PRO SIGNAL PSG90934 User manual

USB 3.0 Active Repeater Lead
PSG90934 & PSG90935
Table of Contents
1.0 Introduction.............................................................................................. 1
2.0 Specifications ...........................................................................................1
3.0 Panel Descriptions ...................................................................................2
4.0 Connection and Operation...................................................................... 2

Please read these instructions carefully before use and retain for future
reference.
When using electrical appliances basic safety precautions should always be
followed.
Do not expose this product to rain or moisture.
1.0 INTRODUCTION
This is a USB3.0 Active Cable with a 5 m cable at the input side and a USB3.0
A type female port at the output side.
It can extend the super speed signals up to 13m max total by connecting an 8m high
quality USB3.0 cable to the output port.
1.1 FEATURES
This USB3.0 Active Cable has many features that enable it to perform in a
superior manner. Among those features you will find:
•Super speed USB3.0 supports 5Gbps data rate, over 10 times of USB2.0
Performance.
•Compatible with USB 3.0/2.0/1.1.
•Support the following speed data rate as follows: Low-speed (1.5Mbps)
Full-speed (12Mbps) / High-speed (480Mbps) / Super-speed (5Gbps).
•Active USB extender cable ensures signal transmission stability.
•Hot plug capability.
•Extend single up to max 13 m.
•Support Windows/MAC OS.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Signal
USB3.0
Output Signal
USB3.0
Operating Frequency
Bandwidth
Max up to 5Gbps
Environmental
Operating Temperature
0℃to +70℃
Operating Humidity
10% to 80 % RH (no condensation)
Storage Temperature
-10℃to +80℃
Storage Humidity
5% to 90 % RH (no condensation)
Contents
User Manual
1 off
Cable
1 off
Note: Specifications are subject to change without notice.
１

3.0 CONNECTOR DESCRIPTIONS
①Device
Connect this port to devices such as HDD, SSD, U disk, etc.
②Host Source
Connect this port to PC/Notebook/Laptop.
4.0 CONNECTION AND OPERATION
4.1 CONNECTION
1) Connect the “Host” side of USB3.0 Active Cable in to the USB3.0 port on PC
or other source device.
2) Connect the “Device” side of USB3.0 active cable to USB 3.0 device by one
USB3.0 A type male to A type male or Micro USB female cable.
5.1 TYPICAL CONNECTION DIAGRAM
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household
waste, but kept separate for the treatment, recovery and recycling of the materials used. Contact
your local authority for details of recycling schemes in your area.
Made in China.
PO Box 13362 Dublin 2
PR2 9PP
２
