ProAG HD4SR User manual

K34987-04A
OPERATOR’S MANUAL
Auto Align Bale Skoop
Models HD4SR and 12SR

Table of Contents
Section 1:
Safety ............................................................................................................................1-1
Signal Words ................................................................................................................. 1-2
General Equipment Safety ............................................................................................ 1-3
General Equipment Safety Guidelines ....................................................................... 1-3
Lighting and Marking .....................................................................................................1- 4
Wheels and Tires ........................................................................................................... 1-4
Tire Safety .................................................................................................................. 1-4
Bale Skoop Operation Safety ........................................................................................ 1- 5
Before Operating ........................................................................................................ 1-5
During Operation ........................................................................................................ 1-6
After Operation (Storage) ........................................................................................... 1-7
Transport Safety ............................................................................................................. 1-8
Highway and Transportation Safety ............................................................................ 1- 8
Maintenance Safety ....................................................................................................... 1-9
Performing Maintenance ............................................................................................ 1-9
Safety Signs ................................................................................................................ 1-10
Safety Decals ........................................................................................................... 1-10
How to install a new decal ........................................................................................ 1-10
Reflector Location Guide .......................................................................................... 1-15
Decal Location Guide ............................................................................................... 1-17
Section 2:
Specifications ..............................................................................................................2-1
Machine Specifications ..................................................................................................2-2
HD4SR .......................................................................................................................2-2
12SR ..........................................................................................................................2-2
Noise Emissions ........................................................................................................2-2
Tractor Requirements .................................................................................................2-2
Tire Specifications ......................................................................................................2-2
Bale Size ....................................................................................................................2-2
Lubricants ..................................................................................................................2-2
Bale Skoop Dimensions ................................................................................................2-3
Section 3:
Checklist ......................................................................................................................3-1
Manuals .........................................................................................................................3-2
Pre-Operation Checklist.................................................................................................3-3
Pre-Operation Check ..................................................................................................3-3
Section 4:
Introduction .................................................................................................................4-1
Introduction ....................................................................................................................4-2
Section 5:
Operation .....................................................................................................................5-1
Tractor ............................................................................................................................5-3
Tires ...........................................................................................................................5-3
Hydraulics ..................................................................................................................5-3
Drawbar ......................................................................................................................5-3
Machine Conventions ....................................................................................................5-4
Auto Align Bale Runner Directional Conventions .......................................................5-4
Hooking Up for the First Time ........................................................................................5-5
Parts Needed .............................................................................................................5-5
Attach Bale Skoop to Tractor .......................................................................................5-5
Connect Safety Chain ................................................................................................5-6
HD4SR & 12SR October 2015 i

Table of Contents
Hooking Up Warning Light Assembly .........................................................................5-6
Lubricate Joints ..........................................................................................................5-6
Prime Hydraulic System .............................................................................................5-7
Pre-Operation Checklist.................................................................................................5-8
Pre-Operation Check ..................................................................................................5-8
Operation of Controls ....................................................................................................5-9
Setting up the Lever Controls .....................................................................................5-9
Hydraulic Sequencing and Lever Operation ...............................................................5-9
Building Stacks ............................................................................................................5-10
Starting Stacks .........................................................................................................5-10
Stacking ....................................................................................................................... 5-11
Gathering Bales........................................................................................................... 5-11
Approaching Bales ................................................................................................... 5-11
Loading Bales ..........................................................................................................5-12
If operating a 12SR model Auto Align Bale Skoop ...................................................5-12
Operating all models of Auto Align Bale Skoops ......................................................5-12
Transporting Bale Skoop ..............................................................................................5-13
Tips and Techniques ....................................................................................................5-14
Rotating Bales ..........................................................................................................5-14
Quarter Turning Bales ...............................................................................................5-14
Repositioning Bales .................................................................................................5-14
Tipping or Rolling Bales ...........................................................................................5-14
Stacking ...................................................................................................................5-15
Stacking bales of different sizes ...............................................................................5-16
Section 6:
Maintenance .................................................................................................................6-1
General ..........................................................................................................................6-2
Safety ............................................................................................................................6-2
Tighten Bolts .................................................................................................................6-3
Tires ..............................................................................................................................6-3
Preventative Maintenance .............................................................................................6-4
Hydraulic System Preventative Maintenance .................................................................6-4
Hydraulic Pressure Relief ..............................................................................................6-5
Daily Maintenance .........................................................................................................6-6
Daily Check ................................................................................................................6-6
General Maintenance ....................................................................................................6-7
General Check ...........................................................................................................6-7
To tighten Alignment Arm Chains ............................................................................6-7
Cylinder Repair ..........................................................................................................6-7
Bed Extensions ..........................................................................................................6-7
Electrical Maintenance ..................................................................................................6-8
Warning Box System ..................................................................................................6-8
Basic Maintenance and Notes ...................................................................................6-8
Wheel Bearing Adjustment ............................................................................................6-8
Wheel Bearing Adjustment Procedure (Double Nut Arrangement) .............................6-8
Electrical Diagrams .......................................................................................................6-9
Lubrication Points ........................................................................................................ 6-11
Lubricants ................................................................................................................6-11
Bolt Torque Specification Chart ................................................................................6-12
Year End Maintenance ................................................................................................6-13
Storage .....................................................................................................................6-13
Preventative Maintenance ........................................................................................6-13
ii October 2015 HD4SR & 12SR

