Primula FLEX DOB User manual

IRONING PRESSING MACHINERIES - FUSING PRESSES
Instruction Manual
FLEX DOB

Instruction Manual
2
Table of Contents
1. ATTENTION!!!..........................................................................................................................3
2. Technical Details………………………………………………………………………………………………………….......4
2.1 Identification Data…..………………………………………………………………………………………………………4
2.2. Use of the instruction Manual…………………………………………………………………………………………4
2.3 Technical Characteristics………………………………………………………………………………………………….5
2.4 Technical Description……………………………………………………………………………………………………….5
3. General rules and Warnings………………………………………………………………………………………………5
3.1. General rules of using the Ironing Table………………………………………………………………………….5
3.2. Warning marks placed on the Ironing table.………………………………………….……………………….6
4. Assembly Instructions………………………………………………………….…………………………………………….6
5. Instructions for Installation ……………………………………………………………………………………………….7
5.1 Installation……………………………………………………………………………………………………………………...7
5.2 Electrical Connection……………………………………………………………………………………………………….7
6. Activation Instructions……………………………………………………………………………………………………….8
7. Maintenance……………………………………………………………………………………………………………………..9
8. Troubleshooting…………………………………………………………………………………………………………………9
8.1The vacuum does not function properly…………………………………………………………………………...9
8.2 The heating of the working surface is not activated………………………………………………………..9
8.3 The heating of the ironing buck is not activated………………………………………………………………9
8.4 The machine operates loudly ………………………………………………………………………..………………10
8.5 The blowing of air does not function……………………………………………………………………………..10
Drawing of the spare parts …………………………………………………………………………………………………11
List of Spare parts …………………………………….………………………………………………………………………..12
Wiring Diagram of Motor…………………..……………………………………………………………………………….14
Wiring Diagram of the machine…………………………………………………………………………………………..15
List of Spare parts of Wiring Diagram of the machine……………….…………………………………………16
TECHNICAL ASSISTANT…………………………………………………………………………………………………………17

Instruction Manual
3
1. ATTENTION!!!
Please read this instruction manual very carefully before you start using your Ironing Table.
The customer by purchasing this product declares that he is fully aware, and accepts
everything mentioned in this operating manual.
Primula SA assumes neither responsibility for any errors herein, nor for incidental nor for
resulting damage in connection with the performance or use of this operating manual.
You may not copy, reproduce, or translate this operating manual, or parts of it, to another
language without prior written consent of Primula SA.
Any information in this manual may be subject to change without any prior notice.
CAUTION! PLEASE READ CAREFULLY THE INSTRUCTION MANUAL BEFORE INSTALLING THE
STEAM GENERATOR!!!
2nd edition –January 2017
© Primula S.A. 2016
Company name: Primula S.A
Address: 14th klm Thessaloniki –Kilkis,
57200 Liti, Thessaloniki, Greece
Industry: Manufacturing of Ironing, Pressing and Finishing Equipment
Telephone: [phone]
Fax: [phone]
Web: www.primula.gr
E-mail: [e-mail]

Instruction Manual
4
2. Technical Details
2.1 Identification Data
The Ironing Table “FLEX DOB”is a machine of high advanced technology with many
advantages, unique in its kind. It is manufactured according to International and European
safety standards by a company with experience, since 1969, in this sector. Congratulations
for your choice!
Regarding its characteristics, the Ironing table includes a serial number plate (see below)
where all its specifications are displayed. Every warning and symbol that is placed on the
Ironing Table is in accordance with the specifications of the European standards.
The serial number plate has been placed in a visible place on the Ironing table and has made
from fadeless material.
Amongst others, the Serial Number plate displays the following:
Company Logo
Manufacturer Information
Model
Serial Number
Rated Voltage of Use
Rated Frequency of Use
Year of manufacturing
Accumulated Installed Wattage
Picture 1: Serial Number Sign
2.2 Use of the instruction Manual
The correct assembly and adjustment of the machine is vital to the safety of the user and the
machine‘s life span. For this reason, the installation, alteration, replacement or extension of
the machine should only be performed by qualified personnel.
Under no circumstances is interventions allowed in the machine, unless it’s for the planned
maintenance by an unauthorized engineer.
If you remain uncertain regarding the correct assembly of the machine after reading the
instructions, contact the manufacturer or an authorized representative before starting the
operation of the machine.

