doors to open 135°.
TRANSPORT AND HANDING
INSTALLATION
1530
905
275 350
1085
135°
-05-

FIRST USE
Before the use of the refrigerator, remove all the packages,
including bottom cushion and foam pads and rubber belts in the
refrigerator.
Adjust the feet and clear the outside and inside of the refrigerator
with warm cloth.
Do not start the refrigerator immediately after vertical
placement. Only start it after 2-6 hours standing to ensure its
proper operation.
To prevent damage to the power cord and any consequence
incidents, the power cord should be not covered by the
refrigerator or other objects. Before switching on the
refrigerator, please check the voltage range of refrigerator
carefully if the same as that of the power supply. When the
refrigerator is first installed, allow it stabilize at normal
operating temperatures for 2-3 hours prior to filling it with fresh or
frozen foods.
If operation is interrupted, waits 5 minutes before restarting.
DISPLAY CONTROLS
Use your appliance according to the following control regulations,
your appliance has the corresponding functions and modes as the
control panels showed in the pictures below. When the appliance is
powered on for the first time, the backlight of the icons on display
panel starts working. If no buttons have been pressed and the doors
are closed, the backlighting will turn off.
-06-

Controlling the temperature
The default temperature for the refrigerator is set to 5°C and the
freezer to -20°C. If you want to change the temperature, follow the
instructions below.
Caution! When you set a temperature, you set an average
temperature for the whole refrigerator cabinet. Temperatures
inside each compartment may vary from the temperature values
displayed on the panel, depending on how much food you store and
where you place them. Ambient temperature may also affect the
actual temperature inside the appliance.
-07-

1. Fridge
Press the “Mode” for 3s to unlock the panel. Press “Fridge”to set fridge
temperature between 2°C and 8°C as needed, and control panel will
display corresponding values according to the following sequence with
the light on. After 3s, the light is off and temperature is set.
5
(Max)
2. Freezer
Press the “Mode” for 3s to unlock the panel. Press “Freezer”to set
freezer temperature between -15°C and -25°C as needed, and control
panel will display corresponding values according to the following
sequence with the light on.After 3s, the light is off and temperature is
set.
(Min)
-20°C
(Min)
-25°C(Max)
-15°C
3. Model Setting
Press the “Mode” for 3s to unlock the panel. Press “Mode” to set
function mode as needed, and the control panel will display
corresponding value according to the following sequence with light
on.After 3s, the light is off and mode is set.
-08-

Super cool
Super Cool can refrigerate your food much faster, keeping food
fresh for a longer period. When super cool function is on,
freezer temperature is not changed and fridge temperature is
set 2°C. Light of the icon and “Max” is on.
It will automatically switch off after 6 hours and the refrigerator
temperature will revert back to the previous setting.
Super freeze
Super freeze will quickly lower the temperature within the freezer,
so food will freeze vitamins and nutrients of fresh food and keep
food fresh longer.
When super freeze function is on, fridge temperature is
not changed and freezer temperature is set -28°C. Light of the
icon and “Max” is on.
In case of the maximum amount of food to be frozen, please wait
about 24h.
It automatically switch off after 26 hours and the freezer temperature
will revert back to the previous setting.
Intelligence
In the mode, the refrigerator works in the most beneficial food
preservation and storage way. The fridge temperature is set 5°C,
and the freezer temperature is -20°C in the mode.
4. Lock/unlock
Press the “Mode” for 3s, light of the icon is off and the panel is
unlocked.
Without any operation in 20s, the panel will be locked automatically
and whole light is off after about 60s.
-09-

The refrigerator is built with water dispenser.
The water dispenser allows access to chilled water without
having to open the refrigerator door.
The number of door openings is thus reduced, less cold air is
lost from the refrigerator and you save on electricity costs.
WATER DISPENSER
Filling the water tank
•Open the cap of the water tank.
•Fill with pure and clean drinking water.
•Do not overfill the tank. The capacity is 2L.
•Close the cap.
Notes: Do not fill water tank with any liquid other than drinking water.
Beverages such as fruit juice, carbonated fizzy soda drinks and alcohol
are not suitable for use with the water dispenser. If such liquids are
used, the water dispenser may malfunction and be damaged beyond
repair. Some chemical ingredients and drink additives may also attack
and damage the water tank material. The guarantee does not cover
such eventualities.
Using the dispenser
•Push in the lever of the water dispenser with your glass.
•Releasing the lever, stops further dispensing of water.
•Flow rate is dependent on how far the lever is pushed back:
Fully back = full flow
Gently back = trickle
•As the level of water in your cup/glass rises, gently reduce the
amount of pressure on the lever to avoid overflow.
-10-

