Prexiso P50 User manual

PREXISO P50 812802b 1
EN
Prexiso P50 - Table of Contents
Instrument Set-up - - - - - - - - - - - - - - - - - - - - - - - - - -2
Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2
Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Insert batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2
Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3
Switching ON/OFF- - - - - - - - - - - - - - - - - - - - - - - - - - -3
Clear - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3
Message Codes - - - - - - - - - - - - - - - - - - - - - - - - - - - -3
Adjusting measuring reference - - - - - - - - - - - - - - - - - -3
Unit setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3
Measuring Functions - - - - - - - - - - - - - - - - - - - - - - -4
Measuring single distance - - - - - - - - - - - - - - - - - - - - -4
Permanent measuring - - - - - - - - - - - - - - - - - - - - - - - - 4
Add / Subtract - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -4
Area- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5
Volume- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Pythagoras (2-point) - - - - - - - - - - - - - - - - - - - - - - - - -6
Technical Data- - - - - - - - - - - - - - - - - - - - - - - - - - - - -7
Message Codes- - - - - - - - - - - - - - - - - - - - - - - - - - - -7
Care - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7
Disposal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7
Warranty- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7
Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - -8
Symbols used - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Permitted use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Prohibited use- - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Hazards in use - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Limits of use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8
Areas of responsibility - - - - - - - - - - - - - - - - - - - - - - - -9
Electromagnetic Compatibility (EMC)- - - - - - - - - - - - - 9
FCC statement (applicable in U.S.) - - - - - - - - - - - - - - 9
Laser classification- - - - - - - - - - - - - - - - - - - - - - - - - - 9
Labelling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -10

PREXISO P50 812802b
2
EN
Instrument Set-up
Overview
The safety instructions and the user manual should be
read through carefully before the product is used for the
first time.
The person responsible for the product must ensure that
all users understand these directions and adhere to them.
Display
On / Measure
Add / Subtract Area / Volume /
Pythagoras
Measuring
reference / Unit Clear / Off
Display
Insert batteries
Battery
Units
Area /
Volume
Addition /
Subtraction
Measuring
reference
Main line
Pythagoras
Info
+
+
-
-
i
Change batteries
when battery
symbol is
flashing.

PREXISO P50 812802b 3
EN
Operations
Switching ON/OFF Clear Message Codes
ON
Device is turned
OFF.
2 sec
i
If no key is
pressed for
180 sec, the
device
switches off
automatically.
Undo last action.
If the info icon appears with a number, observe the
instructions in section "Message Codes".
Example:
Adjusting measuring reference
Distance is measured from the
front of the device.
1
Distance is measured from the rear of
the device (standard setting).
2
Unit setting
2 sec
0.000 m
0‘00‘‘ 1/16
0 in 1/16
Switch between the
following units:

PREXISO P50 812802b
4
EN
Measuring Functions
Measuring single distance
1
Aim active laser at target.
2
8.532 m
8.532 m
3
i
Target surfaces: Measuring errors can occur
when measuring to colourless liquids, glass,
styrofoam or semi-permeable surfaces or when
aiming at hight gloss surfaces. Against dark
surfaces the measuring time increases.
Permanent measuring
2 sec
1
8.532 m
Aim active laser at target.
2
The last value measured
is displayed.
Stops permanent
measuring.
3
Add / Subtract
7.332 m
1
2 x
The next mea-
surement is
added to the
previous one.
2
The next mea-
surement is
subtracted from
the previous
one.
7.332 m
12.847 m
3
i
This process can be repeated as required.
The result is shown in the main line and the
measured value above.
The same process can be used for adding or
subtracting areas or volumes.

PREXISO P50 812802b
Measuring Functions
5
EN
Area
1
2
Aim laser at first
target point.
3
4
Aim laser at
second target
point.
24.352 m2
5
i
The result is shown in the
main line and the
measured distance above.
Volume
2x
1
2
Aim laser at first
target point.
3
4
Aim laser at
second target
point.
5
Aim laser at
third target
point.
6
78.694 m
3
7
i
The result is shown in the main
line and the measured distance
above.

PREXISO P50 812802b
Measuring Functions
6
EN
Pythagoras (2-point)
3x
1
2
Aim laser at
upper point.
3
4
Aim laser
rectangular at
lower point.
8.294 m
5
i
The result is
shown in the
main line and
the measured
distance above.