Instruction Manual
5
2.3 Technical Description
Ironing Table with Heating, adjustable suction and blowing through a lever.
For ironing readymade garments. Suitable for garment industries, workshops and ateliers.
Available in 3 models:
FLEX DOB1242 with suction.
FLEX DOB1242 S+B with automatic suction/blowing adjustment through two pedals.
FLEX DOB1242 M S+B blowing with manual suction/blowing adjustment through a lever.
2.4Technical Characteristics
Model
FLEX DOB
FLEX DOB S+B
FLEX DOB M S+B
Working surface
120X42cm(standard)
120X42cm(standard)
120X42cm(standard)
Height adjustment
75-91cm with screws
75-91cm with screws
75-91cm with screws
Heating
1KW
1KW
1KW
Suction
Adjustable
Automatic
Manual
Blowing
NO
YES
YES
Motor Power
0.75HP
0.75HP
0.75HP
Power supply
230V-1ph-50Hz or
400V-3ph-50Hz
230V-1ph-50Hz or
400V-3ph-50Hz
230V-1ph-50Hz or
400V-3ph-50Hz
3General rules and Warnings
3.4 General rules of using the Ironing Table
For the safe usage of your Ironing Table, please read the following operating instructions
carefully, as listed below:
Install, use and maintain the Ironing Table according to the instructions in this
manual. Otherwise, the manufacturer has no responsibility for the possible failed
operation or safety.
Before connecting the power supply, check that the voltage corresponds to the
voltage indicated on the technical specifications.
Connect the machine only to a power supply that meets the minimum required
frequency and is properly grounded. Do not leave the Ironing Table while it is
operating and is on power without supervision.
Use the Ironing Table ONLY for the intended purpose in accordance with the current
instruction manual and only with the accessories that are provided or that are
intended for this specific Ironing Table. The manufacturer is not liable for any
damages resulting from misuse or wrong use of the Ironing Table.
DO NOT touch the power supply with wet hands.
Do not clean the Ironing Table with corrosive or other damaging materials/chemicals.
Never use the Ironing Table to support any other machine or structure.
It is strictly prohibited to do any kind of welding or alterations on the Ironing Table
or its parts.
It is strictly prohibited to remove any protective device/guards.
It is strictly prohibited to intervene in the control units/circuit boards of the Ironing
Table.

Instruction Manual
6
It is strictly forbidden to do any modification to the technical specifications of the
machine (electrical or mechanical) by third persons.
Please contact your dealer or the manufacturer for any malfunction or further
information requests.
3.2 Warning marks placed on the Ironing Table
Each Ironing Table has the following attention marking:
The operator of the system has the obligation to be informed regarding the dangers which
may occur during usage, so that he/she can avoid them or minimize their occurrence as best
as he/she is able to.
4. Assemby instructions
For the instructions mentioned in the current section please see the below drawing
(picture2).

Instruction Manual
7
Picture 2: Assembly
1. Put base No 01 in the inverted position. Screw the base No 02 to the base of the table No
04 to the base Nο02 after you have connected first the wires to the terminal block No 03.
2. Turn the assembled pieces in their regular position as soon as you screw the base.
3. Screw the working surface Νo 05 to the base No 01.
4. Connect the wire of the working surface with the 4-poles socket which is situated on the
back of the base No 01.
5. Screw the chimney Νo 07 to the back side of the machine.
6. Screw the ATB Swivel bow for suspension of the iron cables No 06.
7. Place the base of the tray Νο 08 in the slots into the front side of the base No 01 and
screw the screws.
8. In case you have purchased the model with the ‘’vario iron system’’ screw the corner of
the vario No 09 to the chimney No 07 and then the iron hanger No 10 to the corner No
09.
9. Connect the cable of lighting No 11 with the 3-poles socket of the lighting and the socket
which is on the back of the base No 01.
10. Screw the corner of the swivelarm No 12 to the working surface and put the swivelarm
No 13 above the corner.
11. Align the machine with the little feet No 14 in order to be stable.
12. The machine is ready for use.
10
1
2
3
4
5
6
7
8
9
11
12
13
14

