Congratulations on your purchase
of a Pro-line Commercial Vacuum Sealer.
Note: Please read through the instructions carefully before using or installing the product and ensure that the
manual is kept in a safe place for future reference.
The system must be properly installed and located in accordance with the installation instructions before it is used.
During the set up of this product if you have any questions / comments / issues DO NOT RETURN TO STORE.
FOR SERVICE AND TECHNICAL ADVICE VISIT WWW.PROLINEAUSTRALIA.COM.AU/CONTACT
Electrical Requirements:
Australia / New Zealand 220-240V 50Hz
Due to manufacturing alterations product may
vary slightly from that pictured.
Pro-line Australia
PO Box 4187
Norwood South LPO
South Australia 5067
Email: [e-mail]
Web: www.prolineaustralia.com.au
Find us
/prolineaustralia
/proline_australia
/proline_australia

INSTALLATION AND OPERATING INSTRUCTIONS 3
• All components need to be installed in accordance with the
user manual instructions for correct performance of unit.
READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATION OF THE UNIT
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Remove and safely discard any packaging material and
promotional labels before using the Vacuum Sealer for the
first time.
• Do not operate appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in
any manner.
• If the cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
• Do not use appliance for other than intended use.
• Do not pull or carry the Vacuum Sealer by the cord.
• This appliance should be used in conjunction with a safety
switch.
• To protect against risk of fire, electric shock and personal
injury, do not immerse cord, plugs, or appliance in water or
other liquid.
• Fully unwind the power cord before use. Connect only to
220V/240V power outlet.
• Position the appliance at a minimum distance of 20cm away
from walls, curtains and other heat or steam sensitive
materials and provide adequate space above and on all sides
for air circulation.
• Switch unit off and unplug from wall outlet when not in use
and before cleaning.
• Do not use attachments not recommended or sold by the
manufacturer as it may lead to fire, electric shock or injury.
• Operate unit on a stable level flat surface, keep away from
moving parts. Ensure surface is clean and free from water etc.
• Do not place the unit near the edge of a bench or table during
operation.
• Do not place the unit near an oven, heater, direct sunlight or
any other heat source.
• If an extension cord is used with this unit, the extension cord
must have a rating equal to the rating of this appliance.
OPERATION CONDITIONS & SAFETY PRECAUTIONS

4INSTALLATION AND OPERATING INSTRUCTIONS
• When disconnecting cord, to avoid injury, unplug by grasping
the plug and not the cord and ensure your hands are dry.
• Appliance does not require or use any lubricants, such as
lubricating oils or water.
• Do not use outdoors or on wet surfaces.
• Do not use appliance for other than intended purpose.
• Clean the Vacuum Sealer Lower and Upper Gaskets, Vacuum
Chamber regularly. Also ensure these parts are cleaned
immediately after handling raw meat, poultry or fish.
• Do not reuse the Vacuum Sealer bags after using with raw
meat, fish or poultry or after the bag has been heated, i.e.
microwave or simmer.
• Keep the Vacuum Sealer bags away from babies and children
to eliminate a choking and suffocation hazard.
• Do not leave the Vacuum Sealer unattended when in use.
• Keep the appliance clean. Follow the cleaning instructions
provided in this Instruction book.
• Before cleaning, always turn the appliance OFF, switch off at
the power outlet, unplug at the power outlet and remove the
power cord, if detachable, from the appliance and allow all
parts to cool.
• After use of the Food Vacuum, leave machine cover open for
unit to cool down before closing cover.
• Use only Vacuum Sealer bags/rolls or specially designed
vacuum bags with this appliance.
IMPORTANT: Do not store or leave appliance for extended
periods with the cover closed and locked into position. It will
cause the gaskets and sealing profile to become compressed and
compromise the sealing ability of the unit. To store the unit start
with the cover in the open position, pull the cover lock handle
down and then close the cover. This will prevent the cover from
locking into place and enable it to be stored.
WARNING: BURN HAZARD. Sealing profile will be hot after use, allow
profile to cool before touching.
Do not wash canister or marinate bowl lids. Wipe it clean with a
soft damp cloth.
System Specifications
Vac Pro Commercial
Model Code VS-C3
Product Dimensions 403 (L) X 196 (W) X 120 (H) mm
Product Weight 2.5KG
Power 220-240V ~ 50Hz, 130W
Noise <72 dB
Max vacuum pressure -0.90 Bar Max.
Air extraction volume 20 Litres / MIN

