Project Timber Corner Shed Windowless Instruction Manual

Covers: 7x7
Corner Shed Windowless
Building Instructions
Please read carefully and retain for future reference
For Queries and Help please contact 01777 802300
V3.0 24.10.18 INS0024
Please note that all images are for illustration purpose only.

*All Garden Buildings must be
built on level, flat base to be
erected correctly.
*Important* PILOT DRILL HOLES
BEFORE FIXING
8 S50
Screws
4 S50
Screws
1780mm
3FT
4FT
1. Fix the Corner Post
to Side Gable Panel
3. Fix the 2 Side Gable Panels
together and screw to the
floor assembly
2. Fix Floor together
Screw Here
7 S50
Screws
2. Fix the Floor Panels
together
Front
SideSide
4. Fix the additional
Side panels
12 S50
Screws
Wall Panel Position
Side
Corner post
Side
Floor
Assembly
S50
Screws
3. Fix the two Side Gables
Panel in this position

5. Fix Plain Panels to side
gable panels and floor
panels
Screw Here
6. Fix the Door Panel to front
of plain panels and floor
panels
5. Plain Panel fixing
6S50
Screws
5. Plain Panel fixing
6 S50
Screws
6. Door Panel fixing
11 S50
Screws
Door Panel fixing
S50
Screws

7. Fix the Centre Purlin
and Fixing Block to the
back corner, then fix
to the Door Panel
8. Fit and fix Roof Support
to the Centre Purlin and
Side Panels
Screw Here
9. Fit the Eaves Purlin to the
Roof Sheets as shown S30
Screws
Fixing
Block
Sits flush
at top
Sits flush
at top
S50
Screws
8. Roof Support fixing
1720mm
Roof Support fittings
S50
Screws
S30
Screws
Eaves Purlin fixing
N30
Nails
9. Eaves Purlin Fixing
Position

10. Fix the Roof Sheets to
the Centre Purlin and
Panels N30
Nails
Roof Side Position
Side
S50
Screws
Side
9. Fix and place the
Roof Sheet
9N30
Nails
Fix the 2nd Roof Sheet
8N30
Nails

11. Lay Doors and fix Hinges
13. Fix Turn Button to the
Top and Bottom
12. Hang Doors and secure
Door Hinges and Turn Button
Fix Hinges to Doors over
Braces
12 S30
Screws
13. Turn Button fixing
To p
Bottom
S30
Screws
S30
Screws

14. Measure and cut
3 lengths of felt.
Roof length + 140mm
Tack Top corners
to hold in place
Tack every 100mm
and fold over edges
17.
16. Fit 1st Felt Strip
T10 Felt
Tacks
18. Fit 2nd Felt Strip
T10
Felt
Tacks
1
2
The Felt must lay on top
of each other
19. Fit the 3rd Felt Strip
3
T10
Felt
Tacks
2
112
3

20. Fix the Cloaking Strips
21. Fix the Fascias to the front
Cloaking Strips fixing details
N30
Nails
N30
Nails