PREXISO P50 812802b 7
EN
Technical Data
* The typical measurement uncertainty of +/- 2 mm is
valid for measurements on white, diffusive, reflective
targets up to 5 m at low ambient light and moderate
temperatures. For distances greater than 5m, the
measurement uncertainty could increase additionally
by 0.1 mm/m. In unfavourable conditions (such as
bright sunlight, targets with poor reflectivity, or high or
low temperatures) the measurement uncertainty
could further increase up to +/- 4 mm for distances
below 5m and additionally by roughly 0.15 mm/m for
distances greater than 5 m.
Message Codes
If the message Error does not disappear
after switching on the device repeatedly,
contact the dealer.
If the message InFo appears with a
number, press the Clear button and
observe the following instructions:
Care
•Clean the device with a damp, soft cloth.
•Never immerse the device in water.
•Never use aggressive cleaning agents
or solvents.
Disposal
CAUTION
Flat batteries must not be disposed of with
household waste. Care for the environ-
ment and take them to the collection points
provided in accordance with national or
local regulations.
The product must not be disposed with
household waste.
Dispose of the product appropri-
ately in accordance with the
national regulations in force in your
country.
Adhere to the national and country specific
regulations.
Product specific treatment and waste
management can be downloaded from our
homepage.
Warranty
The device comes with a 2-year warranty.
For further information contact your dealer.
General
Range 0.05 to 50 m
0.16 to 164 ft
Measuring accuracy* typ.: ± 2 mm
± 0.08 in
Smallest unit displayed 1 mm
1/16 in
Laser class 2
Laser type 635 nm, < 1 mW
Protection class IP54 (dust- and
splash water
protected)
Autom. power switch-off after 180 s
Permanent measuring yes
Addition/Subtraction yes
Dimension (H x D x W) 45 x 115 x 30 mm
1.8 x 4.5 x 1.5 in
Battery durability (2 x AAA) up to 3000 measure-
ments
Weight
(without batteries)
100 g / 3.53 oz
Temperature range:
-Storage
-Operation
-25 to 70 °C
-13 to 158 °F
0 to 40 °C
32 to 104 °F
No. Cause Correction
204 Calculation error Perform measure-
ment again.
252 Temperature too high Let device cool
down.
253 Temperature too low Warm device up.
254 Battery voltage too
low for measurements
Change batteries.
255 Received signal too
weak, measuring time
too long
Change target
surface (e.g. white
paper).
256 Received signal too
high
Change target
surface (e.g. white
paper).
257 Too much background
light
Shadow target area.
258 Measurement outside
of measuring range
Correct range.
260 Laser beam inter-
rupted
Repeat measure-
ment.

PREXISO P50 812802b
8
EN
Safety Instructions
The person responsible for the instrument
must ensure that all users understand
these directions and adhere to them.
Symbols used
The symbols used have the following
meanings:
WARNING
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
will result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation
or an unintended use which, if not avoided,
may result in minor injury and/or appre-
ciable material, financial and environ-
mental damage.
Important paragraphs which must be
adhered to in practice as they enable
the product to be used in a technically
correct and efficient manner.
Permitted use
•Measuring distances
Prohibited use
•Using the product without instruction
•Using outside the stated limits
•Deactivation of safety systems and
removal of explanatory and hazard
labels
•Opening of the equipment by using tools
(screwdrivers, etc.)
•Carrying out modification or conversion
of the product
•Use of accessories from other manufac-
turers without express approval
•Deliberate dazzling of third parties; also
in the dark
•Inadequate safeguards at the surveying
site (e.g. when measuring on roads,
construction sites, etc.)
•Deliberate or irresponsible behaviour on
scaffolding, when using ladders, when
measuring near machines which are
running or near parts of machines or
installations which are unprotected
•Aiming directly in the sun
Hazards in use
WARNING
Watch out for erroneous measurements if
the instrument is defective or if it has been
dropped or has been misused or modified.
Carry out periodic test measurements.
Particularly after the instrument has been
subject to abnormal use, and before,
during and after important measurements.
CAUTION
Never attempt to repair the product your-
self. In case of damage, contact a local
dealer.
WARNING
Changes or modifications not expressly
approved could void the user’s authority to
operate the equipment.
Limits of use
Refer to section "Technical data".
The device is designed for use in areas
permanently habitable by humans. Do not
use the product in explosion hazardous
areas or in aggressive environments.
i
i

PREXISO P50 812802b
Safety Instructions
9
EN
Areas of responsibility
Responsibilities of the manufacturer
of the original equipment:
Prexiso AG
Europastrasse 27
CH-8152 Glattbrugg
Internet: www.prexiso.com
The company above is responsible for
supplying the product, including the User
Manual in a completely safe condition.
The company above is not responsible for
third party accessories.
Responsibilities of the person in
charge of the instrument:
•To understand the safety instructions on
the product and the instructions in the
User Manual.
•To be familiar with local safety regula-
tions relating to accident prevention.
•Always prevent access to the product by
unauthorised personnel.
Electromagnetic Compatibility
(EMC)
WARNING
The device conforms to the most stringent
requirements of the relevant standards
and regulations.
However, the possibility of causing inter-
ference in other devices cannot be totally
excluded.
FCC statement (applicable in U.S.)
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential instal-
lation.This equipment generates, uses and
can radiate radio frequency energy and, if
not installed and used in accordance with
the instructions, may cause harmful inter-
ference to radio communications.
However, there is no guarantee that inter-
ference will not occur in a particular instal-
lation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the interfer-
ence by one or more of the following
measures:
•Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.
Laser classification
The device produces visible laser
beams, which are emitted from the
instrument:
It is a Class 2 laser product in accor-
dance with:
•IEC60825-1 : 2014 „Radiation safety of
laser products“
Laser Class 2 products:
Do not stare into the laser beam or direct it
towards other people unnecessarily. Eye
protection is normally afforded by aversion
responses including the blink reflex.
WARNING
Looking directly into the beam with optical
aids (e.g. binoculars, telescopes) can be
hazardous.
CAUTION
Looking into the laser beam may be
hazardous to the eyes.

PREXISO P50 812802b
Safety Instructions
10
EN
Labelling
Subject to change (drawings, descriptions
and technical data) without prior notice.
Description Value
Wavelength 620 - 690 nm
Maximum radiant output
power for classification < 1mW
Pulse repetition frequency 320 MHz
Pulse duration > 400 ps
Beam divergence 0.16 x 0.6 mrad
Patent no.
• WO 9427164
• WO 9818019
• WO 0244754
• WO 0216964
• US 5949531
• EP 1195617
• US 7030969
• WO 03104748
• EP 2589980
