TECHNICAL SERVICE MANUAL

Product Model PMP5588C_DUO
(silk printing on back
cover just for
reference)
System Physical Standard Configuration:
Type Details Descriptions
Chipset Chipset Amlogic AML8726-MXS
CPU Type Dual Core ARM Cortex A9
Frequency 1.5GHz
GPU Renderer Mali 400 MP ( Dual Core)
Frequency 400MHz
OPENGL OPENGL ES2.0
LCD
Type TN
Screen Size 8-inch
Colors 262.144K
Brightness 250cd/m2
Screen Resolution 1280X768 (wide screen)
TP Type Capacitive Multi-Touch (5 points)
Process Etching under yellow light
RAM Capacity 1GB DDR3
ROM Flash Capacity 8G
Battery Type Lithium-ion Polymer Battery
Capacity 3.7V/5000mAH
Battery Life Video Playing 3.5 hours
Multi-media
(Hardware
encoding/decoding)
Phote Viewer BMP, JPG, GIF, PNG
Video Format DAT, MPG, VOB, TS,AVI, MKV, MP4, MOV, 3GP, RM, RMVB,FLV,WEBM,WMV, ASF
Audio Format MP2, MP3,WMA,WAV,APE,OGG, OGA,FLAC,AAC, M4A
Camera Front Camera 0.3MP
Rear Camera N/A
Rear Flash Light N/A
Speaker Size Built-in 8Ω/1W speaker x1
G-Sensor Built-in 3-directions
Gyro Sensor Built-in N/A
GPS Built-in N/A
A-GPS N/A
Compass Built-in N/A
Proximity Sensor Built-in N/A
Light Sensor Built-in N/A
Network Connections:
Type Details Descriptions
2G GPRS N/A
EDGE N/A
3G HSDPA N/A
WI-FI
WI-FI Module WIFI 802.11b/g/n
Cryptographic Algorithms WEP (40-bit, 64-bit, 128-bit), WPA (TKIP 128-bit), WPA2 (AES 128-bit)
Max range of wireless connection 100m without Barrier
Wi-Fi Direct N/A
Bluetooth Version N/A
Cryptographic algorithms N/A
Max range of wireless connection N/A
Interface Configuration:
Type Details Descriptions
SIM Card Slot SIM Card Slot N/A
Memory card socket External Memory Support micro-SDHC/SDXC,up tp 32GB
USB Data Transfer Micro USB 5pin * 1
Charge Charge Connecter 2.5mm DC in, 5v/2A
Headset Jack Music Output ∮3.5mm standard headphone jack
HDMI interface Video Output N/A
Software Confi
g
uration:
Type Details Descriptions
Operating System OS Version Andriod 4.2
Language Multi-language support
GMS N/A

System Software
OTA N/A
HTML5 Support
FLASH Player Support
Email Support
Browser Support
Calculator Support
Calendar Support
Clock Support
Search Support
Gallery Support
Downloads Support
Camera Support
Music Support
MoviePlayer Support
FileBrowser Support
AppInstaller Support
Settings Support
Package and shipping information
Package contents
Prestigio MultiPad 1 pcs
QSG 1 pcs
Legal and Safety Notices Optional
Warranty card Optional
OTG Cable Optional
USB Calbe 1 pcs
Switchable adaptor Power Adapter
EU plug Yes
UK plug Yes
Stickers for after-service Optional
Protective pouch Yes
Shipping information
Device size (mm) 213x138.5x11.2mm(L x W x H) (appro.)
Device wight (g) Approx. 490g
Gift Box Dimension(mm) 235x228x49 mm
Carton Size(mm) 520x250x260 mm
Qty Per Carton(pcs) 10pcs
G.W Per Carton (kg)
Layers Per Pallet
Cartons Per Layer
Weight Per Pallet(kg)

BOM-First level
BOM Type: PMP5588C ( E8-HD Elite) Prestigio Brand black-T870_MXS_V1.3 ROHS
Part No. Description Specification
Q
ty Remark
6.02.03.05.0158R Semifinished unit-Main Board
T870_MXS_V1.3 Semifinished unit(MainBoard) (EMI)(AFA750)_2D_BW-8Gx1+HY-DDR3-
256Mx4+WiFi+FCM+one speaker+battery slot_TL080WX830(24LED)_ROHS 1
6.02.03.05.0092R Semifinished Touch panel PCB MG8698H-3 Semifinished unit RoHS 1
6.02.03.05.0038R Semifinished unit-Button Board T870_KEY Semifinished unit ROHS 1
6.02.03.05.0161R Semifinished unit-Port board T870_CARD_V2.3(EMI) Semifinished unit_RoHS 1
6.03.03.05.0237R Battery BP4362157 DLG-0005 RoHS; processin
g
product 1
6.03.03.05.0238R back cover MID-8D02/back cover-v3.0 JS(black) ABS0215A; processin
g
product 1
1.01.001.00454R Carbon Film Resistors SMD 0402 0
Ω
±5% RoHS 1ForLCDpanel
1.01.058.00434R LCD Panel TL080WX830-
V
5 (T8W05BR24A4000)(8DW4.0mm) RoHS 1 A+ panel
1.01.058.00366R Touch Panel MO8OGGVWMCBYQ-
V
0RoHS 1
1.01.041.00064R Speaker SOD1524Z39-L450501-S0 24*15 8
Ω
1W 3.9H RoHS 1
3.02.018.00341R Camera
V
FGC2717
V
3.0 Camera （8D02 front camera）ROHS 1.000
2.02.000.00253R Wifi antenna S2B1BE4A1B01000 RoHS 1
2.03.000.00077R Film Cable 6P BP0.5 N6 L83 S2.2/2.2/3.2/3.2/225 C0.035*0.3T43A03-H-S-B1 ROHS 1
2.03.000.00078R Film Cable 6P BP0.5 N6 L30 S2.2/2.2/3.2/3.2/225 C0.035*0.3T43A03-H-S-B1 ROHS 2
2.03.000.00085R Film Cable 24P AP0.5 N24 L120 S2.2/2.2/3.2/3.2/225 C0.035*0.3T43A03-H-S-B1 ROHS 1
2.04.000.00235R cable 5146-0400+UL1571-28# -4P L=50mm ROHS 1
3.03.008.00001R front cover MID-8D02 -v3.0(black)ABS RoHS 1
3.02.003.00420R Button MID-8D02/button B-v1.0 GW (black)ABS757+ 666740 RoHS 1
3.02.006.00931R Middle frame MID-8D02/middle frame-v2.0 JS（black）ABS0215A/ 66740 RoHS 1
3.03.013.00002R Motherboard fixed Holder MID-8D02/Motherboard fixed Holder-2-v1.0(black)ABS0215A RoHS 1
3.01.002.00041R Screw(black）JL-PWP1.4*3.5*4DH RoHS 2 Fix the unit-Port board
3.01.002.00042R Screw(White）JL-PWP1.4*2.8*4.0-DBL(white）RoHS 1 Fix the Motherboard Holder
3.01.003.00115R Screw 1.4X5X2.5 ROHS （Tian
j
ian）8 Fix the Motherboard Holder
3.02.018.00370R Anti-dust Mat 8DWAnti-dust MatB-v1.0 Material;DTS4972(black)+0.4 foam; Size:116.5x2.0x0.4mm RoHS 2.000 Stick on the front face of LCD panel's iron frame
3.02.018.00371R Anti-dust Mat 8DWAnti-dust MatC-v1.0 Material;DTS4972(black)+0.4 foam Size:176x2.0x0.4mm RoHS 2.000 Stick on the front face of LCD panel's iron frame
3.02.018.00368R Uf
g
lue huitian 1421 uf
g
lue 50ml/1 unit RoHS 0.034
3.02.018.00372R Double-side Tape MID-8D02-TP Connector board tape-
V
1.0 Material:300SLE Size:24.5x19.5x0.15mm RoHS 1.000
3.02.018.00198R Button Board Double-side Tape MID-8D02 Button Board Double-side Tape-
V
1.0 RoHS 1.000
3.02.018.00107R Anti-dust Circle MID Camera Anti-dust Circle Size:5.6*0.35mm RoHS 1.000
3.02.018.00346R Absorbin
g
material 3K-XB 0.2x43x9mm RoHS 1.000 paste on the film cable for LCD panel
3.02.018.00347R Absorbin
g
material 3K-XB 0.2x14x6mm RoHS 3.000 2pcs for camera, 1pcs for film cable of earphone
3.02.018.00348R Absorbing material 3K-XB 0.2x27x6mm RoHS 2.000 paste on the port cable connect cable
3.02.018.00352R Conductive Spon
g
e Conductive Spon
g
e 5x3.5x4mm RoHS 5.000 Paste on the mainboard and IO panel
3.02.018.00015R Conductive Tape Conductive Tape 10mm ROHS 185
3.02.018.00351R Plain weave conductive sticker 142x55x0.12mm RoHS 1.000
4.02.009.04443R Security Sticker Presti
g
io-E8-HD Elite Security Sticker -
V
1.0 5x5mm RoHS 1.0000 Paste on the position of scew near the PCBA
4.02.009.04444R warterproofin
g
Sticker Presti
g
io-E8-HD Elite warterproofin
g
sticker-
V
1.0 4x4mm RoHS 1.0000 Paste on PCBA
4.01.007.00036R PE ba
g
netural-E8 PE ba
g
-
V
1.1 Size:225x147mm RoHS 1
5.01.000.00245R Sin
g
le PI tape Sin
g
le PI tape 33M/roll 10mm ROHS 150.000000 Fix the film cable
3.02.014.00116R Protection film Presti
g
io-E8-HD Elite protection film-
V
1.0 Size:208x133mm RoHS 1
3.02.018.00337R Conductin
g
strip AML8726-MXS/conductin
g
strip
V
1.0 14X14mm ROHS 1.000
5.02.000.00351R
Y
ellow Adhesive
Y
ellow Adhesive 15KG/Barrel RoHS 0.100000
Page 1