Instruction Manual
8
5. Instructions for Installation
For the instructions mentioned in the current section please see the above drawing (Picture
2).
5.1 Installation
Put the Ironing Table in the designated area of your choice and align the machine by
increasing/decreasing the height of its feet No 14. Make sure that the ironing Table is stable
and the ironing surface flat.
5.2 Electrical Connection
For the electrical connection and above all for the power supply, please follow carefully the
instructions of the wiring diagram (enclosed) as well the warning signs symbols attached on
the machine. In case you have purchased a single phase machine 230V, connect the machine
to the power into the socket 230V/16A. The connection should be done with 3-phase 3Χ1,5
mm (1 phase, 1 neutral, 1 grounded). The power should be provided with a fuse 10Α. If the
machine is 400V/3 phase, the connection should be made to a 5-poles cable 5Χ1,5 mm (3
phase, 1 neutral, 1 grounding). The power should be secured with a 3-poles safety switch
(3Χ10Α).
CAUTION! For your own safety, pay attention to all the warning labels (yellow colored) that
are placed on the machine. The manufacturer bears no liability for any damages or accidents
due to faulty supplying network or to not specified personnel.
6. Activation Instructions
For the instructions mentioned in the current section please see the below image(picture 3).
Picture 3: Switches
Turn on the main switch No 01.
Switch the thermostat that is placed below the buck to temperature 110°C during the
winter and to 90°C during the summer.
Whenever you want to use the suction just press the left pedal.
Adjust the steam quantity of the steam generator in proportion to the suction
performance of the table, in order to avoid steam liquidation on the working surface.
The refined fabrics require small quantity of steam, while the gross fabrics require big
quantity of steam.
The ironing buck’s heating is activated when you press switch No 03 to position I.
*In case the table disposes Vario iron’s system (optional) hook the steam iron from the
balancer and adjust the distance of the steam iron from the working surface

Instruction Manual
9
(approximately 5cm). After finishing ironing unhook the steam iron from the balancer and
put it on the iron rest mat.
* * In case your table disposes a blowing system of air:
Adjust the volume of the blowing air with the lever according to the requirements of
the fabric (weight, quality , etc.) from the knob which is placed in the main body of
the machine
Push with your foot pedal for using the blowing.
7. Maintenance
Make sure that the covers of the table and the ironing buck remain clean, in order to
have high performance of suction and blowing air. Wash the blue polyester fabric and
the foam blue once per week in the washing machine (30-40 οC).In case you use felt
molletone instead of blue foam, do not wash it in the washing machine, but wash it
on hand. Replace them regularly, in order to keep high suction and blowing
performance.
Clean the dust of the fan wheel /impeller at least 2-3 times per year.
Clean periodically and grease the arm’s as well as the buck’s bearings.
Clean periodically the internal parts of the table as well as the electronic circuit by
using compressed air.
Keep the machine clean.
CAUTION!
Before doing maintenance work, please disconnect the machine from the electrically power
supply.
8. Troubleshooting
For the instructions mentioned in the current section please see the drawing of the spare
parts of the machine on page 11.
8.1The vacuum does not function properly
Check if there is power supply.
Check if the power feeding cable is for some reason cut off.
Check the fuse 12Αwhich is inside the fusecase No 05.
Check if the suction’s bouton pedal No 09 is faulty.
Check if motor No 01 is for some reason damaged.
Check the relay No 13.
Check the electronic circuit Νο 18.
8.2 The heating of the working surface is not activated
Check if the fuse 12Αinside the fusecase No 05 is burnt out. Replace it.
Check if the safety thermostat No 31 is faulty. Replace it.
Check if the thermostat No 32 is faulty. Replace it.
Check if the heating element No 36 is burnt out. Replace it.
Check the power supply cable and power plug on the board surface (No 23).
Check if the switch No 76 is faulty. Replace it.
8.3 The heating of the ironing buck is not activated