INSTALLATION AND OPERATING INSTRUCTIONS 5
14
VACUUM SEALER PARTS IDENTIFICATION
1. Control Panel
2. Vacuum Seal Hose Port
3. Cover Lock Handle
4. Sealing Strip
5. Upper Gasket
6. Vacuum Seal Hose Holder
7. Roll Storage Compartment
8. Bag & Roll Cutter
9. Air Intake
10. Sealing Profile*
11. Vacuum Chamber
12. Removeable Drip Tray
(Inside Vacuum Chamber)
13. Lower Gasket
14. Cord Storage
*Do not remove Teflon Tape
from Sealing Profile
3 5
4
7
10111213
8
9
1 2
6

6INSTALLATION AND OPERATING INSTRUCTIONS
CONTROL PANEL
1. Sealing Time
2. Vacuum Pressure
3. Vacuum & Seal /
Cancel
4. Progress Indicator
5. Manual Seal
6. Canister
7. Marinate
8. Pulse
Sealing
Dry Moist Extended Normal Gentle
Pressure Manual
Seal
Vac&Seal
Cancel
Canister
Working Process
Marinate Pulse
4
5 6 7321 8

INSTALLATION AND OPERATING INSTRUCTIONS 7
Ref Description
1. Sealing Time
Dry: For dry items without moisture - shorter heat sealing time
Moist: For moist items with little liquid - longer heat sealing time
Extended: For very moist/wet items - extended heat sealing time
Default setting is Dry
2. Vacuum Pressure
Normal: For regular items requiring normal vacuum pressure
Gentle: For soft and crushable items where less vacuum pressure
is desired
Default setting is Normal
3. Progress Indicator
Displays the progress of the seal and vacuuming process
4. Vacuum & Seal / Cancel Button
In stand-by mode, pressing the Vac & Seal button starts the automatic
vacuum operation then automatically seals the bag when vacuum is
complete
Pressing the Cancel button stops the vacuuming or sealing function
Ref Description
5. Manual Seal
For sealing the open end of a bag without vacuuming - useful for making
a bag from a roll
When the Vac & Seal function is in operation, this button stops the vacuum
pump and immediately starts to seal the bag
6. Canister
To vacuum canisters. See ‘Storing Food in Canisters’ section
7. Marinate
To marinate using the Marinate Bowl. See ‘Marinating Food with Marinate
Bowl’ section
8. Pulse
Press and hold and the unit will start vacuuming; release the button and
the vacuuming stops.
Used when better control of the vacuum process is required to prevent the
crushing of delicate foods and avoid very wet items drawing moisture into
the machine
CONTROL PANEL DESCRIPTION

8 INSTALLATION AND OPERATING INSTRUCTIONS
MAKING A BAG FROM A VACUUM ROLL
Note: Refer to the diagrams on the next page.
1. Place a Vacuum Roll into the Roll storage compartment.
2. Lift the Bag and Roll Cutter to the back.
3. Unroll the Roll to the desired length and put the Bag and Roll
Cutter back down.
Note: You will require at least 5cms of bag material more than the
item as this extra part will form the seal.
4. Slide the cutter from one end to the other to cut the Roll.
5. Put one end of the bag on top of the Sealing Profile, but not
into the Vacuum Chamber.
6. Close and pull the Cover Lock Handle down to lock the lid.
7. Press the “Manual Seal” button to start sealing the bag. The
indicator light will confirm its operation.
8. When the indicator turns off, the sealing is done. Press the
handle to open the cover and take the bag out of the machine.
The bag is then ready for vacuum sealing.
WARNING: BURN HAZARD – Sealing Profile may be hot after
sealing, do not touch.
Head to our website to view our full range of
Vacuum Sealer accessories at:
www.prolineaustralia.com.au/shop
VS-283 Proline Vacuum Rolls
VS-283 comes in a 3 pack
3 x 28cm wide and 5.4m long
Proline Vacuum Rolls and Bags lock in the freshness
and are BPA Free, Boil, Freezer and Microwave Safe.
These Premium Quality Rolls and Bags use dual
cross venting technology to provide you with superior
consistent results.

