Prestigio P172W User manual

Prestigio TV-Tuner
User’s Manual
Instrukcja użytkownika
Příručka uživatele
Návod na použitie
Руководство пользователя
Navodila za uporabnike

2PRESTIGIO TV-TUNER
ENG
FEDERAL COMMUNICATIONS COMMISSION (FCC) WARNING
Instruction to Users
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio and television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a Class B computing device, pursuant to part 15 of the FCC rules.
Only peripherals (computer input / output devices, terminals, printers etc.) certified to comply to the Class B limits may be attached
to this computer. Operation with noncertified peripherals is likely to result in interference to radio and TV reception.
Remarks
To meet FCC requirement,shielded cables are required to connect the device to a personal computer or other Class B certified device.
Information to Users
The unit is for office equipment used. Any change or modifications expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: FCC Requlations state that any unauthorized changes or modifications to this equipment
not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
The lightning flash with arrowhead symbol,
within an equilateral triangle,is intended to
alert the user to the presence of uninsulated
”dangerous voltage” within the product enclo-
sure that may be of sufficient level to consti-
tute a risk of electric shock to persons.
The exclamation point within a triangle is in-
tended to alert the user to the presence of im-
portant operating and maintenance (servicing)
instructions in the literature accompanying the
product.
IMPORTANT:
To aid reporting in case of loss or theft, please
record the TV’s model and serial numbers in the
space provided. The numbers are located at the
rear of the TV.
Model no.:
Serial No.:

3PRESTIGIO TV-TUNER
ENG
IMPORTANT SAFETY PRECAUTIONS
Electricityis usedto performmany usefulfunctions, butit canalso causepersonal injuriesand propertydamage ifimproperly
handled.Thisproducthas beenengineered andmanufacturedwiththe highestpriority onsafety.However,improperusecan
result in electric shock and /or fire.In order to prevent potential danger,please observe the following instructions when
installing,operatingandcleaningthe product.To ensureyoursafety andprolong the servicelife of yourproduct,pleaseread
thefollowing precautions carefullybefore usingthe product.
• Readinstructions - Alloperating instructionsmust be readand understoodbefore the productis operated.
• Keepthismanualina safeplace- Thesesafety andoperatinginstructions mustbekept ina safeplacefor futurereference.
• Observewarnings - Allwarnings onthe product andin the instructionsmust beobserved closely
• Followinstructions - Alloperating instructionsmust be followed.
• Attachments- Donotuseattachmentsthatarenot recommendedbythe manufacturer.Use ofinadequateattachments
canresult inaccidents.
• Enteringof objects andliquids -Never insert anobject intothe product throughvents oropenings. High voltageexists
inthe product,inserting anobject cancause electricshockand /or shortinternal parts.For thesame reason,do notspill
wateror liquid onthe product.
• Servicing- Donot attemptto servicetheproductbyyourself. Removingcovers canexpose youto highvoltage andother
dangerousconditions. Requesta qualifiedservice person toperform servicing.
• Repair-If anyofthe followingconditions,unplugthe powercordfrom theACoutlet, andrequestaqualified serviceperson
to perform repairs.
a.Whenaliquidwasspilled ontheproductorwhenobjectshavefallen intotheproduct.
b.When the product has beenexposed torain or water.
• Cleaning- Unplugthe powercordfromtheAc outletbefore cleaningthe product.Use adamp clothtoclean theproduct.
Donot use liquidcleaners or aerosolcleaners.
• Water and moisture - Do not use the product near water,such as bathtub,washbasin,kitchen sink and laundry tub,
swimmingpool and ina wetbasement.
• Stand- Donot placethe producton anunstable cart,stand,tripod ortable. Placingthe producton anunstable basecan
causethe product tofall, resultingin serious personalinjuries as wellas damageto the product.Use only acart, stand,
tripod,bracket ortable recommendedby the manufactureror soldwith theproduct. Whenmounting theproduct on a
wall,besureto followthemanufacturer’sinstructions.Useonlythe mountinghardwarerecommendedbythemanufac-
turer.
• Whenrelocating the product placedon a cart,it must be movedwith utmost care.Sudden stops, excessiveforce and
uneven floor surface can cause the product to fall from the cart.
• Ventilation- Thevents andother openingsin thecabinet are designedfor ventilation.Do notcover orblock thesevents
andopenings sinceinsufficientventilation cancause overheatingand/ orshorten thelifeof theproduct.Donotplace the
producton abed,sofa, rugor othersimilarsurfacesincethey canblock ventilationopenings.This productis notdesigned
forbuilt-in installation;donot placethe productinan enclosedplace suchasa bookcaseor rack,unlessproper ventilation
isprovided orthe manufacturer’s instructionsare followed.
• Ifan outsideantenna isconnected tothe televisionequipment, besure theantennasystemisgrounded soas toprovide
enoughprotectionagainstvoltagesurges andbuilt-upstatic charges.Section 810ofthe NationalElectricalCode provides
informationwith respectto propergrounding ofthe mastand supportingstructure, groundingof thelead-in wireto an
antennadischarge unit,sizeof groundingconductors, locationofantenna-discharge unit,connection togroundingelec-
trodes,and requirementsfor thegrounding electrode.
• Foradded protectionto thistelevision equipmentduring alightning storm,orwhen itis leftunattended andunused for
long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the
equipmentdue tolightning andpower-line surges.