Table of Contents
Section 7:
Storage .........................................................................................................................7- 1
Preparing for Storage .................................................................................................... 7- 2
Cylinder Shaft Protection .............................................................................................. 7- 3
Removing from Storage ................................................................................................. 7- 3
Section 8:
Troubleshooting...........................................................................................................8-1
Troubleshooting Guide ...................................................................................................8-2
Hydraulic System Overview ........................................................................................8-2
Troubleshooting the Hydraulics ..................................................................................8-2
Valves and Valve Functions ........................................................................................8-2
12SR Models Only .....................................................................................................8-2
Hydraulic Troubleshooting Chart ....................................................................................8-3
Loader will not raise ......................................................................................................8-3
Loader raises slow ........................................................................................................8-3
Loader lowers when alignment arms are opening .........................................................8-3
Loader lowers before alignment arm open ....................................................................8-3
Loader will not lower ......................................................................................................8-3
Loader lowers slow ........................................................................................................8-3
Alignment Arms do not center bales, or squeeze bales tight .....................................8-3
Alignment Arms open as loader raises, and close as loader lowers ...........................8-3
Grab Hooks push bale away from loader ......................................................................8-3
Grab Hooks will not engage ..........................................................................................8-3
Grab Hooks will not disengage ......................................................................................8-3
Grab Hooks engage before alignment arms ..................................................................8-3
Grab Hooks engage when loader raises, and retract when loader lowers ....................8-3
Section 9:
Parts Breakdown .........................................................................................................9-1
Bale Skoop Final Assembly ........................................................................................9-2
Loader Assembly........................................................................................................9-4
12SR - Grab Hook Assembly - 2014 to Present ..........................................................9-6
HD4SR - Short Alignment Arm Assembly...................................................................9-8
12SR - Medium Alignment Arm Assembly ..................................................................9-9
Bed Assembly ..........................................................................................................9-10
Frame Assembly .......................................................................................................9-12
Bed Rest Assembly ..................................................................................................9-14
Hitch Assembly.........................................................................................................9-16
Implement Tire and Axle Assembly - Prior to 2015 ...................................................9-18
Truck Tire and Axle Assembly - Prior to 2015 ............................................................9-20
Terra Tire and Axle Assembly - Prior to 2015 ............................................................9-22
Terra Tire and Axle Assembly - 2015 to Present ........................................................9-24
HD4SR Hydraulic Hose Schematic ..........................................................................9-26
12SR Hydraulic Hose Schematic - 2015 to Present .................................................9-28
12SR Hydraulic Hose Schematic - 2014 to 2015 ......................................................9-30
12SR Hydraulic Hose Schematic - 2004 to 2014......................................................9-32
Cylinder Specification Sheet ....................................................................................9-34
Electrical Warning Assembly ....................................................................................9-36
Electrical Assembly ..................................................................................................9-37
Index ....................................................................................................................................i
HD4SR & 12SR October 2015 iii