BOM
T
ype: BP4362157 DLG-0005 RoHS; processing product 6.03.03.05.0237R
Part No. Description Specification Qty
1.01.056.00084R Batter BP4362157 DLG-0005 with plug RoHS 1
3.02.018.00349R Aluminium foil aluminium foil size：142x134x0.08mm RoHS 1.000
3.02.018.00353R Double-sided conductive tape Double-sided conductive tape 120x20x0.15mm RoHS 1.000

BOM Type:
MID-8D02/back cover-v3.0 JS(black)
ABS0215A; processing product 6.03.03.05.0238R
Part No. Description Specification Qty
3.02.002.02900R back cover MID-8D02/back cover-v3.0 JS(black)
A
BS0215A 1
3.02.013.01438R Speaker Mesh
PMP8D2016 Speaker Mesh-V1.0 Material;nylon net(with
two side glue) RoHS 1
3.02.018.00320R Conducting strip MID－8D02/Conducting strip-V3.0 105X100mm RoHS 1.000
3.02.018.00350R
A
luminium foil
A
luminium foil size: 141x62x0.08mm RoHS 1.000
3.02.018.00015R Conductive
T
ape Conductive
T
ape width:10mm ROHS 25.000

BOM
T
ype: PMP5588C ( E8-HD Elite) Presti
g
io Brand black-
T
870_MXS_V1.3 ROHS 7.03.05.04.0121R
Part No. Description Specification
Q
ty Remark
6.03.03.05.0212R PMP5588 PMP5588C ( E8-HD Elite) Presti
g
io Brand black-
T
870_MXS_V1.3 ROHS 1
6.03.04.01.0648R Power adapter 5V2A power adapter HND050200X DC：2.5X0.7X10MM ROHS 1
2.02.000.00297R USB cable MICRO USB cable with ma
g
net rin
g
L=1.0m ROHS 1
2.02.000.00260R USB host cable Micro USB host cabel (24+28)black 0.2m RoHS 1
2.02.000.00284R adapter plu
g
EU plu
g
RoHS 1
2.02.000.00286R adapter plu
g
UK plu
g
RoHS 1
4.02.001.02331R Giftbox Presti
g
io-E8-HD Elite
g
iftbox-V1.0 235x228x49mm RoHS 1.000
4.02.002.01957R Le
g
al and safety notices Presti
g
io-E8-HD Elite Le
g
al and safety notices-V1.0 RoHS 1
4.02.002.01958R User manual Presti
g
io-E8-HD Elite User manual-V1.0 RoHS 1
4.02.011.00297R Warranty cards Presti
g
io-E8-HD Elite Warranty cards-V1.0 RoHS 1
3.02.018.00359R leather case E8-Presit
g
io brand leather case model：PMP5588C_DUO RoHS 1.000
4.02.009.04516R Giftbox spec sticker Presti
g
io-E8-HD Elite Giftbox spec sticker-V1.0 50x35mm RoHS 1.0000
4.02.009.04517R SN sticker Presti
g
io-E8-HD Elite SN sticker-V1.0 35x24mm RoHS 1.0000
4.02.009.04518R Carton box sticker Presti
g
io-E8-HD Elite Carton box sticker-V1.0 70x100mm RoHS 0.2000
4.02.009.04451R Fire proof sticker Presti
g
io-E8-HD Elite Fire proof sticker-V1.0 125x115mm RoHS 0.1000
4.02.009.04454R SN barcode sticker Presti
g
io-E8-HD Elite SN barcode sticker 35x10mm RoHS 1.0000
4.01.007.00037R OPP ba
g
Presti
g
io-E8-HD Elite OPP ba
g
-V1.0 170x115mm RoHS 1 used for enlose the books
4.02.010.01205R carton box Presti
g
io-E8-HD Elite carton box-V1.0 520x250x260mm 10台装 RoHS 0.10000
4.02.010.00623R Protectin
g
corner VIEWSONIC-PF8011 Protectin
g
corner-V1.0 RoHS 0.02000
4.01.004.00027R shrink film 500MM 0.03MM RoHS 0.006200
5.01.000.00045R packin
g
belt packin
g
belt RoHS 0.0081000 used for packin
g
the pallet
5.01.000.00283R Film film RoHS 0.002000
5.01.000.00344R packin
g
tape
“
Presti
g
io”LOGO packin
g
tape 50U*48*100Y 48MM 100M/roll RoHS 360.000000 used for packin
g
the carton
5.01.000.00345R Pallet Pallet black. 12~15k
g
;wei
g
ht capacity:1000k
g
s; 120x100x15(cm) RoHS 0.002500