4PRESTIGIO TV-TUNER
ENG
• Anoutside antennasystem shouldnot be locatedin thevicinity ofoverhead powerlines or otherelectric lightor power
circuits,or where itcan fall intosuch powerlines or circuits.When installing anoutside antenna system,extreme care
shouldbe taken tokeepfrom touching suchpower lines orcircuits as contactwith them mightbe fatal.
PACKING CONTENTS (FIG. 1)
Thepackage contains:
1.TV tuner
2.User manual
USING THE REMOTE CONTROL
•Usetheremote controlbypointing ittowards theremotesensor window.Objectsbetween theremotecontrol andsensor
windowmay preventproperoperation.
Cautions regarding use of remote control
•Donot expose the remotecontrol to shock.
Inaddition,do not exposethe remotecontrol toliquids,anddo not placein anarea with highhumidity.
•Donot install or placethe remote controlunder direct sunlight.The heat may causedeformation of theunit.
•Theremote controlmaynot workproperlyif theremote sensorwindowof themain unitisunder directsunlight orstrong
lighting.In sucha case,changetheangleof thelighting orLCD TVset, oroperate theremotecontrol closerto theremote
sensorwindow.
Battery for the Remote Control (fig. 2)
If the remote control fails to to operate the LCD color TV functions, replace the batteries in the remote control.
1. Open the battery bracket.
• Press the hook to release the lock before pulling out the battery bracket.
• While the bracket lock is released, pull the battery bracket out of the remote control.
2. Insertbattery.
• Place the battery onto the bracket.
3. Pushthe bracket insidethe remote controlwith the battery onit.
Caution !
Cautions regarding batteries
Improperuse of batteries canresult in aleakage of chemicals and/ or explosion.Be sure to followthe instructions below.
•Placebattery with theirterminals corresponding to the(+) and (-)indications.
•Different types of batteries have different characteristics. Do not mix batteries of different types.
•Removebatteries when theybecome weak.
•Thebattery supplied withthe product mayhavea shorter lifeexpectancy due tostorage conditions.
•If the remote control is not used for an extended period of time, remove the batteries from the remote control.

5PRESTIGIO TV-TUNER
ENG
Rear Connectors (fig. 3)
A. AC Inlet
B. Video
C. Audio(R)(L)
D. S-Video
E. Audio(R)(L)
F. YCbCr
G. Audio(R)(L)
H.D-Sub Connector
I. RF Connector (TV tuner)
J. Earphone
K. Line-out
ANTENNA CONNECTION
ANTENNAS
•Theantenns requirementsforgood colortelevision receptionare moreimportantthan thosefor black& whitetelevision
reception.For thisreason, agood quality outdoorantenna isstrongly recommended.
Thefollowing isa briefexplanation ofthe typeof connectionsthat areprovided whiththe variousantenna systems.See
Fig.4
1. A75-ohm systemisgenerally around cablewithF-type connectorthat caneasily beattachedto aterminal withouttools
(notsupplied).
2. A300-ohm systemis aflat“twin-lead”cable thatcan beattachedtoa 75-ohmterminalthrougha 300-75-ohmadapter
(notsupplied).
OUTDOOR ANTENNA CONNECTION (Fig.5)
•Useone of thefollowing two diagramsif you connectan outdoor antenna.
A:Using aVHF/UHF combinationoutdoor antenna.
B:Using separate VHFand / orUHF outdoor antennas.
•Connect the outdoor antenna cable lead-in to the ANT.terminal on the rear of the TV set.
CONTROL OPTIONS (FIG. 6)
Note:
•InputSelect, Exit,CH( )UP/( )DOWN,VOL( ) -/ ( )+ ,andMENUon the mainunit havethe samefunctions
as the same buttons on the remote control.Fundamentally,this operation manual provides a description based on
operationwith the remotecontrol.

