Pro-Form PFTL57807.0 User manual

Serial Number
Decal
Model No. PFTL57807.0
Serial No.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER’S MANUAL
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
Write the serial number in the space
above for future reference.
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
V
With Universal Dock for iPod®

TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
2
The decals shown here have been ap-
plied in the locations shown. If a decal
is missing or illegible, call the tele-
phone number on the front cover of
this manual and request a free re-
placement decal. Apply the decal in
the location shown. Note: The decals
may not be shown at actual size.
WARNING DECAL PLACEMENT
PROFORM is a registered trademark of ICON IP, Inc.
iPod®is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or persons
with pre-existing health problems.
2. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
Use the treadmill only as described.
3. Place the treadmill on a level surface, with at
least 8 ft. (2.4 m) of clearance behind it and 2
ft. (0.6 m) on each side. Do not place the
treadmill on any surface that blocks air open-
ings. To protect the floor or carpet from dam-
age, place a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should be used only by persons
weighing 300 lbs. (136 kg) or less.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothes while
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended
for both men and women.
Always wear ath-
letic shoes; never use the treadmill with bare
feet, wearing only stockings, or in sandals.
10. When connecting the power cord (see page
13), plug the power cord into a surge sup-
pressor (not included) and plug the surge
suppressor into a grounded circuit capable of
carrying 15 or more amps. No other appliance
should be on the same circuit. Do not use an
extension cord.
11. Use only a single-outlet surge suppressor that
meets all of the specifications described on
page 13. To purchase a surge suppressor, see
your local PROFORM dealer or call the tele-
phone number on the front cover of this man-
ual and order part number 146148, or see your
local electronics store.
12. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may change
speed, accelerate, or stop unexpectedly,
which may result in a fall and serious injury.
13. Keep the power cord and the surge suppres-
sor away from heated surfaces.
14. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See TROU-
BLESHOOTING on page 25 if the treadmill is
not working properly.)
15. Read, understand, and test the emergency
stop procedure before using the treadmill (see
HOW TO TURN ON THE POWER on page 15).
16. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
17. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
18. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
WARNING: Toreduce the risk of serious injury, read all important precautions and in-
structions in this manual and all warnings on your treadmill before using your treadmill. ICON as-
sumes no responsibility for personal injury or property damage sustained by or through the use of
this product.
IMPORTANT PRECAUTIONS

4
19. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and switch the reset/off cir-
cuit breaker to the off position when the
treadmill is not in use. (See the drawing on
page 5 for the location of the circuit breaker.)
20. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 23.)
You must be able to safely lift 45 lbs. (20 kg)
to raise, lower, or move the treadmill.
21. When folding or moving the treadmill, make
sure that the frame is held securely in the
storage position.
22. Never insert any object into any opening on
the treadmill.
23. Inspect and properly tighten all parts of the
treadmill regularly.
24. DANGER: Always unplug the power
cord immediately after use, before cleaning the
treadmill, and before performing the mainte-
nance and adjustment procedures described in
this manual. Never remove the motor hood un-
less instructed to do so by an authorized ser-
vice representative. Servicing other than the
procedures in this manual should be performed
by an authorized service representative only.
25. This treadmill is intended for in-home use
only. Do not use this treadmill in a commer-
cial, rental, or institutional setting.
SAVE THESE INSTRUCTIONS

5
Thank you for selecting the new PROFORM®7.0 PER-
SONAL FITNESS TRAINER treadmill with Universal
Dock for iPod®.The 7.0 PERSONAL FITNESS
TRAINER treadmill offers a selection of features de-
signed to make your workouts at home more effective
and enjoyable. And when you’re not exercising, the 7.0
PERSONAL FITNESS TRAINER treadmill can be folded
up, requiring less than half the floor space of other tread-
mills.
For your benefit, read this manual carefully before
using the treadmill.If you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model num-
ber and serial number before contacting us. The model
number and the location of the serial number decal are
shown on the front cover of this manual.
To avoid a registration fee for any service needed
under warranty, you must register the treadmill at
www.proformservice.com/registration.
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail
Upright
Key/Clip
Reset/Off
Circuit Breaker
Walking Belt
Platform Cushion
Foot Rail
Rear Roller
Adjustment Bolts
Console
Accessory Tray
Pulse Sensor