Instruction Manual
10
Check the cable and the plug of ironing’s buck power supply.
Check the switch No 08 for the heating of the ironing buck.
Check the heating element of the ironing buck .
8.4 The machine operates loudly
Check if the ball bearings of the motor are faulty. Replace them.
Check the impeller to be sure, that there is no dust which could cause the vibration.
8.5The blowing of air does not function
(If you have purchased the FLEX DOB S+B)
Check if the blowing’s bouton pedal No 09 is damaged.
Check the electronic circuit No 18.
Check the relay No 13.
Check the motor No 01.
Check the motor Flap Motor 12V/DC No 16.
Check the relay 12V/DC No 24.

Instruction Manual
11
Drawing of spare parts

Instruction Manual
12
List of Spare parts
Νο
CODE
DESCRIPTION
1
302-00-001-3
302-00-001-1
302-22-001-2
Electric Motor 0,75ΗΡ/400V/50HZ - 3 N
Electric Motor 0,75ΗΡ/230V/50ΗΖ - 1 Ν
Electric Motor 0,75ΗΡ/220V/60ΗΖ - 1 Ν
2
192-22-002
Metallic shell vacuum
3
302-00-003
Fan wheel Ø180
4
192-22-004
Metallic flange of metallic shell vacuum
5
192-21-005
Base of table 1242
6
192-26-022
192-21-006
Suction pedal 1242 ( for FLEX DOB)
Blowing pedal 1242 (only for FLEX DOD 1242 S+B)
7
192-21-007
Suction pedal 1242
8
302-22-008
Terminal block for the connection of the button pedal
9
302-26-026
Suction and blowing button pedal
10
192-22-010
Male base
11
192-22-011
Female base
12
192-22-012
Dashboard
13
302-00-010
Relay
14
192-22-014
Circuit’s case
15
192-22-015
Vacuum and Blowing interchange system (only for FLEX DOD 1242 S+B)
16
302-03-006
Flap Motor 24V/DC (only for FLEX DOD 1242 S+B)
17
192-22-017
Regulation lever of blowing (only for FLEX DOD 1242 S+B)
18
302-22-018
Electronic circuit (only for FLEX DOD 1242 S+B)
19
302-02-009
Socket 6A
20
302-27-004
Socket for buck with cable
21
302-01-016
Plastic wheel
22
302-26-005
302-00-014
Cable of power supply 3Χ1.5mm with plug
Cable of power supply 5Χ1.5mm
23
302-21-023
Power supply cable of heating element
24
302-21-024
Relay 12V/DC (only for FLEX DOD 1242 S+B)
25
107-03-000
Silicon iron rest mat
26
192-01-027
Hanger of the iron’s cables
27
107-01-000
Antenna
28
192-22-028
Chimney
29
192-22-029
Tamper of chimney
30
192-21-030
Plate of ironing table 1242
31
302-01-010
Safety thermostat 1450C
32
302-00-012
Thermostat of table 1100C
33
302-26-004
Thermostat knob
34
192-21-034
Bracket axle of corner
35
192-21-035
Axle of corner
36
302-01-014
Heating element 1 ΚW 230V
37
192-21-037
Base of tray
38
302-02-014
Leg for the regulation of table
39
302-01-035
Cover’s spring with clip
40
192-21-040
Metallic corner
41
192-21-041
Tamper of swivelarm
42
192-22-042
Corner of swivelarm
43
192-21-043
Tamper of working surface

