Prestigio MultiPad PMP7070C3G Operating manual

PMP7070C3G
Technical
Service Manual

Product Specification Sheet
Product Model PMP7070C3G
Product Type Tablet
System Physical Standard Configuration/系统基本物理参数:
Type/类型 Details/详细规格 Descriptions/说明
Product Form/产品样式
Product Form/产品样式 Portrait or Landscape
Material ABS+PC，ABS，AL1050 (with brush)
Control elements/HW buttons Power,Vol-,Vol+
Dimensions(H*W*D) 190*119*8.8mm
Weight TBD
LCD/显示屏幕
Type/屏幕材质 IPS
Screen Size/屏幕尺寸 7"
Screen Resolution/屏幕分辨率 800×1280
Aspect ratio/长宽比 16:10
DPI/每英寸点数 215 dpi
Maximum brightness and contrast 300cd/m2(typical value); contrast 800:1
Colors/色彩 16.7M
TP/触控面板
Touch Module/触控类型 Capacitive
Numbers of Touch Points(Multi-Touch)/支
持触摸点数 5 dot
Battery/电池
Type/类型 Li-polymer
Capacity/容量 3500mAh
Minimum stand-by time, hour 200 hours
Minimum talk time 2G, min 4 hours
Minimum talk time 3G, min 4 hours
Minimum time video playback HD, min 4 hours
Minimum time in Audio playback, min 8 hours
Minimum Internet surfing time 4hours
System hardware configuration/系统硬件配置:
Type/类型 Details/详细规格 Descriptions/说明
Chipset/芯片组 Vendor/供应商 MTK
Chipset/芯片型号 MT8382
CPU Type/型号 Cortex A7/ Quad core
Frequency/频率 1.3 GHz
Manufacture ARM
GPU
Renderer/渲染率 53.25M Δ/s 1000MP/s
Frequency/频率 500MHz
OpenGL OPENGL ES2.0
Core Dual
Multi-media
(Hardware
encoding/decoding)/多媒
体
（
硬件编码
/
解码
）
Phote Viewer/图片浏览格式 BMP, JPG, GIF, PNG
Video Format/视频支持格式 Decoding: VP8,MPEG-4,H.263,H.264
Encoding:H.263
Audio Format/音频支持格式 Decoding:APE,FLAC,MP3,WAV,MP2,AMR,VDRBIS
Encoding:AMR
Memory
Type Built-in Memory and chip DDR3L（Kingston)，eMMC(Kingston）
RAM Capacity/容量 1GB
ROM Flash/闪存 Capacity/容量 8GB eMMC
Built-in memory available for user, MB 5840MB
Camera/相机
Front Camera/前置摄像头 0.3MP
Rear Camera/后置摄像头 2MP
Rear Flash Light/后置闪光灯 N/A
Speaker/扬声器 Size/规格 41.7×29
Support polyphonic ring (number of tones) N/A

Navigation Built-in GPS Yes
Built-in GLONASS N/A
Support A-GPS Yes
Sensors
G-Sensor/重力感应器 Yes
Gyro Sensor/陀螺仪 N/A
E-Compass/电子罗盘 N/A
Accelerometer N/A
Proximity Sensor/距离感应器 Yes
Light Sensor/光线感应器 Yes
FM-Radio FM Receiver, FM Transmitter FM Receiver
NFC/近场通讯 Built-in No
NFC controller chip No
Special Feature/其他特性 GPS EPO assistance No
Wireless Charging/无线充电 No
Network Connections/网络连接:
Type/类型 Details/详细规格 Descriptions/说明
2G Band/网络制式 850/900/1800/1900MHz GPRS Class12
EDGE EDGE download
3G Band/网络制式 900/2100MHz
HSDPA Uplink 11Mbps,Downlink 42Mbps
4G Band/网络制式 N/A
Technology N/A
WI-FI
WI-FI Module/Wi-Fi 模块 WIFI 802.11b/g/n
Band 2.4GHz
Cryptographic Algorithms/加密方式 WEP (40-bit、64-bit、128-bit), WPA (TKIP 128-bit), WPA2 (AES 128-bit)
Max range of wireless connection/无线连
接最大范围 30m
Wi-Fi Direct/Wi-Fi点对点直接连接 Yes
Wi-Fi Display (Miracast) N/A
Bluetooth/蓝牙
Version/版本 Bluetooth V4.0
Cryptographic Algorithms/加密方式 GFSK,DQPSK,DPSK
Max range of wireless connection/无线连
接最大范围 10m
Interface Configuration/接口参数:
Type/类型 Details/详细规格 Descriptions/说明
SIM Card Slot/SIM卡槽
SIM Card Slot/SIM卡槽 Yes
Type of Dual SIM (Dual SIM Stand-by
(DSS)/Dual SIM Active (DSA)) N/A
Switchible Dual-SIM 3G N/A
Standard 6-pin SIM card interface,
supporting the 1.8/3V USIM card Yes
SIM-cards form factor support Support micro SIM
Memory card socket/内存
卡插槽
External Memory Type Class/可扩展内存 Support SDHC/SDXC,up tp 32GB
SD-card Write Rate SD3.0
SD-card Read Rate SD3.0
USB
Data Transfer Port Type/数据接口类型 Micro USB 5pin
USB Port Data Transfer Rate/数据传输速率 USB2.0
USB Host OTG support/ USB,
Mous/Keyboard No
Charge/充电
Charge Connecter/充电接口 Micro USB 5pin
Same port with data transfer port Yes
Charging time 3h
Headset Jack/耳机插孔
Headphone Jack Standard ∮3.5mm Iphone/CTIA((APPLE) ) standard headphone jack
Support TRRS microphone on the
headset headphones Yes
HDMI interface/HDMI接口 Video, Audio Output/视频输出 N/A
Accessories/附件参数:
Type/类型 Quantity/数量 Descriptions/说明
Travel Charger/旅行充电器 15V/2A
Power Plugs 2EU/UK
OTG Cable 1(consigned part)
USB Cable 1(consigned part)

Pouch 1(consigned part)
Optional accessories NA
Software Configuration/软件参数:
Type/类型 Details/详细规格 Descriptions/说明
Operating System/操作系
统OS Version/系统版本 Andriod 4.4

