Printronix L5520 Quick reference guide

176030-001A 1of2
L5520/L5535
Stacker Addendum
Overview
This Addendum describes tips for using and preventing jams in the
L5520/L5535 Stacker.
Using The Stacker
1. Before you start your print job, make sure the stacker tray is at the top
position by manually pushing it up as far as it will go.
2. Send your print job from the control panel, then immediately go to the
stacker tray.
3. As the paper exits the printer, it passes through the paper guide rollers
located at the top rear of the stacker. You must manually position the
paper so it will stack along its natural fold. If the first fold is correct, the
paper will continue to fold correctly and lay flat.
Natural Fold
of Paper
Paper Guide
Rollers
Stacker Tray

2of2 176030-001A
4. As the printed paper accumulates on the stacker tray, the tray descends
automatically.
5. As the paper stacks, the paper edges may swell out. Press down the
edges of the paper stack as needed, and position the flap lever as
needed.
6. To remove a finished job from the stacker, press the Table Down switch
to lower the tray, lift the stopper unit, and pick up your paper.
7. After removing the paper from the stacker, manually push up the stacker
tray as far as it will go.
A
A
Flap
Lever
Table Down
Switch
Stacker Tray
Stopper Unit