BOM Type:
T870_MXS_V1.3 Semifinished unit(MainBoard) (EMI)(AFA750)_2D_BW-8Gx1+HY-DDR3-256Mx4+WiFi+FCM+one
speaker+battery slot_TL080WX830(24LED)_ROHS 6.01.03.05.0281R
Part No. Description Specification
Q
ty Remark
1.01.001.00454R Carbon Film Resistors SMD 0402 0Ω
±
5% RoHS 13 R37, R41, R190, R193, R269,FB7, FB9, FB13, FB14, FB15, R274 R285、R11
1.01.001.00668R Carbon Film Resistors SMD 0402 2.2Ω
±
5% RoHS 1 R3
1.01.001.00455R Carbon Film Resistors SMD 0402 10Ω
±
5% RoHS 1 R153
1.01.001.00008R Carbon Film Resistors SMD 0402 22Ω
±
5% RoHS 10 R73, R74, R78,R112, R116,R117, R124, R126,R371,R61
1.01.001.00012R Carbon Film Resistors SMD 0402 33Ω
±
5% RoHS 1 FB16
1.01.001.00456R Carbon Film Resistors SMD 0402 100Ω
±
5% RoHS 2 R33, R248
1.01.001.00769R Carbon Film Resistors SMD 0402 150Ω
±
1% RoHS 1 R80
1.01.001.00711R Carbon Film Resistors SMD 0402 200Ω
±
1% RoHS 2 R42, R62
1.01.001.00076R Carbon Film Resistors SMD 0402 470Ω
±
5% RoHS 1 R75
1.01.001.00794R Carbon Film Resistors SMD 0402 560Ω
±
1% RoHS 1 R250
1.01.001.00413R Carbon Film Resistors SMD 0402 750Ω
±
5% RoHS 1 R157
1.01.001.00023R Carbon Film Resistors SMD 0402 1K
±
5% RoHS 4 R10, R77, R183,R184
1.01.001.00581R Carbon Film Resistors SMD 0402 1K
±
1% RoHS 2 R81, R84
1.01.001.00037R Carbon Film Resistors SMD 0402 1.5K
±
5% RoHS 2 R281 R158
1.01.001.00460R Carbon Film Resistors SMD 0402 2.2K
±
5% RoHS 7 R64, R65, R110, R111, R167,R270, R276
1.01.001.00462R Carbon Film Resistors SMD 0402 4.7K
±
5% RoHS 14 R22, R25, R31, R49, R70, R71,R79,R137, R164, R207,R229, R259,R27,R32
1.01.001.00647R Carbon Film Resistors SMD 0402 5K1
±
1% RoHS 1 R152
1.01.001.00466R Carbon Film Resistors SMD 0402 10K
±
5% RoHS 8 R86, R97, R108,R151, R195,R282,R131, R134,
1.01.001.00024R Carbon Film Resistors SMD 0402 10K
±
1% RoHS 2 R127, R143
1.01.001.00033R Carbon Film Resistors SMD 0402 12K
±
5% RoHS 1 R194
1.01.001.00645R Carbon Film Resistors SMD 0402 12K
±
1% RoHS 1 R146
1.01.001.00675R Carbon Film Resistors SMD 0402 22K
±
1% RoHS 1 R236
1.01.001.00078R Carbon Film Resistors SMD 0402 47K
±
5% RoHS 7 R21, R29, R169, R202,R209, R257 R59
1.01.001.00698R Carbon Film Resistors SMD 0402 47K
±
1% RoHS 1 R58
1.01.001.00789R Carbon Film Resistors SMD 0402 82K
±
1% RoHS 1 R180
1.01.001.00026R Carbon Film Resistors SMD 0402 100K
±
5% RoHS 5 R45, R159, R168, R186, R238
1.01.001.00463R Carbon Film Resistors SMD 0402 100K
±
1% RoHS 3 R36, R47, R234
1.01.001.00469R Carbon Film Resistors SMD 0402 200K
±
1% RoHS 1 R16,
1.01.001.00619R Carbon Film Resistors SMD 0402 270K
±
1% RoHS 1 R129
1.01.001.00802R Carbon Film Resistors SMD 0402 360K
±
1% RoHS 1 R57
1.01.001.00079R Carbon Film Resistors SMD 0402 470K
±
5% RoHS 4 R23, R60, R155, R171
1.01.001.00806R Carbon Film Resistors SMD 0402 620K
±
1% RoHS 1 R175
1.01.001.00464R Carbon Film Resistors SMD 0402 1M
±
5% RoHS 1 R85
1.01.001.00418R Carbon Film Resistors SMD 0805 0Ω
±
5% RoHS 2 R197 R199
1.01.001.00780R Carbon Film Resistors SMD 0805 2Ω
±
1% RoHS 1 R165
1.01.001.00821R Carbon Film Resistors SMD 0805 6.8Ω
±
1% RoHS 1 R166
1.01.001.00772R Carbon Film Resistors SMD 1206 0.03Ω
±
1% RoHS 1 R19
1.01.008.00252R Capacitor SMD 0402 5.6P NPO
±
0.5PF 50
V
ROHS 1 C169
1.01.008.00002R Capacitor SMD 0402 12P NPO
±
5% 50
V
ROHS 2 C88, C89
1.01.008.00004R Capacitor SMD 0402 18P NPO
±
5% 50
V
ROHS 2 C81, C82
1.01.008.00306R Capacitor SMD 0402 22P NPO
±
5% 50
V
ROHS 2 C42，C50
1.01.008.00309R Capacitor SMD 0402 102P X7R
±
10% 50V ROHS 6 C16, C166, C167,C168, C179, C193
1.01.008.00268R Capacitor SMD 0402 103P X7R
±
10% 25V ROHS 1 C211
1.01.008.00419R Capacitor SMD 0402 104P X7R ±10% 16V ROHS 36
C5, C10, C17, C22, C24, C25,C26, C38, C44, C49, C54, C56,C114, C120,
C132, C136, C145, C148, C149, C150, C151,C155, C158, C159, C160, C161,
C163, C164, C165, C190, C213, C217, C247, C299, C303,C146
1.01.008.00432R Capacitor SMD 0402 105P X5R ±10% 6.3V ROHS 23
C13, C33, C53, C63, C73, C84,C125, C128, C135, C154, C191,C207, C232,
C270，C35, C48, C313,C83, C103, C209, C233, C234 C265
1.01.008.00407R Capacitor SMD 0603 105P X5R
±
10% 10V ROHS 1 C152
1.01.008.00174R Capacitor SMD 0603 104P X7R
±
10% 50V ROHS 1 C143
1.01.008.00380R Capacitor SMD 0603 106P X5R
±
10% 10
V
ROHS 7 C28, C29, C30, C55,C97, C142, C248
1.01.008.00085R Capacitor SMD 0603 224P X7R
±
10% 10V ROHS 2 C45，C255
1.01.008.00483R Capacitor SMD 0603 475P X5R ±10% 6.3V RoHS 15
C87,C18, C27, C34, C43, C46, C75,C157, C214,C113, C137, C140, C196,
C281,C285
1.01.008.00299R Capacitor SMD 0805 106P X5R
±
10% 6.3V ROHS 9 C6, C8, C15, C20,C31, C32,C40, C41，C260
1.01.008.00434R Capacitor SMD 0805 106P
Y
5
V
-20% +80% 16
V
ROHS 1 C19
1.01.008.00399R Capacitor SMD 0805 226P
Y
5
V
-20%+80% 6.3V ROHS 3 C256, C257,C259
1.01.008.00418R Capacitor SMD 0805 475P
Y
5
V
-20%+80% 16
V
ROHS 1 C39
1.01.008.00238R Capacitor SMD 1206 106P X7R
±
10% 25V ROHS 1 C156
1.01.008.00296R Capacitor SMD 1206 475P X7R
±
10% 25V ROHS 2 C147，C144
1.01.021.00006R
V
olta
g
e Re
g
ulator Tube SMD 6V8 ROHS 1 D10
1.01.025.00034R Schottky Diode SMD MIC B5819W S4 SOD-123 RoHS 4 D3, D4, D6, D12
1.01.023.00009R SMT bidirectional diode BAV99-7-F-31( DIODES) RoHS 2 D7, D9
1.01.030.00057R SMT triode MT2301 ROHS 5 Q1, Q18，Q21, Q23 Q8
1.01.016.00007R SMT ma
g
netic beads 0402 ROHS 4 FB8, FB11，FB18, FB21
1.01.016.00031R SMT ma
g
netic beads CBG100505U601B 600Ω
/
100M RoHS 1 R196
1.01.015.00257R Inductor 4.7uH_1.7A (SWPA4018S4R7MT) SDS4X4 RoHS 4 L6, L17, L19, L20
1.01.015.00259R Inductor 10uH_1.3A (SWPA4018S100MT) SDS4X4 RoHS 1 L8
1.01.015.00289R Inductor SWPA5020S4R7NT SDS505020S RoHS 2 L7，L18
1.01.015.00288R Inductor SWPA5020S2R2NT SDS505020S RoHS 1 L9
1.01.033.00795R SMT IC AXP202-02 QFN48 RoHS 1 U1
1.01.033.00871R SMT IC TCS5515_F SOT23-6 ROHS 1 U14
1.01.033.00872R SMT IC TCS3354 TSOT23-5 ROHS 1 U15
1.01.033.00852R SMT IC TT7238RADJED TSOT23-5L RoHS 1 U2
1.01.033.00790R SMT IC SY6280 SOT23-5 RoHS 1 U33
1.01.033.00897R SMT IC AML8726-MXS BGA408 ROHS 1 U37
1.01.033.00913R SMT IC AFA750-L LGA-16 ROHS 1 U21
1.01.033.00898R SMT IC WM8960GEFL/RV QFN-32 ROHS 1 U6
1.01.033.00870R SMT IC TCS9208_F SOT23-6 ROHS 1 U16
1.01.033.00901R SMT IC MT3420 TDFN3x3-10 ROHS 1 U4
1.01.033.00863R SMT IC TCS2109_E28 LDO SOT23-5 RoHS 1 U31
1.01.033.00861R SMT IC TCS2109_E18 LDO SOT23-5 RoHS 1 U32
1.01.033.00896R SMT IC H5TQ2G83EFR-PBC（Hynix DDR3）ROHS 4 U41, U42, U43, U44
1.01.033.00916R SMT IC BW29F64G08CBABA TSOP48 ROHS 1 U10
1.01.057.01391R Circuit board T870_MXS_V1.3PCB RoHS 1
1.01.033.00891R SMT module USB wifi module MLK-017A ROHS 1 U7
1.01.060.00136R SMT socket 4p 1.85mm 1.25mm distance 5146S-0411 ROHS 2 CON7 CON11
1.01.038.00055R Quartz Crystal 32.768K_12.5P (hedeyu) ROHS 1
Y
3
1.01.038.00056R Quartz Crystal 24MHz_12P (hedeyu) ROHS 1
Y
2
1.01.077.00007R ESD Suppressor ESD Suppressor model:0402ESDA-MLP1 RoHS 2 D18, D19

BOM Type:
T870_MXS_V1.3 Semifinished unit(MainBoard) (EMI)(AFA750)_2D_BW-8Gx1+HY-DDR3-
256Mx4+WiFi+FCM+one speaker+battery slot_TL080WX830(24LED)_ROHS 6.01.03.05.0282R
Part No. Description Specification
Q
ty Remark
1.01.001.00454R Carbon Film Resistors SMD 0402 0Ω±5% RoHS 3 R35, R147, R206
1.01.001.00668R Carbon Film Resistors SMD 0402 2.2Ω±5% RoHS 1 R4
1.01.001.00455R Carbon Film Resistors SMD 0402 10Ω±5% RoHS 1 R53
1.01.001.00006R Carbon Film Resistors SMD 0402 18Ω±5% RoHS 2 R261, R262
1.01.001.00008R Carbon Film Resistors SMD 0402 22Ω±5% RoHS 4 R68,R82 R115 R67
1.01.001.00769R Carbon Film Resistors SMD 0402 150Ω±1% RoHS 1 R93
1.01.001.00764R Carbon Film Resistors SMD 0402 240Ω±1% RoHS 5 R83, R94, R95, R99, R101
1.01.001.00023R Carbon Film Resistors SMD 0402 1K ±5% RoHS 3 R263, R264,R172
1.01.001.00462R Carbon Film Resistors SMD 0402 4.7K ±5% RoHS 3 R63, R122 R123
1.01.001.00666R Carbon Film Resistors SMD 0402 4.7K ±1% RoHS 1 R187
1.01.001.00466R Carbon Film Resistors SMD 0402 10K ±5% RoHS 2 R138, R201
1.01.001.00078R Carbon Film Resistors SMD 0402 47K ±5% RoHS 2 R106, R188
1.01.001.00026R Carbon Film Resistors SMD 0402 100K ±5% RoHS 1 R239
1.01.008.00494R Capacitor SMD 0402 1P NPO ±0.25PF 50V ROHS 1 C242
1.01.008.00309R Capacitor SMD 0402 102P X7R ±10% 50V ROHS 1 C188
1.01.008.00419R Capacitor SMD 0402 104P X7R ±10% 16V ROHS 58
C12, C59, C60, C61, C66, C67, C71, C74, C78, C93, C94, C95,C96, C98,
C99, C101, C102,C104, C106, C107, C108, C109, C110, C111, C112,
C115, C116, C117, C121, C122, C123, C126, C127, C129, C130, C133,
C134,C138, C139, C171, C173, C174, C178, C183, C184, C186,
C189,C192, C200, C201, C203, C204,C205, C206, C246, C282,C283,
C254
1.01.008.00432R Capacitor SMD 0402 105P X5R ±10% 6.3V ROHS 9 C7,C36, C80, C153, C170, C202,C208, C296，C239
1.01.008.00380R Capacitor SMD 0603 106P X5R ±10% 10V ROHS 8 C47,C58, C65, C92, C100, C105,C131 C4
1.01.008.00265R Capacitor SMD 0603 475P Y5V -20%+80% 10V ROHS 1 C284
1.01.030.00043R SMT triode 2N3904 ROHS 1 Q27
1.01.016.00008R SMT ma
g
netic beads 0603 60Ω/100MHz 500mA ROHS 2 FB3, FB4
1.01.016.00039R SMT ma
g
netic beads CBG100505U121T 120Ω/100M RoHS 1 FB33
1.01.016.00031R SMT ma
g
netic beads CBG100505U601B 600Ω/100M RoHS 1 R255
1.01.015.00297R Inductor 0402 1.8NH ±5% ROHS 1 L11
1.01.060.00124R SMT socket AXK724147 bam04_24153_0502-pl RoHS 1 CN5
1.01.060.00132R SMT socket 0.8T-2AWB 0.8 distance2P H=1.7mm RoHS 1 CON10
1.01.060.00165R SMT socket 40P 0.5mm distance 1.2mm ROHS 1 J1
1.01.060.00157R SMT socket 6P 0.5mm distance 1.2mm ROHS 2 J4, J7
1.01.060.00162R SMT socket 24P 0.5mm distance 1.2mm ROHS 1 J5
1.01.077.00007R ESD Suppressor ESD Suppressor modle:0402ESDA-MLP1 RoHS 1 D21

