Project Source 5217236 User manual

1
ITEM #5217236, 5217237
MODEL #B30B, B36B
BASE CABINET
ASSEMBLY INSTRUCTION
Español p. 17
Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
SS23140
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 866-389-8827, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also
contact us at [email protected].
Scan for assembly video
PROJECT SOURCE and logo design are
trademarks or registered trademarks of LF,
LLC. All rights reserved.

2
TABLE OF CONTENTS
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................4
Safety Information............................................................................................................................5
Preparation.......................................................................................................................................5
Assembly or Installation Instructions................................................................................................6
Toe-Kick Assembly Instruction..........................................................................................................13
Care and Maintenance..........................................................................................................................14
Troubleshooting..............................................................................................................................14
Warranty............................................................................................................................................15
Replacement Parts..........................................................................................................................16

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A LH GABLE 1
B RH GABLE 1
C BOTTOM PAN EL 1
D TOP FRONT RAIL 1
E BACK RAIL 2
F BACK PANEL 1
G DOOR 2
H TOP DRAWER FRONT 1
J LOW_DRWR BACK 1
K LOW_DRWR SIDE 2
L DRAWER BOTTOM 1
M SHELF 1
N TOP BACK RAIL 1
O DRAWER BOT SUPPORT 1

4
HARDWARE CONTENTS (shown actual size)
Minix Cam Lock
Qty. 13
Hinge Mounting Plate
Qty. 4
105oHinge
Qty. 4
CSK Screw 5/8"
Qty. 24
CSK Screw 1 1/2
Qty. 10
Minix Shaft
Qty. 13
Epoxy Roller Runner
Qty. 1 Set
PVC Adjustable Leg
Qty. 4
Leg Clip
Qty. 2
BBAA CC DD
EE FF HHGG II
Wooden Dowel
Qty. 18
JJ
Bumper 2MM
Qty. 6
KK
Euro Screw 1/2
Qty. 4
LL
Shelf Support Clear
Qty. 4
MM
Pan Head Screw 5/8
(For Toe-Kick Clip)
Qty. 4
NN

5
SAFETY INFORMATION
• Electric, plumbing, gas lines, and other utilities are frequently installed or embedded behind wall
Where cabinets are being installed. To reduce the risk of shock, explosion or injury, turn o󰀨 all gas,
Electrical and water connections prior to performing any work. Shut o󰀨 the power to any appliances
and receptacles in the kitchen including lights at the fuse-breaker box. Use a circuit tester to ensure
the power is o󰀨. Failure to follow these instructions may result in property damage and serious or fatal
Injury. If you do not feel condent in your ability to ensure that you will not make contact with utilities
behind a wall during installation, please contact a licensed contractor to install the cabinets.
• Prior to starting the installation, ensure you read and understand the entire installation guide.
• At least two people are required for safe installation.
• Screws or ttings are not included. Select suitable screws and ttings that are su󰀩cient to secure the
Cabinets properly to the wall. If you are uncertain, contact lowes customer service. Failure to properly
secure the cabinets may result in serious injury!
• Do not over-tighten connectors (screws, bolts, etc.). Overtightening can lead to product damage.
WARNING
CAUTION
• Check the inventory you received against the bill of materials you have ordered to ensure all items
Have been delivered. If there are missing or damaged items contact lowes customer service.
• Be sure to check all packing materials carefully for small parts that may have come loose inside the
Carton during shipment. If parts are missing, contact lowes customer service.
PREPARATION
Before beginning assembly of product, make sure all parts are present.
Compare parts with package contents list and hardware contents list. If
any part is missing or damaged, do not attempt to assemble the product.
Estimated assembly time: 45 minutes
Tools required for assembly (not included): list here tools that are required but not included.
Example: wrench, phillips screwdriver, hammer, pliers

6
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
Minix shaft
Minix cam lock
Wooden dowel
x 12
x 13
x 18
1
2
3
BB
AA
JJ
BB
AA
JJ
1. Using a rubber mallet, tap in wooden dowels in the
correct positions as per the illustration. For added
strength, apply a small amount of wood glue to each
dowel prior to placement (not included).
2. Using a phillips head screwdriver, fasten
the minix shafts in the correct positions as
shown.
3. Insert the minix cam lock in the correct positions
based on the illustration. Please note the arrow mark
should face the bore hole as per the illustration.

7
ASSEMBLY INSTRUCTIONS
5
4
5. Using a phillips head screwdriver, attach the
mounting plate as shown in the illustration.
Insert the shelf support hardware on the
required hole
6
Hardware Used
CSK screw 5/8" x 2
HH
Euro screw 1/2" x 4
LL
Hardware Used
Hardware Used
Hinge mounting plate
105oHinge
x 4
x 2
FF
GG
Bumper 2MM x 4
KK
Epoxy runner x 1
CC
Shelf support clear x 4
MM
4. Place the epoxy runner in the correct position as
per the illustration. Use the euro and csk screws
as shown. Ensure the left & right hardware slides
are placed on the correct panels.
6. Insert the hinge in the bore hole. Using a phillips
head screwdriver, turn the pre-installed screws
clockwise to lock into place.
Place the bumper on the door as shown.
HH
LL
CC
FF
MM
KK
GG

8
ASSEMBLY INSTRUCTIONS
8
7
9
Hardware Used
Hardware Used
Hardware Used
Bumper 2MM
CSK Screw 1 1/2
CSK Screw 5/8"
x 2
x 10
x 6
KK
II
HH
KK
BB
HH
Minix Shaft x 1
BB
Minix Cam Lock x 1
Step 1
Step 3
Step 2
Step 4
AA
7. Place the bumper pad on the drawer front as shown.
Attach the minix shaft using phillips screwdriver as
shown.
8. Using a phillips head screwdriver, secure the
drawer box with csk screws 1 ½" as shown in the
illustration. Be careful not to over-tighten as this
may damage the product.
9. Using a phillips head screwdriver, secure the epoxy
bottom runner to the underside of the drawer
box with the csk screws 5/8" as shown in the
illustration. Be careful not to over-tighten as this
may damage the product.
AA
II
O
O
O

9
ASSEMBLY INSTRUCTIONS
11
10
12
AA
N
N
11. Insert the back panel as shown in the drawing.
10. Assemble the cabinets parts as per the illustration.
Using a phillips head screwdriver, rotate the minix
cam clockwise to fasten into place. Ensure all
cams are locked into place before moving the
cabinet.
12. Assemble the cabinets parts as per the illustration.
Ensure all cams are locked into place before
moving the cabinet.

10
ASSEMBLY INSTRUCTIONS
14
13
DD
HH
15. Insert the shelf onto the cabinet at some angle as
per the drawing and press the shelf from the top
until it gets held with the shelf support hardware.
15
14. Insert the assembled drawer box into the
assembled cabinet box as per the illustration.
If adjustments to the drawer are needed, instructions
are available on page 12 of this manual.
13. Position the mounting bracket for the legs on the
underside of the cabinet box and using a phillips
head screwdriver, secure into place with csk screws
5/8" as per the illustration.
Hardware Used
PVC adjustable leg x 4
DD
Leg Mounting bracket
CSK screw 5/8" x 16
HH