ID Sub-part
number Material name Sub-part Specification dosage Remark alternative materials
0 SMB-D70230012 [Finished] - Tablet PC SMB-D7023 Linkage BT7002AWX-AALV ACE-GG7.0A-365-L
BT-D015-3268120-3500mAh Front 0.3MP+ Rear 2MP
HW201404011A PMP7070C3
1.000000 No
1 0990030020564 Package [virtual components] SMB-D7023,HW201404011A PMP7070C3G_BK_CIS Air
packages 1.000000 No
2 0101090020005 Other bags 140*250mm,CPE,NA,NA,NR 1.000000 Machine bags No
3 0101090020004 Other bags 125*200mm,OPP,NA,NA,NR 1.000000 Instructions bags No
4 0101050099998 Shrink film bags 200*350mm,NA 1.000000 Shrink with box No
5 0104020020390 Gift box Prestigio,PMP7070C3G_CIS,V1.0,NR 1.000000 Gift packaging, customer
specified supplier No
6 0108020020374 Printed Carton Prestigio,PMP7070C3G_CIS,V1.0,NR 0.100000 Carton 10 units installed No
7 0105070020040 Cardboard sheet 535*200mm,Single B-watt, two-sided cattle card 0.200000 Pad up and down outside the box No
8 0105070020041 Cardboard sheet 200*140mm,Single B-watt, two-sided cattle card 0.100000 Mat outer box nailing side No
9 0107020020002 Other trays 1200*1000*150mm(PP card comes with a board), 3000Kg,
black semi-new PP material 0.001390 When air is 720 units / ADS, each nine boxes, piled eight layers.
After stacking tray overall
dimensions: 1200 * 1000 *
1478mm
No
10 0109000099961 Paper Corner 960*60*60*5mm 0.005560 Each tray with four, stuck in the
top of the tray, put the box in
order to avoid packaged with Le
bad
No
11 0109000099995 Paper Corner 1220*60*60*5mm 0.005560 Each tray with around for pallets No
12 0990010021016 Logo pieces [virtual components] SMB-D7023,HW201404011A/B PMP707C3G Logo pieces
(package) 1.000000 No
13 1013120020074 Blank stickers SMBD1013-T02,40*20mm, White PET (single permutation),
halogen 1.000000 Print SN / IMEI code, coding rules according to customer
requirements
No
14 1013120020082 Blank stickers SMBD7808-T04,50*32mm(Print Eastern Europe Prestigio
trademark), white PET, halogen 1.000000 Paste color box No
15 1013120020077 Blank stickers SMBD7808-T03,80*140mm(Print Eastern Europe Prestigio
trademark), white PET, halogen 0.200000 Post Carton 2 (10 units installed) No
16 1013120020038 Blank stickers BS046A,68*110mm,Coated stickers 0.014000 Each tray 4 (300 pack) No
17 1013010320018 Copperplate paper stickers Lithium goods labels,120*110mm,Coated stickers 0.014000 Each tray 4 (300 pack) No
18 1013010320106 Copperplate paper stickers SMB-D7018,T01,NR,NR,Color Stickers (diameter 4mm-
green),NR,V1.0 1.000000 Paste color box No
19 0990020020506 Included accessories [virtual
components] SMB-D7023,HW201404011A PMP7070C3G_BK Included accessories 1.000000 No
20 1016000020160 Quick Guide Prestigio,PMP7070C3G,V1.0,ASBIS 1.000000 No
21 0414130020019 USB power supply connecting
cables USB-12mm +0.5 / -0 - logo printed on the reverse side - male - Right Angle = MICRO USB-5.5mm +0.2 / -0 - logo printed on
the reverse side - the public - at right angles, [1.0m, without a
rin
g
, black
]
/
Xin
y
u
g
lad
1.000000 No
22 0991300020016 Power functional components SMB-D7023, with HKA01105021-XE, European standard,
interchangeable feet, black 1.000000 No
23 0422010020076 Outsourcing-AC adapter HKA01105021-XE, European standard, interchangeable feet,
Prestigio, USB, NR, NR, black / Huntkey 1.000000 No
24 SMBD70231001
2[Host] - Tablet PC SMB-D7023 Linkage BT7002AWX-AALV ACE-GG7.0A-365-L BT-D015-3268120-3500mAh Front 0.3MP+ Rear 2MP
HW201404011A PMP7070C3
1.000000 No
25 0990010021015 Logo pieces [virtual components] SMB-D7023,HW201404011A/B PMP707C3G Logo pieces
(assembled) 1.000000 No
26 1013010220125 Plain paper stickers SMB-D7018, T02, Eastern Europe Prestigio, PMP5670C,
water damage sticker 7 * 5mm, NR, V1.0 1.000000 Sticker board suitable location No
27 1004000020016 Warranty seal Eastern Europe Prestigio, NR (straight through 4mm), V1.0,
halogen 1.000000 Sticker board suitable location No
28 0301020120109 Alien PET protective film SMBD7023-BF02, screen protective film 0.05PET, (multi-color
printing, with 3G, Eastern Europe Prestigio PMP7070C3G),
NR
1.000000 Sticker Machine No
29 0990040020711 Structure [virtual components] SMB-D7023,HW201404011A PMP7070C3G_BK Structure 1.000000 No
30 0723000020697 Subassemblies SMB-D7023, Back cover assembly (with metal trademark
without flash), black rubber paint (contract number
HW201404011A-V1.0), NR
1.000000 No
31 0616201520048 Mid case plastic parts SMBD7023-RE03, mid case, spray (matt UV) + silk, metallic
silver, NR 1.000000 No
32 0616390020034 Decorative plastic pieces SMBD7023-RE02, decorative pieces, black rubber spray
paint, black 1.000000 No
33 0616390020035 Decorative plastic pieces SMBD7023-RE04, lower garnish, black rubber spray paint,
black 1.000000 No
34 0617090020115 Rear panel Hardware SMBD7023-PT01,aluminum back cover, T = 1.0mm aluminum
alloy (1050), drawing sandblasting oxidation + laser engraving
(contract number HW201404011A-V1.0), Black, NR
1.000000 No
35 0616390020003 Decorative plastic pieces SMBC8003-RE04, camera decorative pieces, plating, bright
silver 1.000000 No
36 0608030000002 Copper nut M1.6*2,Copper, knurling 4.000000 No
37 0614010120008 Die-cast metal trademark
licensing SMBD7018-H04, Eastern Europe, metal trademarks, W24.4 * L25mm (black housing), silver 1.000000 No
38 0617230020007 Platen Hardware SMBD7023-PT02, USB + headphones plate, galvanized sheet
thickness 0.5 1.000000 No