MO8OGGVWMCBYQ-V0 RoHS 6.02.03.05.0092R
Part No. Description Specification Qty Remark
1.01.001.00466R Carbon Film Resistors SMD 0402 10K ±5% RoHS 2 R3 R4
1.01.001.00026R Carbon Film Resistors SMD 0402 100K ±5% RoHS 2 R1 R2
1.01.008.00419R Capacitor SMD 0402 104P X7R ±10% 16V ROHS 3 C2 C4 C5
1.01.008.00017R Capacitor SMD 0402 105P Y5V -20%+80% 6.3V ROHS 2 C1 C3
1.01.033.00845R SMT IC JZ6206A18M LDO SOT23-3 RoHS 1 U2
1.01.033.00881R SMT IC MG8698H-3 QFN56 RoHS 1 U1
1.01.060.00127R SMT socket 51P 0.3mm distance FPC0310-51RL-
T
AG RoHS 1 J1
1.01.060.00131R SMT socket FPC0510-06RL-
T
AG 6P RoHS 1 J2
1.01.057.01339R SMT module mg8698h_V1.1 PCB RoHS 1

T
870_KEY Semifinished unit ROHS 6.02.03.05.0038R
Part No. Description Specification Qty Remark
1.01.001.00777R Carbon Film Resistors SMD 0402 750Ω±1% RoHS 1 R202
1.01.001.00778R Carbon Film Resistors SMD 0402 910Ω±1% RoHS 1 R203
1.01.060.00157R SMT socket 6P 0.5mm 1.2mm ROHS 1 J201
1.01.057.01290R SMT module
T
870_KEY_V1.2 PCB ROHS 1
1.01.041.00055R microphone BO4015CPC-29-CE403 RoHS 1 MK201
1.01.091.00005R Mental Dome MID8D02-Mental Dome V2.0 RoHS 1 SW201 SW203 SW204

T
870_CARD_V2.3(EMI) Semifinished unit_RoHS 6.01.03.05.0275R
Part No. Description Specification Qty Remark
1.01.008.00419R Capacitor SMD 0402 104P X7R ±10% 16V ROHS 2 D308 D309
1.01.008.00309R Capacitor SMD 0402 102P X7R ±10% 50V ROHS 1 C301
1.01.008.00017R Capacitor SMD 0402 105P Y5V -20%+80% 6.3V ROHS 1 C303
1.01.016.00041R SMT magnetic beads CBG100505U102T 1KΩ
/
100M RoHS 5 FB4 FB8 FB9 FB10 FB11
1.01.016.00034R SMT magnetic beads PZ2012D121-2R5TF L0805 RoHS 1 FB56
1.01.060.00136R SMT socket 4p 1.85mm height 1.25mm distance 5146S-0411 ROHS 1 CON4
1.01.060.00163R SMT socket 24P 0.5mm distance 1.2mm ROHS 1 J302
1.01.060.00131R SMT socket FPC0510-06RL-
T
AG 6P RoHS 2 J305 J402
1.01.077.00007R ESD Suppressor 0402ESDA-MLP1 RoHS 1 D307
1.01.077.00008R ESD protective device SOD923 (0402) 1PF 5V ESD module:
T
EVB1R0V05B1X ROHS 5 D306 D307 D310 D308 D309
1.01.057.01392R SMT module
T
870_CARD_V2.3 PCB ROHS 1

T
870_CARD_V2.3(EMI) Semifinished unit_RoHS 6.01.03.05.0276R
Part No. Description Specification Qty Remark
1.01.001.00668R Carbon Film Resistors SMD 0402 2.2Ω±5% RoHS 1 R254
1.01.001.00012R Carbon Film Resistors SMD 0402 33Ω±5% RoHS 1 R255
1.01.008.00252R Capacitor SMD 0402 5.6P NPO ±0.5PF 50V ROHS 1 C304
1.01.008.00265R Capacitor SMD 0603 475P Y5V -20%+80% 10V ROHS 1 C302
1.01.016.00011R SMT magnetic beads 0805 60/100MHz ROHS 2 FB301 FB55
1.01.074.00026R SMT USB socket MICRO 5P-1.25MM ROHS 1 P301
1.01.075.00014R SMT holder with Micro SD socket
T
F-CKT01-009D RoHS 1 J304
1.01.074.00010R SMT DC seat DC-041 RoHS 1 J301
1.01.062.00023R SMT earphone socket ST-0269S00-061-182 RoHS 1 J401
1.01.077.00009R ESD protective device MLV(0603) 8PF 5V ESD module:
T
EVC8R0V05B1X ROHS 1 J401 between2th~3th foot SMT
1.01.019.00011R common mode Inductor
T
LCMI2012-2-371TF ROHS 1 L301

Maintainance for Defect of PMP5588
Fault dia
g
nosis and maintainance
Item Fault Phenomenon Possible Reasons Maintainance
1 Cannot power on
1、Battery run out
2、POWER button on keyboard with defect
3、system halted
4、LCD with defect
5、PCB MXS with fault welding, provided with
normal voltage and 24M oscillator vibrated
6、PCB DDR with fault welding, provided with
normal voltage and 24M oscillator vibrated
1、Check if charger is with charging icon
2、If charging icon appears and cannot power on, POWER
button be incontrollable, replace keyboard
3、Re-upgrade
4、Replace LCD screen
5、Re-weld or replace MXS
6、Re-weld or replace DDR
2 Cannot upgrade
1、TF card slot with defect if cannot read TF
card, can power on but cannot upgrade.
2、MXS with problem if can read TF card, can
power on and cannot upgrade.
1、Replace TF card slot
2、Replace MXS
3 Interference
1、LCD with problem if Main interface
interfered
2、40P winding displacement with fault
connection
3、MXS with fault welding or defect
1、Check if LCD screen with problme
2、Check if 40P winding displacement or its slot is properly
connected.
3、Re-weld or replace MXS
4cannot connect to PC
or U disk
1、USB terminal of the CARD board with
problem
2、MXS with fault welding or defect
1、Replace CARD board or USB terminal
2、Re-weld or replace MXS
5Can connect to PC but
cannot copy files
1、Need to pre-install the patch“wmp11-
windowsxp-x86-zh-cn”before copy files,
because of OS 4.2 Android, 1、install the patch“wmp11-windowsxp-x86-zh-cn”
6Camera interference or
cannot connect
1、Camera socket with fault connection
2、VDD1.8_CM及AVDD_CM with problem of
power supply
3、Camera with problem
4、MXS with fault welding or defect
1、Check if camera socket is correctly connected and in good
condition
2、Voltage problem of U31 and U32, replace if necessary
3、Replace camera
4、Re-weld or replace MXS
7 Cannot read card Card board or 24P socket with problem 1、Replace TF card slot
2、Re-connect 24P winding displacement
8 WIFI fault 1、WIFI module with problem
2、MXS with defect 1、Replace WIFI module 2、Replace MXS
9 Weak WIFI signal 1、WIFI antenna with fault welding or damaged 2、WIFI module technology or WIFI module
with problem
1、Replace WIFI antenna
2、Replace WIFI module
10 TP not work
1、6P button with loose connection
2、TP damaged
3、MG8698H of TP board with fault welding or
defect
4、MXS with defect
1、Replace 6P socket
2、Replace TP
3、Replace MG8698H or TP board
4、Replace MXS
11 Cannot charge 1、Battery with defect
2、AXP202 with fault welding or defect 1、Replace battery
2、Replace or re-welding XP202
12 Outside sound of
earphone
1、6P button of CARD board with loose
connection
2、Earphone slot with defect
1、Replace 6P button of card board
2、Replace earphone slot
13 System halted
1、32.768 oscillator with vibration problem if
cannot enter main interface or system halted
when power on
2、DDR,MXS or BGA with problem if can enter
main interface while program operating halted
1、Replace 32.768 oscillator
2、Re-weld or replace MXS
3、Re-weld or replace DDR