INSTALLATION AND OPERATING INSTRUCTIONS 9
1 2
6
3
7
4
85

10 INSTALLATION AND OPERATING INSTRUCTIONS
Note: Refer to the Figures on the next page.
1. Prepare a bag to be vacuum sealed.
Note: Do not overload the bag. Always allow enough space at
the open end of the bag to be properly placed into the Vacuum
Chamber.
2. Open the unit and insert open end of the filled bag into the
Vacuum Chamber over the Sealing Profile. Ensure the Air
Intake is not covered by the bag.
See Fig 1
Note:
Ensure no items or food is covering the Sealing Profile and
make sure bag has no wrinkles or ripples that will inhibit the seal.
Note: The Vacuum Chamber draws air out of the bag and catches
any liquid overflow in the Removeable Drip Tray. Lower Gasket,
Removeable Drip Tray and Vacuum Chamber should be cleaned
regularly. Always ensure these parts are cleaned immediately after
handling raw meat, poultry or fish.
3. Close and pull the Cover Lock Handle down to lock the lid.
See Fig 2
4. Check the LED indicator light of the Sealing button and
Pressure button to confirm that the moisture (Dry/Moist/
Extended) and pressure (Normal/Gentle) status is set
according to the type of food to be packaged.
5. Press the Vac & Seal button. The unit will start to vacuum
and will seal the bag automatically. Wait for indicator lights to
switch off before opening cover.
See Fig 3 and 4
6. Refrigerate or freeze sealed food bag if needed.
7. Before repeating with a new bag and food item, always wipe
away any excess liquid or food residue in the vacuum chamber.
IMPORTANT: Do not store or leave appliance for extended
periods with the cover closed and locked into position. It will
cause the gaskets and sealing profile to become compressed and
compromise the sealing ability of the unit. To store the unit start
with the cover in the open position, pull the cover lock handle
down and then close the cover. This will prevent the cover from
locking into place and enable it to be stored.
STORING FOOD IN VACUUM BAGS

INSTALLATION AND OPERATING INSTRUCTIONS 11
Fig 1 Fig 3Fig 2 Fig 4

12 INSTALLATION AND OPERATING INSTRUCTIONS
1. Ensure canisters are clean and dry.
Note: Do not immerse canister lids in water, clean with a damp
cloth only.
2. Fill canister with the item to be stored and secure lid onto the
canister.
Note: Leave at least 2cm from canister cover rim, and make sure
upper lid is securely on before vacuuming.
3. Turn canister lid dial arrow to SEAL.
4. Connect one end of the Vacuum Seal Hose to the Vacuum Seal
Hose Port, located on the right hand side of the Control Panel,
and the other end to the Vacuum Seal Canister Lid. Ensure
both connections are pushed in tightly.
See Fig 1
5. Check that the Pressure setting is on ‘Normal’. Press the
Canister button on the Control Panel to draw out air from
Canister. Vacuum action will stop automatically when all air
has been drawn out from canister.
6. Remove Vacuum Seal Hose connection to the canister.
7. To open canister after vacuum packaging, turn the canister
lid dial arrow to OPEN. Wait several seconds for the lid to be
released before removing.
Note: Canister lids are not to be used in microwaves or in freezers.
STORING FOOD IN CANISTERS
Fig 1

INSTALLATION AND OPERATING INSTRUCTIONS 13
1. Place the food and marinade into the Marinate bowl.
2. Secure the lid onto the Marinate Bowl.
Note: Leave at least 2cm from the top
3. Turn marinate bowl lid dial arrow to SEAL.
4. Connect one end of the Vacuum Seal Hose to the Vacuum Seal
Hose Port and the other end to the Marinate Bowl Lid. Ensure
both connections are pushed in tightly.
5. Press the Marinate Button on the control panel to begin
vacuum process.
Note: The default vacuum speed is Normal.
6. The pump will cycle applying vacuum and then turn off. After a
few minutes it will release and allow air to enter the container,
the pump will then come on and apply vacuum again. This
cycle will repeat throughout the marinating process.
7. When the Marinate indicator light turns off, the process is
complete.
8. Remove Vacuum Seal Hose connection to the Marinate Bowl.
9. To open the Marinate bowl turn the lid dial arrow to OPEN.
Wait several seconds for the lid to be released before
removing.
Note: Marinate bowl not to be used in microwave, freezer or oven.
MARINATING MEAT WITH MARINATE BOWL USING PULSE VACUUM FUNCTION
1. Press and hold the Pulse button to start vacuuming, releasing
the button will stop the vacuum function.
See Fig 1
Continue as needed - observing carefully to ensure delicate
food is not being crushed and to avoid very wet items drawing
moisture into the machine.
2. Once the desired pressure is achieved, press the Manual Seal
button to seal the bag.
See Fig 2
Fig 1 Fig 2