Table of Contents
Notes
iv October 2015 HD4SR & 12SR

HD4SR & 12SR June 2015 1-1
Section 1:
Safety
Safety
Section 1:
Safety 1-1
Signal Words ....................................................................................................................1-2
General Equipment Safety ...............................................................................................1-3
General Equipment Safety Guidelines .......................................................................1-3
Lighting and Marking ........................................................................................................1-4
Wheels and Tires..............................................................................................................1-4
Tire Safety..................................................................................................................1-4
Bale Skoop Operation Safety ...........................................................................................1-5
Before Operating........................................................................................................1-5
During Operation........................................................................................................1-6
After Operation (Storage)...........................................................................................1-7
Transport Safety ...............................................................................................................1-8
Highway and Transportation Safety............................................................................1-8
Maintenance Safety..........................................................................................................1-9
Performing Maintenance ............................................................................................1-9
Safety Signs ...................................................................................................................1-10
Safety Decals ...........................................................................................................1-10
How to install a new decal........................................................................................1-10
Reector Location Guide .........................................................................................1-15
Decal Location Guide...............................................................................................1-17
Section Contents

Safety
1-2 June 2015 HD4SR & 12SR
Three words are used in conjunction with the safety-alert symbol:
Signal Words
The words DANGER,WARNING or CAUTION are used
with the safety alert symbol. Learn to recognize the
safety alerts, and follow the recommended precautions
and safe practices.
Replace any DANGER, WARNING, CAUTION or
instructional decal that is not readable or is missing. The
location and part number of these decals is identied
later in this section of the manual.
The words Important and Note are not related
to personal safety but are used to give additional
information and tips for operating or servicing this
equipment.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly
observed could result in damage to, or
destruction of the machine, process or
its surroundings.
NOTE: Indicates points of particular interest for more
efcient and convenient repair or operation.
Indicates an imminently hazardous situation that, if not
avoided, will cause DEATH OR VERY SERIOUS INJURY.
DANGER
Indicates a potentially hazardous situation that, if not
avoided, could cause DEATH OR SERIOUS INJURY.
WARNING
Indicates a potentially hazardous situation that, if not
avoided, may cause a MINOR OR MODERATE INJURY.
CAUTION
Watch for this symbol. It identifies potential hazards
to health or personal safety. It means:
ATTENTION - BE ALERT.
YOUR SAFETY IS INVOLVED.
Familiarize yourself with the location of all decals. Read them
carefully to understand the safe operation of your machine.
SAFETY-ALERT
SYMBOL

Safety
HD4SR & 12SR June 2015 1-3
General Equipment Safety
SAFETY. . .YOU CAN LIVE WITH IT!
General Equipment Safety Guidelines
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers
and manufacturers build in as many safety features as possible. However, every year many accidents occur which
could have been avoided by a few seconds of thought and a more careful approach to handling equipment. You,
the operator, can avoid many accidents by observing the following precautions presented in this manual. To avoid
personal injury, study the following precautions and insist those working with you, or for you, follow them.
Replace any CAUTION, WARNING, DANGER or instruction safety decal that is not readable or is missing. Location
of such decals is indicated in this booklet.
Do not attempt to operate this equipment under the inuence of drugs or alcohol.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation.The operator should be a responsible
adult familiar with farm machinery and trained in the equipment’s operations. Do not allow persons to operate or
assemble this unit until they have read this manual and have developed a thorough understanding of the
safety precautions and of how it works.
To prevent injury or death, use a tractor equipped with a Roll Over Protective System (ROPS). Do not paint over,
remove or deface any safety signs or warning decals on your equipment. Observe all safety signs and practice the
instructions on them. Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in
question - DON’T TRY IT.

Safety
1-4 June 2015 HD4SR & 12SR
Lighting and Marking
It is the responsibility of the operator to know the lighting and marking requirements of the local highway authorities
and to install and maintain any additional equipment to provide compliance with the regulations. Aftermarket lighting
kits are often available from your dealer.
This machine is equipped with lighting, marking, and signs in compliance with standards published by the American
Society of Agricultural Engineers for Slow Moving Agricultural Implements on Public Roadways.
Wheels and Tires
Tire Safety
• Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may
result in serious injury or death.
• Do not attempt to mount a tire unless you have the proper equipment and experience.
• Inating or servicing tires can be dangerous. Only trained personnel should be called to service and/or mount
tires.
• Only install tires and wheels with appropriate capacity to meet or exceed the anticipated weight to be placed on
the equipment.
DON’T FORGET! Your best assurance against accidents is a careful and responsible operator. If there is any portion
of this manual or function you do not understand, contact your local authorized dealer or the manufacturer.