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
HDMI_CEC
HPD
DDCSDA
HDMI_SCL
HDMI_SDA
DDCSCL
HDMI_SCL
HDMI_HPD
HDMI_SDA
HDMI_CEC
TX_C+
TX_C-
TX_0+
TX_0-
TX_1-
TX_1+
TX_2-
TX_2+
HDMI_HPD
TX2+
TX1+
TX0+
TXC+
HPD
DDCSDA
TX2-
DDCSCL
TX1-
TX0-
TXC-
HDMI_CEC
TX_1-
TX_0-
TX_0+
TXC-
TXC+
TX0+
TX0-
TX1+
TX1-
TX2-
TX2+
TX_C+
TX_C-
TX_2+
TX_2-
TX_1+
HDMI_3.3V
AVDD2.5V
AVDD2.5V
GND
VCC2.8V
GND
GND
HDMI_3.3V
HDMI_PW
GNDGND
VCC3.3V
HDMI_3.3V
GND
GND
HDMI_PW
GND
GND
HDMI_PWVCC5V
GND
GND
GND
GND
HDMI3V_EN1
HDMI Power
For HDMI Certification, welding Q6/R20, NC
R11;
Without HDMI Certification, welding R11 only.
NC for MX-L
NO on board HDMI
HDMI Spec.
+4.8V < PVDD5 < +5.3V
2012-11-17 Sheet: 10of 13
Custom Document: E8-HD_MXS
Title
Ver
V1.0.0
Size
Data: HDMI
C184
0.1uF
C0402
C184
0.1uF
C0402
C209
1uF_6.3V
C0402
C209
1uF_6.3V
C0402
R243
1.8K
R0402
R243
1.8K
R0402
F1 SMD1206P020TF/24
F1206
F1 SMD1206P020TF/24
F1206
CCE1 TEF2012A4X101MT
Common Mode Choke + ESD
TEF2012A4X101MT
CCE1 TEF2012A4X101MT
Common Mode Choke + ESD
TEF2012A4X101MT
1
2
3
45
7
8
6
910
DS
G
Q6
WPM2301
SOT-23
DS
G
Q6
WPM2301
SOT-23
3
1
2
J8
CON20_05
J8
CON20_05
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 21
22
R247
10K
R0402
R247
10K
R0402
C215
1uF
C0402
C215
1uF
C0402
R242
1.8K
R0402
R242
1.8K
R0402
C188
1nF
C0402
C188
1nF
C0402
R244 22R R0402R244 22R R0402
CCE2 TEF2012A4X101MT
Common Mode Choke + ESD
TEF2012A4X101MT
CCE2 TEF2012A4X101MT
Common Mode Choke + ESD
TEF2012A4X101MT
1
2
3
45
7
8
6
910
R179
NC/27K
R0402
R179
NC/27K
R0402
C213 0.1uF
C0402
C213 0.1uF
C0402
R246 1K R0402R246 1K R0402
D22 NC/B5819W
SOD-123
D22 NC/B5819W
SOD-123
D25
ESD ESD_0402
D25
ESD ESD_0402
R11 NC/0R R0402R11 NC/0R R0402
D11
NC/BAT54C
SOT-23
D11
NC/BAT54C
SOT-23
1
3
2
R20 47K R0402R20 47K R0402
R245 22R R0402R245 22R R0402
R250 560R_1% R0402R250 560R_1% R0402
D24
ESD ESD_0402
D24
ESD ESD_0402
D23 ESD
ESD_0402
D23 ESD
ESD_0402
Not available
IN MX-L
(Lib Version:1108)
AML8726-MXS
U37E
BGA408_0.65mm
Not available
IN MX-L
(Lib Version:1108)
AML8726-MXS
U37E
BGA408_0.65mm
AVDD25_HDPLL T3
AVDD25_HDMI T2
HDMIREXT_600 U3
HDMITX_CKN U2
HDMITX_CKP U1
AVDD33_HDMI V3
HDMITX_0N V1
HDMITX_0P V2
HDMITX_1N W3
HDMITX_1P W2
HDMITX_2N Y1
HDMITX_2P Y2
GPIOC_10 (HDMI_HPD ) U5
GPIOC_11 (HDMI_SDA ) U4
GPIOC_12 (HDMI_SCL) AA1
GPIOC_13 (HDMI_CEC) AB1

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
CM_PWDN1
CM_Reset
CM_PWDN2
CM_Reset
AV_CM
AV_CM
AVDD_CM
AVDD_CM
GND
AVDD_CM
VCC2.8V
GND
VDDIO_CM
AVDD_CM
VDD1.8_CM
VCC2.8V
AVDD_CM
AVDD_CM VDDIO_CM
VDD1.8_CM
VCC3.3V
AVDD_CM
VDDIO_CM VDD1.8_CM
VDD1.8_CM
AVDD_CM
CMMCLK
CM_RSTn
CMHREF
CMVREF
CM_PWDN1 2
CMDATA7
CMDATA6
CMDATA5
CMDATA4
CMDATA3
CMDATA2
CMDATA1
CMDATA0
CMPCLK
I2C_SDA_A 2,5
I2C_SCK_A 2,5
CMMCLK
CMDATA1
CMDATA0
CMDATA7
CMPCLK
CMHREF
CMVREF
CMDATA6
CMDATA5
CMDATA4
CMDATA3
CMDATA2
CM_RSTn
CMMCLK
CM_PWDN2 2
CMPCLK
I2C_SDA_A 2,5
I2C_SCK_A 2,5
CMHREF
CMVREF
CMDATA7
CMDATA6
CMDATA5
CMDATA4
CMDATA3
CMDATA2
CMDATA1
CMDATA0
CM_RSTn
Note: The direction of the camera imaging
and LCD screen must be horizontal direction,
or 180 °, otherwise the software can not be
adjusted.
Hand solder
not use connector
for low cost
Camera Power
2MGalaxycore camera:
200W pixels/30fps
Some camera models require IO voltage <AVDD +0.3
Otherwise use 0R resistor to replace the diode
Note: The direction of the camera imaging
and LCD screen must be horizontal direction,
or 180 °, otherwise the software can not be
adjusted.
Camera Power
0.3M
2012-11-17 Sheet: 11of 13
Custom Document: E8-HD_MXS
Title
Ver
V1.0.0
Size
Data: CAMERA
C73
1uF
C0402
C73
1uF
C0402
C267
NC
C0402
C267
NC
C0402
FB18 磁珠
L0402
FB18 磁珠
L0402
R76 NC
R0402
R76 NC
R0402
FB28
22R
FB28
22R
TP68
TEST2
TP68
TEST2
FB29
22R
FB29
22R
C207
1uF
C0402
C207
1uF
C0402
R255
100R
R0402R255
100R
R0402
FB23
22R
FB23
22R
C53
1uF
C0402
C53
1uF
C0402
R41 0R
R0402
R41 0R
R0402
FB24
22R
FB24
22R
FB31
CBG100505U121T 120Ω/100M
FB31
CBG100505U121T 120Ω/100M
R19622R
R0402
R19622R
R0402
FB32
22R
FB32
22R
FB25
22R
FB25
22R
AXK724147
CN6
bam04_24153_0502-pl
AXK724147
CN6
bam04_24153_0502-pl
D9
1NC 24
D8
2POWER 23
D7
3RESET 22
D6
4AGND 21
D5
5AVDD 20
D4
6DGND 19
D3
7DVDD 18
D2
8DOVDD 17
HS
9SDA 16
VS
10 SCL 15
PCLK
11 AF-GND 14
XCLK
12 AF-VCC 13
FB26
22R
FB26
22R
C210
0.1uF
C0402
C210
0.1uF
C0402
C268
NC
C0402
C268
NC
C0402
C205
0.1uF
C0402
C205
0.1uF
C0402
FB30
22R
FB30
22R
C269
NC
C0402
C269
NC
C0402
U32
JZ6219C18
SOT23-5
U32
JZ6219C18
SOT23-5
VIN
1
GND
2
ON/OFF
3NC 4
VOUT 5
C204
0.1uF
C0402
C204
0.1uF
C0402
AXK724147
CN5
bam04_24153_0502-pl
AXK724147
CN5
bam04_24153_0502-pl
D9
1NC 24
D8
2POWER 23
D7
3RESET 22
D6
4AGND 21
D5
5AVDD 20
D4
6DGND 19
D3
7DVDD 18
D2
8DOVDD 17
HS
9SDA 16
VS
10 SCL 15
PCLK
11 LED+ 14
XCLK
12 LED- 13
R53 10R
R0402
R53 10R
R0402
FB21
磁珠
L0402
FB21
磁珠
L0402
(Lib Version:1108)
AML8726-MXS
U37F
BGA408_0.65mm
(Lib Version:1108)
AML8726-MXS
U37F
BGA408_0.65mm
GPIOZ_0 (ITU601_FIR // ITU601_IDQ) E8
GPIOZ_1 (ITU601_HS) B8
GPIOZ_2 (ITU601_VS) C7
GPIOZ_3 (ITU601_D0) B7
GPIOZ_4 (ITU601_D1) C6
GPIOZ_5 (ITU601_D2) B6
GPIOZ_6 (ITU601_D3) A6
GPIOZ_7 (ITU601_D4) C5
GPIOZ_8 (ITU601_D5) A5
GPIOZ_9 (ITU601_D6) B5
GPIOZ_10 (ITU601_D7) C4
GPIOZ_11 (ITU601_CLK) B4
GPIOZ_12 (CLK_OUT0 ) C3
C262
NC
C0402
C262
NC
C0402
C202
1uF
C0402
C202
1uF
C0402
FB27
22R
FB27
22R
C208
1uF
C0402
C208
1uF
C0402
C63
1uF
C0402
C63
1uF
C0402
C206
0.1uF
C0402
C206
0.1uF
C0402
FB19
22R
FB19
22R
FB33
CBG100505U121T 120Ω/100M FB33 CBG100505U121T 120Ω/100M
FB22
22R
FB22
22R