ASSEMBLY
Tohire an authorized service technician to assemble the treadmill, call 1-800-445-2480.
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to
the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the included hex keys and your own Phillips screwdriver ,
adjustable wrench , scissors , and needlenose pliers .
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number after the parentheses
is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it is preattached
to one of the parts to be assembled. Extra hardware may be included. To avoid damaging plastic parts,
do not use power tools for assembly.
Base Pad Spacer
(104)–2
M
M8 x 25mm Bolt (6)–4
M4.2 x 25mm
Screw (2)–4
M8 Star
Washer (10)–4
M4 x 20mm
Screw (3)–2
M10 Star
Washer (8)–4
M4.2 Star
Washer (70)–2
M4.2 x 19mm
Screw (1)–4 #10 x 1" Tek
Screw (76)–2
M10 x 96mm Bolt (5)–4
Bolt Spacer (79)–4
6

7
2. Remove the M10 Nut (33), the M10 x 50mm Bolt
(4), and the shipping bracket (C) from the Base
(85). Attach a Wheel (86) with the Bolt and the
Nut that you just removed. Do not overtighten
the Nut; the Wheel must turn freely. Discard
the shipping bracket.
85
4
33
C
2
86
1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (48) so that the treadmill is more stable;
do not fully fold the Frame yet.
Remove and discard the two indicated bolts (A)
and the shipping bracket (B).
Cut the tie securing the Upright Wire (77) to the
Base (85). Locate the tie in the indicated hole in
the Base, and use the tie to pull the Upright Wire
out of the hole.
Attach a Base Pad (81) to the Base (85) in the
location shown with a Base Pad Spacer (104)
and an M4.2 x 25mm Screw (2). Then, attach a
Base Pad (81) in the location shown with only an
M4.2 x 25mm Screw (2).
85
2
48 81
1
81 2
77
Hole
104
B
A

8
4. Hold a Bolt Spacer (79) inside the lower end of
the Right Upright (78). Insert an M10 x 96mm
Bolt (5) with an M10 Star Washer (8) into the
Right Upright and the Bolt Spacer. Repeat this
step with a second Bolt Spacer (79), M10 x
96mm Bolt (5), and M10 Star Washer (8).
Hold the Right Upright Spacer (80) and the
Right Upright (78) against the Base (85). Be
careful not to pinch the Upright Wire (77).
Tighten the M10 x 96mm Bolts (5) with your fin-
gers; do not fully tighten the Bolts yet.
Press a Base Endcap (82) into the Base (85).
80
78
77
8
82
79
79
5
4
85
3. Identify the Right Upright (78) and the Right
Upright Spacer (80), which are marked with
stickers. Insert the Upright Wire (77) through the
Right Upright Spacer as shown.
See the inset drawing. Tie the wire tie in the
Right Upright (78) securely around the end of
the Upright Wire (77). With the help of a second
person, hold the Right Upright near the Base
(85). Then, pull the other end of the wire tie until
the Upright Wire is routed completely through
the Right Upright.
85
77
78
80
77
3
Wire
Tie
78
77
Tie

5. With the help of a second person, carefully tip
the treadmill onto its right side. Partially fold the
Frame (48) so the treadmill is more stable; do
not fully fold the Frame yet.
Remove and discard the two indicated bolts (A)
and the shipping bracket (B).
Attach a Base Pad (81) to the Base (85) in the
location shown with a Base Pad Spacer (104)
and an M4.2 x 25mm Screw (2). Then, attach a
Base Pad (81) in the location shown with only
an M4.2 x 25mm Screw (2).
Remove the M10 Nut (33), the M10 x 50mm
Bolt (4), and the shipping bracket (C) from the
Base (85). Attach a Wheel (86) with the Bolt and
the Nut that you just removed. Do not over-
tighten the Nut; the Wheel must turn freely.
Discard the shipping bracket.
5
85
86
48
4
33
C
81
2
81
104
2
6. With the help of a second person, hold a Bolt
Spacer (79) inside the lower end of the Left
Upright (73). Insert an M10 x 96mm Bolt (5) with
an M10 Star Washer (8) into the Left Upright
and the Bolt Spacer. Repeat this step with a
second Bolt Spacer (79), M10 x 96mm Bolt
(5), and M10 Star Washer (8).
Orient the Left Upright (73) and the Left Upright
Spacer (83) as shown. Hold the Left Upright
Spacer and the Left Upright against the Base
(85). Tighten the M10 x 96mm Bolts (5) with
your fingers; do not fully tighten the Bolts yet.
Press a Base Endcap (82) into the Base (85).
With the help of a second person, tip the tread-
mill so that the Base (85) is flat on the floor.
83
73
5
85
7982
8
6
7. Set the Console (87) face down on a soft sur-
face to avoid scratching the Console. Remove
the six M4.2 x 19mm Screws (1). Save all six
Screws for step 9.
Lift off the Pulse Support (109).
1
1
1
7
87
109
9
B
A