Instruction Manual
13
Νο
CODE
DESCRIPTION
44
192-22-043
Brass muff of corner 60mm
45
102-22-010-1
Arm of buck
46
302-21-046
Screw of arm
47
192-22-045
Muff of arm’s brass bearing
48
192-21-048
Cover of tamper
49
302-21-072
Cover of table
50
302-21-050
302-21-050-1
302-21-050-2
Foam layer 1242
Vacufix layer 1242
Felt molletone 1242
51
302-21-051
Plastic lattice
52
192-21-052
Perforated
53
192-22-055
Blade of bar support S
54
302-01-057
Elastic stop
55
192-21-055
Plate of lighting
56
302-22-055
Lighting
57
302-00-044
Fluorescent lighting
58
302-22-054
Lighting’s switch
59
302-22-056
Lighting’s socket
60
192-22-059
Corner of vario
61
192-22-051
Suspension’s bar
62
302-00-051
Iron’s suspension
63
302-22-050
Ball bearing of stretcher’s suspension
64
302-00-049
Stretcher suspension
65
300-00-008
Gland Ø 13.5mm
66
302-22-020
4-poles corner socket
67
192-22-031
Metallic cover (only for FLEX DOD 1242)
68
192-21-068
Base of iron
69
302-21-069
Cable of lighting power
70
192-22-055-1
Blade of bar support L
71
192-22-071
Metallic Cover of Chimney
72
192-22-072
Metallic Cover of male base
73
192-21-073
Metallic holder of screw
74
192-21-074
Spring of Tamper
75
302-22-074
Indicator light overheating motor
76
308-00-006
Switch ON-OFF 16A
77
302-00-017
Double switch ON-OFF
78
302-22-078
Cover of micro switch
79
192-22-065
Metallic base of electronic circuit
80
192-22-047
Bearing of arm
81
302-21-081
Cover for FLEX DOB tray
82
302-22-004
302-22-004-1
Vacuum 0.75Hp 400V complete
Vacuum 0.75Hp 230V complete

Instruction Manual
14
Wiring Diagram of Motor

Instruction Manual
15
Wiring Diagram of the machine
L1L2L3
1 2 3 4 5 6 7 8 9
CV M1
TPE
41 42
F52
2.5A
RLE
1 2 3 4 5 67 8 910
TM3
TM2
FSM
MB MV2
FS 2.5A
S1 SI SII
K1
A1
135
24 6 A2
LS
TM1 1 2 3 4 5 6 7 8 910
L1L2L3 NN N
PS2
PS1
PS3
12
2
5
36
14
25
LINE 3x220 V-60 Hz
LINE 400 V 3 N 50 Hz
CV
TPE
230 V- MAX 6 A
UVW
Z X Y
UVW
Y
XZ
DC
1 2
3
21
3
PRIMULA
WARNING DIAGRAM
FLEX FL1365
FLEX DOB 1242

Instruction Manual
16
List of Spare Parts of Wiring Diagram of the machine
Symbol
Articel
Description
RLE
302-22-018
Electronic circuit
FSM
302-03-006
Flap motor
TPE
302-01-071
Brass terminal block of grounding
PS1
302-22-020
4-poles socket of working surface
PS2
302-02-009
Socket
PS3
302-27-004
Socket for buck with cable
TM1
302-22-072
Power supply terminal block
TM2
302-22-073
Flap moter terminal block
TM3
302-22-008
Bouton pedal terminal block
CV
302-26-005
302-00-014
Cable of power supply 3Χ1.5mm with plug
Cable of power supply 5Χ1.5mm
LS
302-22-074
Indicator light overheating motor
K1
302-00-010
Relay motor fuse
FS
302-22-075
Cicuit safety fuse 2,5 A
F52
302-22-075
PC Board safety fuse 2,5 A
MB
302-26-006
Blowing Bouton
MV2
302-26-006
Suction Bouton
SI
308-00-006
Operation ON-OFF switch
SII
302-00-017
Working surface table ON-OFF switch
SII
302-00-017
Buck’s heating operation switch ON-OFF
14th klm Thessaloniki –Kilkis, 57200 Liti, T
hessaloniki, Greece

Instruction Manual
17
Tel.: [phone] Fax : +30
For any advice about the operation of the machine or the spare parts, please contact the
dealer you have purchased the machine from or us directly at:
14th klm Thessaloniki –Kilkis, 57200 Liti, Thessaloniki, Greece
Tel.: [phone] Fax : [phone]
E-mail : [e-mail]
All specifications have been made to the best of our knowledge.
Primula S.A preserves the right to make changes to the system and its parts without prior
notice.
23940 71 438
E-mail : info@primuthe best of our knoTECHNICAL ASSISTANCE
TECHNICAL ASSISTANCE