Notes: Push the water dispenser lever with a rigid cup. If you are
using a plastic disposable cup, then push the lever with your fingers
from behind the cup.
Clean the water tank
•Remove the fridge door tray II.
•Take off the cover of water tank. Clean them with warm and clean
water and dry them with clean and soft cloth.
•Install them with opposite steps.
•To prevent possible leakage, ensure that any parts removed
during cleaning are refitted correctly in their original locations.
Notes: The water tank and dispenser components are not
dishwasher-proof.
STORAGE OF FOOD
You appliance has the accessories as the “Description of the
appliance”showed in general, with this part instruction you can have
the right way to storage your food.
Fridge compartment
The fridge compartment is mainly used to store foods that are
preserved for a short time.
It is suitable for storing fruits, vegetables, drinks and other foods
that will be eaten recently. It is suggested to seal food and then put
them into the refrigerator. Suggested sections of fridge compartment
for various foods and variety name:
Glass shelves: wheaten foods, milk, etc. They can be taken out to
be cleaned and adjusted to achieve different storage volume as you
need.
Drawer: fruits, vegetables, etc.
Door rack: eggs, canned liquid, bottled drinks and packed food,
etc. Do not place too many heavy things in the racks
-02-
-11-

Freezer compartment
The freezer compartment is used to freeze foods, store deeply
frozen foods and make ice cubes. It can preserve foods for a
long time.
It is suitable for retaining the freshness of foods for a long time.
When storing meat, it is suggested to cut them into pieces which
are easy to take out and mark the freezing date to prevent foods
from exceeding the time limit.
Suggested sections of fridge compartment for various foods and
variety name:
Glass shelves: frozen foods, such as fish, meats and ice creams.
They can be taken out to be cleaned and adjusted to achieve
different storage volume as you need.
Drawer: packaged frozen foods, etc.
Door rack: small frozen articles, thin packaging food, foods stored
for a short time, etc. Do not place too many heavy things in the
racks
Removable ice box
Freezer compartment is equipped with a big and removable
ice box to make ice cubes.
Fill 4/5 water from the top of the box and put it into freezer
compartment. It can be on any shelf as you like. After frozen,
rotate the knob clockwise and the ice cubes will fall down to the
drawer under the trays. Clean it with clean and warm water and
dry it with soft and clean cloth.
-12-

Helpful hints and tips
We recommend that you follow the tips below to save energy.
·Try to avoid keeping the door open for long periods in
order to conserve energy.
·Ensure the appliance is away from any sources of
heat(Direct sunlight, electric oven or cooker etc)
·Don't set the temperature colder than necessary.
·Don't store warm food or evaporating liquid in the appliance.
·Place the appliance in a well ventilated, humidity free room.
Please refer to Installing your new appliance chapter.
·If the diagram shows the correct combination for the
drawers, crisper and shelves, do not adjust the combination as
this is designed to be the most energy efficient configuration.
Hints for fresh food refrigeration
·Do not place hot food directly into the refrigerator or freezer,
the internal temperature will increase resulting in the
compressor having to work harder and will consume more
energy.
·Do cover or wrap the food, particularly if it has a strong flavor.
·Place food properly so that air can circulate freely around it.
Hints for refrigerator
Meat (All Types) Wrap in polythene food: wrap and place on the
glass shelf above the vegetable drawer. Always follow food
storage times and use by dates suggested by manufacturers.
HELPFUL HINTS AND TIPS
·Cooked food, cold dishes, etc.: They should be covered
and may be placed on any shelf.
·Fruit and vegetables: They should be stored in the special
drawer provided.
·Butter and cheese: Should be wrapped in airtight foil or plastic
film wrap.
·Milk bottles: Should have a lid and be stored in the door racks.
-13-

Hints for freezing
·When first starting-up or after a period out of use, let the
appliance run at least 2 hours on the higher settings before
putting food in the compartment.
·Prepare food in small portions to enable it to be rapidly
and complete frozen and to make it possible to subsequently
thaw only the quantity required.
·Wrap up the food in aluminum foil or polyethylene food
wraps which are airtight.
·Do not allow fresh, unfrozen food to touch the food which is
already frozen to avoid temperature rise of the latter.
·Iced products, if consumed immediately after removal
from the freezer compartment, will probably cause frost burns to
the skin.
·It is recommended to label and date each frozen package in
order to keep track of the storage time.
Hints for the storage of frozen food
·Ensure that frozen food has been stored correctly by the food
retailer
·Once defrosted, food will deteriorate rapidly and should not
be re-frozen. Do not exceed the storage period indicated by the
food manufacturer.
Switching off your appliance
If the appliance needs to be switched off for an extended
period, the following steps should be taken prevent mould on the
appliance.
1. Remove all food
2. Remove the power plug from the mains socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged open slightly to allow air
to circulate.
-14-