10
8. Identify the Right Handrail (90), which has a
large hole in the location shown. Hold the Right
Handrail near the Console (87).
Insert the tie on the console wire into the large
hole in the Right Handrail (90) and out of the top
as shown; use needlenose pliers if necessary.
Next, insert the included plastic tie through the
Right Handrail as shown. Make sure that the
plastic tie holds the console wire against the
inner side. Then, tighten the plastic tie.
Attach the Right Handrail (90) with two M4.2 x
19mm Screws (1). Make sure that no wires are
pinched. Start both Screws before tightening
either of them; do not overtighten the
Screws. Then, remove the plastic tie.
Attach the Left Handrail (not shown) to the
Console (87) in the same way. Note: There are
no wires on the left side of the Console.
90
Tie
8
1
1
Large Hole
Console
Wire
Plastic Tie
87
9. Hold the Pulse Support (109) near the Console
Base (88). Connect the Console Ground Wire
(40) on the Pulse Support to the ground wire on
the Console Base. Then, insert the ground wires
into the Console Base and set the Pulse
Support on the Console Base. Make sure that
no wires are pinched.
Tighten two M4 x 20mm Screws (3) with two
M4.2 Star Washers (70) into the Pulse Support
(109).
Tighten the six M4.2 x 19mm Screws (1) from
step 7 into the Pulse Support (109) and the
Console Base (88). Start all six Screws before
tightening any of them.
3
70
Ground
Wire
1
1
70
1
1
9
88
109
40
3

11
10. Remove the plastic ties from the Right Handrail
(90) and the Left Handrail (not shown). If neces-
sary, press the Cage Nuts (38) into place.
Have a second person hold the console assem-
bly near the Right Upright (78). Remove the long
tie from the Upright Wire (77) and the tie from the
console wire.
Connect the Upright Wire (77) to the console
wire. See the inset drawing. The connectors
should slide together easily and snap into
place. If they do not, turn one connector and
try again. IF THE CONNECTORS ARE NOT
CONNECTED PROPERLY, THE CONSOLE
MAY BE DAMAGED WHEN THE POWER IS
TURNED ON. Then, insert the connectors into
the Right Upright (78).
Set the console assembly on the Right Upright
(78) and the Left Upright (not shown). Make sure
that no wires are pinched.
78
Console Assembly
Console
Wire
Long
Tie
77
10
11. Finger tighten two M8 x 25mm Bolts (6) with two
M8 Star Washers (10) into the Left Upright (73)
and the Left Handrail (89).
Next, finger tighten two M8 x 25mm Bolts (6)
with two M8 Star Washers (10) into the Right
Upright (78) and the Right Handrail (90). Then,
tighten all four Bolts.
See steps 4 and 6. Tighten the M10 x 96mm
Bolts (5).
Press the Left Accessory Tray (110) and the
Right Accessory Tray (111) into the Console
Base (88).
6
6
6
10
10
88
110
111
73
89
90
78
10
10
11
77
90
Console
Wire
6
38
Plastic
Ties

