Tronic TLAL 2 A1 User manual

IAN 354269_2010
IN-CAR CHARGER /
KFZ-LADEADAPTER /
CHARGEUR ALLUME-CIGARE
TLAL 2 A1
CHARGEUR
ALLUME-CIGARE
Mode d’emploi
KFZ-LADEADAPTER
Bedienungsanleitung
IN-CAR CHARGER
Operating instructions
AUTO-LAAD-
ADAPTER
Gebruiksaanwijzing
NABÍJEČKA
DO AUTA
Návod k obsluze
ŁADOWARKA
SAMOCHODOWA
Instrukcja obsługi
NABÍJACÍ
ADAPTÉR DO AUTA
Návod na obsluhu
BILOPLADER
Betjeningsvejledning
CARGADOR
PARA COCHE
Instrucciones de uso
CV_354269_TLAL2A1_LB8_online.indd 1-3 14.04.2021 14:22:12

GB/ IE Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 31
FR/BE Mode d’emploi Page 61
NL/BE Gebruiksaanwijzing Pagina 99
CZ Návod k obsluze Strana 129
PL Instrukcja obsługi Strona 157
SK Návod na obsluhu Strana 187
ES Instrucciones de uso Página215
DK Betjeningsvejledning Side 245
CV_354269_TLAL2A1_LB8_online.indd 1-3 14.04.2021 14:22:12

CV_354269_TLAL2A1_LB8_online.indd 4-6 14.04.2021 14:22:12

GB│IE │ 1 ■TLAL 2 A1
Contents
Introduction................. 3
Information about these
operating instructions ...............3
Notes on trademarks ...............4
Proper use .......................5
Warnings and symbols used .........6
Safety ..................... 9
Basic safety instructions .............9
Package contents ........... 12
Description of components . . . 13
Use....................... 14
Troubleshooting ............ 18
Cleaning and storage........ 19
Disposal................... 20
Disposal of the device .............20
Disposal of the packaging ..........21
IB_354269_TLAL2A1_LB8_online.indb 1 19.04.2021 17:12:30

■ 2 │ GB│IE TLAL 2 A1
Attachment ................ 22
Technical specifications ............22
Notes on the EU Declaration
of Conformity ....................23
Kompernass Handels GmbH warranty . 23
Service .........................28
Importer........................29
IB_354269_TLAL2A1_LB8_online.indb 2 19.04.2021 17:12:30

GB│IE │ 3 ■TLAL 2 A1
Introduction
Information about these
operating instructions
Congratulations on the purchase of your
new device.
You have selected a high-quality product.
The operating instructions are part of this
product. They contain important information
about safety, usage and disposal. Before
using the product, please familiarise your-
self with all the operating and safety instruc-
tions. Use the product only as described
and for the range of applications specified.
Keep these operating instructions as a
reference and store them near the product.
Please pass on all documentation incl. these
operating instructions to any future owner(s)
if you sell this product or give it away.
IB_354269_TLAL2A1_LB8_online.indb 3 19.04.2021 17:12:30

■ 4 │ GB│IE TLAL 2 A1
Notes on trademarks
■ Qualcomm®Quick ChargeTM is a product
of Qualcomm Technologies, Inc. and/or
its subsidiaries.
Qualcomm®is a trademark of Qualcomm
Incorporated, registered in the United
States and other countries.
Quick ChargeTM is a trademark of
Qualcomm Incorporated.
■ USB®is a registered trademark of USB
Implementers Forum, Inc.
All other names and products may be
trademarks or registered trademarks of
their respective owner.
IB_354269_TLAL2A1_LB8_online.indb 4 19.04.2021 17:12:30