Safety
HD4SR & 12SR June 2015 1-5
Bale Skoop Operation Safety
Before Operating
• Carefully study and understand this manual.
• Install the safety warning light to indicate when the hitch is offset.
• Do not wear loose-tting clothing which may catch in moving parts.
• Always wear protective clothing and substantial shoes.
• It is recommended that suitable protective hearing and sight protectors (eye protection) be worn.
• The operator may come in contact with certain materials which may require specic safety equipment, relative to
the handling of such materials (examples: extremely dusty molds, fungus, bulk fertilizers, etc.)
• Keep wheel lug nuts or bolts tightened to specied torque.
• Ensure that the tires are inated to the recommended pressure.
• Give the unit a visual inspection for any loose bolts, worn parts or cracked welds, and make necessary repairs.
Follow the maintenance safety instructions included in this manual.
• Be sure that there are no tools lying on or in the equipment.
• Do not use the unit until you are sure that the operating area is clear, especially of people and animals.
• Because it is possible that this equipment may be used in dry areas or in the presence of combustibles, special
precautions should be taken to prevent res and re ghting equipment should be readily available.
• Don’t hurry the learning process or take the unit for granted. Ease into it and become familiar with your new
equipment.
• Practice operation of your equipment and it’s attachment. Completely familiarize yourself and other operators with
its operation before using.
• Make sure that the brakes are evenly adjusted (if equipped with brakes).
• Use a tractor equipped with a Roll Over Protective System (ROPS) and fasten your seat belt prior to starting the
engine.
• The manufacturer does not recommend usage of a tractor with ROPS removed.
• Move tractor wheels to the widest recommended settings to increase stability.
• Securely attach to towing unit. Use the plates, bolts and nuts provided with the machine.
• Do not allow anyone to stand between the hitch and the towing vehicle when backing up to the equipment.

Safety
1-6 June 2015 HD4SR & 12SR
Bale Skoop Operation Safety - Continued
During Operation
• SAFETY CHAIN: If the Bale Skoop is going to be transported on a public highway, the safety chain should be
connected. Always follow state and local regulations regarding a safety chain and auxiliary lighting when towing
farm equipment on a public highway. Only a safety chain (not an elastic or nylon/plastic tow strap) should be
used to retain the connection between the towing and towed machines in the event of separation of the primary
attaching system.
• Install the safety chain by crossing the chains under the hitch and secure to the draw bar cage, hitch or bumper
frame.
• Beware of bystanders, particularly children! Always look around to make sure that it is safe to start the engine
of the towing vehicle or move the unit. This is particularly important with high noise levels and quiet cabs, as you
may not hear people shouting.
• NO PASSENGERS ALLOWED: Do not carry passengers anywhere on or in the tractor or equipment.
• The tops of the bed and loader are extremely slippery, do not climb, stand, or crawl on them.
• Keep bystanders at least twenty-ve feet away from an operating machine or stacked hay. This allows bystanders
time to get away from a falling stack or away from a moving machine. The operator is a very busy person and it
is easy to miss seeing an observer while operating the Bale Skoop.
• Keep hands and clothing clear of moving parts.
• Do not clean, lubricate or adjust your equipment while it is moving.
• When halting operation, even periodically, set the tractor’s or towing vehicle’s brakes, disengage the PTO, shut
off the engine and remove ignition key.
• Be especially observant of the operating area and terrain - watch for holes, rocks or other hidden hazard. Always
inspect the area prior to operation.
• DO NOT operate near the edge of drop-offs or banks.
• DO NOT operate on steep slopes as overturn may result.
• Operate up and down (not across) intermediate slopes. Avoid sudden starts and stops.
• Pick the attest possible route when transporting across elds. Avoid the edges of ditches or gullies and steep
hillsides.
• Always return the hitch to the in-line position whenever moving from the stack to the bales or the bales to the
stack.
• Be extra careful when working on inclines.
• Periodically clear the equipment of brush, twigs or other materials to prevent buildup of dry combustible materials.
• Maneuver the tractor or towing vehicle at safe speeds.
• Avoid overhead wires or other obstacles. Contact with overhead lines could cause serious injury or death.
• Avoid loose ll, rocks and holes; they can be dangerous for equipment operation or movement.
• Allow for unit length when making turns.
• Do not walk or work under raised components or attachments unless securely positioned and blocked.
• Keep all bystanders, pets and livestock clear of the work area.