12
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Keep the included hex keys in a secure place; the large hex key is used to adjust the walking belt (see
pages 26 and 27).
12. Attach the Latch Housing (71) to the Left Upright
(73) with two #10 x 1" Tek Screws (76). Make
sure that the large hole in the Latch Housing
is on the side shown. Do not overtighten the
Latch Screws.
Locate the Latch Pin (72). Remove the knob
from the Latch Pin. Make sure that the collar
and the spring are on the Latch Pin. Then, insert
the Latch Pin into the Latch Housing (71), and
tighten the knob back onto the Latch Pin.
76
Spring
Knob
71
12
73
72
Collar
Large
Hole
If you purchase the optional chest pulse sensor (see page 22), follow the steps below to install the re-
ceiver included with the chest pulse sensor.
1. Make sure that the power cord is unplugged.
Remove the indicated M4.2 x 16mm Screw (12)
and the Access Door (116) from the Console
Base (88).
2. Connect the wire on the receiver (A) to the indi-
cated wire extending from the Console Base
(88). Hold the receiver so the small cylinder
is oriented as shown and is facing the
Console Base. Attach the receiver to the plastic
posts on the Access Door (116) with the two in-
cluded small screws.
3. Make sure that no wires are pinched.
Reattach the Access Door (116) with the M4.2 x
16mm Screw (12). Discard the other wires in-
cluded with the receiver.
A
116
Small
Cylinder
12
88
Wire
Small
Screws

13
OPERATION AND ADJUSTMENT
THE PRE-LUBRICATED WALKING BELT
Your treadmill features a walking belt coated with high-
performance lubricant. IMPORTANT: Never apply sil-
icone spray or other substances to the walking
belt or the walking platform. Such substances will
deteriorate the walking belt and cause excessive
wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge
suppressor with your treadmill (see drawing 1 at
the right). To purchase a surge suppressor, see
your local PROFORM dealer or call the telephone
number on the front cover of this manual and order
part number 146148, or see your local electronics
store.
Use only a single-outlet surge suppressor that is
UL 1449 listed as a transient voltage surge sup-
pressor (TVSS). The surge suppressor must have a
UL suppressed voltage rating of 400 volts or less
and a minimum surge dissipation of 450 joules.
The surge suppressor must be electrically rated for
120 volts AC and 15 amps. There must be a moni-
toring light on the surge suppressor to indicate
whether it is functioning properly. Failure to use a
properly functioning surge suppressor could result
in damage to the control system of the treadmill. If
the control system is damaged, the walking belt
may change speed, accelerate, or stop unexpect-
edly, which may result in a fall and serious injury.
This product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord into a surge suppressor,
and plug the surge suppressor into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Important: The treadmill is not compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
DANGER: Improper connection
of the equipment-grounding conductor can
result in an increased risk of electric shock.
Check with a qualified electrician or service-
man if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product—if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin

1414
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features designed to make your workouts more effec-
tive and enjoyable.
When you use the manual mode, you can change the
speed and incline of the treadmill with the touch of a
button. As you exercise, the console will display instant
exercise feedback. You can even measure your heart
rate using the handgrip pulse sensor or the optional
chest pulse sensor (see page 22).
In addition, the console features eight personal trainer
workouts. Each workout automatically controls the
speed and incline of the treadmill as it guides you
through an effective exercise session.
The console also features a fitness journal, which auto-
matically records and stores your exercise information
so that you can view your workout history and track
your progress.
You can even listen to your favorite workout music or
audio books with the console’s premium stereo sound
system while you get in shape. This product has been
designed specifically to work with iPod and has been
certified by the developer to meet Apple performance
standards.
To turn on the power,follow the steps beginning on
page 15. To personalize the console settings,see
page 15. To use the manual mode of the console,
see page 17. To use a personal trainer workout, see
page 19. To view the fitness journal,see page 20.
To reset the fitness journal, see page 21. To use
the stereo sound system,see page 21. To use the
information mode,see page 22.
IMPORTANT: If there are sheets of clear plastic on
the console, remove the plastic. To prevent damage
to the walking platform, wear clean athletic shoes
while using the treadmill. The first time you use the
treadmill, observe the alignment of the walking
belt, and center the walking belt if necessary (see
page 27).
Note: The console can display speed and distance in
either miles or kilometers. To find out which unit of
measurement is selected or to change the unit of mea-
surement, see THE INFORMATION MODE on page
22.For simplicity, all instructions in this section refer to
miles.
Key
Clip
CONSOLE DIAGRAM