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
I2C_SDA_B
I2C_SCK_BGSEN_INT
BA_CSB
BA_CSB
I2C_SDA_B
I2C_SCK_B
GSEN_INT
CS
BA_CSB
VCC2.8V GSEN_VCC
GND
GND
GND
GSEN_VCC
GSEN_VCC
GND
VCC2.8V
VDD1.8_CM
GND
GSEN_VCC
GSEN_VCC
GND GND
GSEN_VCC
GND
VDD1.8_CM
GND
GND
GND
GSEN_VCC
GND
GSEN_VCC
GND
GSEN_INT 2
I2C_SDA_B 2,11,12
I2C_SCK_B 2,11,12
GSEN_INT 2
GSEN_INT 2
3-Axis G Sensor
Notes: G-sensor must place to
the center of MID.
BOSCH
Notes: G-sensor must place to
the center of MID.
Notes: G-sensor must place to
the center of MID.
connect to the gyroscope by default
connecte to the CPU when no gyroscope
VDD =1.95 -3.6V
I2C ADDRESS:0011100(0x1C)
ST
2012-11-17 Sheet: 9of 13
Custom Document: E8-HD_MXS
Title
Ver
V1.0.0
Size
Data: SENSOR
R176
NC/4.7K
R0402
R176
NC/4.7K
R0402
U21
MMA8452Q
MMA8452Q
U21
MMA8452Q
MMA8452Q
VDDIO
1
BYP
2
NC
3
SCL
4
GND
5
SDA
6
SA0
7
NC
8
INT2 9
GND 10
INT1 11
GND 12
NC 13
VDD 14
NC 15 NC 16
C176
NC/224P
C0402
C176
NC/224P
C0402 C177
NC/224
C0402
C177
NC/224
C0402
R136 NC/0R
R0402
R136 NC/0R
R0402
C191
1uF
C0402
C191
1uF
C0402
R173 NC/0R
R0402
R173 NC/0R
R0402
R133 NC/0R
R0402
R133 NC/0R
R0402
U20
NC/LIS35DE
LGA14
U20
NC/LIS35DE
LGA14
Vdd_IO
1
GND
2
AVDD
3
GND
4
GND
5
AVDD
6
CS
7
INT1 8
INT2 9
GND 10
GND 11
SDO 12
SDA 13
SCL 14
U34
NC/BMA222
BMA250
U34
NC/BMA222
BMA250
SDO
1
SDI
2
VDIO
3
NC
4
INT1
5
INT2
6
VDD 7
GNDIO 8
GND 9
CSB 10
PS 11
SCX 12
C214
4.7uF/X5R/6.3V
C0603
C214
4.7uF/X5R/6.3V
C0603
R174 NC/0RR0402R174 NC/0RR0402
C217 0.1uF
C0402
C217 0.1uF
C0402
R229
4.7K
R0402
R229
4.7K
R0402
C192
0.1uF
C0402
C192
0.1uF
C0402
C247
0.1uF
C0402
C247
0.1uF
C0402
C190
0.1uF
C0402
C190
0.1uF
C0402
FB11 120R/100MHz_0.3A
L0402
FB11 120R/100MHz_0.3A
L0402
R198
NC/4.7K R0402
R198
NC/4.7K R0402
R177
NC/4.7K
R0402
R177
NC/4.7K
R0402

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
WIFI_D2
WIFI_WAKE
BT_WAKE
WIFI_PWRENWIFI_VBAT
BT_TXD
WIFI_D1
WIFI_D0
WIFI_D3
WIFI_D2
WIFI_CMD
BT_RXD
WIFI_CLK
BT_UART_RTS
BTPCM_SYNC
BTPCM_DOUT
BTPCM_CLK
BTPCM_DIN
BT_UART_CTS
WIFI_D1
WIFI_D0
WIFI_CLK
ANT1
WIFI_CMD
BT_EN
WIFI_D3 WIFI_ANT
ANT
ANT
ANT1
VDDIO_AO
WIFI_VBAT
VCC3.3V
VCC2.8V
WIFI_VBAT
VCC2.8V
VDDIO_AO
VCC5V
UART_A_TX2
WIFI_SD_CMD2,13
WIFI_SD_CLK2,13
WIFI_SD_D32,13
WIFI_32K 2
WIFI_SD_D22,13
WIFI_SD_D02,13
WIFI_SD_D12,13
MSYS_RST 2
WIFI_WAKE 2
BT_WAKE2
BTPCM_CLK2
BTPCM_DOUT2
BTPCM_SYNC2 BTPCM_DIN2
WIFI_PWREN 2
UART_A_RTS_N2
UART_A_CTS_N2
UART_A_RX2
BT_EN2,5 HOST_DP 2
HOST_DM 2
ANT 2
WIFI_PWREN3
WIFI_CLK 2,13
ANT1 2
MT6620/6628 WIFI/BT antenna
R258 close to wifi module
RF_OUT trace: 50ohm impedance
Close to CPU
Interface IO power input
DUT VIO
需與平台介面電壓相等
MT6620/6628/6622/5931 IO power : 1.8 ~ 3.3V
External 32K input option MT5931 MT6620/6628 R260NC
Host VRTC power source for MT6620/6628/6622
MT6620/6628RQ GPS_SYNC
MT6620/6628RQ GPS LNA EN
MT6620/6628RQ GPS LNA POWER
MT6620/6628/5931/5370/7650/7601
Power 3.3+/-10%
MT6622 Power 3.2V~3.3V
MT6620/6628 PMU_EN
MT6620/6628 WIFI INT
2012-11-17
Document:
Custom 7of 13Sheet:
Size V1.0.0
Ver
Title E8-HD_MXS
WIFI&BT MTK
Data:
R12NC/10K R12NC/10K
R2780R R0402 R2780R R0402
L12
NC/39nH
L0402
L12
NC/39nH
L0402
R48NC/10K R48NC/10K
R280 22R R0402R280 22R R0402
C300 NC
C0402
C300 NC
C0402
R61
22R
R0402
R61
22R
R0402
R59
47K
R0402
R59
47K
R0402
R44NC/10K R44NC/10K
R43
22R/NC
R0402
R43
22R/NC
R0402
R26022R/NC R0402 R26022R/NC R0402
R60
470K
R0402
R60
470K
R0402
R34 0R/NC R0603R34 0R/NC R0603
C240 0.1uF
C0402
C240 0.1uF
C0402
C241 10uF_6.3V
C0603
C241 10uF_6.3V
C0603
J16
ACA-5036-A3-CC-S
WIFI_ANT
J16
ACA-5036-A3-CC-S
WIFI_ANT
FEED
1
G2
2G1 3
G3 4
R2770R R0402 R2770R R0402
M1
MTK_P2PUM_15X15
MTK_UM_PAD0.7_PITCH1.3
M1
MTK_P2PUM_15X15
MTK_UM_PAD0.7_PITCH1.3
GND1
4
SD_D1
11
SD_CMD
8
SD_D3
7
SD_CLK
9
GND3 25
AUOUT_L
17
UR_CTS
14
FM SANT
18
AUOUT_R
16
UR_RTS
15
URXD
13
FM_GND
20
FM_LANT
19
MT6628/6620/6622 BGF INT B 41
USB UDP 32
SYS_RST 22
WIFI aux / MT7650/6622 BT antenna 24
GND2 23
GPS RF
21
GPS_LNA_EN 36
VRTC 34
Ext 32K 35
PCM CLK 37
PCM IN 38
PCM OUT 39
PCM SYNC 40
SD_D0
10
RT5370 VIO2
2
MT5931 WIFI EN/MT6628/6620 PMU EN 30 VBAT
3
MT6622 BT EN
1
EFUSE 28
WIFI main ANT / WIFI BT single ANT / 2G 5G single ANT 26
GND4 27
VIO1
5
SD_D2
6
UTXD
12
MT5931/6620/6628 WIFI INT B 29
USB UDM 31
GPS_SYNC 33
TLDO_SW 42
R7NC/10K R7NC/10K
C2990.1uF
C0402
C2990.1uF
C0402
C263 10pF_NPO
C0402
C263 10pF_NPO
C0402
R18 0R/NC R0603R18 0R/NC R0603
C296
1uF
C0402
C296
1uF
C0402
C294 18pF_NPO
C0402
C294 18pF_NPO
C0402
TP69
TEST
TP69
TEST
Q8
MT2302SOT-23
Q8
MT2302SOT-23
S
2
G
1
D3
R2750R R0402 R2750R R0402
R282 10KR0402R282 10KR0402
R306 0R
R0402
R306 0R
R0402
R8NC/10K R8NC/10K