39 0606020020069 Irregular silica SMBD7023-H02, MIC silicone sets, hardness of 45 degrees,
NR, black 1.000000 No
40 0606020000220 Irregular silica SPC5002-H04, IR silicone sets, hardness of 45 degrees, NR,
black 1.000000 No
41 0610020120000 Nickel-plated machine screw M1.4*2CMHNI,(K=0.5 D=3.5 Drop-resistant) 5.000000 No
42 0311010020016 Rules insulation pad D5*d2.7*1mm,Single back ordinary plastic, transparent 4.000000 No
43 0607000020009 Speaker Network SMBD7014-H01, speaker mesh, 0.1 stainless steel, single-
sided adhesive back T4000, character, NR 1.000000 No
44 0610020120006 Nickel-plated machine screw M1.6*2.5CWMHNI(k=0.9,W=5.5) Drop-resistant 1.000000 No
45 0616010020090 Key pieces of plastic SMBD7806-RE04,Volume keys, electroplating, metal silver 1.000000 No
46 0616010020091 Key pieces of plastic SMBD7806-RE03,Power button, plating + Sun Wen, silver 1.000000 No
47 0616170120025 Die-cut pieces of plastic lenses SMBD7002-H03,Camera lens, single back 3M9448 glue, silk,
black 1.000000 No
48 0610020100031 Nickel Metal Screws M1.6*2.5CMHNI(K=0.5 D=3 Drop-resistant) 4.000000 No
49 0602010020107 Irregular Poron SMBD7023-H06,Rear camera dust mats, ES, back-sided
ordinary plastic, black 1.000000 No
50 0602010020223 Irregular Poron SMBD7808-H09, the SMB-D7808 camera dust mats, water
WS05, single-sided adhesive Tesa4982, black, NR 1.000000 No
51 0723000020474 Subassemblies SMB-D7808, Nano_Sim Card Tray(metal + plastic), silver 1.000000 No
52 0616390020036 Decorative plastic pieces SMBD7808-RE10, Nano_Sim Card Tray (plastic), spray
common paint, metallic silver 1.000000 No
53 0617210020002 Pallet Hardware SMBD7808-PT08, Nano_Sim Card Tray, stainless steel
(powder metallurgy), sand colored, silver 1.000000 No
54 0606030020010 Rules Silicone 23.5 * 3.5 * 1.4, hardness 60 degrees, NR, black 1.000000 No
55 0606030020011 Rules Silicone 10.5 * 3.5 * 1.4, hardness 60 degrees, NR, black 1.000000 No
56 0602020020064 Rules Poron 13 * 7 (+ / -0.2) * 0.3 (+ / -0.1 with glue), ES, back-sided
ordinary plastic, black, NR 2.000000 No
57 0309010000007 Rules sponge pad 6 * 6 * 1MM, single-sided adhesive, ordinary plastic, black 1.000000 No
58 0991160020170 Functional components of the
camera SMB-D7023, with 0.3MP+2MP 1.000000 No
59 0715000020120 Built-in camera U-SMB-D7023-2235-329-V1.0, CMOS, front 0.3MP & rear
2MP, front & rear 640 * 480 1600 * 1200, YUV / / Xin Yu
Shen
g
1.000000 No
60 0991130020051 Battery functional components SMB-D7023, with BT-D015, 3268120 (lithium polymer -
Peoples - China Guangdong Po) battery 1.000000 No
61 0705020020074 Bare battery pack BT-D015, 3268120 (lithium polymer - Peoples - China
Guangdong Po), 3500mAh, 3.7V 1.000000 No
62 Bare 1.000000 No
63 SMBD70234000
6[Semi-finished products] - LCD Screen SMB-D7023, LCD & Touch Screen Module Linkage domain BT7002AWX-AALV ACE-GG7.0A-365-L HW201404011A
PMP7070C3G_BK structure
1.000000 No
64 0991100020132 Touchscreen functional
components SMB-D7023, with ACE-GG7.0A-365-L Black Configuration 1.000000 No
65 0703010020243 Screen touchpad ACE-GG7.0A-365-L, V1.0, capacitive, 7 "& 16:9, without gum,
Halogen / ACE 1.000000 No
66 0991090020162 LCD screen functional
components SMB-D7023, with a joint creation BT7002AWX-AALV LCD screen configuration 1.000000 No
67 0720020020089 Outsourcing - digital LCD screen BT7002BWX-AALV, Linkage, 7 "& 16:10, LED, without a
touchpad, without TCON, halogen / Linkage 1.000000 No
68 0990040020712 Structure [virtual components] SMB-D7023,HW201404011A PMP7070C3G_BK LCD screen
structure 1.000000 No
69 0723000020468 Subassemblies SMB-D7023, the front housing assembly,black 1.000000 No
70 0616201120147 Front housing plastic parts SMBD7023-RE01, front cover, NR, black 1.000000 No
71 0608030000002 Copper nut M1.6*2,Copper, knurling 3.000000 Supplier of hot melt front shell No
72 0615010020184 Irregular double-sided adhesive SMBD7023-H08, Saint-Gobain TG3730PL gel (T = 0.3mm),
touch screen double-sided adhesive 1.000000 No
73 0610020100031 Nickel Metal Screws M1.6*2.5CMHNI(K=0.5 D=3 Drop-resistant) 3.000000 No
74 0607000020021 Speaker Network SMBD7021-PT02, receiver filter, 0.1 nickel plate, back
tesa4972 glue, oxidation, Black 1.000000 No
75 0602010020197 Irregular Poron SMBD7023-H07, word of mouth plastic dust, water WS05,
double-sided adhesive TESA68562 (strength glue) &
TESA4972), black, NR
1.000000 No
76 7001230120162 [Semi-finished products] - adapter
plate 8672C,SMT 1.000000 No
77 0502010200053 Horizontal FPC socket 6P, 0.5mm, non-broken plate, rear clamshell, dual access,
single row, SMD, Halogen / FPC0509-06R-TAG / Zhiyong 1.000000 No
78 0226010020602 PCB circuit boards 8672C,V2.0,2014.04.18,Halogen 1.000000 No
79 0201060220010 Photoelectric Sensor IC LTR-559ALS-01,DFN-8-APDS,SMD,No Halogen/LITE-ON 1.000000 No
80 SMBD70232000
8[Semi-finished products] - Motherboard SMB-D7023 motherboard 8671C, DIP without a single with a gravity sensor 8G INAND 1G DDR3L MT8382V/WA with
distance sensor with WCDMA (900MHz/2100MHz) 3G 8671C,
vibration motor V3.0 with front 0.3MP + rear 2MP Apple
headphones standard Linkage BT7002AWX-AALV
1.000000 No

