Procom ELR Series User manual

EARTH LEAKAGE RELAY
ELR - 1
ELR - 2
ELR - 3
Plot No. 20-21, Sector 59 Phase- ||,
Faridabad, Haryana
Pin - 121004
Phone : [phone]
E-mail Address
[email protected]
CONNECTION DIAGRAM
Function Diagram
Supply
Trip Level
Reset
Level
Current
Relay O/P
ELR Function Diagram :
ELR-2
RESET
ELR-3
RESET
Current
Range
Time
Delay
Aux.
Supply
Contact
Reset
Type
Model
Type
30 mA -
30 A
0.02 -
10 sec
30 - 300v
AC/DC
1CO + 1
NO
Auto
ELR-1A
Mannual
ELR-1M
50 mA -
300 mA
0.2 - 10
sec
30 - 300v
AC/DC
1CO + 1
NO
Auto
ELR-2A
Mannual
ELR-2M
0.2 A - 1.2
A
0.2 - 10
sec
30 - 300v
AC/DC
1CO + 1
NO
Auto
ELR-3A
Mannual
ELR-3M
PRODUCT
CMR 1AL/
CMR 1AL-N
CMR 1ML/
CMR 1ML-N
CMR 5AL/
CMR 5AL-N
Auxiliary Supply
35VAC / DC-300 VAC / DC
Power Consumption
(max.)
5VA (APPROX.)
EL SETTING
0.03-30Amp
50-300 mAmp
0.2 - 1.2 Amp
Trip Time
0.02 - 10 Sec
0.2 - 10 Sec
0.2 - 10 Sec
Reset Type
A/M
A/M
A/M
Reset Time
3 SEC
3 SEC
3 SEC
Power On Delay
< 500 ms
LED Indication
Mains
EL
POWER ON / CBCT ERROR
EARTH LEACKAGE
Test Function
YES
Setting Accuracy
+ / - 5%
Repeat Accuracy
+ / - 2%
Hysterisis
+ / - 5%
Relay Output :
Contact
Arrangement
Contact
1C/O
5A Res. @ 250 VAC / 30VDC
Ag Alloy
TECHNICAL CHARACTERISTICS :
Test/Reset
12 3 456
CT IN Aux. Supply
78 9 10 11 12
COM
NO
NC
*COM
65
68
56
35 for DIN RAIL
92
48.5
32
37
1 2 3 4 5 6
1 2 3 4 5 6
96

RESET
1. Auto Reset
Relay reset occurs automatically when the Earth leakage
fault disappears. Auto reset is enabled for 4 times only.
After 4 trips relay doesn't reset automatically. It has to be
reset manually
2. Manual Reset
In Manual Reset, Relay reset can be obtained by pressing
switch button only after Earth Leakage fault disappears.
3. Remote Reset
For Remote reset, connect an external push button switch
between Pin No. 7 & 12.
Test Function:
For test function, press and hold the Reset push button for
duration of trip time selected. The re;ay will trip and all LED’s
would glow.
FEATURES
• Auto / Mannual reset available
• Wide range of Earth Leakage current adjustment.
• Adjustable Earth Leakage trip time.
• Test feature to check complete product functionality.
• Reset feature through reset switch on product.
• Remote reset feature.
• 1 C/O Relay output 1CO + 1NO.
• LED indications for all failure conditions.
• Wide Auxiliary supply range. (30V - 300VAC/DC)
• DIN rail mounting.
• Compact Size 35mm width
FUNCTIONAL DESCRIPTION
EARTH LEAKGE PROTECTION
Earth Leakage relay is a microcontroller based device
meant to measure low level of leakage current and
protect the faulty circuit from the system. Leakage
current is sensed through core balance current
transformer (CBCT). Earth leakage fault occurs when
the current exceeds the set Earth Leakage Current (Ie)
which is adjustable by means of a front mounted
potentiometer. Definite time trip occurs when the set
time delay trip level expires which is adjustable from 0.2
Sec to 10 Sec by means of a front mounted
potentiometer.The Red LED indicates the presence of
Earth Leakage.
CBCT CONNECTION
All conductors to be protected shall pass through the
core balance current transformer. Main winding of
current transformer and test winding should be
connected to the product terminals by a twisted pair of 1
2
mm wires. The CT wires should be placed adequately
away from high current carrying conductors of source of
strong magnetic field to avoid noise pickup. The Earth
Leakage Relay also verifies CT connection. If CT is
open power LED blinks CBCT error
CBCT DIMENSIONS
CBCT Variant
ID
L
B
T
CBCT38
38
90
70
20
CBCT55
55
117
97
20
CBCT92
92
155
132
20
CAUTION
1. Do not touch the terminal area while the power is
turned ON.
2. Before installation, check to ensure that
specifications agree with intended application.
T
B
L
L
ID
1 2 3 4 5 6
E
L
N
7 8 9 10 11 12
Load
Cont.
1 2 3 4 5 6
7 8 9 10 11 12
E
L1
L2
L3
N
Load
Cont.
CONNECTION DIAGRAM 3P 4W
CONNECTION DIAGRAM 3P 3W