15
HOW TO TURN ON THE POWER
IMPORTANT: If the treadmill has been exposed to
cold temperatures, allow it to warm to room tem-
perature before turning on the power. If you do not
do this, the console displays or other electrical
components may become damaged.
Plug in the power cord
(see page 13). Next, lo-
cate the reset/off circuit
breaker on the treadmill
frame near the power
cord. Switch the circuit
breaker to the reset posi-
tion.
IMPORTANT: The console features a display demo
mode, designed to be used if the treadmill is dis-
played in a store. If the display lights as soon as
you plug in the power cord and switch the circuit
breaker to the reset position, the demo mode is
turned on. To turn off the demo mode, hold down
the Stop button for a few seconds. If the display re-
mains lit, see THE INFORMATION MODE on page
22 to turn off the demo mode.
Next, stand on the foot rails of the treadmill. Find the
clip attached to the key (see the drawing on page 14)
and slide the clip onto the waistband of your clothes.
Then, insert the key into the console. After a moment,
the display will light. IMPORTANT: In an emergency
situation, the key can be pulled from the console,
causing the walking belt to slow to a stop. Test the
clip by carefully taking a few steps backward; if the
key is not pulled from the console, adjust the posi-
tion of the clip.
HOW TO PERSONALIZE CONSOLE SETTINGS
The console has a user mode that allows you to desig-
nate yourself as User 1 or User 2, enter user informa-
tion before you begin exercising, and select console
settings. The user information you enter will also be
recorded and stored in the fitness journal, which allows
you to view your workout history (see HOW TO VIEW
THE FITNESS JOURNAL on page 20).
Follow the steps below to personalize console settings.
1. Select the user mode.
The console can store information and keep track
of workout history for two different users.To select
the user mode, press the Enter button.
When you select the user mode, the word LOGIN
will appear in the display for a few seconds and
then the user mode menu will appear.
Important: To highlight options within a menu,
press the up, down, left, or right Navigation
(NAV) buttons. To select options within a
menu, press the Enter button.
Note: To exit the user mode at any time, press the
Back button repeatedly until the manual mode is se-
lected (see step 2 on page 17). To re-enter the user
mode from the manual mode, press the Enter but-
ton.
2. Enter user information.
To enter your user information, first highlight the
SETUP option and press the Enter button. The
setup menu will then appear in the display.
Next, highlight the SETUP USER 1 or SETUP USER
2option and press the Enter button. The user infor-
mation menu will then appear in the display.
Reset
Position

16
You can now enter your name and your weight.
Highlight the desired option in the menu and press
the Enter button. A cursor will appear in a field in
the display. To enter a number or letter above the
cursor, press the up and down Navigation buttons.
To move the cursor, press the left and right
Navigation buttons. When you have finished enter-
ing the desired numbers or letters in the field,
press the Enter button. Repeat this action to enter
all the desired user information. Note: For more in-
formation about the RESET JOURNAL option, see
page 21.
To exit the user information menu, highlight the
SAVE AND EXIT option and press the Enter but-
ton.
3. Select a default user setting.
The console can record, store, and load informa-
tion for two different users. The default user setting
allows you to choose the user information that will
be loaded and recorded when you turn on the con-
sole at the beginning of a workout session.
To select a default user setting, first highlight the
SELECT DEFAULT USER option in the setup
menu and press the Enter button. A list of default
user options will then appear in the display.
To select a default user option, press the up and
down Navigation buttons until an arrow appears
next to the desired option. Then, press the Enter
button. When you select an option, an “x” will ap-
pear in the box next to the selected option.
Note: You can also turn on or turn off the welcome
screen from this menu. If the SHOW WELCOME
SCREEN option is selected, then a welcome mes-
sage with the name of the selected user will ap-
pear in the display each time you turn on the con-
sole. To turn on or turn off the welcome screen,
highlight the SHOW WELCOME SCREEN option
and press the Enter button.
To exit the default user menu, press the Back but-
ton. The setup menu will then appear in the dis-
play.
4. Set the date and time.
Setting the date and time will allow the console to
record your workout history accurately in the fit-
ness journal.
To set the date and time, first highlight the
CHANGE DATE OR TIME option in the setup
menu and press the Enter button. The date setting
will then appear in the display.
To set the date, first press the left and right
Navigation buttons to highlight the month, day, or
year field. Then, press the up and down Navigation
buttons to select the desired month, day, or year.
When you have finished setting the date, press the
Enter button. The time setting will then appear in
the display.
To set the time, first press the left and right
Navigation buttons to select the hour or minute
field. Then, press the up and down Navigation but-
tons to select the desired hour or minute; make
sure to select the correct AM or PM time in the
hour field. When you have finished setting the
time, press the Enter button. The console will then
exit the user mode.