GB│IE │ 5 ■TLAL 2 A1
Proper use
The car charger adapter is a car accessory
that is compatible with the vehicle socket
(cigarette lighter) and is designed solely
for charging and operating devices with a
USB port. The car charger adapter is suitable
only for vehicles in which the negative
terminal of the battery is connected to the
bodywork.
The device is not intended for any other
purpose nor for use beyond the scope de-
scribed. The device is not intended for use
in commercial or industrial environments.
Claims of any type due to damage from
improper use are excluded. The operator
bears sole liability.
IB_354269_TLAL2A1_LB8_online.indb 5 19.04.2021 17:12:30

■ 6 │ GB│IE TLAL 2 A1
Warnings and symbols used
The following warnings are used in these
operating instructions:
DANGER
A warning notice at this hazard
level indicates an imminently
hazardous situation.
Failure to avoid this hazardous situation
could result in serious injuries or even
death.
► Follow the instructions in this warning
notice to avoid the risk of death or
serious injury.
IB_354269_TLAL2A1_LB8_online.indb 6 19.04.2021 17:12:32

GB│IE │ 7 ■TLAL 2 A1
CAUTION
A warning at this hazard level
indicates a risk of property
damage.
Failure to avoid this situation could result
in property damage.
► Follow the instructions in this warning
notice to prevent property damage.
NOTE
► A note provides additional information
that makes handling the device easier
for you.
The e-Mark is a certification mark
for the labelling of components
requiring approval in motor
vehicles and states that the necessary tests
have been carried out and that an ECE
component approval has been issued. The
letters “xx” are placeholders and stand for
the country where the licence was issued.
IB_354269_TLAL2A1_LB8_online.indb 7 19.04.2021 17:12:33

■ 8 │ GB│IE TLAL 2 A1
The Qualcomm®Quick ChargeTM
3.0 technology symbol indicates
that the technology used enables
a reduced charging time for compatible
devices connected to the green USB port of
the car charger adapter. Compatible con-
nected devices are automatically detected
and provided with the appropriate output
voltage and output current from the car
charger adapter.
The Smart Fast Charge symbol
indicates that the technology used
allows for a reduced charging time
for compatible devices. Compatible con-
nected devices automatically receive a
signal to draw the maximum available
charging current.
IB_354269_TLAL2A1_LB8_online.indb 8 19.04.2021 17:12:35

GB│IE │ 9 ■TLAL 2 A1
Safety
This section contains important safety
instructions for handling the device. This
device complies with the statutory safety
regulations. Improper use may result in
personal injury and property damage.
Basic safety instructions
To ensure safe operation of the device,
follow the safety guidelines set out below:
■ Check the device for visible external
damage before use. Do not operate
a device that has been damaged or
dropped.
■ This device may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental
capabilities, or lack of experience and
knowledge, provided that they are under
supervision or have been told how to use
the device safely and are aware of the
potential risks.
IB_354269_TLAL2A1_LB8_online.indb 9 19.04.2021 17:12:35

■ 10 │ GB│IE TLAL 2 A1
Do not allow children to play with the
device. Cleaning and user maintenance
tasks may not be carried out by children
unless they are supervised.
■ DANGER! Do not allow children
to play with the packaging material!
Keep all packaging materials away from
children. There is a risk of suffocation!
■ Never subject the device to extreme heat
or humidity. This particularly applies to
storage in a car. Extreme temperatures
can occur in car interiors and glove
compartments during long periods of
immobilisation. Remove any electrical
and electronic devices from the vehicle.
■ Do not operate the device whilst steering
a car or any other vehicle. This is hazard-
ous to other road users.
IB_354269_TLAL2A1_LB8_online.indb 10 19.04.2021 17:12:35

GB│IE │ 11 ■TLAL 2 A1
■ When using the car charger (incl. any
connected devices), ensure that it does
not interfere with the steering, braking
or the operation of other vehicle systems
(such as airbags) and does not restrict
your field of view when driving.
■ Do not allow any liquids or moisture to
get into the device.
■ The device must always be supervised
during use.
■ Unplug the device from the vehicle
socket immediately if you notice unusual
noises, a burnt smell or smoke. Have the
device checked by a qualified specialist
before using it again.
IB_354269_TLAL2A1_LB8_online.indb 11 19.04.2021 17:12:35

