ProLights RA2000PROFILEHB User manual

USER MANUAL
RA2000PROFILEHB
LED MOVING PROFILE
EN

All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be
reproduced in any form or by any means for any commercial use.
In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the
characteristics stated in this instruction manual at any time and without prior notice.
All revisions and updates are available in the ‘manuals’ section on site www.musiclights.it
REV .01-12/19

1
RA2000PROFILEHB
Packing content • RA2000PROFILEHB
• Power cable
• OS25 (2 pcs)
• Safety cable
• User manual
TABLE OF CONTENTS Safety
General instructions
Warnings and installation precautions
1 Introduction
1. 1 Description
1. 2 Operating elements and connections
2 Installation
2. 1 Mounting
3 Functions and settings
3. 1 Operation
3. 2 Basic
3. 3 Menu structure
3. 4 Linking
3. 5 DMX addressing conguration
3. 6 DMX mode conguration
3. 7 DMX addressing
3. 8 Movement
3. 9 Screen
3. 10 Fixture settings
3. 11 Fans mode
3. 12 Auto and manual test
3. 13 Reset of the function
3. 14 Adjust
3. 15 Informaion of the device
3. 16 DMX view
3. 17 Connection of the DMX line
3. 18 Construction of the DMX termination
3. 19 DMX control
3. 20 Color - Gobos wheel
4 Maintenance
4. 1 Maintenance and cleaning the unit
4. 2 Fuse replacement
4. 3 Trouble shooting
2
2
3
4
5
6
6
7
10
10
10
10
11
12
12
13
13
13
13
13
14
15
15
16
22
23
23
24

RA2000PROFILEHB
2
WARNING! Before carrying out any operations with the unit, carefully read this instruction
manual and keep it with cure for future reference. It contains important information about
the installation, usage and maintenance of the unit.
SAFETY
General instruction
• The products referred to in this manual conform to the European Community Directives and are there-
fore marked with and approved for the North American Market.
• The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.
Never make any modications on the unit not described in this instruction manual, otherwise you will
risk an electric shock.
• Connection must be made to a power supply system tted with ecient earthing (Class I appliance ac-
cording to standard EN 60598-1). It is, moreover, recommended to protect the supply lines of the units
from indirect contact and/or shorting to earth by using appropriately sized residual current devices.
• The connection to the main network of electric distribution must be carried out by a qualied electrical
installer. Check that the main frequency and voltage correspond to those for which the unit is designed
as given on the electrical data label.
• This unit is not for home use, only professional applications.
• Never use the xture under the following conditions:
• - in places wet;
• - in places subject to vibrations or bumps;
• - in places with a temperature of over 45 °C.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Do not dismantle or modify the xture.
• All work must always be carried out by qualied technical personnel. Contact the nearest sales point for
an inspection or contact the manufacturer directly.
• If the unit is to be put out of operation denitively, take it to a local recycling
• plant for a disposal which is not harmful to the environment.
Warnings and installation precautions
• If this device will be operated in any way dierent to the one described in this manual, it may suer
damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like
short circuit, burns, electric shock, etc.
• Before starting any maintenance work or cleaning the projector, cut o power from the main supply.
• Always additionally secure the projector with the safety rope. When carrying out any work, always com-
ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country
in which the xture’s being used.
• For inside use only. Not designed for outside use.
• The minimum distance between the xture and surrounding walls must be more than 50 cm and the
air vents at the housing must not be covered in any case.
• Install the xture in a well ventilated place.
• Keep any inammable material at a safe distance from the xture.
• The maximum temperature that can be reached on the external surface of the tting, in a thermally
steady state, is high. After power o, please cool down over 15 minutes.
• Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent
that their eectiveness is impaired.
• The lamp (LED) shall be changed if it has become damaged or thermally deformed.
• Never look directly at the light beam. Please note that fast changes in lighting, e. g. ashing light, may
trigger epileptic seizures in photosensitive persons or persons with epilepsy.
• This product was designed and built strictly for the use indicated in this documentation. Any other use,
not expressly indicated here, could compromise the good condition/operation of the product and/or
be a source of danger.
• We decline any liability deriving from improper use of the product.

