Pride Mobility 24BC2000T-1 User manual

1
BATTERY CHARGER MANUAL
0001463–081820

2
UPG 24V, 2.0A Sealed Lead-Acid Charger
Model numbers: 24BC2000T-1, 24BC2000T-2,
24BC2000T-3, 24BC2000T-4
4
UPG 24V, 3.5A
Sealed Lead-Acid Charger
Model No: 24BC3500T-4
8
UPG 24V, 5.0A
Sealed Lead-Acid Charger
Model No: 24BC5000T-4
12
UPG 24V, 8.0A
Sealed Lead-Acid Charger
Model No: 24BC8000T-4
16
Battery Maximizer 24V, 2.0A
Lead-Acid Charger
Model No: EA1065-P
20
Battery Maximizer 24V, 3.0A / 5.0A
Lead-Acid Charger for Victory®10
Model Numbers: EA24030-9C, EA1148B
24
TABLE OF CONTENTS

3
Metco 29.2V, 2.5A
Lithium Ion Charger for Go-Go®Folding Scooter
Model No: NL07C-25HT
30
Intertek 29.4V, 2.5A
Lithium Ion Charger for Go-Go®Folding Scooter
Model No: LS-018C20-2402500
32
ACI SUPER POWER 24V, 5.0A
Lead-Acid Class II Battery Charger
Model No: ACI245000
34
28.8V, 8.0A
Battery Charger
Model No: 4C24080A
38
36V / 2A
Battery Charger for iRIDETM Scooter
Model No: HP1202L3
40
TABLE OF CONTENTS
High Power Technology 24V, 2.0A
Battery Charger for Jazzy®Passport
Model No: HP0060W(L2)-M
28

4
SEALED LEAD-ACID CHARGER
OWNER'S MANUAL
FOR MODEL NUMBER:
24BC2000T-1
24BC2000T-2
24BC2000T-3
24BC2000T-4
UNIVERSAL POWER GROUP
1720 Hayden Drive, Carrollton, TX 75006
Tel: [phone] Fax: [phone]

5
SAVE THESE INSTRUCTIONS
This manual contains safety and operating instructions for your charger. Before using your charger, read
all instructions for the charger, the battery to be charged, and the product that uses the batteries.
WARNINGS
• To reduce the risk of injury, charge only 24V, 7-18AH lead acid rechargeable batteries with the charger.
Do not charge a non-rechargeable battery. Other types of batteries might burst, causing personal injury
or other damage!
• Donotdisassemblethecharger.Haveitservicedorrepairedbyqualiedservicepersonnel.Incorrect
 assemblycanresultinriskofelectricshockorre.
• Never use the charger as a DC power source for any electrical equipment.
• Never operate a charger with a damaged cord or plug. Inspect both input and output cords for any
damage before using the charger.
• Never unplug a cord by pulling on the cord itself. Always grasp the plug when disconnecting the charger.
• For indoor use only. Do not expose charger to rain, snow or excessive moisture.
• Never charge a frozen battery.
• The battery must be placed in a well-ventilated area during charging.
• Do not use the charger while the equipment is operating.
CHARGING A BATTERY
Follow these steps to charge a battery:
1. Connect the DC output cable to the battery terminal receptacle.
2. Plug the charger power cord into the charger.
3. Plug the power cord into wall outlet.
4. The POWER LED and CHARGING LED light should be ON.
5. When batteries are fully charged, the CHARGING LED will be OFF. Unplug the charger from the wall,
then the battery receptacle.
2 COLOR LEDs FOR STATUS INDICATION
A. POWER LED (dual color):
• Red color -Power on
• Green color -Charging a battery
B. CHARGING LED (Red color):
• LED on -Fast charge
• LED off -Float charge
PROTECTIONS
1. Short-circuit protection – protects the charger from short-circuit damage.
2. Overcurrent protection – protects the charger from over-current demand.
3. Overvoltage protection – protects the batteries from damage.
4. Battery polarity reversal – protects the charger and batteries against incorrectly installed batteries.

6
Note: Charger comes with one power cord depending on the charger model number. Please refer to the
table above for corresponding cord information.
AC CORD AND PLUG REQUIREMENTS
Cord rating: 120V, 1A, Type SJT, No. 18AWG (for use with 100-240VAC) 240V. 1A, Type SJT
or equivalent, No. 18 AWG (for use with 200 - 240V AC)
Plug rating: Type NEMA5-15P (for use with 100-120VAC) Always use a plug that matches the type and
rating of the AC outlet. Attachment plug with grounding pin (for use with 200 -240V AC)
Cord length: Min. 1.8m (6 feet). Max. 6.1 m (20 feet) including output cord.
Type: MustcomplywithrequirementssetoutbytheSafetyApproval/CerticationOrganization
of each country of use.
Note: Always use a plug that matches the type and rating of the AC outlet.
Model # Plug Type Input Voltage Power Cord
24BC2000T-1 UL AC 120V, 60Hz
24BC2000T-2 GS AC 230V, 50Hz
24BC2000T-3 SAA AC240V, 50Hz
24BC2000T-4 BS AC 230V, 50Hz
SPECIFICATIONS
POWER CORD SELECTION
1. Input Voltage 100 – 240Vac +/-10%
2. Input Frequency 50 – 60 Hz
3. Output Voltage
Fast Charge DC 29.6V
Float Charge DC 27.6V
4. Output Current
Fast Charge DC 2,000mA
Float Charge DC 500mA
5. Battery Capacity 7 – 18 AH (Suggested)