Safety
HD4SR & 12SR June 2015 1-7
Bale Skoop Operation Safety - Continued
During Operation - Continued
• Operate the towing vehicle from the operator’s seat only.
• Never stand alongside of unit with engine running or attempt to start engine and/or operate machine while standing
alongside of unit.
• Never leave running equipment attachments unattended.
• As a precaution, always recheck the hardware on equipment following every 100 hours of operation. Correct all
problems. Follow the maintenance safety procedures.
After Operation (Storage)
• Following operation, or when unhitching, stop the tractor or towing vehicle, set the brakes, disengage the PTO
and all power drives, shut off the engine and remove the ignition key.
• Store the unit in an area away from human activity.
• Do not park equipment where it will be exposed to livestock for long periods of time. Equipment damage and
livestock injury could result.
• The tops of the bed and loader are extremely slippery, do not climb, stand, or crawl on them.
• Do not permit children to play on or around the stored unit.
• Make sure all parked machines are on a hard, level surface and engage all safety devices.
• Wheel chocks may be needed to prevent unit from rolling.

Safety
1-8 June 2015 HD4SR & 12SR
Transport Safety
Highway and Transportation Safety
CAUTION: Exceeding speeds of 20 mph (32 km/h) is not legal or safe on public roads.
DO NOT exceed 20 mph (32 km/h) with this machine.
WARNING: This machine is over width. Use extreme caution transporting on Public
Roadways and through narrow areas.
WARNING: Use Hitch Safety Pin to lock hitch in the in-line position before transporting
Bale Skoop on public roads. This will secure hitch in case of accidental activation or
failure of hitch cylinder.
• Adopt safe driving practices. . .
• Keep the brake pedals latched together at all times. NEVER USE INDEPENDENT BRAKING WITH MACHINE
IN TOW AS LOSS OF CONTROL AND/OR UPSET OF UNIT CAN RESULT.
• Always drive at a safe speed relative to local conditions and ensure that your speed is low enough for an emergency
stop to be safe and secure.
• Reduce speed prior to turns to avoid the risk of overturning.
• Avoid sudden uphill turns on steep slopes.
• Always keep the tractor or towing vehicle in gear to provide engine braking when going downhill. Do not coast.
• Do not drink and drive!
• Comply local laws governing highway safety and movement of farm machinery on public roads.
• Be sure stock lights as well as accessory lights are connected and operating properly.
• Use approved accessory lighting, ags and necessary warning devices to protect operators of other vehicles on
the highway during daylight and night time transport. Various safety lights and devices are available from your
dealer.
• The use of ashing amber lights is acceptable in most localities, however some localities prohibit their use. Local
laws should be checked for all highway lighting and marking requirements.
• When driving the tractor and equipment on the road or highway under 20 mph (32 km/h) at night or during the
day, use ashing amber warning lights and a slow moving vehicle (SMV) identication emblem.
• Plan your route to avoid heavy trafc.
• Be a safe courteous driver. Always yield to oncoming trafc in all situations, including narrow bridges, intersections,
etc.
• Watch for obstructions overhead and to the side while transporting.
• Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased
length, width and weight of the equipment when making turns, stopping the unit, etc.

