Prestigio Nobile PER3374B User manual

www.prestigio.com
PRESTIGIO NOBILE
e-Book Reader PER3374B

7’ eBook Reader
EN-2
Table of Contents
Disclaimer
3
Introduction
3
Package Content
4
Getting Started
5
Charging the Reader
6
Power On/Off, Reset Device, Insert MicroSD
7
Main Menu
8
Reading History
9
Ebooks
11
Music
13
Video
16
18
Radio
21
Explorer
20
Settings
22
Games
31
User Manual
28
Calculator
30
Search
27
Calendar
25
Product Specifications
33
Technical Support and Warranty Information
33
Copyright and Trademark Notice
34

7’ eBook Reader
EN-3
Disclaimer
All the information, design and specifications contained in this manual were at the
time of publication. However, as the product is under development and upgrading,
the final device may have a slightly different appearance or modifications in
functionality than presented in thismanual.
Introduction
Prestigio Nobile PER3374B is an e-book reader with full color TFT display screen 19
cm (7”) diagonal and resolution of 800*480.
PER3374B supports e-books encrypted with FB2, HTML, etc.
Support of 22 languages including English, Russian, Greek, Polish, German, etc.
Includes audio and video playback and a photo viewer.
4GB built in flash memory.
Inbuilt speakers.

7’ eBook Reader
EN-4
Package Content
1. E-book Reader
2. USB cable
3. AC adapter
4. Quick Start Guide in multiple languages
5. International warranty card

7’ eBook Reader
EN-5
Getting Started

7’ eBook Reader
EN-6
Getting Started
Rotation
Rotate the screen while reading orviewing
picture and popping the keyboard while
searching.
Zoom in/out
Enlarge/reduce font size while reading and
picture size while viewing pictures and change to
exexternal
external memory while searching.
Direction buttons
Up /down/left/right directions buttons.
Menu
Pop up the menu and also OK function.
Back
Back to the previous page. Long press the button
to go back main menu.
Pause
Pause while playing music or video. Delete while
in file explorer.
Next
Go to the next file while in reading ebook,
viewing picture, playing music or video.
Previous
Go to the previous file while in reading ebook,
viewing picture, playing music or video.
Power button
Turn on/off the device
Reset
Reset the device by inserting a small pin into the
hole
USB port
Connect to the USB cable
Earphone Jack
Connect to the earphones
Micro SD card slot
Insert micro SD storage card
11
12
13
8
7
10
9
6
5
3
4
2
1

7’ eBook Reader
EN-7
Getting Started
Charging the Reader
You need to charge the Reader prior to using it for the first time or when battery
power is low.
Note: It’s recommended to charge the battery for 4 hours before the first time
use. Normally it takes approximately 4~5 hours to fully charge the device.
Recharge the device as soon as possible when the battery is in low-power level
shown as . icon appears once the battery is fully charged.
You can charge the Reader by:
Inserting Mini USB connector to the
USB port on the device and
connecting power adapter to wall
socket for charging.
Connecting the host PC USB port
and the device with the included USB
cable to start charging.
Note: When charging through PC, you cannot operate the Reader. To operate the
reader during charging, click the Safely Remove Hardware icon on your desktop
with the Reader connected to PC. Click any button on the Reader to go from “USB
Connection” screen.
Switch the Reader to stand-by mode to speed up the charging process.

7’ eBook Reader
EN-8
Getting Started
Power Reader On and Off
Press and hold the [Power] button for 3-5 seconds to turn on Reader - it will
automatically enter the main menu on Home screen after the start-up screen.
It may take a few moments for reader to turn on and load the content.
If Reader does not turn on, charging is required.
To turn off Reader, press and hold [Power] button for 3-4 seconds.
Restoring to Factory Default Settings
Reset the device by pressing reset button when device fails to start up orfunction
properly.
Using a micro SD Card (Not Included)
Insert micro SD card into
micro SD slot.