14 INSTALLATION AND OPERATING INSTRUCTIONS
1. Do not overload the bag; leave enough space at the open end of the
bag so that the bag can be easily placed over the Sealing Profile and
in the Vacuum Chamber.
2. To avoid overfilling, always leave at least 5cm of bag material
between bag contents and top of bag. Then leave at least one
additional 2cm of bag material for each time you plan to reuse bag.
3. Clean and straighten the open end of the bag before sealing. Make
sure nothing is left on the open area of the bag and the bag has no
wrinkles or creased lines. Foreign objects or a creased bag may
cause difficulty in sealing the bag tightly.
4. Do not vacuum package objects with sharp points like fish bones and
hard shells! Sharp points may penetrate and tear the bag! You may
want to cover the sharp points with an additional piece of film, or use
a canister instead of a bag.
5. Allow the appliance to cool down for one minute between each
sealing operation.
6. Clean the Vacuum Chamber and Gaskets after each vacuuming
operation.
7. When using a canister, remember to leave 2cm from canister cover
rim, and make sure the upper lid is already locked before vacuuming.
IMPORTANT: Do not reuse the Vacuum Sealer bags after using with raw
meat, fish or poultry or after the bag has been heated, i.e. microwave
or simmer.
The Vacuum Sealer will change the way you purchase and
store food. The Vacuum Sealer removes air from the specially
designed Vacuum Sealer bags and canisters to create a
commercial quality vacuum.
The ease and convenience of preserving and extending the
freshness of your food with the Vacuum Sealer will become an
indispensable part of your food preparation.
The Vacuum Sealer removes air from specially designed bags
and canisters to extend food freshness up to 5 times longer than
conventional storage methods.
Oxygen and moisture in air causes food to degrade over time, by
removing the air before sealing items airtight the Vacuum Sealer
extends the life of food naturally.
Vacuum Sealing is not intended to replace the refrigeration or
freezing of foods, food should still be refrigerated or frozen if
normally required.
IMPORTANT: It is best to Vacuum Seal fresh food, Vacuum
Sealing will not restore or revive food past its prime. Do not
consume food that has gone bad.
HINTS FOR BEST VACUUMING PERFORMANCE FOOD STORAGE/PRESERVATION GUIDELINES

INSTALLATION AND OPERATING INSTRUCTIONS 15
Freezer Conventional
Storage
Pro-line
Vacuum Sealer
Beef, Pork or Lamb 6 months 2-3 years
Minced Meat 4 months 1 year
Poultry 6 months 2-3 years
Fish 6 months 2 years
Soups, Stews, Sauces 3-6 months 1-2 years
Vegetables 8 months 2-3 years
Berries 1-2 months 6-8 months
Fridge Conventional
Storage
Pro-line
Vacuum Sealer
Semi Hard Cheeses
(Swiss, Cheddar) 1-2 weeks 4-8 months
Hard Cheeses (Parmesan) 1-2 weeks 4-8 months
Lettuce, Spinach 3-6 days 2 weeks
Avocado (cut) 1-2 days 5-6 days
Blueberries 3-6 days 2 weeks
Other berries (Blackberries,
Strawberries, Raspberries) 1-3 days 1 week
Pantry Conventional
Storage
Pro-line
Vacuum Sealer
Nuts 6 months 2 years
Coffee Beans 6 months 1 year
Rice 6 months 2 years
Flour 6 months 1-2 years
Sugar 6 months 1-2 years
Chips 1-2 weeks 3-6 weeks
Cookies, Crackers 1-2 weeks 3-6 weeks
FOOD PRESERVATION CHART
Note: Storage preservation chart are estimates only and should be
used as a guide only. The storage life will depend on the original
quality of the foods and the integrity of the packages seal.