CLEANING AND CARE
For hygienic reasons the appliance (including exterior and interior
accessories)should be cleaned regularly at least every two months.
Caution! The appliance must not be connected to the mains during
cleaning. Danger of electrical shock! Before cleaning switch the
appliance off and remove the plug from the mains socket.
Exterior cleaning
To maintain good appearance of your appliance, you should clean it
regularly.
-Wipe the digital panel and display panel with a clean, soft
cloth.
-Spray water onto the cleaning cloth instead of spraying
directly on the surface of the appliance. This helps ensure an even
distribution of moisture to the surface.
-Clean the doors, handles and cabinet surfaces with a mild detergent
and then wiped dry with a soft cloth. Caution!
-Don't use sharp objects as they are likely to scratch the surface. -
Don't use Thinner, Car detergent, Clorox, ethereal oil, abrasive
cleansers or organic solvent such as Benzene for cleaning. They may
damage the surface of the appliance and may cause fire.
Interior cleaning
You should clean the appliance interior regularly. It will be easier to
clean when food stocks are low. Wipe the inside of the fridge freezer
with a weak solution of bicarbonate of soda, and then rinse with warm
water using a wrung-out sponge or cloth. Wipe completely dry before
replacing the shelves and baskets. Thoroughly dry all surfaces and
removable parts.
Although this appliance automatically defrosts, a layer of frost may
occur on the freezer compartment's interior walls if the freezer door is
opened frequently or kept open too long. If the frost is too thick,
choose a time when the supply of food stocks are low and proceed as
follows:
-15-

1. Remove existing food and accessories baskets,unplug
the appliance from the mains power and leave the doors open.
Ventilate the room thoroughly to accelerate the thawing process.
2. When defrosting is completed, clean your freezer as described
above.
Caution!
Don't use sharp objects to remove frost from the freezer. Only after
the interior completely dry should the appliance be switched back
on and plugged back into the mains socket.
Door seals cleaning
Take care to keep door seals clean. Sticky food and drinks can
cause seals to stick to the cabinet and tear when you open the
door. Wash seal with a mild detergent and warm water.
Rinse and dry it thoroughly after cleaning.
Caution! Only after the door seals are completely dry should the
appliance be powered on.
Replacing the LED light
Warning: The LED light must not be replaced by the user! If
the LED light is damaged, contact the customer helpline
for assistance. To replace the LED light, the below steps can be
followed:
1. Unplug your appliance.
2. Remove light cover by pushing up and out.
3. Hold the LED cover with one hand and pull it with
the other hand while pressing the connector latch.
4. Replace LED light and snap it correctly in place.
-16-

Problem Possible cause & Solution
Appliance is
not working
correctly
Check whether the power cord is plugged
into the power outlet properly.
Check the fuse or circuit of your power supply,
replace if necessary.
The ambient temperature is too low. Try setting
the chamber temperature to a colder level to
solve this problem.
TROUBLESHOOTING
If you experience a problem with your appliance or are concerned
that the appliance is not functioning correctly, you can carry out
some easy checks before calling for service, please see below. You
can carry out some easy checks according to this section before
calling for service.
Warning! Don't try to repair the appliance yourself. If the problem
persists after you have made the checks mentioned below, contact
a qualified electrician, authorized service engineer or the shop
where you purchased the product.
The light is not
working
·The LED light may be damaged. Refer to
replace LED lights in cleaning and care
chapter.
·The control system has disabled the light due
to the door being kept open too long, close and
reopens the door to reactivate the light.
-17-

Problem Possible cause & Solution
Appliance is
not working
correctly
It is normal that the freezer is not operating
during the automatic defrost cycle, or for a short
time after the appliance is switched on to protect
the compressor.
Odors from
the appliance
The interior may need to be cleaned.
Some food, containers or wrapping cause
odors.
Noise from
the
appliance
The sounds below are quite normal:
·Compressor running noises.
·Air movement noise from the small fan
motor in the freezer compartment or other
compartments.
·Gurgling sound similar to water boiling.
·Popping noise during automatic defrosting.
·Clicking noise before the compressor starts.
Other unusual noises are due to the reasons
below and may need you to check and take
action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
The motor
runs
continuously
It is normal to frequently hear the sound of the
motor, it will need to run more when in following
circumstances:
·Temperature setting is set colder than
necessary
-18-

Problem Possible cause & Solution
The motor
runs
continuously
·Large quantity of warm food has
recently been stored within the appliance.
·The temperature outside the appliance
is too high.
·Doors are kept open too long or too often
·After your installing the appliance or it has
been switched off for a long time.
A layer of frost
occurs in the
appliance
Check that the air outlets are not blocked by
food and ensure food is placed within the
appliance to allow sufficient ventilation. Ensure
that door is fully closed. To remove the frost,
please refer to cleaning and care chapter.
Temperature
inside is too
warm
You may have left the doors open too long or
too frequently; or the doors are kept open by
some obstacle; or the appliance is located with
insufficient clearance at the sides, back and top.
Temperature
inside is too
cold
Increase the temperature by following the
“Display controls” chapter.
Doors can't
be closed
easily
Check whether the top of the refrigerator is
tilted back by 10-15mm to allow the doors to
self close, or if something inside is preventing
the doors from closing.
Water drips
on the floor
The water pan(located at the rear bottom of the
cabinet)may not be properly positioned to
direct water into this pan, or the water spout is
blocked. You may need to pull the refrigerator
away from the wall to check the pan and spout.
-19-