HOW TO IDENTIFY YOURSELF AS USER 1 OR
USER 2
The console can load information and keep track of the
workout history for two different users. To identify your-
self as User 1 or User 2 for a workout session, first
press the Enter button and enter the user mode.
The word LOGIN will appear in the display for a few
seconds and then the user mode menu will appear.
Press the up and down Navigation buttons to highlight
USER 1 or USER 2. Note: If you have personalized the
console settings (see page 15), then the name you en-
tered will appear instead of USER 1 or USER 2.
Press the Enter button to confirm your choice. The
console will then exit the user mode.
HOW TO USE THE MANUAL MODE
1. Insert the key into the console.
See HOW TO TURN ON THE POWER on page 15.
2. Select the manual mode.
When the key is inserted, the manual mode will be
selected. If a personal trainer workout has been se-
lected, remove the key and then reinsert it. Note:
To turn on or turn off the welcome screen, see step
3on page 16.
3. Start the walking belt.
To start the walking belt, press the Start button, the
Speed increase button, or one of the Precision
Quick Speed buttons numbered 1 through 10.
If you press the Start button or the Speed increase
button, the walking belt will begin to move at 1 mph.
As you exercise, change the speed of the walking
belt as desired by pressing the Speed increase and
decrease buttons.Each time you press a button,
the speed setting will change by 0.1 mph; if you
hold down a button, the speed setting will change
in increments of 0.5 mph. Note: After you press a
button, it may take a moment for the walking belt to
reach the selected speed setting.
If you press one of the numbered Precision Quick
Speed buttons, the walking belt will gradually
change speed until it reaches the selected speed
setting.
To stop the walking belt, press the Stop button. To
restart the walking belt, press the Start button or the
Speed increase button.
17

4. Change the incline of the treadmill as desired.
Tochange the incline of the treadmill, press the
Incline increase and decrease buttons. Each time
you press the Incline increase and decrease but-
ton, the incline will change by 0.5%. Note: After you
press an Incline button, it may take a moment for
the treadmill to reach the selected incline setting.
5. Select a display mode and monitor your
progress with the display.
As you walk or run on the treadmill, the display can
show the following workout information:
•The elapsed time.
•The distance that you have walked or run.
•The speed of the walking belt.
•The approximate number of calories you have
burned.
•The date.
•A1/4-mile (400 meter) track. As you walk or run,
indicators will appear in succession around the
track until the entire track appears. The track will
then disappear and the indicators will again begin
to appear in succession.
•The incline level of the treadmill.
•Your heart rate. Note: Your heart rate will be
shown only when you use the handgrip pulse
sensor or the optional chest pulse sensor (see
step 6).
•An animation of a runner.
When the manual mode is selected, the console of-
fers three display modes. Press the Display button
repeatedly to select the desired display mode.
Regardless of which display mode you select, the
speed or incline setting will appear in the display for
afew seconds each time you change the setting. In
addition, your heart rate will appear in the display
each time you use the handgrip pulse sensor or the
optional chest pulse sensor.
To reset the console, press the Stop button, re-
move the key, and then reinsert the key.
6. Measure your heart rate if desired.
Note: If you use the handgrip pulse sensor and
the optional chest pulse sensor at the same
time, the display will not show your heart rate
accurately.
Before using the
handgrip pulse
sensor, remove
the sheets of
clear plastic from
the metal con-
tacts on the pulse
bar. In addition,
make sure that
your hands are
clean.
To measure your heart rate, stand on the foot
rails and hold the pulse bar with your palms on the
metal contacts. Avoid moving your hands.When
your pulse is detected, a heart symbol will flash in
the display and then your heart rate will be shown.
For the most accurate heart rate reading, con-
tinue to hold the contacts for about 15 seconds.
7. When you are finished exercising, remove the
key from the console.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
setting. The incline must be at the lowest setting
or you may damage the treadmill when you fold
it to the storage position. Next, remove the key
from the console and put it in a secure place.
When you are finished using the treadmill,switch
the reset/off circuit breaker to the “off” position and
unplug the power cord. IMPORTANT: If you do
not do this, the treadmill’s electrical compo-
nents may wear prematurely.
Contacts
18