81 SMBD70233000
8[Semi-finished products] - Motherboard SMB-D7023 motherboard 8671C, SMT without a single with a gravity sensor 8G INAND 1G DDR3L MT8382V/WA with
distance sensor with WCDMA (900MHz/2100MHz) 3G 8671C,
vibration motor V3.0 with front 0.3MP + rear 2MP Apple
headphones standard Linkage BT7002AWX-AALV
1.000000 No
82 0991410020149 Board functional components SMB-D7023 motherboard 8671C, sharing materials SMT 1.000000 No
83 0210050200202 Chip ordinary resistors 0201,0R,1/20W,J,SMD/RC0201JR-070RL/YAGEO/RC-
01W000JT/Fenghua Hi-Tech 8.000000 null No
84 0210050220065 Chip ordinary resistors 0201,1.5K,1/20W,F,SMD/RC0201FR-071K5L/YAGEO 4.000000 No
85 0210050200192 Chip ordinary resistors 0201,100K,1/20W,J,SMD/RC0201JR-07100KL/YAGEO 4.000000 No
86 0210050200211 Chip ordinary resistors 0201,100R,1/20W,J,SMD 3.000000 No
87 0210050200193 Chip ordinary resistors 0201,10K,1/20W,J,SMD/RC0201JR-0710KL/YAGEO ######## No
88 0210050200214 Chip ordinary resistors 0201,1K,1/20W,F,SMD 6.000000 No
89 0210050200248 Chip ordinary resistors 0201,1K,1/20W,J,SMD/RC0201JR-0701KL/YAGEO 1.000000 No
90 0210050200206 Chip ordinary resistors 0201,27R,1/20W,J,SMD/RC0201JR-0727RL/YAGEO/RC-
01W27RFT/Fenghua Hi-Tech 1.000000 No
91 0210050200308 Chip ordinary resistors 0201,3.3K,1/20W,J,SMD/RC0201JR-073K3L/YAGEO/RC-
01W332JT/Fenghua Hi-Tech 1.000000 No
92 0210050200207 Chip ordinary resistors 0201,33R,1/20W,J,SMD/RC0201JR-0733RL/YAGEO/RC-
01W33RJT/Fenghua Hi-Tech 1.000000 No
93 0210050200219 Chip ordinary resistors 0201,4.7K,1/20W,J,SMD/RC0201JR-074K7L/YAGEO/RC-
01W472JT/Fenghua Hi-Tech 6.000000 No
94 0210050200228 Chip ordinary resistors 0201,470K,1/20W,J,SMD/RC0201JR-07470KL/YAGEO/RC-
01W474JT/Fenghua Hi-Tech 2.000000 No
95 0210050220062 Chip ordinary resistors 0201,470R,1/20W,J,SMD/RC0201JR-07470RL/YAGEO/RC-
01W471JT/Fenghua Hi-Tech/CR0201J0471T/Huaxin 2.000000 No
96 0210050200224 Chip ordinary resistors 0201,47K,1/20W,J,SMD/RC0201JR-0747KL/YAGEO/RC-
01W473JT/Fenghua Hi-Tech 1.000000 No
97 0210050200341 Chip ordinary resistors 0201,5.1K,1/20W,F,SMD/RC0201FR-075K1L/YAGEO/RC-
01W512FT/Fenghua Hi-Tech 1.000000 No
98 0210050200225 Chip ordinary resistors 0201,56K,1/20W,J,SMD/RC0201JR-0756KL/YAGEO/RC-
01W563JT/Fenghua Hi-Tech 2.000000 No
99 0210050220129 Chip ordinary resistors 0201,56R,1/20W,F,SMD/RC01W56RFT/Fenghua Hi-
Tech/RC0201FR-0756RRL/YAGEO/CR0201F56R0T/Aijiani 1.000000 No
100 0210050220064 Chip ordinary resistors 0201,8.06K,1/20W,F,SMD/RC0201FR-078K06L/YAGEO 2.000000 No
101 0210050200065 Chip ordinary resistors 0402,0R,1/16W,J,SMD 4.000000 null No
102 0210050220121 Chip ordinary resistors 0201,16.9K,1/20W,F,SMD/RC0201FR-0716K9L/YAGEO 1.000000 No
103 0210050200301 Chip ordinary resistors 0201,20K,1/20W,F,SMD 1.000000 No
104 0210050200212 Chip ordinary resistors 0201,240R,1/20W,F,SMD/RC0201FR-07240RL/YAGEO/RC-
01W241FT/Fenghua Hi-Tech 2.000000 No
105 0210050220125 Chip ordinary resistors 0201,27K,1/20W,F,SMD/RC0201FR-0727KL/YAGEO/RC-
01W273FT/Fenghua Hi-Tech/CR0201F0273T/Huaxin 2.000000 null No
106 0210050200362 Chip ordinary resistors 0201,330K,1/20W,F,SMD/RC0201FR-07330KL/YAGEO/RC-
01W334FT/Fenghua Hi-Tech 1.000000 No
107 0210050200313 Chip ordinary resistors 0201,39K,1/20W,F,SMD/RC0201FR-0739KL/YAGEO/RC-
01W393FT/Fenghua Hi-Tech 3.000000 null No
108 0210050299458 Chip ordinary resistors 0805,2R,1/8W,F,SMD 1.000000 No
109 0210050200300 Chip ordinary resistors 0201,20K,1/20W,J,SMD 2.000000 No
110 0210050200252 Chip ordinary resistors 0201,2.49K,1/20W,F,SMD 1.000000 No
111 0210050200243 Chip ordinary resistors 0201,62K,1/20W,F,SMD 1.000000 No
112 0209030000005 SMD potentiometer EVM2GSX80B13,1K,L2.81*W2.2*H0.85,SMD 1.000000 No
112 0209030000002 SMD potentiometer EVM2NSX80B13,1K,L2.81*W2.2*H0.81,SMD 1.000000 Yes
113 0208080200101 SMD ceramic capacitors 0201,100PF,25V,COG,0.3mm,J,SMD 6.000000 No
114 0208080200087 SMD ceramic capacitors 0201,102,25V,X5R,0.3mm,K,SMD 3.000000 No
115 0208080200098 SMD ceramic capacitors 0201,103,10V,X7R,0.3mm,K,SMD 1.000000 No
116 0208080200062 SMD ceramic capacitors 0201,104,6.3V,X5R,0.3mm(Max.),K,SMD ######## No
117 0208080220030 SMD ceramic capacitors 0201,150pF,25V,0.3mm,K,SMD 1.000000 No
118 0208080200119 SMD ceramic capacitors 0201,15pF,25V,COG,0.3mm,J,SMD 1.000000 No
119 0208080200107 SMD ceramic capacitors 0201,18pF,25V,COG,0.3mm,J,SMD 4.000000 No
120 0208080220048 SMD ceramic capacitors 0201,220pF,25V,X7R,0.3mm,K,SMD/CC0201KRX7R8BB221/
YAGEO 1.000000 No
121 0208080200091 SMD ceramic capacitors 0201,223,6.3V,X5R,0.3mm,K,SMD/CC0201KRX5R5BB223/Y
AGEO/C0603X5R0J223KT00NN/TDK 2.000000 No
122 0208080200085 SMD ceramic capacitors 0201,33pF,25V,COG,0.3mm,J,SMD 8.000000 No
123 0208080200088 SMD ceramic capacitors 0201,472,10V,X7R,0.3mm,K,SMD 1.000000 No
124 0208080200104 SMD ceramic capacitors 0201,680PF,25V,X7R,0.3mm,K,SMD 1.000000 No
125 0208080200108 SMD ceramic capacitors 0402,104,25V,X5R,0.55mm,K,SMD ######## null No
126 0208080200014 SMD ceramic capacitors 0402,1uF,10V,X5R,0.55mm(Max.),K,SMD ######## null No
127 0208080299932 SMD ceramic capacitors 0402,2.2uF,6.3V,X5R,0.5mm,M,SMD/CC0402MRX5R5BB225
/YAGEO ######## No
128 0208080200150 SMD ceramic capacitors 0402,4.7uF,6.3V,X5R,0.5mm,M,SMD/CC0402MRX5R5BB475
/YAGEO ######## No
129 0208080299908 SMD ceramic capacitors 0402,473,50V,X7R,NA,K,SMD 1.000000 No
130 0208080299880 SMD ceramic capacitors 0603,104,50V,X7R,NA,K,SMD 2.000000 No
131 0208080200148 SMD ceramic capacitors 0603,105,25V,X5R,0.8mm,K,SMD 4.000000 No
132 0208080220044 SMD ceramic capacitors 0603,106,10V,X5R,0.9mm(Max.),M,SMD/CT41-
0603B106M100NT/holder 1.000000 No
133 0208080299874 SMD ceramic capacitors 0603,10uF,6.3V,X5R,NA,M,SMD ######## No
134 0208080220032 SMD ceramic capacitors 0603,225,16V,X5R,0.9mm(Max.),K,SMD 2.000000 No

