Pro-Elec PELL0357 User manual

1
LED Floodlight with PIR - Black
Models: PELL0357, PELL0358, PELL0359
and PELL0360
Please read these instructions carefully before use and retain for future
reference.
This oodlights must be installed by a qualied electrician in accordance with current
building and IET wiring regulations (BS7671).
IMPORTANT SAFETY INFORMATION
• Do not use PVC cable to connect this oodlight to your wiring supply. Rubberised
cable (type H05RN-F), with three conductors of at least 1.0mm² cross-sectional
area must be used. This product must be connected to Earth.
• The front of this oodlight is made of tempered glass, replace if cracked.
• LED lamps are extremely bright. To avoid possible damage to the eyes, do not
stare into the LED beam.
• In use, avoid touching any external surface of the oodlight, due to the possibility
of high temperatures.
• Do not use near ammable materials.
• The oodlight must be positioned so that there is at least 1m between the front of
the light unit and the surface to be illuminated.
• It is suitable for use in an ambient temperature between -30°C and +45°C.

2
The oodlight has a beam angle of 120°. It can be tilted upwards and downwards at a
recommended angle of approximately 90°. The angle of adjustment will vary slightly
between models.
INSTALLATION
The oodlight is suitable for connection to a 220-240V 50Hz earthed AC supply. It is
designed for permanent connection to xed wiring, which must be a suitable circuit
protected by an RCD with an operating current not exceeding 30mA and an MCB or
fuse of the correct rating.
Mounting the Floodlight
• Before commencing installation, check that you have all of the tools you need.
• Check that the oodlight is not damaged. If there is any damage, return it to the
place of purchase. Do not attempt to repair it yourself.
• Choose your location to x the oodlight, taking into account the guidance above.
• Use the oodlight bracket to mark the position of the xing holes.
• Drill the xing holes and x the oodlight into position using appropriate size
screws and wall plugs (not provided). Check that it is securely xed.
• This oodlight is suitable for outdoor lighting applications, and domestic use only.
• Do not use in areas where an explosive or chemical atmosphere may exist. Do not
use in areas where ventilation is restricted.
• It is suitable for mounting on plasterboard, wood or masonry surfaces. Highly
ammable surfaces such as plastic or polystyrene must not be used.
• Do not install on damp or conductive surfaces such as metal. It should be placed
away from any ammable materials.
• Before drilling any xing holes, check that there are no hidden obstructions behind
the mounting surface such as pipes or cables.
• The recommended height for installation of the oodlight is between 0.5 and 3
metres.
• Ensure that there is space around the oodlight to allow adequate circulation of air.
• Orientation of the oodlight is important as shown below:
POSITIONING
Angle of Adjustment
90o
O
P
Beam Angle
120o

3
Wiring the Floodlight
• Ensure that the mains supply is isolated before commencing installation.
• A suitable rated connector must be used to connect the lead from the oodlight to
the mains supply.
• Connect the mains cable to the connector. Ensure that the correct polarities for
Live, Neutral and Earth are observed i.e.
- Green/yellow - Earth terminal
- Brown - Live terminal
- Blue - Neutral terminal
• After wiring, check that there are no stray strands and that all the wires have been
correctly installed.
• Before connecting power, perform the electrical tests specied in the current
Building and IET Wiring Regulation to ensure that the installation is safe and that
the wiring has been performed correctly.
• Restore the mains power supply and check that the oodlight illuminates the
required area. Tighten the oodlight using the bolts on the brackets.
CLEANING & MAINTENANCE
• Clean the oodlight only with a soft dry cloth. Do not use any chemicals, abrasives
or solvents that could damage the oodlight.
• The oodlight has a sealed LED lamp and is maintenance free. The LED lamp
cannot be replaced. When the LED lamp reaches the end of its life, the oodlight
will have to be replaced.
OPERATION
Time Sens Lux
• Adjusting the PIR Sensor
• There are three adjustments on the back of the PIR sensor, one adjusts the
duration the oodlight remain lit, the second one is for the sensitivity of movement
detection and the third is to set the level of ambient light before the sensor triggers
the illumination. Some trial and error may be required to set these correctly.
• Adjust the light level so the oodlight doesn’t activate until the light level is low
enough for oodlighting to be required.
• Adjust the timer setting for the required duration you require for the oodlight to
remain illuminated.

4
SPECIFICATION
Model PELL0357 PELL0358 PELL0359 PELL0360
Cable Length 0.5m 0.5m 0.5m 0.5m
Input Voltage 220-240V AC
50Hz
220-240V AC
50Hz
220-240V AC
50Hz
220-240V AC
50Hz
Luminous ux 720lm 1450lm 2200lm 3800Xlm
Wattage 10W 20W 30W 50W
Beam angle 120° 120° 120° 120°
Dimmable No No No No
Nominal lifetime
25,000h 25,000h 25,000h 25,000h
Light source SMD2835 SMD2835 SMD2835 SMD2835
Colour temperature 6000K 6000K 6000K 6000K
Ingress rating IP44 IP44 IP44 IP44
PIR Detection
Range 8M (±2M) max 8M (±2M) max 8M (±2M) max 8M (±2M) max
PIR Lux Adjustment <5-2000lux <5-2000lux <5-2000lux <5-2000lux
PIR Detection Angle 120° 120° 120° 120°
PIR Time Setting 10Sec (±3s) -
10min (±2min)
10Sec (±3s) -
10min (±2min)
10Sec (±3s) -
10min (±2min)
10Sec (±3s) -
10min (±2min)
Earthing Class I Class I Class I Class I
Weight 0.32kg 0.42kg 0.61kg 0.79kg
Dimensions WxHxD
(mm) 163x95x60 174x115x60
208x147x61 235x173x60
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.0
These products contain a light source of energy e󰀩ciency class F
