Parts Breakdown HM1211B
Page 1 of 3 2/8/2008

Parts Breakdown HM1211B
Fig # Part ID Part Name Quantity
1 151310-9 BARREL COMPLETE, HM1211B 1
2 922451-6 H.S.H. BOLT M8X30, LS1013 4
3 213655-4 O RING 56, HR3851 1
4 321732-9 STRIKER, HM1211 1
5 412049-2 PISTON RING 40, HM1211 1
6 341862-0 INNER RING 36, HM1211 1
7 412049-2 PISTON RING 40, HM1211 1
8 341862-0 INNER RING 36, HM1211 1
9 256120-0 PIN 10, HM1211 1
10 150041-7 CRANK CAP CPL., HM1211B 1
11 213754-2 O RING 71, HR5000 1
12 315419-3 CONNECTING ROD, HR5000 1
13 212208-6 N. BEARING 1516, HR5000 1
14 152180-9 CRANK SHAFT COMPLETE, HM1211 1
15 254001-2 WOODRUFF KEY 4, HM1303B 1
16 962251-2 RETAINING RING R-52, HR5000 1
17 211314-4 BALL BEARING 6304, HM1211,T1 1
17 211327-5 BALL BEARING 63604LLU, HR5000 1
18 213656-2 O RING 53, AN451 1
19 156863-3 CRANK HOUSING COMPLETE, HM1211B 1
20 213306-9 OIL SEAL 20, HM1211 1
21 221701-9 H. GEAR 50, HM1211 1
22 211209-1 BALL BEARING 6202, HM1211 1
23 256111-1 PIN 6, HM1500 1
24 157799-9 GEAR HOUSING, HM1211 1
25 321441-0 PISTON, HM1211 1
26 267059-2 F. WASHER 32, HM211B 1
27 261054-4 NYLON WASHER 32, HM1211 1
28 253845-7 F. WASHER 31, HM1211 1
29 213604-1 O RING 50, 6911D 1
30 322569-7 IMPACT BOLT, HM1211B 1
31 213472-2 X RING 35, HM1211 1
32 213464-1 O RING 34, HM1211 1
33 256219-1 PIN 4, HM1500 1
34 322570-2 TOOL RETAINER, HM1211B 1
35 322571-0 TOOL HOLDER, HM1211B 1
36 922451-6 H.S.H. BOLT M8X30, LS1013 4
37 231281-7 COMP. SPRING 15, HM1500 1
38 322699-4 RETAINING RING, HM1500 1
38 322560-5 RETAINER RING, HM1800 1
39 331180-4 SEAL, HM1211 1
40 213460-9 O RING 35, HM1500 1
41 211206-7 B. BEARING 6202LLB, NHP1310 1
42 213202-1 DUST SEAL 15, 5402A 1
43 241638-4 FAN 94, HM1211B 1
44 514776-8 ARMATURE ASS'Y 115V, HM1211B 1
44 514776-8 ARMATURE ASS'Y 115V, HM1211B 1
45 681624-7 INS. WASHER, HM1800,T1 1
45 681635-2 INSULATION WASHER, HM1211B 1
46 211066-7 B. BEARING 6200LLB, BO4552 1
46 211087-9 B. BEARING 6200DDW, JR3000V 1
47 213406-5 O RING 30, HR5000 1
48 410163-8 BAFFLE PLATE, HR3851 1
49 265347-1 HEX BOLT M5X45, HR3851 2
50 524631-6 FIELD ASS'Y 115V, HM1211B 1
52 857315-4 NAME PLATE, HM1211B 1
53 159034-1 MOTOR HOUSING , HM1211B 1
53 159034-1 MOTOR HOUSING , HM1211B 1
54 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
55 181048-2 CARBON BRUSH 155, HR5000 1
Page 2 of 3 2/8/2008

Parts Breakdown HM1211B
56 284055-5 REAR COVER, HR3851 1
57 942101-7 SPRING WASHER 5, 9005B 2
58 922221-3 HEX BOLT M5X16, 6906 2
58 922222-1 H.S.H. BOLT M5X16, HM1211B 2
59 922371-4 H.S.H. BOLT M6X50, HM1211 4
60 941151-9 F. WASHER 6, 5007NB 4
61 931302-2 HEX NUT M6, HR2400 1
62 942151-2 SPRING WASHER 6, 5007NB 1
63 941151-9 F. WASHER 6, 5007NB 1
64 911243-8 P.H. SCREW M5X25, GA7911 2
66 182564-7 HANDLE SET, HM1211B 1
67 911129-6 P.H. SCREW M4X16, HR5000 1
68 651145-3 SWITCH, HM1500B 1
69 421265-5 DUST COVER, HM1500 1
71 952257-8 SPLIT PIN 3-20, HM1303B 2
71 265439-6 HEX BOLT M8X150, HM1100C 1
72 343322-8 SIDE HANDLE, HM1211B,T1 1
72 416009-6 SIDE HANDLE, HM1100C 1
72 417003-1 SIDE HANDLE, HM1202C 1
74 417002-3 SIDE HANDLE CAM, HM1202C 1
74 416010-1 HANDLE BASE 60, HM1100C-T1 1
74 416396-3 HANDLE BASE 60,HM1100C 1
74 343321-0 GRIP BASE, HM1211B,T1 1
77 922316-2 HEX BOLT M6X14, HR3851 2
78 343755-7 CUSHION PLATE, HM1211 (T2) 2
79 182564-7 HANDLE SET, HM1211B 1
80 321210-9 HANDLE SHAFT, HR3851 1
81 682503-2 CORD GUARD 8-90, 9005B 1
81 682567-6 CORD GUARD 8, HM0810B 1
82 664658-5 CORD (3X18X16 SJ), HR2511 1
83 687001-1 STRAIN RELIEF, 6013BR 1
84 911133-5 P.H. SCREW M4X18, N9501B 2
85 645105-5 NOISE SUPPRESSOR, HK1800 1
86 685700-9 SPONGE SHEET, 9035KB 1
87 265914-2 H.S.H.BOLT M6X25, HM1211B 2
88 257636-8 SLEEVE 6, HR3851 2
89 262052-1 RUBBER RING 9, HR3851 2
90 262051-3 RUBBER RING, HR3851 2
91 152620-7 SIDE HANDLE BASE CPL.,HM1100C 1
91 344379-2 HANDLE SPRING 60, HM1100C-T1 1
91 344559-0 HANDLE SPRING 60,HM1100C-T1 1
92 252640-2 WING NUT M8, HM1100C 1
93 416396-3 HANDLE BASE 60,HM1100C 1
93 416010-1 HANDLE BASE 60, HM1100C-T1 1
93 417002-3 SIDE HANDLE CAM, HM1202C 1
94 819063-3 MAKITA LABEL, 6992DWDE 2
1,001 182700-5 STEEL TOOL CASE, HM1211B 1
1,001 150586-5 PLASTIC CASE, HM1211B 1
1,001 181997-3 N/A 1
1,002 783202-0 HEX WRENCH 4, JR3000V 1
1,004 835258-0 N/A 1
2,001 134793-8 SIDE HANDLE ASS'Y, HM1100C 1
2,001 134909-5 SIDE HANDLE ASSEMBLY,HM1100C 1
5,001 810227-2 N/A 1
