Pro Work AS 12 User manual

AS 12
Operating Instructions
Battery-powered Drill/Screwdriver
with Adjustable Torque
Art.-Nr.: 45.125.22 I.-Nr.: 01013
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 1


Important: Read and note the operating
instructions and safety regulations before
using!
Please pull out pages 2
2
Items supplied:
1 battery-powered drill/screwdriver
1 removable battery pack
1 battery charger
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 2

Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 3

Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 4

5
GB
Tool illustration:
Figure 1: Torque adjustment facility
Figure 2: Bit holder
Figure 3: Forward / Reverse selector switch
Figure 4: On/Off switch
Figure 5: Removable battery pack; press both
clips to take out the battery pack
Important notes:
It is imperative to read these notes before putting
your battery-powered drill/screwdriver into operation:
1. The removable Ni-Cd battery pack supplied
with your battery-powered drill/screwdriver has
to be charged before you use the tool for the
first time.
2. Charge the battery pack with the supplied
charger. It takes approx. 6 hours to charge an
empty battery. Never use the supplied charger
to charge any other tools or appliances.
3. The battery pack reaches its maximum capacity
after approx. five discharge/charge cycles.
4. Ni-Cd batteries will also discharge when they
are not in use. It is recommended, therefore, to
charge the batteries regularly.
5. Please note the data quoted on the rating plate
of the battery charger. Operate the charger only
from the same mains voltage as that quoted on
the rating plate.
6. In periods of heavy duty the battery pack will
grow warm. Allow the battery pack to cool to
room temperature before starting to charge it.
Safety regulations:
1. Protect your battery-powered drill/screwdriver
and charger from the damp and rain.
2. Keep the charger and battery-powered
drill/screwdriver safe from children.
3. Use only sharp drill bits and undamaged,
properly fitting screwdriver bits.
4. Wear suitable working clothes and safety
goggles.
5. Never use the battery-powered drill/screwdriver
and charger in the vicinity of vapours and
combustible liquids.
6. Look for concealed electric cables, gas pipes
and water pipes before drilling and screwdriving
in walls.
7. Never throw old batteries into an open fire. Risk
of explosion!
8. Old and defective batteries do not belong in the
refuse bin. Think of the environment! Cadmium
is toxic. For correct disposal, return old and
defective batteries postage-paid to ISC or
take them to your local old battery depot. Ask at
your town hall for details of the old battery
depots in your area.
9. Avoid contact with leaky batteries. Should
contact arise nevertheless, wash the affected
area of skin immediately with soap and water. If
battery acid gets in your eye, rinse the eye with
clear water for at least 10 minutes and consult
a doctor immediately.
10. Protect the charger and its cable from damage
and sharp edges. Damaged cables are to be
replaced immediately by an electrician.
11. Examine your tool for any signs of damage.
Have repairs carried out only by an electrician.
12. Make sure that the contacts of the Ni-Cd
battery pack do not touch other metallic objects,
e.g. nails and screws. Risk of short-circuiting!
Putting into operation:
Loading the Ni-Cd battery pack
1. Pull the battery pack out of the handle (Figure
5) by depressing the clips on the side.
2. Check that your mains voltage is the same as
that quoted on the rating plate. Insert the
charger in a socket-outlet and connect the
charging cable with the charging adapter.
3. Insert the battery pack in the charging adapter.
The red LED indicates that the battery pack is
being charged. It takes a maximum of 6 hours
to charge an empty battery. The battery pack
may grow warm while it is being charged. This
is normal. Important! The charger does not
switch off automatically when the battery
pack is fully charged!
If the battery pack fails to become charged, please
check
whether there is voltage at the socket-outlet
whether there is proper contact at the charging
contacts on the charger.
If the battery still fails to become charged, please
return
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 5

