PRO SIGNAL PSG03927 User manual

Audio Pre-Amplier
PSG03927
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future reference.
When using electrical appliances basic safety precautions should always be followed.
• To prevent re or shock hazard, do not expose this product to rain or moisture.
• Beware that usage for long periods at high volume levels may cause fatigue and
hearing damage.

OPERATION
• The Pre-Amplier allows the use of a magnetic stereo phono cartridge with an
amplier that does not have a dedicated phono input.
• The Pre-Amplier has RIAA compensation designed for low noise.
• Connect the turntable output leads to the L and R input RCA sockets on the pre-
amplier.
• Connect the pre-amplier L and R outputs to the L and R input (Aux/CD/Tuner) on
an amplier and select that input.
• Switch the power on with the slide switch on the end of the unit.
• If unused for long periods turn the power off to prolong battery life. For very long
periods, remove the battery.
NOTE: if the sound quality deteriorates the battery may require changing.
• To change the battery remove the screws and unclip the cover.
• Disconnect the power connector from the old battery and replace it with a new one
reconnecting the power lead, noting the polarity.
OVERVIEW
CLEANING & MAINTENANCE
• Clean the casing with a soft cloth lightly moistened with a mild detergent.
• Never use any abrasive or solvents.
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL & ELECTRONIC
EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic Equipment (WEEE).
Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment,
recovery and recycling of the materials used. Contact your local authority for details of recycling schemes in your area.
Made in Taiwan
PR2 9PP
Man Rev 1.0
SPECIFICATIONS
Connections Standard RCA Stereo L and R sockets
Input Impedance 50k ohms
Amplitude Gain 34dB
Rated Input Level 3mV (Max 38mV)
Output Level 1.8V RMS
Frequency Response 30Hz - 20kHz +/- 1dB
Compensation RIAA with deviation <+/-1dB
S/N Ratio 50dB with normal input
Crosstalk Better than 50dB
Current Drain 1mA average
Battery Type 9VDC PP9