135 0208080200106 SMD ceramic capacitors 0603,22uF,6.3V,X5R,0.8mm,M,SMD/CC0603MRX5R5BB226/
YAGEO 3.000000 No
136 0208080299812 SMD ceramic capacitors 0603,4.7uF,16V,X7R,NA,K,SMD 1.000000 No
137 0208080299777 SMD ceramic capacitors 0805,10uF,16V,X7R,1.25mm(Max.),K,SMD 2.000000 No
138 0208080299739 SMD ceramic capacitors 0805,4.7uF,25V,X7R,1.25mm(Max.),M,SMD 2.000000 No
139 0207080020003 Stacked Chip Inductor 0201,7.5nH,-5%~+5%,300mA,14@500MHz,SMD 1.000000 No
139 0207080020018 Stacked Chip Inductor 0201,7.5nH,-
5%~+5%,200mA,13@500MHz,SMD/SDCL0603Q7N5JT02/Su
nlord
1.000000 Yes
140 0207080000011 Stacked Chip Inductor 0402,82nH,-5%~+5%,200mA,8@100MHz,SMD 2.000000 No
141 0207030020014 H inductance HPC4018B-100M,L4*W4*H1.8,10uH,-
20%~+20%,1.2A,SMD/TaiQing 2.000000 No
142 0207030020038 H inductance VLS252010MNT-2R2M,L2.5*W2*H1.0,2.2uH,-
20%~+20%,1.6A,SMD/TDK 1.000000 No
142 0207030000176 H inductance LVF252A12-2R2M-N,L2.5*W2*H1.2,2.2uH,-
20%~+20%,1.8A,SMD 1.000000 Yes
143 0207040220002 High-frequency common mode
inductance DLP0NSN900HL2L,90R@100MHz,SMD 5.000000 No
144 0205040020000 Ordinary beads 0402,600R,300mA,SMD 1.000000 No
145 0205040099986 Ordinary beads 0603,50R,3A,SMD 1.000000 No
146 0205010020001 PB Beads BLM15HD102SN1,0402,1000R@100MHz&2000R@1Ghz,25
0mA,SMD 5.000000 No
147 0205010099969 PB Beads NA,0603,220R,2A,SMD 3.000000 null No
148 0210080099998 Varistor AVLC 5S 02 100,0402,100pF,5.5V,SMD 6.000000 No
149 0210080000014 Varistor ES0402V014BT-MP,0402,0.25pF,14V,SMD ######## null No
150 0211060299995 Catamaran ordinary diode BAT54S,30V,0.2A,SOT-23,SMD(No Halogen) 2.000000 No
151 0211090100003 Monomer Schottky diode 1N5819HW,40V,1A,SOD-123,SMD 2.000000 No
152 0204010099978 N-channel FET 2SK3541,100mA,30V,VMT3,SMD 1.000000 No
153 0204020099980 P-channel FET IT2305B,2.8A,20V,SOT-23,SMD 1.000000 No
154 0211080000022 Zener diode PZ3D4V2H,5.1V,-10%~+10%,5mA,SOD323,SMD/Presemi 1.000000 No
155 0218010020010 Passive crystal 7M26000028,26.000MHz,-
10PPM~+10PPM,4P,L3.2*W2.5*H0.7,SMD/TXC 1.000000 No
156 0218010099944 Passive crystal FC-135,32.768KHz,-
20PPM~+20PPM,2P,L3.2*W1.5*H0.8,SMD 1.000000 No
157 0218020000035 Active crystal 7L26002009,26.000MHz,-
0.5PPM~+0.5PPM,1.70V~3.30V,SMD/TXC 1.000000 No
158 0225000099980 Passive filters SAFEB1G57KE0F00,Surface Acoustic,1411,SMD/Murata 1.000000 No
159 0201170220000 RF amplifier IC BGU7005,XSOU6,SMD/NXP 1.000000 No
160 0502220020000 Coaxial socket C168-JL-1663,MHF3,Without switch, vertical,SMD 1.000000 No
161 0502110000015 Conventional socket SUR0.8-2A,Single row, horizontal,SMD 3.000000 null No
162 0502010200038 Horizontal FPC socket 39P,0.3mm,Non-breaking plate, front clamshell, then under,
double row,SMD/FH26-39S-0.3SHW(05)/HRS 1.000000 No
163 0502010220001 Horizontal FPC socket 25P,0.3mm,Non-breaking plate, clamshell, then under, double
row,SMD 1.000000 No
164 0502010220006 Horizontal FPC socket 41P,0.3mm,Non-breaking plate, front clamshell, then under,
double row, SMD / Zhiyong 1.000000 No
165 0502110020012 Conventional socket MH1.25-5A,Single row, horizontal, SMD / Xin Technology 1.000000 No
166 0505030099999 Micro SD card connector 01780000.BG,Board type, can pop up with a card detection,
SMD 1.000000 No
167 0201360320006 Video Converter IC MT8193,LVFBGA150,SMD/MTK 1.000000 No
168 0201170120005 Analog audio power amplifier IC AW8736FCR,FC-16,SMD 1.000000 No
169 0201040120000 Non-linear charge management
IC BQ24196RGER,QFN24,SMD 1.000000 No
170 0201150020004 Modulator & Demodulator IC MT6627N/A,QFN,SMD/MTK 1.000000 No
171 0201050120002 Capacitive touch control IC GT911,QFN52,SMD 1.000000 No
172 0201120320003 PMU Power IC MT6323GA/A,VFBGA-145L,SMD/MTK 1.000000 No
173 0201120299973 Built-in DC-DC power MOS IC MP1540,SOT-23-5,SMD(No Halogen) 1.000000 No
174 0201120220006 Built-in DC-DC power MOS IC SYQ201ABC,SOT-23-6,SMD 1.000000 No
175 0201310220015 Not adjustable LDO Regulator IC TLV70233DSE,SON-6,SMD/TI 1.000000 No
176 0201310220014 Not adjustable LDO Regulator IC TLV70012DSE,SON-6,SMD/TI 1.000000 No
177 0617160020101 Shield Hardware SMBD7023-PT03,GPS+WiFi Shield, 0.2mm tin plate 1.000000 No
178 0230010000002 Shield mounts ICSRC5210SFR,L5.2*W1.0*H1.3,SMD 7.000000 No
179 0207030020035 H inductance VLS252010MNT-R68N,L2.5*W2*H1.0,0.68uH,-
30%~+30%,3.0A,SMD/TDK 1.000000 No
180 0211010020007 TVS Diodes ESD7951ST5G,5.0V,150mW,Two-way,SOD923,SMD/ON 2.000000 null No
181 0201420020017 Diplexer IC RFDIP1608060TM7T62,L1.6*W0.8*H0.6,SMD/Huaxin
Technology 1.000000 No
182 0210050220034 Chip ordinary resistors 0201,154K,1/20W,F,SMD 1.000000 No
183 0210050220144 Chip ordinary resistors 0201,2.7K,1/20W,F,SMD,No Halogen/RC0201FR-
072K7L/YAGEO/RC-01W272FT/Huaxin Technology 1.000000 No
184 0210050200239 Chip ordinary resistors 0201,7.5K,1/20W,F,SMD 1.000000 No
185 0210050299764 Chip ordinary resistors 0603,0R,1/10W,J,SMD/RC0603JR-
070RL/YAGEO/CR0603J0000T/Thick sound/RS-
03000JT/Huaxin Technolo
gy
1.000000 No
186 0210050299598 Chip ordinary resistors 0603,470R,1/10W,J,SMD 1.000000 No
187 0502010220029 Horizontal FPC socket 4P, 0.5mm, non-broken plate, clamshell, dual access, single
row, SMD (Zhiyong) 1.000000 No
188 0226010020634 PCB circuit boards 8671C,V3.0,2014.05.14,Halogen 1.000000 No
189 0617160020155 Shield Hardware SMBD7023-PT05, power shield, 0.2 tin plate - no film, SMD,
Tape, NR 1.000000 No