the charger
the battery pack
to our Customer Service Department.
Timely recharging of the Ni-Cd battery pack is
recommended in the interest of long battery life.
Recharging is always necessary when you notice
that the power of the battery-powered
drill/screwdriver is decreasing.
Never allow the battery pack to discharge
completely. This will result in damage to the Ni-Cd
battery pack!
Adjusting the torque (Figure 1)
The Einhell battery-powered drill/screwdriver is
equipped with a 16-step mechanical torque
adjustment facility. The torque for a specific size of
screw is selected with the set-collar (Figure 1). The
correct torque depends on several factors:
on the type and hardness of material in question
on the type and length screws used
on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
Drilling (Figure 1)
For drilling purposes, move the set-collar to the last
step „Drill“ (Figure 1). In this setting the slip clutch is
inactive. The maximum torque is available in drilling
mode.
Forward/Reverse switch (Figure 3)
With the slide switch above the On/Off switch you
can select the direction of rotation of the battery-
powered drill/screwdriver and secure it against being
switched on accidentally. You can choose between
clockwise and anticlockwise rotation. To avoid
causing damage to the gearing it is advisable to
change the direction of rotation only when the tool is
at a standstill. The On/Off switch is blocked when the
slide switch is in centre position.
Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
Technical data
Voltage supply 12 V =
Speed 550 rpm
Torque 16 levels
Forward and reverse rotation yes
Chuck clamping width 1.0 - 10 mm
Battery charging voltage 12 V =
Battery charging current 400 mA
Mains voltage for charger 230 V ~ 50 Hz
Sound pressure level LPA: 68,1 dB(A)
Sound power level LWA: 81,1 dB(A)
Weight of: 2,6 kg
Vibration a
– w< 2,5 m/s2
Old and defective batteries do not belong in the
refuse bin. Think of the environment! Cadmium is
toxic. For correct disposal, return old and defective
batteries postage-paid to ISC or take them to your
local old battery depot. Ask at your town hall for
details of the old battery depots in your area.
6
!

iNTERNATiONALESSERViCE CENTER GmbH

GB
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 6

7
EC ∆λωση περι της ανταπκρισης
Dichiarazione di conformità CE
EC Overensstemmelseserklæring
EU prohlášení o konformitě
EU Konformkijelentés
EU Izjava o skladnosti
Oświadczenie o zgodności z normami
Europejskiej Wspólnoty
Vyhásenie EU o konformite
EG Konformitätserklärung
EC Declaration of Conformity
Déclaration de Conformité CE
EC Conformiteitsverklaring
Declaracion CE de Conformidad
Declaração de conformidade CE
EC Konformitetsförklaring
EC Yhdenmukaisuusilmoitus
EC Konfirmitetserklæring
EC Заявление о конформности
Dichiarazione di conformità CE
Declaraţie de conformitate CE
AT Uygunluk Deklarasyonu
CZ
SLO
RUS
HR
98/37/EG
73/23/EWG
97/23/EG
89/336/EWG
90/396/EWG
89/686/EWG
87/404/EWG
R&TTED 1999/5/EG
2000/14/EG:
Landau/Isar, den 21.07.2003
Archivierung / For archives: 4512520-45-4141800-E
Karg
Produkt-Management
EN 60335-1; DIN VDE 0700-207; prEN 50260-1; prEN 50260-2-1; prEN 50260-2-2; EN 55014-1;
EN 55014-2; EN 61000-3-2; EN 61000-3-3
ISC GmbH
Eschenstraße 6
94405 Landau/Isar
Akkuschrauber AS 12
SK
Brunhölzl
Leiter produkt-Management
x
x
x
Der Unterzeichnende erklärt in Namen der Firma die Übe-
reinstimmung des Produktes.
The undersigned declares in the name of the company that
the product is in compliance with the following guidelines and
standards.
Le soussigné déclare au nom de l’entreprise la conformité du
produit avec les directives et normes suivantes.
De ondertekenaar verklaart in naam van de firma dat het pro-
duct overeenstemt met de volgende richtlijnen en normen.
El abajo firmante declara, en el nombre de la empresa, la
conformidad del producto con las directrices y normas
siguientes.
O signatário declara em nome da firma a conformidade do
produto com as seguintes directivas e normas.
Undertecknad förklarar i firmans namn att produkten över-
ensstämmer med följande direktiv och standarder.
Allekirjoittanut ilmoittaa liikkeen nimissä, että tuote vastaa
seuraavia direktiivejä ja standardeja:
Undertegnede erklærer på vegne av firmaet at produktet
samsvarer med følgende direktiver og normer.
Лодлисавшийся лодтверждает от имени фирмыб что
настояшее изделие соответствует требованиям
следующих нормативных документов.
Az aláíró kijelenti, a cég nevében a termék megegyezését a
következő irányvonalakkal és normákkal.
Subsemnatul declară În numele firmei că produsul core-
spunde următoarelor directive și standarde.
∑mzalayan kiµi, firma adına ürünün aµa©ıda anılan yönetme-
liklere ve normlara uygun olduµ©unu beyan eder.
∂Ó ÔӉ̷ÙÈ Ù˘ ÂÙ·ÈÚ›·˜ ‰ËÏÒÓÂÈ Ô ˘ÔÁÂÁÚ·Ì̤ÓÔ˜ ÙËÓ
Û˘Ìʈӛ· ÙÔ˘ ÚÔ˚fiÓÙÔ˜ ÚÔ˜ ÙÔ˘˜ ·ÎfiÏÔ˘ıÔ˘˜
ηÓÔÓÈÛÌÔ‡˜ Î·È Ù· ·ÎfiÏÔ˘ı· ÚfiÙ˘·.
Il sottoscritto dichiara a nome della ditta la conformità del
prodotto con le direttive e le norme seguenti.
På firmaets vegne erklærer undertegnede, at produktet imø-
dekommer kravene i følgende direktiver og normer.
Níže podepsaný jménem firmy prohlašuje, že výrobek odpo-
vídá následujícím směrnicím a normám.
Az aláíró kijelenti, a cég nevében a termék megegyezését a
következő irányvonalakkal és normákkal.
Podpisani izjavljam v imenu podjetja, da je proizvod v sklad-
nosti s slede ˇcimi smernicami in standardi.
Niżej podpisany oświadcza w imieniu firmy, że produkt jest
zgodny z następującymi wytycznymi i normami.
Podpisujúci záväzne prehlasuje v mene firmy, že tento
výrobok je v súlade s nasledovnými smernicami a normami.
LWM dB(A); LWA dB(A)
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 7

Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 8

Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 9

GARANTIEURKUNDE
Wir gewähren Ihnen zwei Jahre Garantie gemäß nachstehenden
Bedingungen. Die Garantiezeit beginnt jeweils mit dem Tag der
Lieferung, der durch Kaufbeleg, wie Rechnung, Lieferschein oder
deren Kopie, nachzuweisen ist. Innerhalb der Garantiezeit besei-
tigen wir alle Funktionsfehler am Gerät, die nachweisbar auf
mangelhafte Ausführung oder Materialfehler zurückzuführen
sind. Die dazu benötigten Ersatzteile und die anfallende Arbeits-
zeit werden nicht berechnet.
Ausschluß: Die Garantiezeit bezieht sich nicht auf natürliche Ab-
nutzung oder Transportschäden, ferner nicht auf Schäden, die in-
folge Nichtbeachtung der Montageanleitung und nicht norm-
gemäßer Installation entstanden. Der Hersteller haftet nicht für
indirekte Folge- und Vermögensschäden.
Durch die Instandsetzung wird die Garantiezeit nicht erneuert
oder verlängert. Bei Garantieanspruch, Störungen oder Ersatz-
teilbedarf wenden Sie sich bitte an.
ISC GmbH · International Service Center
Eschenstraße 6 · D-94405 Landau/Isar (Germany)
Info-Tel. [phone] (62 Ct/Min.) • Telefax 0 99 51-26 10 und 52 50
Service- und Infoserver: http://www.isc-gmbh.info
Technical changes subject to change
 EINHELL-WARRANTY CERTIFICATE
The guarantee period begins on the sales date
and is valid for 2 years.
Responsibility is assumed for faulty construction
or material or funcitional defects.
Any necessary replacement parts an necessary
repair work are free of charge.
We do not assume responsibility for
consequential damage.
Your customer service partner
Einhell UK Ltd
Morpeth Wharf
Twelve Quays
Birkenhead, Wirral
CH 41 1NG
Tel. [phone], Fax [phone]
EH 07/2003
Anleitung AS 12 GB Prowork 23.07.2003 8:28 Uhr Seite 10