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
USBVBUS
USB_ID1
DM2
DP2
KEY_ ADC
KEY_ ADC
PWR_KEY
SD_CMD
SD_D3
SD_CLK
SD_D0
SD_D1
SD_D2
CARD_DET
GND
GND
DM2
DP2
GND
USB_ID1
GND
CARD_DET
SD_D1
SD_D0
GND
SD_CLK
CARD_VCC
SD_CMD
SD_D3
SD_D2
USBVBUS
GND
HP_AGND
HP_MIC
AOR-
AOL-
HP_IN
HP_AGND
MIC1P
MIC1N
USB_PWR
USBVBUS
VCC5V
AVDD2.5V
VCC3.3V
CARD_VCC
VCC3.3V
HP_AGND
CARD_VCC
DM12
DP12
VBUS12
ID12
USB_PWR_CTL1,5 PWR_KEY 1
MIC1P 11,12
ADC_KEY2
MIC1N 11,12
CARD_DET2
SD_D1_B2
SD_D0_B2
SD_CMD_B2
SD_D3_B2
SD_D2_B2
SD_CLK_B2
CARD_EN2
HP_IN 11
AOL- 11
HP_MIC 11,12
AOR- 11
limite output current
USB OTG
NO on board USB
pull-up: 4.7K_1%，MAX 8 ADC KEYs
KEY
ADC KEY
14% 26%
VOL+VOL-
close to CPU
Resister
Please follow below resistor value
when using less keys,
delete right side buttons.
Only the left key works when
pressing multiple keys imultaneously
key like "OK", and other
special keys should be placed to the right side
Button labeled corresponding function
KEY 1
NO on board key
Value
2345678
0% 14% 26% 38% 50% 62% 75% 87%
750R
1%
910R
1%
1.2K
1%
1.8K
1%
3K
1%
6.2K
1%
18K
1%
TF CARD
Close to CPU
Close to Card
NO on board TF Card
2012-11-17 Sheet: 6of 13
Custom Document: E8-HD_MXS
Title
Ver
V1.0.0
Size
Data: Key &IR&USB & Card
U33
SY6280
SOT23-05
U33
SY6280
SOT23-05
EN
4
VOUT 1
GND
2
ISET 3
VIN
5
FB9 0RFB9 0R
1 2
R202 47K R0402R202 47K R0402
TP23
TEST2
TP23
TEST2
TP9
TEST2
TP9
TEST2
R188 47K R0402R188 47K R0402
R206 0R
R0402
R206 0R
R0402
TP24 TEST2TP24 TEST2
C169 NC/10pF
C0402
C169 NC/10pF
C0402
C168
102pF
C0402
C168
102pF
C0402
TP18
TEST2
TP18
TEST2
FB13 0RFB13 0R
1 2
R191
NC/10K
R0402
R191
NC/10K
R0402
R187
4.7K_1%
R0402
R187
4.7K_1%
R0402
R193 0R R0402R193 0R R0402
C167
1nF
C0402
C167
1nF
C0402
FB14 0RFB14 0R
1 2
R192
NC/10K
R0402
R192
NC/10K
R0402
TP19
TEST2
TP19
TEST2
R183 1K R0402R183 1K R0402
FB15 0RFB15 0R
1 2
R194
12K
R0402
R194
12K
R0402
R209
47K
R0402
R209
47K
R0402
R190 0R R0402R190 0R R0402
C166
1nF
C0402
C166
1nF
C0402
FB16 22RFB16 22R
1 2
R201
10K
R0402
R201
10K
R0402
R215
NC/10K
R0402
R215
NC/10K
R0402
TP21
TEST2
TP21
TEST2
R184 1K R0402R184 1K R0402
DS
G
Q23
MT2301
SOT-23
DS
G
Q23
MT2301
SOT-23
3
1
2
TP22
TEST2
TP22
TEST2
J5
CON20_05
J5
CON20_05
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
26
25
FB7 0RFB7 0R
1 2
R186
100K
R0402
R186
100K
R0402
J4
CON6_05
CON6_05
J4
CON6_05
CON6_05
1
2
3
4
5
6
8
7
C165
0.1uF
C0402
C165
0.1uF
C0402
C170
1uF
C0402
C170
1uF
C0402
D15
NC/ESD
R0402
D15
NC/ESD
R0402