HOW TO USE A PERSONAL TRAINER WORKOUT
1. Insert the key into the console.
See HOW TO TURN ON THE POWER on
page 15.
2. Select a personal trainer workout.
To select a personal trainer workout, press the
Personal Trainer Workouts button repeatedly. The
name, maximum incline setting, duration, and max-
imum speed setting of the workout will appear in
the display. In addition, a profile of the speed set-
tings of the workout will appear in the display.
3. Press the Start button or the Speed increase
button to start the workout.
Amoment after you press the button, the treadmill
will automatically adjust to the first speed and in-
cline settings of the workout. Hold the handrails and
begin walking.
Each workout is divided into one-minute segments.
One speed setting and one incline setting are pro-
grammed for each segment. Note: The same
speed setting and/or incline setting may be pro-
grammed for consecutive segments.
A profile of the speed settings of the workout will ap-
pear in the display. A small arrow below the profile
will indicate your progress.
At the end of the first one-minute segment of the
workout, a series of tones will sound. If a different
speed setting and/or incline setting is programmed
for the second segment, the speed setting and/or
incline setting will flash in the display for a moment
to alert you. The treadmill will then automatically
adjust to the speed and incline settings for the sec-
ond segment and the arrow will move one segment
to the right.
The workout will continue in this way until the arrow
reaches the right end of the profile. The walking
belt will then slow to a stop.
If the speed or incline setting for the current seg-
ment is too high or too low, you can override the
setting by pressing the Speed or Incline buttons;
however, when the next segment begins, the
treadmill will automatically adjust to the speed
and incline settings for the next segment.
To stop the workout at any time, press the Stop
button. To restart the workout, press the Start but-
ton. The walking belt will begin to move at 1 mph.
When the next segment of the workout begins, the
treadmill will automatically adjust to the speed and
incline settings for the next segment.
4. Select a display mode and monitor your
progress with the display.
See step 5 on page 18.
5. Measure your heart rate if desired.
See step 6 on page 18.
6. When you are finished exercising, remove the
key from the console.
See step 7 on page 18.
19

HOW TO VIEW THE FITNESS JOURNAL
1. Insert the key into the console.
See HOW TO TURN ON THE POWER on page
15.
2. Identify yourself as User 1 or User 2.
See page 17.
3. Select the fitness journal.
To select the fitness journal, press the iFit
Fitness Journal button. The console will then load
the stored journal information for the selected user.
To enter the date and time, see page 16.
Note: As you view the fitness journal, press the
Back button at any time to return to the previous
menu or display.
The fitness journal can display the following exer-
cise information for the current year:
Time—The total number of hours you have walked
or run on the treadmill.
Distance—The total distance you have walked or
run on the treadmill.
Calories—The approximate total number of calo-
ries you have burned.
Average Speed—Your average walking or running
speed.
Average Pace—Your average walking or running
pace in minutes per mile or per kilometer.
Vertical Feet—The distance you have climbed in
feet or meters.
Weight—Your weight, as entered in your user in-
formation.
4. View exercise information by year.
When you select the fitness journal, the year totals
will appear in the display.
To view exercise information for a different year,
press the up and down Navigation buttons to
change the year. Note: The fitness journal can
store information for 11 different years.
5. View exercise information by month.
After several seconds, the view month menu will
appear in the display.
To view exercise information by month, press the
up and down Navigation buttons to highlight the
desired month in the right side of the display. Then,
press the Enter button. The exercise information
for the selected month will appear in the display.
6. View exercise information by week.
After several seconds, the view week menu will ap-
pear in the display.
To view exercise information by week, press the up
and down Navigation buttons to highlight the de-
sired week in the right side of the display. Then,
press the Enter button. The exercise information
for the selected week will appear in the display.
7. View exercise information by day.
After several seconds, the view day menu will ap-
pear in the display.
To view exercise information by day, press the left
and right Navigation buttons until an arrow appears
above the desired day in the right side of the dis-
play. Then, press the Enter button. The exercise
information for the selected day will appear in the
display.
8. Continue to view the fitness journal as
desired.
Repeat steps 4 through 7 to view exercise informa-
tion for the desired year, month, week, or day.
9. Exit the fitness journal.
Press the iFit Fitness Journal button to exit the fit-
ness journal at any time.
Note: To delete the exercise information stored in
the fitness journal, see HOW TO RESET THE FIT-
NESS JOURNAL on page 21.
20