190 0207030020054 H inductance VLS252010HBX-R68M,L2.5*W2*H1.0,0.68uH,-
20%~+20%,4.17A,SMD,No Halogen/TDK 1.000000 null No
190 0207030020050 H inductance VLS252010HBT-R68M-LR,L2.5*W2*H1.0,0.68uH,-
20%~+20%,3.2A,SMD/TDK 1.000000 Yes
191 0205040000022 Ordinary beads 0402,120R,300mA,SMD 2.000000 No
192 0210050220134 Chip ordinary resistors 0201,270R,1/20W,F,SMD,No Haloge/RC0201FR-
07270RL/YAGEO/RC-01W271FT/Fenghua Hi-Tech 1.000000 No
193 0207030020026 H inductance HPC4018B-2R2M,L4*W4*H1.8,2.2uH,-
20%~+20%,2.2A,SMD/TaiQing 1.000000 No
194 0991010320180 WCDMA3G functional
components SMB-D7023 Mainboard 8671C,With WCDMA(900MHz/2100MHz)3G function SMT 1.000000 No
195 0208080200101 SMD ceramic capacitors 0201,100PF,25V,COG,0.3mm,J,SMD 2.000000 No
196 0208080200107 SMD ceramic capacitors 0201,18pF,25V,COG,0.3mm,J,SMD 2.000000 No
197 0208080220049 SMD ceramic capacitors 0201,39pF,25V,NPO,0.3mm,J,SMD/CC0201JRNPO8BN390/
YAGEO 1.000000 null No
198 0208080200100 SMD ceramic capacitors 0201,4.7pF,25V,COG,0.3mm,C,SMD 2.000000 No
199 0208080200086 SMD ceramic capacitors 0201,56pF,25V,COG,0.3mm,J,SMD 2.000000 No
200 0208080200062 SMD ceramic capacitors 0201,104,6.3V,X5R,0.3mm(Max.),K,SMD 2.000000 No
201 0208080200108 SMD ceramic capacitors 0402,104,25V,X5R,0.55mm,K,SMD 2.000000 No
202 0208080299951 SMD ceramic capacitors 0402,152,50V,X7R,NA,K,SMD 2.000000 No
203 0208080200014 SMD ceramic capacitors 0402,1uF,10V,X5R,0.55mm(Max.),K,SMD 5.000000 No
204 0208080200083 SMD ceramic capacitors 0201,22pF,25V,COG,0.3mm,J,SMD 4.000000 No
205 0208080200085 SMD ceramic capacitors 0201,33pF,25V,COG,0.3mm,J,SMD 1.000000 No
206 0208080299920 SMD ceramic capacitors 0402,39pF,50V,NPO,NA,J,SMD 1.000000 No
207 0208080220048 SMD ceramic capacitors 0201,220pF,25V,X7R,0.3mm,K,SMD/CC0201KRX7R8BB221/
YAGEO 1.000000 No
208 0208080200094 SMD ceramic capacitors 0201,474,6.3V,X5R,0.3mm,M,SMD/CC0201MRX5R5BB474/Y
AGEO/C0603X5R0J474MT00NE/TDK/JMK063BJ474MP-
F/TAIYO YUDEN
6.000000 No
209 0208080299932 SMD ceramic capacitors 0402,2.2uF,6.3V,X5R,0.5mm,M,SMD/CC0402MRX5R5BB225
/YAGEO 1.000000 No
210 0208080200106 SMD ceramic capacitors 0603,22uF,6.3V,X5R,0.8mm,M,SMD/CC0603MRX5R5BB226/
YAGEO 1.000000 No
211 0210050200202 Chip ordinary resistors 0201,0R,1/20W,J,SMD/RC0201JR-070RL/YAGEO/RC-
01W000JT/Fenghua Hi-Tech 2.000000 No
212 0210050200206 Chip ordinary resistors 0201,27R,1/20W,J,SMD/RC0201JR-0727RL/YAGEO/RC-
01W27RFT/Fenghua Hi-Tech 2.000000 No
213 0210050200249 Chip ordinary resistors 0201,34.8R,1/20W,F,SMD 1.000000 No
214 0210050200250 Chip ordinary resistors 0201,51R,1/20W,F,SMD 1.000000 No
215 0210050200214 Chip ordinary resistors 0201,1K,1/20W,F,SMD 4.000000 No
216 0210050220060 Chip ordinary resistors 0201,2K,1/20W,F,SMD/RC0201FR-072KL/YAGEO 1.000000 No
217 0210050200244 Chip ordinary resistors 0201,10K,1/20W,F,SMD 1.000000 No
218 0210050200363 Chip ordinary resistors 0201,24K,1/20W,F,SMD 1.000000 No
219 0210050200065 Chip ordinary resistors 0402,0R,1/16W,J,SMD 2.000000 No
220 0210080000014 Varistor ES0402V014BT-MP,0402,0.25pF,14V,SMD 3.000000 No
221 0207080000056 Stacked Chip Inductor 0201,18nH,-5%~+5%,160mA,14@500MHz,SMD 1.000000 No
222 0207080000053 Stacked Chip Inductor 0201,2.2nH,-0.2nH~+0.2nH,600mA,14@500MHz,SMD 4.000000 No
223 0207080020043 Stacked Chip Inductor 0201,2nH,-
0.3nH~+0.3nH,380mA,4@100MHz,SMD/HK06032NOS-
T/TAIYO
2.000000 null No
224 0207080000055 Stacked Chip Inductor 0201,4.7nH,-0.3nH~+0.3nH,350mA,14@500MHz,SMD 2.000000 null No
225 0207080000029 Stacked Chip Inductor 0201,1.5nH,-0.3nH~+0.3nH,430mA,6@100MHz,SMD 2.000000 No
226 0207080000033 Stacked Chip Inductor 0201,5.6nH,-0.3nH~+0.3nH,260mA,7@100MHz,SMD 1.000000 No
227 0207080000057 Stacked Chip Inductor 0201,33nH,-5%~+5%,130mA,10@500MHz,SMD 1.000000 No
228 0207080020006 Stacked Chip Inductor 0201,39nH,-
5%~5%,120mA,10@300MHz,SMD/MLG0603P39NJT/TDK 1.000000 No
229 0207080000061 Stacked Chip Inductor 0201,10nH,-5%~+5%,250mA,10@500MHz,SMD 2.000000 No
230 0201420020005 Diplexer IC SAYRF1G95HQ0F0A,L2.0*W1.6*H0.6,SMD/Murata 1.000000 No
231 0201170200005 RF amplifier IC RF7241,RF7241DS,SMD 1.000000 No
232 0201170200007 RF amplifier IC RF7248,RF7248DS,SDM 1.000000 No
233 0225000020019 Passive filters RFBLN2012090BM5T25,MLC,2.0*1.2*0.9,SMD/PSA 1.000000 No
234 0201150020005 Modulator & Demodulator IC MT6166V/A,TFBGA,SMD/MTK 1.000000 No
235 0201170220010 RF amplifier IC SKY77589,6*6*0.9mm,SMD/SKYWORKS 1.000000 No
236 0218010020010 Passive crystal 7M26000028,26.000MHz,-
10PPM~+10PPM,4P,L3.2*W2.5*H0.7,SMD/TXC 1.000000 No
236 0218010020016 Passive crystal X3S026000B71HZ-HPR,26.000MHz,-
10PPM~+10PPM,4P,L3.2*W2.5*H0.65,SMD/Heightening 1.000000 Yes
237 0502220020000 Coaxial socket C168-JL-1663,MHF3,Without switch, vertical,SMD 1.000000 No
238 0502220099989 Coaxial socket MM8430-2610RB3,I-PEX,With switch, vertical,SMD 1.000000 No
239 0505080020007 SIM card SF58S006VBA,Pop-up,SMD/JAE 1.000000 No
240 0617160020083 Shield Hardware SPD4501-PT08, RF shield bracket, 0.15mm copper-nickel
alloy Yang 1.000000 No
241 0201420020009 Diplexer IC SAYFH897MHC0F0A,L2.0*W1.6*H0.6,SMD/Murata 1.000000 No
242 0207080020008 Stacked Chip Inductor 0201,12nH,-
3%~+3%,180mA,14@500MHz,SMD/MLG0603P12NHT/TDK 1.000000 null No
243 0208080200154 SMD ceramic capacitors 0201,8.2pF,25V,C0G,0.3mm,C,SMD 1.000000 No
244 0207080020052 Stacked Chip Inductor 0201,15nH,-
5%~+5%,250mA,14@500MHz,SMD/MLG0603P15NJTZ10/T
DK
1.000000 No
245 0208080200138 SMD ceramic capacitors 0201,5.6pF,25V,COG,0.3mm,C,SMD 1.000000 No
246 0208080200157 SMD ceramic capacitors 0201,2.2pF,25V,C0G,0.3mm,B,SMD 1.000000 No