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
LEDP
LEDP
BL_EN
LEDN
BL_ADJ
BL_EN
BL_ADJ
LVDS_1P
LVDS_1N
LVDS_0P
LVDS_3P
LVDS_2P
LVDS_0N
LVDS_3N
LVDS_2N
LVDS_5N
LVDS_5P
SW
EVEN
XON
U/D
R/L
EVEN
OEV
LVDS_3P
LVDS_2N
LVDS_CKP
LCD_3.3V
LVDS_3N
POL
LD
LVDS_4P
LVDS_4N
LVDS_5N
STV1
LVDS_5P
CPV
U/D
XON
LVDS_0P
R/L
STH1
LVDS_1P
LVDS_0N
LVDS_1N
LVDS_2P
LVDS_CKN
VGH
VGL
LVDS_2N
LVDS_3P
LVDS_1P
LVDS_0P
LVDS_0N
LVDS_3N
LVDS_1N
LVDS_2P
LVDS_5P
LVDS_5N
LVDS_CKP
LVDS_4P
LVDS_4N
VGL
LCD_AVDD
VCOM
VGH
LCD_3.3V
STV1
STH1
OEV
POL
LD
CPV
LVDS_CKN
EVEN
LEDP
U/D
LED1+
R/L
VCCX3_EN
LVDS_4P
LVDS_4N
LVDS_CKP
LVDS_CKN
STH1
STV1
OEV
CPV
LD
POL LED1+
LEDN
LCD_AVDD
VCCx3
VCCx3VCCx
VGH
VGL
AVDD2.5V
LCD_3.3V
VCC3.3V
AVDD2.5V
AVDD2.5V
VCOM VCOM
AVDD2.5V
VCC5V
VGH
VGL
VCCx3
LCD_AVDD
GND
LCD_AVDD
LCD_AVDD
TCH3.0V
TCH3.0V
GND
VCOM
VGL
VGH
LCD_AVDD
LCD_AVDD
LCD_3.3V
GND
LCD_3.3V
GND
VCC3.3V
TCH3.0V
VCC2.8V
VCC5V
VCCX3_EN1
LCD_PWR_ENn2
VGHL_PWM 1
SPK_MUTE 11
CAP_TP_EN
I2C_SDA_A2,10
I2C_SCK_A2,10
TOUCH_INT2
CAP_TP_EN
BT_EN 2,7
USB_PWR_CTL 1,6
backlight current:180mA/9.3V
FB=0.2.5V
VCOM=3.2V
Vovp=36V
LED Backlight
dimming step of dcurrent source: 10uA; MAX:150uA.
calculate the value
of resistor according
to the max
dimming current
Please check to make sure
the package is OK.
If some DC/CD no-load voltage is too high,
add a 20V regulator to limit the
Voltage to use the 25V capacitor
Check PCB package pin1 carefully
Touch panel ： Imax = 30mA
5 fingers
： 2.8V -3.5V
2 fingers
： 3.0V -5.5V
Analog dimming to about 20% min
Use PWM diming if you want darker backlight
LOW:POWER ON;
High-Z:POWER DOWN
10uH_1.3A
+20V
-6.8V
R_VGH
R_VGL
LCD_AVDD
VGH/VGL
VCOM_BIAS
10.5V
TOUCH panel 以结构图上的顺序为准
注意
Touch 的封装及 pin1 的方向， PCB 的层；
Capacitive touch
叠 Lay
2012-11-17 Sheet: 5of 13
Custom Document: E8-HD_MXS
Title
Ver
V1.0.0
Size
Data: Panel&TOUCH
TP92
TEST2 TP92 TEST2
FB10 NC/120R/100MHz_0.3A
L0402
FB10 NC/120R/100MHz_0.3A
L0402
R166
7R5_1%/NC
R0805
R166
7R5_1%/NC
R0805
TP99TEST2 TP99TEST2
D8
20V/NC
SOD80
D8
20V/NC
SOD80
U14
TCS5515
SOT23-6p
U14
TCS5515
SOT23-6p
VIN
6
OVP
5
/SHDN
4FB 3
GND 2
LX 1
TP93TEST2 TP93TEST2
R159
100K
R0402
R159
100K
R0402
C145 0.1uF
C0402
C145 0.1uF
C0402
TP108TEST2 TP108TEST2
R137
4.7K
R0402
R137
4.7K
R0402
TP57
TEST2
TP57
TEST2
LVDS
MiniLVDS
TTL
(Lib Version:1108)
AML8726-MXS
U37D
BGA408_0.65mm
LVDS
MiniLVDS
TTL
(Lib Version:1108)
AML8726-MXS
U37D
BGA408_0.65mm
AVDD25_DPLL
N4
DPLL_LDO_EXTCAP
K1
LVDS_CLKN // MiniLVDS_5N
K2
AVDD25_LVDS1
P4
LVDS_CLKP // MiniLVDS_5P
L3
AVDD25_LVDS2
N5
LVDS_3N
L2 LVDS_3P
M3 LVDS_2N
M2 LVDS_2P
N3 LVDS_1N
N2 LVDS_1P
N1 LVDS_0N
P1 LVDS_0P
P2
LVDS_REXT_600
R3
GPIOC_7 (TCON_5_A // TCON_CPH1)
T4 GPIOC_8 (TCON_6_A // TCON_VCOM // SPDIF_in)
R5 GPIOC_9 (TCON_7_A // SPDIF_out)
T5
GPIOC_0 (PWM_A)
J19 GPIOC_3 (TCON_1_A // TCON_STV1)
H19 GPIOC_4 (TCON_2_A // TCON_OEH)
H18
LED_CS0 B20
GPIOB_2 (LCD_R2) C17
GPIOB_3 (LCD_R3) A17
GPIOB_4 (LCD_R4) B17
GPIOB_5 (LCD_R5) C16
GPIOB_6 (LCD_R6) B16
GPIOB_7 (LCD_R7) C15
GPIOB_10 (LCD_G2) D17
GPIOB_11 (LCD_G3) E17
GPIOB_12 (LCD_G4) E16
GPIOB_13 (LCD_G5) E15
GPIOB_14 (LCD_G6) D15
GPIOB_15 (LCD_G7) D14
GPIOB_18 (LCD_B2) B15
GPIOB_19 (LCD_B3) C14
GPIOB_20 (LCD_B4) B14
GPIOB_21 (LCD_B5) A14
GPIOB_22 (LCD_B6) C13
GPIOB_23 (LCD_B7 ) A13
GPIOD_0 (LCD_VGHL_PWM // PWM_C) E14
GPIOD_1 (LED_BL_PWM // PWM_D) B13
GPIOD_2 (TCON_0_B // TCON_STH1_B) C12
GPIOD_3 (TCON_1_B // TCON_STV1_B) B12
GPIOD_4 (TCON_2_B // TCON_OEH_B) C11
GPIOD_7 (TCON_5_B // TCON_CPH1_B) B11
GPIOD_8 (TCON_6_B // TCON_VCOM_B) C10
GPIOD_9 (TCON_7_B // PWM_A) B10
LVDS_4N
N7 LVDS_4P
N8
MINILVDS_CKN
P7 MINILVDS_CKP
P8
R162
7R5_1%
R0805
R162
7R5_1%
R0805
C143
0.1uF_35V
C0603
C143
0.1uF_35V
C0603
TP98
TEST2 TP98 TEST2
C142
10uF_6.3V
C0603
C142
10uF_6.3V
C0603
R170
10K/NC
R0402
debug
R170
10K/NC
R0402
debug
R175
178K_1%
R0402
R175
178K_1%
R0402
TP55
TEST2
TP55
TEST2
C155 0.1uF
C0402
C155 0.1uF
C0402
R155 470K R0402R155 470K R0402
C183
0.1uF
C0402
C183
0.1uF
C0402
TP87TEST2 TP87TEST2
R79
4.7K
R0402
R79
4.7K
R0402
TP106TEST2 TP106TEST2
R180
24K_1%
R0402
R180
24K_1%
R0402
R281 1.5K R0402R281 1.5K R0402
DS
G
Q21
MT2301
SOT-23
DS
G
Q21
MT2301
SOT-23
3
1
2
J7
CON6_05
CON6_05
J7
CON6_05
CON6_05
SDA
1
SCL
2
INT
3
RSTB
4
GND
5
VCC
6
C147
4.7uF/X5R/25V
C1206
C147
4.7uF/X5R/25V
C1206
TP95
TEST2 TP95 TEST2
C160
0.1uF
C0402
C160
0.1uF
C0402
R151
10K
R0402
R151
10K
R0402
TP45TEST2 TP45TEST2
C136
0.1uF
C0402
C136
0.1uF
C0402
R171
470K
R0402
R171
470K
R0402
R157 750R
R0402
R157 750R
R0402
C137
4.7uF_6.3V
C0603
C137
4.7uF_6.3V
C0603
C164
0.1uF
C0402
C164
0.1uF
C0402
TP94TEST2 TP94TEST2
D12 SS14
SOD123
D12 SS14
SOD123
C162
NC
C0402
C162
NC
C0402
R181
0R/NC R0402
R181
0R/NC R0402
TP105TEST2 TP105TEST2
R152
5.1K 1%
R0402
R152
5.1K 1%
R0402
R169
47K
R0402
R169
47K
R0402
C159
0.1uF
C0402
C159
0.1uF
C0402
TP85TEST2 TP85TEST2
TP89TEST2 TP89TEST2
L8
SWPA4018S100MT
SDS404020S
L8
SWPA4018S100MT
SDS404020S
C152
1uF/X5R/10V
C0603
C152
1uF/X5R/10V
C0603
TP91TEST2 TP91TEST2
R158 1.2K R0402R158 1.2K R0402
R146
12K 1%
R0402
R146
12K 1%
R0402
TP97
TEST2 TP97 TEST2
FB=1.25V
U15
TSC3354
SOT23-5
FB=1.25V
U15
TSC3354
SOT23-5
LX 1
GND 2
FB 3 EN
4
VIN
5
C149 0.1uF
C0402
C149 0.1uF
C0402
R189
0R/NC
R0402
R189
0R/NC
R0402
C146
0.1uF/25V
C0402
C146
0.1uF/25V
C0402
TP44TEST2 TP44TEST2
C303 0.1uF
C0402
C303 0.1uF
C0402
C158
0.1uF
C0402
C158
0.1uF
C0402
TP102TEST2 TP102TEST2
R178
0R/NC R0402
R178
0R/NC R0402
D7
BAV99
SOT-23
D7
BAV99
SOT-23
1
3
2
C156
10uF/X5R/16V
C1206
C156
10uF/X5R/16V
C1206
C151
0.1uF
C0402
C151
0.1uF
C0402
TP73
TEST2
TP73
TEST2
R160
NC
R0402
debug
R160
NC
R0402
debug
TP96
TEST2 TP96 TEST2
R167 2.2K
R0402
R167 2.2K
R0402
R164 4.7K R0402R164 4.7K R0402
R182
0R/NC R0402
R182
0R/NC R0402
FH28-55S-0.5SH(050
J1
FPC40PIN-0-5MMB
FH28-55S-0.5SH(050
J1
FPC40PIN-0-5MMB
VCOM0
1
EVEN
2
GND0
3
VCC0
4
VCC1
5
VGL
6
VGH
7
STV2
8
STV1
9
CPV
10
U/D
11
OE
12
XON
13
VCOM1
14
SHT1
15
GND1
16
R/L
17
LV0A
18
LV0B
19
LV1A
20
LV1B
21
LV2A
22
LV2B
23
CLKA
24
CLKB
25
LV3A
26
LV3B
27
LV4A
28
LV4B
29
LV5A
30
LV5B
31
AVDD0
32
OEH
34
REV
35
POL
36
GND3
37
AVDD1
38
STH2
39
VCOM2
40
GND2
33
GND
41
GND
42
TP90TEST2 TP90TEST2
C150
0.1uF
C0402
C150
0.1uF
C0402
TP74
TEST2
TP74
TEST2
L7
4.7uH_1.2A
SDS505020S
L7
4.7uH_1.2A
SDS505020S
C153
1uF
C0402
C153
1uF
C0402
TP88TEST2 TP88TEST2
TP56
TEST2
TP56
TEST2
C140
4.7uF_6.3V
C0603
C140
4.7uF_6.3V
C0603
TP109TEST2 TP109TEST2
C161
0.1uF
C0402
C161
0.1uF
C0402
CON10
BL
con2_08
CON10
BL
con2_08
1
2
3
4
R63
4.7K
R0402
R63
4.7K
R0402
TP84TEST2 TP84TEST2
C148
0.1uF
C0402
C148
0.1uF
C0402
C139
0.1uF
C0402
C139
0.1uF
C0402
TP107TEST2 TP107TEST2
R161
1R5_1%
R0805
R161
1R5_1%
R0805
C157
4.7uF/X5R/6.3V
C0603
C157
4.7uF/X5R/6.3V
C0603
C154 1uF
C0402
C154 1uF
C0402
D10
6.8V
SOD80
D10
6.8V
SOD80
TP43TEST2 TP43TEST2
C163
0.1uF
C0402
C163
0.1uF
C0402
C144
4.7uF_35V
C1206
C144
4.7uF_35V
C1206
TP86TEST2 TP86TEST2
C135
1uF
C0402
C135
1uF
C0402
FB8 120R/100MHz_0.3A
L0402
FB8 120R/100MHz_0.3A
L0402
D6 SS14
SOD123
D6 SS14
SOD123
R207
4.7K R0402
R207
4.7K R0402
DS
G
Q18
WPM2301
SOT-23
DS
G
Q18
WPM2301
SOT-23
3
1
2
R165
1R5_1%/NC
R0805
R165
1R5_1%/NC
R0805
D9
BAV99
SOT-23
D9
BAV99
SOT-23
1
3
2
R168
100K
R0402
R168
100K
R0402