6PRESTIGIO TV-TUNER
ENG
OSD FUNCTION KEYS OPERATION:
Use the“INPUT”function key to change the display setting mode.There are five display setting modes ofPC,TV,AV,SV &
YCbCravailable inthis product.
Onanyfour ofthe followingdisplaymode (PC,AV,SVor YCbCr),itwill automaticallyreturntoTVmode ifuser pressCH+( )
or CH-( ) key.
For PC Setting Mode:
Somedirectfunction keys areasfollows:
Pressthe“AUTO”keyto autoadjustthe picturequality todefault setting.It will takefew seconds toadjustthe screensetting
when“AutoAdjusting…”message displayson thescreen.
Press the“+”or“-”keys to increase or decrease the audio volume.
OSD operation: (Image Page) (fig. 7)
Pressthe“MENU”key,the“ImagePage”willbe availableforadjustment.Therearesixitems suchasBrightness,Contrast,Clock,
Phase,H-Position&V-positionavailablefor adjustment.(Pressthe“EXIT”key toreturnone levelup of the OSDmenu.)
Press the“MENU”key again to enter (highlight) the item and use“+”or“-”keys to adjust the value.
Use the“UP”or“DOWN”keys to select the desired items and use“+”or“-”keys again to adjust the value.
Use the“EXIT”key to return one level up of the OSD menu.
Inthe PCSettingMode,pressthe“DOWN”keytoselect“ColorTemperaturePage”,“OSDPage”,“Audiopage”,“FactoryPage”&“PIP/
POPPage.”
Color Temperature Page (fig. 8):
Thereare threemodes available:6500K,7500K, 9300K.
Usethe“MENU”Keytohighlight thefirst itemanduse the“UP”or“DOWN”keystoselect thecolor temperatureorfurther down
to“R”,“G”or“B”items and use“+”or“-”keysto adjust thesetting value.
OSD Page (fig. 9):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value.
Audio Page (fig. 10):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value.
Factory Page (fig. 11):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
Afterthedesireditem hasbeen selected,use the“+”or“-”keystoexecutethefunction.
PIP/POP Page (fig. 12):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to execute the function or adjust the value.

7PRESTIGIO TV-TUNER
ENG
For TV Setting Mode:
Somedirectfunction keys areasfollows:
Press the“+”or“-”keys to increase or decrease the audio volume.
Pressthe“UP”or“DOWN”keysto selectthe Channel.
OSD operation:
Pressthe“MENU”key,the“SystemPage”will be availablefor adjustment.There arefive itemssuchasTVSystem,Auto Search,
MTS,Channel Edit & Clean Memory for adjustment.(Press the“EXIT”key to return one level up of the OSD menu.)
Press the“MENU”key again to enter (highlight) the first item and use“+”or“-”keys to adjust the value.
Usethe“UP”or“DOWN”keys toselectthe desireditems anduse“+”or“-”keysagain to adjust thevalue.
Use the“EXIT”key to return one level up of the OSD menu.
IntheTV SettingMode,press the“DOWN”keyto select“Image Page”,“OSDPage”,“Audiopage”&“Display Page.”
TV System Page (fig. 13):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to execute the function.
OSD Page (fig. 14):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Image Page (fig. 15):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value.
Thereare three modes availablefor selection: Standard, ViVidor Favorite.
Audio Page (fig. 16):
Usethe“MENU”Key tohighlight thefirst item and use the“UP”or“DOWN”keysto select the desired
items.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the
function.
Display Page (fig. 17):
There are six items such as“Close Caption”,“V-Chip Setting”,“Timer”,“Aspect”,“Noise Reduce”&“Recall Default”available for
adjustment.
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
CloseCaption itemselections :CC1, CC2,TT1, TT2.
Timeritem selections: 30, 60,90, Mins.
Aspectitem selections: Normal,1:1, 4:3.
NoiseReduce itemselections :Weak, Medium,Strong.