247 0208080220097 SMD ceramic capacitors 0201,7.5pF,25V,NP0,0.3mm,D,SMD/CC0201DRNP08BN7R5/
YAGEO/0201N7R5D250CT/Huaxin/0201CG7R5D250NT/Fen
g
hua Hi-Tech
1.000000 No
248 0207080020021 Stacked Chip Inductor 0201,9.1nH,-5%~+5%,170mA,13@500MHz, SMD/
SDCL0603Q9N1JT02/Sunlord 1.000000 No
249 0991730020001 Sensing functional components SMB-D7023 motherboard 8671C, light sensor + distance
sensor function configuration SMT 1.000000 No
250 0210050299925 Chip ordinary resistors 0402,22R,1/16W,J,SMD 1.000000 No
251 0208080200014 SMD ceramic capacitors 0402,1uF,10V,X5R,0.55mm(Max.),K,SMD 2.000000 No
252 0502010200053 Horizontal FPC socket 6P, 0.5mm, non-broken plate, rear clamshell, dual access,
single row, SMD, No Halogen / FPC0509-06R-TAG / Zhiyong 1.000000 No
253 0991190020095 CPU frequency functional
components SMB-D7023 Mainboard 8671C,with MT8382V/WA CPU function SMT 1.000000 No
254 0201260220030 CPU controller IC MT8382V/W,MT8382V/W,FCCSP475,SMD/MEDIATEK 1.000000 No
255 0991040020141 DDR functional components SMB-D7023 Mainboard 8671C,with1G DDR3L SMT 1.000000 No
256 0201071220016 DDR3 SDRAM memory IC D5128EETBPGGBU,FBGA78,SMD/Kingston 2.000000 No
257 0991110020272 Memory function components SMB-D7023 Mainboard 8671C,with 8G eMMC SMT 1.000000 No
258 0201070520022 INAND FLASH memory IC eMMC08G-S100,FBGA153,SMD,No Halogen/Kingston 1.000000 No
259 0991060020064 Gravity sensor assembly SMB-D7023 Mainboard 8671C,With a gravity sensor SMT 1.000000 No
260 0208080200062 SMD ceramic capacitors 0201,104,6.3V,X5R,0.3mm(Max.),K,SMD 2.000000 No
261 0201060300015 Acceleration sensor IC BMA250E,LGA-12,SMD/BOSCH 1.000000 No
262 空1.000000 No
263 0991260020047 Motor functional components SMB-D7023 Mainboard 8671C,Motor Function Deployment
SMT 1.000000 No
264 0208080200014 SMD ceramic capacitors 0402,1uF,10V,X5R,0.55mm(Max.),K,SMD 1.000000 No
265 0211090120003 Monomer Schottky diode RB521CS-30,30V,100mA,SOD-923,SMD/ROHM 1.000000 null No
265 0211090120009 Monomer Schottky diode RB521C30-2/TR,30V,100mA,SOD-923,SMD,No Halogen/Will 1.000000 Yes
266 0502110000015 Conventional socket SUR0.8-2A,Single row, horizontal,SMD 1.000000 No
267 0991160020178 Functional components of the
camera SMB-D7023 motherboard 8671C,front 0.3M(2M)/front 0.3M+rear 2M Function Deployment SMT 1.000000 No
268 0208080200014 SMD ceramic capacitors 0402,1uF,10V,X5R,0.55mm(Max.),K,SMD 3.000000 No
269 0208080200062 SMD ceramic capacitors 0201,104,6.3V,X5R,0.3mm(Max.),K,SMD 3.000000 No
270 0502320020011 Board To Board Connector
Receptacle GY071S-24P, 24P, 0.4mm, female, SMD (Zhiyong) 1.000000 No
271 0991670020064 Headset standard functional
components SMB-D7023 motherboard 8671C, CTIA (Apple) headset standard SMT 1.000000 No
272 0210050200202 Chip ordinary resistors 0201,0R,1/20W,J,SMD/RC0201JR-070RL/YAGEO/RC-
01W000JT/Fenghua Hi-Tech 2.000000 No
273 0991090020163 LCD screen functional
components SMB-D7023 motherboard 8671C, with a joint creation BT7002AWX-AALV LCD screen configuration 1.000000 No
274 0991010320195 WCDMA3G functional
components SMB-D7023 motherboard 8671C, WCDMA3G functional configuration DIP 1.000000 No
275 0617160020082 Shield Hardware SPD4501-PT09, RF shield, 0.2mm stainless steel 1.000000 No
276 0991410020150 Board functional components SMB-D7023, motherboard 8671C, sharing materials DIP 1.000000 No
277 0311020020033 Shaped insulating pad SMBD7023-H03, the main shield insulation pads, single
ordinary plastic, black 1.000000 Mounted inside the main shield No
278 0617160020100 Shield Hardware SMBD7023-PT04,Main shield 0.2 tin plate 1.000000 No
279 7001230120164 [Semi-finished products] - adapter
plate 8674C(With Hall features) 1.000000 No
280 0502010220001 Horizontal FPC socket 25P,0.3mm,Non-breaking plate, clamshell, then under, double
row,SMD 1.000000 No
281 0502030020014 Micro USB socket DX4R005JJE, non-breaking flat plate, being posted, SMD /
JAE 1.000000 No
282 0502230820027 Headphone jack audio and video NJP402-103T, D3.5, 3-channel, with a switch, on-board flat,
horizontal, SMD / Majestic 1.000000 No
283 0201060199997 MR sensor IC OCH168TWAD,SOT23,SMD 1.000000 No
284 0207040200003 High-frequency common mode
inductance ICMEF112P900MFR,90R@100MHz,SMD 1.000000 No
285 0210080000014 Varistor ES0402V014BT-MP,0402,0.25pF,14V,SMD 2.000000 No
286 0208080299968 SMD ceramic capacitors 0402,102,50V,NPO,NA,J,SMD 1.000000 No
287 0208080200108 SMD ceramic capacitors 0402,104,25V,X5R,0.55mm,K,SMD 1.000000 No
288 0226010020603 PCB circuit boards 8674C,V3.0,2014.04.18,Halogen 1.000000 No
289 bare 1.000000 No
290 0991260020050 Motor functional components SMB-D7023,With vibration motor function configuration 1.000000 No
291 0221020020034 DC motors LCM-0827A2038F(90mm length with terminal +0.2 mm foam),
do not specify the / LCM-0827A2038F / Synaptic Micro 1.000000 No
292 0226020120106 Irregular flexible circuit board 8692C,V1.0,2013.11.08 1.000000 No
293 0226020120105 Irregular flexible circuit board 8693C,V1.0,2013.11.07 1.000000 No
294 0227000020067 Speaker MA1813-D7023-SPKBOX-G ,0.7W,8R,L41.7*W29*H3.2,With
SUR0.8-2Y-B35mm twisted black and red 1.000000 No
295 0227000020068 Speaker MA1206RC2332-RW-
B01,20mW,32R,32R,L12*W6.0*H2.3,With SUR0.8-2Y-45mm
black and red strands
/
Xin AAC
1.000000 No
296 0991010320259 WCDMA3G functional
components SMB-D7023, with WCDMA (900MHz/2100MHz) 3G functionality 1.000000 No
297 0224010020267 Built-in passive antenna N18-0557-R0A,FPC,824MHz~2170MHz,leader line I-PEX
D0.81*L78,No Halogen / South Douxing 1.000000 No
298 0991150020210 EMI countermeasure functional
components SMB-D7023,Import EMI countermeasure configuration 1.000000 No
299 0304010020078 Rules conductive foam NR, full-conductive, single-sided adhesive, 18 * 7 * 1.0mm,
NR, halogen / F2014043001 / Fa Side 1.000000 No