16 INSTALLATION AND OPERATING INSTRUCTIONS
• Before Vacuum Sealing, it is necessary to clean your hands,
and all utensils and surfaces to be used for cutting and
Vacuum Sealing foods.
• Refrigerate or freeze perishable foods immediately, if they
have been vacuum sealed do not leave them sitting at room
temperature.
Note: It may be harmful if you consume foods which have been left
out at room temperature.
• Store dry foods such as nuts, biscuits or cereals, in a cool,
dark dry place.
• Vacuum Sealed bags prevent freezer burn. Foods that thaw
easily should be placed at the back of the freezer where the
temperature is more constant. When thawing foods it is best
to thaw foods in the refrigerator. Never thaw meats, poultry,
fish or dairy at room temperature or in hot water. If thawing
food by microwave, foods should be cooked immediately after
processing to prevent bacteria growth.
• VACUUM SEALER Vacuum Bags and Rolls are MICROWAVE
safe, to microwave cut off one corner of the bag so that steam
can escape and place in microwave.
• VACUUM SEALER Vacuum Bags and Rolls are SIMMER/BOIL
safe. Place bag into pot of boiling water with the top of the bag
above the water for easy removal.
Note: Bags or rolls are not reusable if they have been microwaved
or simmered/boiled.
• To Freeze SOUPS and SAUCES pour liquid into a bag, allowing
at least 8cm of space at the top of the bag (this allows space
for expansion of liquid when frozen and sealing space for
the bag). Do not seal at this point. Place the filled liquid bag
upright into a freezer, when liquid is frozen, remove bag from
freezer and Vacuum Seal.
• Vacuum Sealing FRUITS, for best results pre-freeze cut soft
fruit prior to vacuum sealing. This helps prevent the fruit from
being crushed during the vacuum process.
• VEGETABLES, for best results blanch vegetables in hot water
otherwise they may turn black. Blanch so that vegetables are
still crunchy, then transfer immediately into icy cold water to
cool. Drain and separate into convenient portions then vacuum
seal in bags.
• Vacuum Sealing POULTRY and whole FISH, for best results
wash poultry and pat dry with a paper towel. Then place foods
between two paper towels inside bag before Vacuum Sealing.
The paper towels helps to absorb excess moisture and juices.
• Vacuum Sealing red MEATS and fish fillets, for best results pat
dry with a paper towel. Then place foods between two paper
towels inside bag before Vacuum Sealing. The paper towels
helps to absorb excess moisture and juices.
HINTS & TIPS

INSTALLATION AND OPERATING INSTRUCTIONS 17
Note: Vacuum Sealing may cause meat to darken. This is due to the
removal of oxygen and does not indicate spoilage.
• The Vacuum Sealer Home Vacuum Sealer can also protect
NON-FOOD ITEMS from oxidation, corrosion and moisture.
Simply store and seal items in a Vacuum Sealer Vacuum Bag
and follow the “Storing Food in a Vacuum Bag” instructions.
• Vacuum Seal items to help keep them dry, and take up
less room for storage. e.g. camping, batteries, important
documents, travelling and emergency equipment.
• Vacuum seal wet paint brushes between paint jobs without
cleaning, it keeps them moist and saves on clean up time.
• Use the Canisters to store DELICATE ITEMS such as berries,
biscuits and salad leaves or use to store sauces or soups.
• The Marinate Bowl is a great solution for marinating meats
in minutes, not hours, as Vacuum Sealing opens the pores in
foods such as meat, poultry and seafood’s allowing foods to
absorb marinades in a fraction of the time.
• For the busy family, on-the-go meals can be prepared ahead
and Vacuum Sealed in individual servings, and ready to heat
anytime.
• Prepare foods in advance for picnics and camping trips or
barbecues.
• To make an ICE PACK, pour water into a bag, allowing at
least 8cm of space at the top of the bag (this allows space for
expansion of liquid when frozen and sealing space for the bag).
Do not seal at this point. Place the filled liquid bag upright into
a freezer, when liquid is frozen, remove bag from freezer and
Vacuum Seal. Use for ice in the cooler, or ice packs for sports
injuries.
• Primarily the Vacuum Sealer is used for vacuum sealing,
however you are able to reseal foil based bags such as chip
and biscuit bags using the Manual Seal function.
HINTS & TIPS

