Profile PCL-324 Sirius User manual

ELECTRIC QUARTZ HEATER EN -1
PCL-324 Sirius
Thank you for purchasing this Profile product. Please
note: It is important that you read this manual before
using the product and that you retain it for future use.
Technical data
Mains voltage: 230V (50Hz)
Power: 600W – 1200W
Supplied with pull cord
Supplied with wall mount
Warms rooms rapidly
Ideal for use in room sizes up to 24m³
Safety precautions
To ensure safe operation of your heater, the
appliance must be fitted and connected in
accordance with the recommendations contained in
the manual. Failure to comply with these instructions
will void the manufacturer warranty.
This appliance is suitable only for interior domestic
use.
Do not use this appliance in damp environments
(such as a bathrooms, utility rooms, etc.).
Covering the heater could cause a fire hazard.
Ensure that the appliance is always used upright on
a level dry surface.
Do not use the appliance if the feet are not fitted, or
not fitted correctly.
The surfaces of the appliance, and especially the
grille, become very hot when the appliance is in use.
Ensure that these surfaces are out of reach of small
children.
Do not insert any object through the grille openings.
Doing so could impede operation and cause the
appliance to catch fire.
Never use the appliance in conjunction with a timer.
Unsupervised automatic use of heaters can be very
dangerous.
Ensure that you do not allow the mains cable to
come into contact with the hot appliance.
Electric heaters are designed to provide
supplementary heating and are therefore not
suitable for use as the main source of heating in
cold weather.
If the appliance falls over, first disconnect the power
supply before righting the appliance. Remove the
cause of the heater falling before re-use.
Never leave your appliance unattended. Also always
pull the plug out of the socket when you leave the
room.
Do not use an extension lead.
In use, the heater must be at least 100 cm from the
nearest object. Ensure that the heating elements do
not directly face highly flammable items (e.g.
curtains and/or heat-sensitive synthetic materials).
Connection
The heater is supplied complete with mains plug.
Never use the heater if the mains cable and/or plug
are damaged or if the heater is not working correctly or
is damaged in any way.
A mains cable and/or plug should be replaced only by
a qualified specialist familiar with the applicable
regulations.
Installation
Always keep sufficient distance between the heater,
the wall and any other object. The heater must
never be installed in such a way that the heat
radiates directly against a wall or any other object.
If you are installing the heater in a bathroom, ensure
that you comply with all legal minimum safety
distances.
Wall-hung installation:
oTilt the wall mount fully one way so that you can
loosen one of the central screws holding the
cover in place. Then repeat the operation to
remove the other screw. You can then remove
the cover from the wall mount.

ELECTRIC QUARTZ HEATER EN -2
PCL-324 Sirius
oUsing these holes as a template, position the
fixing, mark the positions on the wall and drill two
6 mm holes. Insert wall plugs.
oThe electrical connection must be EARTHED!
There are 2 connection options:
- Plugging the attached cable into a mains
socket
- Using a fixed wire connection
oWhen the cable is securely fixed in place, use
the enclosed screws to secure the wall fixing
oFOR XVB CONNECTION ONLY: Remove the
two screws (marked D above) from the cable
clamp, then remove the original connector cable
and insert the XVB cable into the cable clamp.
Make sure that the connections are made in
accordance with the symbols shown and in
accordance with the following data.
Important!
The wires in the mains cable are colour-coded as
follows:
oGreen and yellow: earth = connect to E or earth
symbol.
oBlue: neutral = connect to N
oBrown (black, red. etc.): live = connect to L
Connect the XVB wires into the connector block.
Tighten the screw to secure the XVB cable in the
cable clip.
Replace the wall cover fixing and tighten screw.
Use part A to set the heater to the desired angle.
It is important to avoid touching the heating
elements during installation, because doing so may
leave finger marks that could reduce heat output
and/or damage the elements.
Operation
Pull cord (S):
o0 = OFF
o1 = 600W
o2 = 1200W
It is normal for the indicator lamps to flicker when
the cord (S) is pulled.
Please note
Before moving the quartz heater, make sure that it is
completely cold and always use the handle supplied.
When using the heater for the first time, you may see
a little smoke or detect a slight odour. This may
occur if a heating element acquires a thin film of oil
during the manufacturing process, and is quite
normal. The oil will soon evaporate, and does not
normally cause any damage.
Cleaning
We recommend that you clean your quartz heater
once a month to remove any dirt and dust. This will
ensure that the appliance operates efficiently and
safely.
Always turn off the switch (S) and pull out the plug
before you start cleaning!
Clean the casing with a clean, soft, slightly
dampened cloth. Never clean the heating elements
or switches. Ensure that the appliance is completely
dry before switching back on. Do not use any
detergent (wax) or cleaning agents, which may
cause the coloured components to fade when
heated.
Never touch the quartz elements.
When your heater is not in use, we recommend that
it is stored in its original packaging. Store in clean
dust-free surroundings.
Warranty
The PCL-324 is supplied with a 2-year warranty,
commencing on the date of purchase. During the
warranty period, Eltra NV will repair any defects due to
faulty materials or production faults. Eltra NV may
repair or replace the defective heater at its own
initiative.
Eltra NV is not obliged to repair or replace appliances
which have become defective as a result of damage,
inappropriate use, modification or adaptation after the
date of purchase.
Return the defective appliance, together with the
original receipt, to the shop you bought it from. Please
attach a note describing the problem.
Liability
Under no circumstances will Eltra NV accept liability
for damage of any nature whatsoever where an
appliance is not correctly installed in accordance with
the above installation instructions, nor for any damage
resulting from unforeseen circumstances, such as
natural disasters, lightning strike, etc. All and any
consequential expenses are therefore the exclusive
liability of the buyer, and are not covered by the
warranty.
www.profile.eu
Eltra nv, Pachtgoedstraat 2, 9140 Temse, BELGIUM
Eltra DIYeuronet, Frontstraat 14, 5405 AM Uden,
THE NETHERLANDS