7
SAFETY STANDARDS: UU/cUL, CE, GS, c-Tick and SAA
THREE STAGE CHARGE CYCLE
An integrated circuit monitors and controls both the output voltage and current of tile charger
through three separate charge states:
I. A high current, fast charge state: battery charges at 2,000mA fast charge current rate
until battery voltage reaches 29.6V.
II. A topping charge state: battery charges at 29.6V constant voltage and current begins
to taper until current is less than 500mA.
III. A precision oat charge state:thechargerchangestotheoatstateandholdsthebattery
voltage at 27.6V continuously. This allows the charger to remain connected to the batteries
during periods of non-use, keeping the batteries in a state of full charge.
FCC STATEMENT
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with time limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
interference energy and, if not installed and used in accordance with the instructions, may case harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet or on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

8
OWNER'S MANUAL
24V 3.5A Sealed Lead-Acid Charger
Model No: 24BC3500T-4
SAFETY STANDARDS: UL, cUL, CE, GS, C-tick, SAA, FCC
FCC STATEMENT
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
interference energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet or on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

9
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS:
This manual contains safety and operating instructions for your charger. Before using your charger, read all
instructions and cautionary markings on the battery charger, and the product using the battery.
CAUTION: To reduce the risk of injury, charge only AGM or GEL Sealed Lead-Acid batteries. Other types of
batteries may burst, causing personal injury and damage.
WARNINGS:
• This charger is not intended for use by persons with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless under direct supervision. Do not allow children to operate
the charger unsupervised. Keep out of reach of children.
 • Donotdisassemblethecharger.Haveitservicedorrepairedbyqualiedservicepersonnel.Incorrect
  assemblycanresultinriskofelectricshockorre.
• Never use the charger as a DC power source for any electrical equipment.
• Never operate a charger with a damaged cord or plug. Inspect both input and output cords for any
damage before using the charger.
• Never unplug a cord by pulling on the cord itself. Always grasp the plug when disconnecting the charger.
• For indoor use only. Do not expose charger to rain, snow or excessive moisture.
• Never charge a frozen battery.
• The battery must be placed in a well-ventilated area during charging.
CHARGING A BATTERY:
Follow these steps to charge a battery:
1. Check battery-type selection switch to match your batteries - AGM or GEL. The default selection for this
charger Is AGM.
2. Connect the charger DC output cable to the battery charge receptacle.
3. Plug the charger power cord into the charger.
4. Plug the power cord into wall outlet.
5. The POWER LED and CHARGING LED light should be ON.
6. When batteries are fully charged, the CHARGING LED will be steady GREEN. Unplug the charger from
the wall, then the battery receptacle.
LED INDICATORS:
2 color LEDs for status indication:
A. POWER LED (CLEAR lens):
Red Color – Power On
B. CHARGING/ FAULT LED (CLEAR LENS-DUAL Color):
RED color STEADY ON – Fast Charge
GREEN color FLASHING – Float Charge
GREEN color STEADY – Charge nished
RED color FLASHING – FAULT

10
THREE STAGE CHARGE CYCLE:
An Electronic Control Module (ECM) controls both the output voltage and current of the charger through three
separate charge states:
1. A high current, fast charge state: Battery charges at 3,500mA fast charge current rate until battery
voltage reaches peak voltage.
2. A topping charge state: Battery charges at peak constant voltage and current begins to fall until
current is less than 700mA.
3. A precision oat charge state:Thechargerchangestotheoatstateandholdsthebatteryvoltage
  atcontinuousoatvoltage.Thisallowsthechargertoremainconnectedtothebatteriesduring
periods of non-use, keeping the batteries in a state of full charge.
4. Charger cut-off: To comply with mandate of DOE this charger automatically cuts off after 20 hours
of continuous operation, and CHARGE STATUS LED turns off. It is designed with auto restart to
keep batteries charged.
SAFETY FEATURES:
1. Short-circuit Protection – protects the charger from short-circuit damage.
2. Overcurrent Protection – protects the charger from overcurrent demand.
3. Overvoltage Protection – protects the batteries from damage.
4. Battery Polarity Reversal – protects the charger and batteries against incorrectly installed batteries.
5. Low Battery Voltage – when the battery ls under14V, the charger will not engage.
SPECIFICATIONS:
FAULT CODES
INDICATION CHARGE/FAULT - Red LED FAULT
1Off No batteries - Voltage < 9V
2Continuousashing 12 hour charge timed out
31ashevery3seconds Battery voltage < 14V
42ashesevery3seconds Batteries are connected in reverse polarity
53ashesevery3seconds Overvoltage from batteries
64ashesevery3seconds Overcurrent from charger
1 Input Voltage 100 – 240Vac +/-10%
2 Input Frequency 50–60 Hz
3
Output Voltage
Fast Charge (Bulk)
Float
AGM
DC 29.6V +/- 0.2V
DC 27.4V +/- 0.4V
GEL
DC 28.6V +/- 0.2V
DC 26.6V +/- 0.4V
4Output Current
Fast Charge (Bulk) DC 3,500mA
5 Battery Capacity 12-35 Ah (Suggested)
6Operating Temperature -13˚F/-25˚Cto+122˚F/50˚C
7Storage Temperature -13˚F/-25˚Cto+140˚F/60˚C
8 Power Supply Cord SJT,18AWGX3C,300V,105˚C