8PRESTIGIO TV-TUNER
ENG
For AV Setting Mode:
Somedirect function keys arefollows:
Press the“+”or“-”keys to increase or decrease the audio volume.
OSD operation:
Press the“MENU”key,the“Image Page”will be available for adjustment.There are five items such as
Brightness,Contrast,Sharpness,Color &Tint available for adjustment.(Press the“EXIT”key to exit or return one level up of
theOSD menu.)
Image Page (fiG. 18):
Press the“MENU”key again to enter (highlight) the item and use“+”or“-”keys to adjust the value.
Use the“UP”or“DOWN”keys to select the desired items and use“+”or“-”keys again to adjust the value.
Use the“EXIT”key to return one level up of the OSD menu.
Inthe AV Setting Mode,press the“DOWN”keytoselect“OSDPage”,“Audiopage”&“DisplayPage.”
Therearethree modes availablefor selection: Standard ,ViVid or Favorite.
OSD Page (fiG. 19):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Audio Page (fiG. 20):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Display Page (fiG. 21):
There are six items such as“Close Caption”,“V-Chip Setting”,“Timer”,“Aspect”,“Noise Reduce”&“Recall Default”available for
adjustment.
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
CloseCaption itemselections :CC1, CC2,TT1, TT2.
Timeritem selections: 30, 60,90, Mins.
Aspectitem selections: Normal,1:1, 4:3.
NoiseReduce itemselections :Weak, Medium,Strong.
For SV Setting Mode:
Somedirectfunction keys areasfollows:
Press the“+”or“-”keys to increase or decrease the audio volume.
OSD operation:
Press the“MENU”key,the“Image Page”will be available for adjustment.There are five items such as Brightness,Contrast,
Sharpness,Color &Tint available for adjustment.(Press the“EXIT”key to exit or return one level up of the OSD menu.)

9PRESTIGIO TV-TUNER
ENG
Image Page (fig. 22):
Press the“MENU”key again to enter (highlight) the item and use“+”or“-”keys to adjust the value.
Usethe“UP”or“DOWN”keys toselectthe desireditems anduse“+”or“-”keysagain to adjust thevalue.
Use the“EXIT”key to return one level up of the OSD menu.
In the SV Setting Mode,press the“DOWN”key to select“OSD Page”,“Audio page”&“Display Page.”There are three modes
availablefor selection: Standard ,ViVid or Favorite.
OSD Page (fig. 23):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Audio Page (fig. 24):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Display Page (fig. 25):
There are six items such as“Close Caption”,“V-Chip Setting”,“Timer”,“Aspect”,“Noise Reduce”&“Recall Default”available for
adjustment.
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keys toselectthe desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
CloseCaption itemselections :CC1, CC2,TT1, TT2.
Timeritem selections: 30, 60,90, Mins.
Aspectitem selections: Normal,1:1, 4:3.
NoiseReduce itemselections :Weak, Medium,Strong.
For YCbCr Setting Mode:
Somedirectfunction keys areasfollows:
Press the“+”or“-”keys to increase or decrease the audio volume.
OSD operation:
Press the“MENU”key,the“Image Page”will be available for adjustment.There are five items such as Brightness,Contrast,
Sharpness,Color &Tint available for adjustment.(Press the“EXIT”key to exit or return one level up of the OSD menu.)
Image Page (fig. 26):
Press the“MENU”key again to enter (highlight) the item and use“+”or“-”keys to adjust the value.
Usethe“UP”or“DOWN”keys toselectthe desireditems anduse“+”or“-”keysagain to adjust thevalue.
Use the“EXIT”key to return one level up of the OSD menu.
IntheYCbCrSetting Mode,pressthe“DOWN”keyto select“OSDPage”,“Audiopage”&“DisplayPage.”Thereare threemodes
availablefor selection: Standard ,ViVid or Favorite.

10 PRESTIGIO TV-TUNER
ENG
OSD Page (fig. 27):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Audio Page (fig. 28):
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
Display Page (fig. 29):
There are six items such as“Close Caption”,“V-Chip Setting”,“Timer”,“Aspect”,“Noise Reduce”&“Recall Default”available for
adjustment.
Usethe“MENU”Keyto highlight thefirst item anduse the“UP”or“DOWN”keysto select the desireditems.
After the desired item has been selected,use the“+”or“-”keys to adjust the value or execute the function.
CloseCaption itemselections :CC1, CC2,TT1, TT2.
Timeritem selections: 30, 60,90, Mins.
Aspectitem selections: Normal,1:1, 4:3.
NoiseReduce itemselections :Weak, Medium,Strong.
BASIC OPERATION
Volume (Direct control) or control (fig. 30)
1.Press to increase thesound volume. Thecontrol bar ofthe indicator increases.
2. Press todecrease the sound volume. Thecontrol bar of theindicator decreases.
To mute the sound
1. Press MUTEto temporarily turn offthe sound.
2.PressMUTE to soundback to theprevious level.
ON / OFF Control (fig. 31)
Toturnoff the LCDTV
Press onthe remote control. ThePower indicator willturnoff.
To turn the LCD TV back on
Press again.The Power indicatorwill turngreen.
Changing the channels on TV (fig. 32)
On anyfour ofthe followingdisplay mode (PC,AV,SV orYCbCr),it will automatically returntoTV modeif user pressCH+(
) or CH-( ) key.
Changingchannels by usingChannel Selecton theremote control