7’ eBook Reader
EN-9
Main Menu
There are 3 sections on main menu. On the upper there is time and date. On
middle part there are 10 icons referring to different applications, including Reading
History,Ebook,Music,Video,Photo,Radio,Explorer, Radio, Settings, Games
and User Manual.On the lower part there are 3 tool applications:Search,
Calculator and Calendar.Press the Direction buttons on the middle or Previous
and Next buttons on the left to choose the desired application and then press M
button to enter it.

7’ eBook Reader
EN-10
Main Menu: Reading History
Reading History
Ebooks viewed in the past will be displayed on the screen.
·Press the Direction buttons on themiddle
to view the ebook reading history. Press
Previous and Next buttons on the left to go
to the previous or next page of the list.
·Press M button to get the submenu.
Delete, delete all and exit options are
available for deleting the current ebook
from the history, deleting all reading
history and go back from the submenu.
·3/82 displayed under the ebook tile shows
the total pages of this ebook are 82 and
your last reading page is 3.
·2012-6-7 displayed under the ebook tile
shows your last reading time of this ebook.
Note: Files that were saved on the
MicroSD card will not be displayed in History
list if the MicroSD card is removed.

7’ eBook Reader
EN-11
Main Menu: Ebook
Ebook
Nobile PER3374B supports most of popular e-book formats, including PDF, EPUB,
FB2, PDB, TXT(ANSI/UNICODE code), HTML,RTF,WTXT and etc.
Press the Direction buttons on the
middle or Previous and Next buttons on
the left moving to Ebook. Then press M
button to enter the ebook list.

7’ eBook Reader
EN-12
Main Menu: Ebook
Choose the desired book to start reading. Press M button to popup the menu. Here
below options in the menu.
Item
Description
Page jump
Press direction button left or right to move the place and
press direction button up or down to change the numbers.
Then press M button to jump to the desired page.
Save bookmark
Press M button to save the current page as a bookmark.
Total 5 bookmarks can be saved.
Load bookmark
Press direction button up or down to choose the bookmark
that saved. Then press M button to open the bookmark.
Delete bookmark
Press direction button up or down to choose the bookmark
that saved. Then press M button to delete it.
Browser mode
Press direction button up or down to choose Auto flip or
Manual flip. Then press M button to set it.
Flip time
Press direction button up or down to choose the Flip time
and then press M button to confirm. Then it will automatically
turning pages after the chosen time period if you already
choose Auto flip mode to read.
Brightness
Press direction button up or down to choose the brightness
level and then press M button to confirm. Default brightness
is level Two.
Code type
Press direction button up or down to choose the Code type.
There are UTF-16LE/UTF-16BE/UTF-8 and all 22 languages
available in settings.
Font set
Press direction button up or down to choose the font type
and then press M button to confirm. Calibri,Default font, Arial,
Times New Roman and Droid Sans Fallback are available.

7’ eBook Reader
EN-13
Main Menu: Music
Music
Press the Direction buttons on the middle or Previous and Next buttons on the left
moving to Music and then press M button to enter it. It supports MP3, WAV, FLAC,
AAC, OGG, WMA (WMA lossless not supported) .
Note: Music files saved on micro SD card
are also displayed in the list.
All music, Artist, Album, Genre, My
favorites, Record, Directory List and
Update media library are displayed.

7’ eBook Reader
EN-14
Main Menu: Music
Item
Description
All music
List of all tracks. Press Previous and Next button to
turn pages of the list. Press direction button up/left or
down/right to move to the desired music.
Current Play
The current playing tracks.
Resume Play
The last played tracks.
Artist
The album list of artists.
Album
The track list of the album.
Genre
The artist list in the same genre.
My favorites
The favorite tracks list. On the all music list, press
button Pause to add the desired music to favorites.
Record
The recorded files list. Play all recorded files from
Record.
Directory list
Files list sorted by Flash and SD Card.
Updating media library
To update media library.