■ 12 │ GB│IE TLAL 2 A1
■ Never open the device housing. There
are no parts inside the device which
can be maintained. All repairs must
be carried out by authorised specialist
companies or by the Customer Service
department. Improper repairs may put
the user at risk. It will also invalidate any
warranty claims.
Package contents
♦ Remove all parts and the operating
instructions from the box.
♦ Remove all packaging material.
DANGER
► Do not allow children to play with
packaging materials.
There is a risk of suffocation.
IB_354269_TLAL2A1_LB8_online.indb 12 19.04.2021 17:12:35

GB│IE │ 13 ■TLAL 2 A1
The following components are included in
delivery:
▯ In-car charger
▯ These operating instructions
NOTE
► Check the package for completeness
and signs of visible damage.
► If the delivery is incomplete or damage
has occurred as a result of defective
packaging or during transport, contact
the service hotline (see section Service).
Description of components
1USB type A socket (green) featuring
Qualcomm®Quick ChargeTM 3.0
2USB type A socket
3Operating LED
IB_354269_TLAL2A1_LB8_online.indb 13 19.04.2021 17:12:35

■ 14 │ GB│IE TLAL 2 A1
Use
CAUTION
► The total power consumption of all
of the devices connected to the two
USB sockets 1/2may not be higher
than 5.4 A. Make sure that the power
consumption of your device is not
higher than 3 A when you are using
the USB socket (green) 1. When you
are using the USB socket 2, make
sure that the power consumption of
your device is not higher than 2.4 A.
Refer to your USB device instruction
manual for more information.
► The maximum power output of the
car charger adapter is 5.4 A.
The maximum power output of the
USB socket (green) 1is 3 A.
The maximum power output of the
USB socket 2is 2.4 A.
IB_354269_TLAL2A1_LB8_online.indb 14 19.04.2021 17:12:35

GB│IE │ 15 ■TLAL 2 A1
NOTE
► The USB socket (green) 1supports
Qualcomm®Quick ChargeTM 3.0
(compatible with Quick ChargeTM 2.0
and Quick ChargeTM 1.0). If the con-
nected device is compatible with this
charging standard, it will automatically
be detected by the car charger adapt-
er. The car charger adapter supplies
the appropriate output voltage or
output current so that the device can
be charged more quickly. Devices
without this charging standard can
be charged normally using the USB
socket (green) 1.
IB_354269_TLAL2A1_LB8_online.indb 15 19.04.2021 17:12:35

■ 16 │ GB│IE TLAL 2 A1
♦ Insert the car charger adapter into the
12/24V connection of your car. This
is usually the vehicle socket (cigarette
lighter) on the dashboard of your vehicle.
Many vehicles have a second socket
by the rear seats or in the boot. 24 volt
batteries are often used in lorries or on
boats.
♦ The operating LED 3lights up white to
signal that the car charger adapter is
being supplied with power. The operating
LED 3also lights up if no device is
connected. Depending on the vehicle
type, it is possible that the ignition has
to be switched on first.
♦ Connect your device to the car charger
adapter. Use the original USB cable
supplied with your device to optimise
the charging process.
♦ If required, you can switch your connected
device on for further use.
IB_354269_TLAL2A1_LB8_online.indb 16 19.04.2021 17:12:35

GB│IE │ 17 ■TLAL 2 A1
NOTE
► Observe the charging status on your
connected device.
♦ Disconnect your connected device from
the car charger adapter once the device
has completed charging.
♦ Unplug the car charger adapter from
the vehicle power outlet when you are
finished using it.
CAUTION
► Never connect the car charger adapter
unless you are charging a device. The
car charger adapter also consumes
power in standby mode and therefore
must be disconnected from the vehicle
socket after use! Otherwise the battery
will discharge when the engine is not
running.
IB_354269_TLAL2A1_LB8_online.indb 17 19.04.2021 17:12:35
