Prince 7000 User manual

Prince Global Sports
3280 Peachtree Road NE, Suite 2000
Atlanta, Georgia 30305
United States of America
PRINCE 7000 – 6 Point
ELECTRONIC STRINGING MACHINE
OWNER’S MANUAL

2
TABLE OF CONTENTS
COMPONENTS
…………………..
3 & 4
ASSEMBLY INSTRUCTIONS
…………………..
5 & 6
MOUNTING THE FRAME
…………………..
7
KEYBOARD FUNCTION
…………………..
8
MAINTENANCE TIPS + WARRANTY
…………………..
9 & 10

3
SLR06
SOM8x25SUS
SCB4x8
SLR06
SOM8x20
SLR05
SOM6x20
SOM8x40
SLR06
Remove all parts from the shipping container carefully.
Save the container and packing for future storage or
shipment.
Components

4
From left to right:
1. Parallel Plier
2. String Bed Cutter
3. Awl
4. Straightening Awl
5. Starting Clamp
6. Screw Driver for Calibration
7. Cutter
Various Pads for 6 point mounting holders
Top :
Tennis clamps
Bottom :
Squash / Badminton clamps

5
A
B
C
A. Attach bottom Plate to the Stand with 4 screws with 5mm Allen wrench. Use screws attached to
the Stand.
B. Attach white Power connection to the plug in of the Stand.
C. Turn around fully mounted Stand.
D
E
F
D. Position the Platform over the center of the stand. Guide Power Cable through center hole.
E. Once the Platform is centered on center of the Stand, secure it with 4 cap screws (8mm x 20mm)
using 6mm L-shaped Allen wrench.
F. Remove cover on the bottom of the Platform. 4 screws need to be removed with screw driver.
G
H
I
G. Put Tension Head on the Platform. Connect 2 cables with the plug ins of the Tension Head. Fix
screw by hand of each cable connector
H. Shows second cable that need to be connected.
I. Slide in the Tension Head onto the platform until it sits flat on the Platform.
ASSEMBLY INSTRUCTIONS

6
J
K
L
J. Fix the Tension Head to the Platform with 4 screws using 6mm L-shaped Allen wrench.
K. Fix the bottom cover which has been removed under F with 4 screws and screw driver.
L. Put the Mounting Table onto the Platform and fix with 4 screws while using the 6mm L-shaped
wrench
M
N
O
M. Plug In the Power Plug at the bottom of the Stand.
N. Push the Power Button at the Tension Head. If everything is connected the Power Button will turn
on the machine and show a green light. Display will turn on too.
O. Use Power Plug (Black Button on the Bottom of the Stand) on the side for LED lights at the Stand.
The crank on side of the Stand will adjust the height. The crank is removable.

7
A
B
C
A. Adjust each Mounting Tower with the bottom screw.
B. Adjust the 6 & 12 o’clock holders with the outside adjustment screw (smaller one) to fix the
racquet.
C. Adjust the side arms with the bigger inside adjustment screw to fix the frame from the sides
D
E
F
D. Once the frame is fixed start stringing from the center of the frame. Move towards the outside to
each side by pulling each individual main string
E. Use the clamps to keep the tension on each string. Use Tennis specific clamp for Tennis racquets,
use Squash/Badminton clamp for those frames
F. Fix clamp base after every tension pull to make sure clamp base does not move and to keep the
tension.
G
H
I
G. Lock the clamp to fix the string inside the clamp
H. Lock the clamp base to keep the pulled tension
I. Use 2 awl holder for the Awl and straightening AWL
Mounting a frame

8
LBS / KGS :
Select kgs or lbs by pressing the LBS/KGS button for 3 seconds to switch.
TENSION :
Adjust the tension setting by pressing the
↑
and
↓
arrows on the control panel.
SPEED OF PULL :
Select LOW/MED/HIGH by pushing the SPEED button. It is recommended to use the
low speed with low elongation strings such as Kevlar, or strings of a more fragile
nature such as natural gut. The medium speed is well suited for polyester type
strings, and the high speed is suited for nylon based string types.
PRE-STRETCH :
The amount the machine pulls beyond the desired tension before setting back to
that tension. Many stringers like to pre-stretch strings to reduce the amount of
tension loss. Select the amount of pre-stretch by pushing the PRE-STRETCH button.
KNOT :
Press the Knot Button to have the machine making one pull with +10% increased
tension
MUTE :
Press the Mute Button if you do not want to hear the BEEP sound while pulling the
tension
BRAKE :
Press the Brake button for 3 sec. to switch between automatic or manual break.
Automatic means that with every tension pull the break will lock. Manual means
that the stringer decides by pushing the button when the break locks in.
Display Functions

9
1.
2.
3.
1. Cleaning the machine
a. String clamps, string clamp rails, and speed jaws must be cleaned regularly with alcohol to
minimize string slippage.
b. If the string clamp base slips after cleaning rails turn the base adjustment screw 1/8 turn
clockwise using the 3mm L-shaped allen wrench.
c. Do not over tighten adjustment screw or damage may occur
2. Clamp Maintenance
a. To improve the life of your clamps, apply a small amount of grease to contact points
(picture #2). Open and close the clamp several times to distribute the grease. Wipe off
any excess grease before stringing.
b. Periodically check the 2 points to insure they remain greased. Apply grease to clamp
post, then wipe gently with a dry cloth leaving a thin film of grease on the surface. The
lubricated surface ensures a smooth operation and provides rust protection.
3. To calibrate the machine, remove the knob on the right side of the Tension Head / Display. Use
screw driver out of the tool kit to adjust the correct pulling tension. Additionally needed is a pulling
scale that is not delivered with the machine.
AS WITH ANY MACHINE WITH MOVING PARTS AND ELECTRONIC POWER, SIGNIFICANT INJURY CAN
OCCUR IF PROPER CARE IS NOT EXCERCISED WHEN USING THE PRINCE 7000 STRINGING MACHINE.
THIS MACHINE IS ONLY TO BE UTILIZED IN STRICT COMPLIANCE WITH THE INSTRUCTIONS SET FORTH
IN THIS MANUAL.
Maintenance Tips

10
For all service and warranty questions please contact:
Western Hemisphere:
Tennis Machines Sales & Services
8131 Delmar Blvd
University City, MO 63130
800-572-1055
[e-mail]
http://www.tennismachines.com
Eastern Hemisphere:
Prince Global Sports International
Hill Place House 2nd Floor
55A High Street
Wimbledon Village SW19 5BA
United Kingdom
???@princeglobalsports.com
Warranty contacts