18 INSTALLATION AND OPERATING INSTRUCTIONS
The condition of the Upper Gasket and Lower Gasket parts on
your Vacuum Sealer are critical to the forming of an air tight seal
around the bag when the cover is locked in position.
Food debris or deformation of the gaskets due to the machine
being stored in the locked position can affect the ability of the
machine to evacuate air from the bag successfully.
To prevent this:
• Always store the machine in an unlocked position. To do this
start with the cover in the open position, pull the cover lock
handle down to the lock position but with the cover still open.
Then close the cover. This will enable you to shut the unit but
not deform the gaskets.
• Regularly inspect the Upper and Lower Gaskets to ensure they
are clean, in good condition and not deformed (compressed).
Spare Gaskets can be purchased from
www.prolineaustralia.com.au/accessories
If your machine is failing to remove air from the bag, it may be due
to the gaskets. If this happens:
1. Inspect Upper and Lower Gasket and ensure they are clean
and in good condition and that they sealed correctly.
2. If no damage is apparent the gaskets may be deformed
(compressed).
3. Remove the gaskets, turn upside down and replace back into
the machine.
4. If these steps fail then replace the gaskets with a replacement
kit from Proline Australia. Part VS-C3-Gasket.
Spare Gaskets can be purchased from
www.prolineaustralia.com.au/accessories
STORING YOUR VACUUM PRESERVATION SYSTEM
Keep the unit in a flat and safe place, out of the reach of children.

INSTALLATION AND OPERATING INSTRUCTIONS 19
It is important to ensure that all parts of your Vacuum Sealer
sealing system is cleaned on a regular basis.
Follow the care and cleaning guidelines below:
1. Always unplug the unit before cleaning.
2. Do not immerse appliance in water or any other liquid.
3. Do not use abrasive cleaners to clean the unit.
4. Wipe the outside of the unit with a damp cloth, sponge or mild
dish soap.
5. Wipe away food residue and water inside or around component
with a paper towel.
6. Dry thoroughly before use.
Cleaning Vacuum Bags:
Note: Do not reuse the Vacuum Sealer bags after using with
raw meat, fish or poultry or after the bag has been heated, ie
microwave or simmer.
1. Wash bag material in warm water with a mild dishwashing
soap.
2. Alternatively, Bags can be washed on the top rack in your
dishwasher by turning the bag inside out. Stand bags up so
that the washing water can rinse the entire surface.
Cleaning Gaskets:
Remove Lower and Upper Gasket from its indentation location
and wash with warm soapy water then rinse thoroughly. Ensure
Gaskets are completely dry before installing back into indentation
location.
IT IS IMPORTANT that the Gaskets are not out of shape or damaged
in any manner otherwise air tight seal will not be formed when
cover is closed.
Cleaning Accessories:
(Including canister base and hose accessories.)
1. Wash all vacuum accessories in warm water with a mild
dishwashing soap
(except canister lids.)
2. Canisters (not lids) are top rack dishwasher safe. Canister and
marinate bowl lids should be wiped down with a damp cloth
and must not be immersed in water.
3. Ensure all accessories are thoroughly dried before use.
Note: Canister lids are not to be used in microwaves or in freezers.
CLEANING AND MAINTENANCE

20 INSTALLATION AND OPERATING INSTRUCTIONS
TROUBLE SHOOTING
BEFORE YOU EMAIL FOR SERVICE PLEASE REVIEW THE TROUBLE SHOOTING TIPS FIRST.
Problem Possible Cause Solution
Nothing happens when I
press the vacuum sealer
1. Power cord is not plugged in.
2. Power cord is damaged.
1. Make sure the power cord is correctly plugged into the
electrical outlet, and in the “on” position.
2. Check power cord and plug, and make sure they are not
damaged in any way. If damaged, do not use the vacuum sealer.
Air is not removed from the
bag completely
1. The bag has not been placed
correctly inside the Vacuum
Chamber.
2. Debris covering sealing strip
or upper and lower gaskets.
Sealing strip gaskets may be out
of place.
3. Bag may have a hole.
4. Unit cover has not been closed
properly.
1. To seal properly, open end of bag should be resting entirely
inside the Vacuum Chamber.
2. Check sealing strip, upper gasket and lower gasket
for debris. Ensure Gaskets are correctly sealed and
are not compressed. See page 15 for further information on
Gaskets.
3. To test, seal the bag with some air in it, submerge in water, and
apply pressure. If there are bubbles present, it does indicate a
leak and a new bag should be used.
4. Open cover and re-close the cover. Push down firmly on the
cover until you hear it ‘click’ indicating the cover is now fully
closed and locked in.