7’ eBook Reader
EN-15
Main Menu: Music
Music Playback
Choose All music / current music / Resume music, Artist, Album, Genre, My
favorites, or Directory list to play the music. Press Record to play the audio files
recorded by PER3374B.
Press Pause button to pause while playing and press it again to continue playing.
Press direction button left/right to the
previous/next music in the list.
Press direction button up/down to
increase/decrease volume.
Press M button to popup sub menu.
Play mode/ EQ sel/User EQ
setup/Display/Brightness are
available.
Play mode : Once, Repeat once, All
once, All repeat, In order, and
Random mode are available.
EQ sel : Normal, Rock, POP,
Classic, Bass, Jazz and User EQ are
available.
User EQ setup : To adjust the EQ
and the set EQ can be chosen in the
EQ sel section. Press direction
button up/down to choose the setting
options and press left/right button to
adjust the data.
Display : choose to display the lyric or not.
Brightness : Adjust the brightness and 7 levels are available.

7’ eBook Reader
EN-16
Main Menu: Video
Video
Press the Direction buttons on the middle or Previous and Next buttons on the left
moving to Video and then press M button to enter it. It supports 3GP, ASF, AVI, FLV,
MOV, MP4, RM, RMVB( 2mbps rmvb non -support real g2), VOB, WMV.

7’ eBook Reader
EN-17
Main Menu: Video
On the playback screen, the following operations can be performed. The video
orientation is set to Horizontal (left). (Default Settings)
1. Press Pause button to pause while playing and press it again to continue playing.
2. Press direction button left/right to the previous/next music in the list.
3. Press direction button up/down to increase/decrease volume.
4. Press M button to popup sub menu. Select time play, Full screen and
Brightness are available.
5. Select time play :Press direction button up or down to move the place and
press direction button left or right to change the numbers. Then press M button
to jump to the desired time. HH for hour, MM for minute.
6. Full screen : move to full screen and then press M button, there are threemode
are available : Full screen, Normal and Original screen.
7. Brightness : Adjust the brightness and 7 levels are available.
Note: Since the default display screen is horizontal, the left/right button here are the
up/down button on other sections and the up/down button here are the left/right
button on other sections.

7’ eBook Reader
EN-18
Main Menu: Photo
The device supports only the following picture formats: JPEG, GIF, BMP and PNG.
All other file formats will not be displayed.
Press Previous/up/left button to turn to the previous picture and press
Next/right/down button to turn to the next picture.
Press M button to popup the submenu. Rotate right/Rotate Left, Zoom
in/Zoom out, Browse mode, Scale to page, Set desktop, Recover desktop
and Brightness are available.
Rotate : choose Rotate right/ Rotate Left, press hard button Rotation to rotate
the current picture.
Zoom : choose Zoom in/Zoom out,Scale to page, or press hard button Zoom
in/out to change the picture size. 3 levels are available.
Bowser mode: Manual flip or flip time 5 sec, 10 sec, 20sec available for auto
flip.
Set desktop : set the current picture as desktop
Recover desktop : recover the desktop to the default one.
Brightness : Adjust the brightness and 7 levels are available.
Note: Zoom in/out function only applies to .JPEG, .PNG and .BMP picture
formats.

7’ eBook Reader
EN-19
Main Menu: Radio
Radio
FM radio is supported by PER3374B. It will request to insert earphone once open.
Press M button to enter submenu as below:
Manual search: Press left/right button
to increase/ decrease 0.1MHz.
Auto search: choose auto search and
it will be 0.1MHz added each
searching from 87.
Preset mode : channels saved can be
selected here. Choose preset mode
and it will be saved Channel 1. Then
press left/ right button turning to other
channels in order.
Save channel : 30 channels can be
saved.
Delete channel: delete the saved
channel from the list.
Receive area: China/ Japan/ USA/
Europe/ Campus Radio are available.

7’ eBook Reader
EN-20
Main Menu: Explorer
Explorer
Files in Flash or TF Card will be displayed under Explorer. Press M button to open
all supported files from this directory, and press Pause button to delete.
Note: Only a single file but not the
whole folder can be applied to
delete.