Safety
HD4SR & 12SR June 2015 1-9
Maintenance Safety
Performing Maintenance
• Good maintenance is your responsibility. Poor maintenance is an invitation for trouble.
• Make sure there is plenty of ventilation. Never operate the engine of the towing vehicle in a closed building. The
exhaust fumes may cause asphyxiation.
• Before working on this machine, stop the towing vehicle, set the brakes, disengage the PTO and all power drives,
shut off the engine and remove the ignition key.
• Be sure the bed is lowered against the bed rest and the loader is resting on the hitch or in its lowered position.
• Be certain all moving parts on attachments have come to a complete stop before attempting to perform maintenance.
• Always use a safety support and block the wheels. Never use a jack to support the machine.
• Always use the proper tools or equipment for the job at hand. Use extreme caution when making adjustments.
• A torque chart is provided in this manual for reference when tightening bolts and nuts.
• Never use your hands to locate a hydraulic leak on attachments. Use a piece of cardboard or wood. Hydraulic
uid escaping under pressure can penetrate the skin.
• When disconnecting hydraulic lines, shut off hydraulic supply and relieve all hydraulic pressure (see maintenance
section for instructions).
• Openings in the skin and minor cuts are susceptible to infection from hydraulic uid. If injured by escaping hydraulic
uid, see a doctor at once. Without immediate medical treatment, serious infection, gangrene and allergic reactions
can occur.
• Replace all shields and guards after servicing and before moving.
• After servicing, be sure all tools, parts and service equipment are removed.
• Do not allow grease or oil to build up on any step or platform.
• Never replace hex bolts with less than grade eight bolts unless otherwise specied. Refer to bolt torque chart for
head identication marking.
• Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement parts
must be used to restore your equipment to original specications. The manufacturer will not claim responsibility
for use of unapproved parts and/or accessories and other damages as a result of their use.
• If equipment has been altered in any way from original design, the manufacturer does not accept any liability for
injury or warranty.
• A re extinguisher and rst aid kit should be kept readily accessible while performing maintenance on this equipment.

Safety
1-10 June 2015 HD4SR & 12SR
DANGER
To prevent serious injury or death
from crushing:
Stand clear of machine and stack to
avoid being struck by falling bale.
10110
Part # 10110 – Danger Falling Bale Hazard
Location: Both sides of bed.
DANGER
CRUSHING HAZARD
• Always rest loader on hitch
and turn off tractor before
working on loader.
10111
Part # 10111 Danger Crushing Hazard
Location: Left side of bed.
Safety Signs
Safety Decals
• Keep safety decals and signs clean and legible at all times.
• Replace safety decals and signs that are missing or have become illegible.
• Parts that have been replaced that once displayed a safety sign should have the sign replaced as well.
• Safety decals or signs are available from your distributor, dealer parts department, or the manufacturer.
How to install a new decal
1. Be sure that the installation area is clean and dry.
2. Decide on the exact position before you remove the backing paper.
3. Remove the smallest portion of the split backing paper.
4. Align the decal over the specied area and carefully press the small portion with the exposed sticky backing in
place.
5. Slowly peel back the remaining paper and carefully smooth the remaining portion of the decal in place.
6. Small air pockets can be pierced with a pin and smoothed out using the decal backing paper.
To determine missing decals, or to locate proper locations of replacements refer
to the “Decal Location Guide” later in this section.

Safety
HD4SR & 12SR June 2015 1-11
Safety Signs - Continued
Familiarize yourself with the location of all decals. Read them
carefully to understand the safe operation of your machine.
DANGER
To avoid injury:
U nload a ll ba les before dis c onnec ting
from tra c tor.
M ove bed a nd loade r to lowes t pos ition
before dis c onnec ting hydraulic hos es
a nd hitc h.
HITC H HAZAR D
10119
Part # 10119 – Danger Hitch Hazard
Location: Top of hitch.
DANGER
K eep pe ople c lear of mac hine
while in motion.
Warn people not to approac h from
the R IG H T s ide.
OF F S E T MAC HINE
10109
Part # 10109 - Danger Offset Machine
Location: Right side of bed.
DANGER
10108
To prevent serious injury or death
from pinching:
• Keep all persons and objects clear
while any part of this machine is in
motion.
Part # 10108 - Danger Pinch Injury
Location: Both sides of bed.
DANGER
ELECTROCUTION HAZARD
To prevent serious injury or death from
electrocution:
• Stay away from overhead power lines
when transporting or raising stacker.
This machine is not grounded.
Electrocution can occur without direct
contact.
10106
Part # 10106 - Danger Electrocution Hazard
Location: On warning light box.

