Proceq OS8000 Operation instructions

Original Schmidt OS8000
Silver Schmidt OS8200
Tutorial 02
Hammer controls

Identical operation
Original Schmidt OS8000
Silver Schmidt OS8200

© 214 Proceq
Slide3
Power ON / OFF
Press –ON
Press and hold > 5s –OFF
Press –ON
Press and hold > 5s –OFF

© 214 Proceq
Slide4
Back light ON / OFF
Press and hold > 1.4s - ON
Press and hold > 1.4s –OFF

© 214 Proceq
Slide
5
Quick start a new series
Press and hold > 1.4s
Operation possible at any time
Current series is saved
New series is started

© 214 Proceq
Slide6
Menu navigation

# 1
# 2
# 3
# 4

# 1
# 2
# 3
# 4

# 1
# 2
# 3
# 4
# 1
# 2


<
# 1
# 2 

<
Scroll Select

© 214 Proceq
Slide
Mode selection (Print versions only)
7
MEAN
#00
LIVE
S0071

Mode
Standard
Memory
Info
LIVE
PRINT


<
Scroll
Select

© 214 Proceq
Slide
Standard selection
8
MEAN
#00
LIVE
S0071

Mode
Standard
Memory
Info
ASTM
JGJ

JSCE
JIS



<
Scroll
Select
2x

© 214 Proceq
Slide
Clear memory
9
MEAN
#00
LIVE
S0071

Mode
Standard
Memory
Info <
Clear

3x
Delete all
series
Delete
Cancel

Any unsynchronized
data will be lost

© 214 Proceq
Slide
Info
10
MEAN
#00
LIVE
S0071
Mode
Standard
Memory
Info
4x
<
OS82-001-0008
FW:2.0.1
MEAN
#00
LIVE
S0071
Serial number
Firmware version

© 214 Proceq
Slide
11
Measurement
39.5
X(09)
LIVE
S0071
EN
#00
LIVE
S0071
37
#01
LIVE
S0071
38
#09
LIVE
S0071
8x
+
#09

S0071
NEW
Delete last measurement
Delete whole series
Standard Last measurement
Series ID Impact No.
Calculated rebound
value

© 214 Proceq
Slide
12
Viewing Results
39.5
X(20)
LIVE
S0071
37 35 35 38
39 40 40 48
38 39 32 43
39 47 43 37
LIVE
S0075
1/2
43 38
LIVE
S0075
2/2
39.5
X(20)
LIVE
S0075
38
#18
LIVE
S0075
Scroll through results Return to series
+
S0075
NEW
Delete whole series
Start new series
No. of impacts

© 214 Proceq
Slide
13
Printing Results
39.5
X(20)
LIVE
S0071
37 35 35 38
39 40 40 48
38 39 32 43
39 47 43 37
PRINT
S0075
1/2
43 38
PRINT
S0075
2/2
39.5
X(20)
PRINT
S0075
38
#18
PRINT
S0075
Scroll through results Return to series
+
S0075
NEW
S0075

© 214 Proceq
Slide
14
Time out
No activity > 5 minutes
•Power off
•Current series is saved
•Current series is closed

© 214 Proceq
Slide
15
Download a print out of this tutorial
https://www.proceq.com/downloads/