300 0304010020076 Rules conductive foam NR, full-conductive, single-sided adhesive, 8 * 4 * 1.0mm, NR,
halogen / F2014042901 / Fa Side 4.000000 No
301 0303010020002 Rules conductive foam Plain, two-sided conductive, single-sided adhesive, adhesive
conductive, 30 * 55mm, NR 1.000000 No
302 0226020120179 Irregular flexible circuit board 8690C,V2.0.2014.04.18,Halogen 1.000000 No
303 0226020120181 Irregular flexible circuit board 8689C,V2.0,2014.04.22,Halogen 1.000000 No
304 0228000020033 Electret receiver KRB4015RCCJL85J-623-R,D4.0*H1.5,with SUR0.8-2P-85mm
Red and black, halogen / Linda Lake 1.000000 No
305 0224010020266 Built-in passive antenna N14-0330-R0A,FPC,1575.42MHz~2500MHz,leader line I-PEX
D0.81*L155,No Halogen / South Douxing 1.000000 No

2Overview

System Physical Standard Configuration/系统基本物理参数:
Type/类型 Details/详细规格 Descriptions/说明
Product Form/
产品样式
Product Form/产品样式 Portrait or Landscape
Material ABS+PC，ABS，AL1050 (with
brush)
Control elements/HW
buttons Power,Vol-,Vol+
Dimensions(H*W*D) 190*119*8.8mm
Weight TBD
LCD/显示屏幕
Type/屏幕材质 IPS
Screen Size/屏幕尺寸 7"
Screen Resolution/屏幕分
辨率 800×1280
Aspect ratio/长宽比 16:10
DPI/每英寸点数 215 dpi
Maximum brightness and
contrast
300cd/m2(typical value); contrast
800:1
Colors/色彩 16.7M
TP/触控面板
Touch Module/触控类型 Capacitive
Numbers of Touch
Points(Multi-Touch)/支持
触摸点数
5dot
Battery/电池
Type/类型 Li-polymer
Capacity/容量 3500mAh
Minimum stand-by time,
hour 200 hours
Minimum talk time 2G,
min 4hours
Minimum talk time 3G,
min 4hours
Minimum time video
playback HD, min 4hours
Minimum time in Audio
playback, min 8hours
Minimum Internet surfing
time 4hours
System hardware configuration/系统硬件配置:
Type/类型 Details/详细规格 Descriptions/说明
Chipset/芯片组 Vendor/供应商 MTK
Chipset/芯片型号 MT8382

CPU Type/型号 Cortex A7/ Quad core
Frequency/频率 1.3 GHz
Manufacture ARM
GPU
Renderer/渲染率 53.25M Δ/s 1000MP/s
Frequency/频率 500MHz
OpenGL OPENGL ES2.0
Core Dual
Multi-media
(Hardware
encoding/decodi
ng)/多媒体
（硬件编码/解
码）
Phote Viewer/图片浏览格
式BMP, JPG, GIF, PNG
Video Format/视频支持格
式
Decoding: VP8,MPEG-
4,H.263,H.264
Encoding:H.263
Audio Format/音频支持格
式
Decoding:APE,FLAC,MP3,WAV,MP2
,AMR,VDRBIS
Encoding:AMR
Memory
Type Built-in Memory
and chip
DDR3L（Kingston)，
eMMC(Kingston）
RAM Capacity/容量 1GB
ROM Flash/闪存
Capacity/容量 8GB eMMC
Built-in memory
available for user, MB 5840MB
Camera/相机
Front Camera/前置摄像头 0.3MP
Rear Camera/后置摄像头 2MP
Rear Flash Light/后置闪光
灯N/A
Speaker/扬声器
Size/规格 41.7×29
Support polyphonic ring
(number of tones) N/A
Navigation
Built-in GPS Yes
Built-in GLONASS N/A
Support A-GPS Yes
Sensors
G-Sensor/重力感应器 Yes
Gyro Sensor/陀螺仪 N/A
E-Compass/电子罗盘 N/A
Accelerometer N/A
Proximity Sensor/距离感
应器 Yes
Light Sensor/光线感应器 Yes
FM-Radio FM Receiver, FM
Transmitter FM Receiver
NFC/近场通讯 Built-in No

NFC controller chip No
Special Feature/
其他特性
GPS EPO assistance No
Wireless Charging/无线充
电No
Network Connections/网络连接:
Type/类型 Details/详细规格 Descriptions/说明
2G
Band/网络制式 850/900/1800/1900MHz
GPRS Class12
EDGE EDGE download
3G Band/网络制式 900/2100MHz
HSDPA Uplink 11Mbps,Downlink 42Mbps
4G Band/网络制式 N/A
Technology N/A
WI-FI
WI-FI Module/Wi-Fi 模块 WIFI 802.11b/g/n
Band 2.4GHz
Cryptographic
Algorithms/加密方式
WEP (40-bit、64-bit、128-bit),
WPA (TKIP 128-bit), WPA2 (AES
128-bit)
Max range of wireless
connection/无线连接最大
范围
30m
Wi-Fi Direct/Wi-Fi 点对点
直接连接 Yes
Wi-Fi Display (Miracast) N/A
Bluetooth/蓝牙
Version/版本 Bluetooth V4.0
Cryptographic
Algorithms/加密方式 GFSK,DQPSK,DPSK
Max range of wireless
connection/无线连接最大
范围
10m
Interface Configuration/接口参数:
Type/类型 Details/详细规格 Descriptions/说明
SIM Card
Slot/SIM 卡槽
SIM Card Slot/SIM 卡槽 Yes
Type of Dual SIM (Dual
SIM Stand-by (DSS)/Dual
SIM Active (DSA))
N/A
Switchible Dual-SIM 3G N/A
Standard 6-pin SIM card
interface, supporting the
1.8/3V USIM card
Yes
SIM-cards form factor Support micro SIM

support
Memory card
socket/内存卡插
槽
External Memory Type
Class/可扩展内存 Support SDHC/SDXC,up tp 32GB
SD-card Write Rate SD3.0
SD-card Read Rate SD3.0
USB
Data Transfer Port Type/
数据接口类型 Micro USB 5pin
USB Port Data Transfer
Rate/数据传输速率 USB2.0
USB Host OTG support/
USB, Mous/Keyboard No
Charge/充电
Charge Connecter/充电接
口Micro USB 5pin
Same port with data
transfer port Yes
Charging time 3h
Headset Jack/耳
机插孔
Headphone Jack
Standard
∮3.5mm Iphone/CTIA((APPLE) )
standard headphone jack
Support TRRS
microphone on the
headset headphones
Yes
HDMI
interface/HDMI
接口
Video, Audio Output/视
频输出 N/A
Accessories/附件参数:
Type/类型 Quantity/数量 Descriptions/说明
Travel Charger/
旅行充电器 15V/2A
Power Plugs 2EU/UK
OTG Cable 1(consigned part)
USB Cable 1(consigned part)
Pouch 1(consigned part)
Optional
accessories NA
Software Configuration/软件参数:
Type/类型 Details/详细规格 Descriptions/说明
Operating
System/操作系统 OS Version/系统版本 Andriod 4.4
Schematic Diagram

Printed Circuit
Main board 8761C
A: TOP LAYER
B:L2 LAYER
C: GND3 LAYER

D: L4 LAYER
E: GND5 LAYER
F: L6 LAYER

G:Vcc7LAYER
H:Bottom LAYER

Detailed Circuit
MAIN BOARD
1) MT8382 POWER
2) CPU