Safety
1-12 June 2015 HD4SR & 12SR
Part # 10107 - Warning Offset Machine
Location: On warning light box.
WARNING
Avoid possible loss of control or
tractor overturn.
Tow only with correctly ballasted
tractor weighing:
12SR - no less than 14 000 lbs
(6350 kg)
HD4SR - no less than 10 750 lbs
(4880 kg)
10853
Part # 10853 - Warning Avoid Loss of Control
Location: Top of hitch.
WARNING
HITCH SAFETY PIN
• Always secure hitch by
installing safety pin before
driving down the road,
highway or street.
10123
Part # 10123 - Warning Hitch Safety Pin
Location: Front of frame above hitch.
Safety Signs - Continued
Familiarize yourself with the location of all decals. Read them
carefully to understand the safe operation of your machine.
WARNING
HIGH-PRESSURE FLUID HAZARD
To prevent serious injury or death:
• Relieve pressure on system before
repairing or adjusting or disconnecting.
• Wear proper hand and eye protection
when searching for leaks. Use wood or
cardboard instead of hands.
• Keep all components in good repair.
10120
Part # 10120 - Warning High Pressure Fluid
Location: Top of hitch.
WARNING
To Prevent Serious Injury or Death
Avoid unsafe operation or
maintenance.
Do not operate or work on this
machine without reading and
understanding the operator’s
manual.
If manual is lost, contact your
nearest dealer for a new manual.
10121
Part # 10121 – Warning To Prevent Serious Injury
Location: Top of hitch.
This machine may require a long distance
to stop because of NO BRAKES.
To Prevent Accidents
11839
WARNING
• Do not pull over 20 mph (32 km/h)
• Avoid steep inclines
• Minimum Tractor Horsepower Required:
• HD4SR - 125 HP (93 kW)
• 12SR - 125 HP (93kW)
• 12K - 150 HP (112kW)
• 16K - 180 HP (134 kW)
Part # 11839 - Warning No Brakes
Location: Top of hitch.

Safety
HD4SR & 12SR June 2015 1-13
Safety Signs - Continued
Familiarize yourself with the location of all decals. Read them
carefully to understand the safe operation of your machine.
CAUTION
• Exceeding speeds of 25 mph is not legal or safe on Public Roads.
This Machine is Over Width.
• Do Not Exceed Speeds of 25 mph with this Machine.
• Use Extreme Caution when Transporting on Public Roadways and
Through Narrow Areas.
This machine is equipped with lighting, markings, and signs in compliance with
standards published by the American Society of Agricultural Engineers for Slow
Moving Agricultural Implements on Public Roadways.
11159
Part # 11159 - Caution Speed
Location: On warning light box.
CAUTION
10112
SLIPPERY SURFACE
To avoid injury:
• Do not stand or walk on machine.
Part # 10112 - Caution Slippery Surface
Location: Both sides of bed.
Part # 10195 - Notice
Location: Left side of hitch.
CAUTION
1. Read Operator's Manual before using machine.
2. Stop tractor engine, lower machine to the ground, place all
controls in neutral, set park brake, remove ignition key and
wait for all moving parts to stop before servicing, adjusting,
repairing, unplugging or fitting.
3. Keep hands, feet, hair and clothing away from moving parts.
4. Do not allow riders.
5. Keep all hydraulic lines, fittings and couplers tight and free
of leaks before using.
6. Install safety locks before transporting or working beneath
components.
7.
Add extra lights and use pilot vehicle when transporting during
times of limited visibility.
8. Use hazard flashers in tractor when transporting.
9. Install safety chain when attaching to tractor.
10. Keep away from overhead electrical lines. Electrocution can
occur without direct contact.
11. Review safety instructions with all operators annually.
FN-D-10122
Part # 10122 – Caution Read Op Manual
Location: Top of hitch.

Safety
1-14 June 2015 HD4SR & 12SR
Safety Signs - Continued
Familiarize yourself with the location of all decals. Read them
carefully to understand the safe operation of your machine.
For Replacement
Operator's Manuals
Call: 306-933-8585
Or write to:
MORRIS Industries (USA) Inc.
Box 1117
Minot, ND 58702-1117
12195
Part # 12195 - Replacement Manual
Location: On frame by op manual box
Part # 10117 - HD4SR
Location: Both sides of bed.
Part # 10115 - Auto Align Bale Skoop
Location: Both sides of bed.
PATENTED MACHINE
Copying this machine is
illegal and any company or
corporation found to have a
copy or copies of this
machine will be infringing on
U.S. Patent No. 5,211,345;
Issue date 5/18/93 and
U.S. Patent No. 5,397,208;
Issue date 3/14/95 and will be
penalized for said act
according to U.S. patent law.
10113
Part # 10113 - Patented Machine
Location: Both sides of bed.
Part # 10116 - 12SR
Location: Both sides of bed.
12194
Part # 12194 - ProAG Logo Decal
Location: Rear sides of bed.