3
RA2000PROFILEHB
- 1 - INTRODUCTION
1.1 TECHNICAL DRAWING
443
697
293
443
697
507
Technical drawing Fig.1

RA2000PROFILEHB
4
13
89 10 11 12
6 7
7
1
2
3
5
4
1.3 OPERATING ELEMENTS AND CONNECTIONS
1. MOVING HEAD
2. TILT Mechanism Lock and Release
3. ROTARY ARM
4. PAN Mechanism Lock and Release
5. BASE
6. HANDLE
7. CONTROL PANEL with TFT display
and 5 button used to access
the control panel functions and
manage them.
8. POWER IN (PowerCON TRUE
IN): for connection to a socket
(100-240V~/50-60Hz) via the
supplied mains cable.
9. POWER OUT (PowerCON
TRUE OUT): power output for
connection of multiple units in
series.
10. MAIN FUSE HOLDER: replace a
burnt-out fuse by one of the same
type only.
11. DMX IN (5-pole XLR):
1 = ground, 2 = DMX-, 3 = DMX+,
4 N/C, 5 N/C.
12. DMX OUT (5-pole XLR):
1 = ground, 2 = DMX-, 3 = DMX+,
4 N/C, 5 N/C.
13. RUBBER FEET
Fig.2

5
RA2000PROFILEHB
- 2 - INSTALLATION
2.1 MOUNTING
The RA2000PROFILEHB may be set up on a solid and even surface. By means of the xing facilities of the
baseplate, the unit can also be mounted upside down to a cross arm. The base plate is shown in g.3. For
xing, stable mounting clips are required. According to the gure, the bolts of the brackets are placed into
the openings provided in the base plate and turned clockwise until they lock (to the stop). Always ensure
that the unit is rmly xed to avoid vibration and slipping while operating.The mounting place must be of
sucient stability and be able to support a weight of 10 times of the unit’s weight. When carrying out any
installation, always comply scrupulously with all the regulations (particularly regarding safety) currently
in force in the country in which the xture’s being used. Always additionally secure the projector with the
safety rope from falling down. For this purpose, fasten the safety rope at a suitable position so that the
maximum fall of the projector will be 20 cm.
Fig.3
CLAMPS
OMEGA

RA2000PROFILEHB
6
- 3 - FUNCTIONS AND SETTINGS
3.1 OPERATION
Connect the supplied main cable to a socket (100-240V~/50-60Hz). The unit will run built-in program to
reset all motors to their home position. Shortly after that the RA2000PROFILEHB is ready for operation.
To switch o, disconnect the mains plug from the socket. For a more convenient operation it is recom-
mended to connect the unit to a socket which can be switched on and o via light switch.
NOTE: remove the pan and tilt lock before connecting the RA2000PROFILEHB to the power supply.
3.2 BASIC
The control panel of RA2000PROFILEHB has a display and 5 buttons for the complete programming and
management of the projector menu (g.4).
Fig.4 - Functions of the buttons and display icons
UP DOWN LEFT RIGHT ENTER
Increases the value
displayed or passes
to the previous item
in a menu
Decreases the value
displayed or passes
to the next item in
the menu
Return to the top
level
Commute from
units, tens, hundred
in the menu
Conrms the
displayed value,
or activates the
displayed function,
or enters the
successive menu

7
RA2000PROFILEHB
3.3 MENU STRUCTURE
MENU
1CONNECT ðAddress ðValue (1-512)
DMX Mode ðStandard 38Ch
Standard 40Ch
Extended 39Ch
Extended 41Ch
Extended 42Ch
Standard 38Ch
2SET UP ðMovement ðPan Reverse ðNO/YES Default: No
Tilt Reverse ðNO/YES Default: No
Pan Feedback ðNO/YES Default: Yes
Tilt Feedback ðNO/YES Default: Yes
Screen ðBacklight ðOn/10s/20s/ 30s Default: On
Flip Display ðNO/AUTO/YES Default: No
Warn Cue ðON/OFF Default:On
Key Lock ðNO/YES Default: No
Fixture ðDimmer Mode ðOFF/Dimmer 1/Dimmer 2/Dimmer 3 Default: O
Fans Mode ðAuto/Silent/High/O Default: Auto
Temperature unit ð°C /°F Default: °C
Auto Test ðAutoTest …
Manual Test ðPan
Pan Fine
Tilt
Tilt Fine
P/T Speed
Dimmer
Shutter
Cyan
Magenta
Yellow
CTO
Color
Gobo
RGobo
PrismRot.
Eect
REect
Focus
Zoom
Frost 1
Frost 2
Iris
ðValue (000-255) for each function Default:
Tilt=128
Dimmer=255
Shutter = 255

RA2000PROFILEHB
8
Fr.shutters Rot.
Fr.shutter 1 Move.
Fr.shutter 1 Swiv.
Fr.shutter 2 Move.
Fr.shutter 2 Swiv.
Fr.shutter 3 Move.
Fr.shutter 3 Swiv.
Fr.shutter 4 Move.
Fr.shutter 4 Swiv.
ðValue (000-255) for each function
3ADVANCED ðReset ðAll
Pan
Tilt
Cyan
Magenta
Yellow
CTO
Color
Gobo
Prism
Eect
Focus
Zoom
Frost1
Frost2
Iris
Fr.shutters Rot.
Fr.shutter 1 M1
Fr.shutter 1 M2
Fr.shutter 2 M1
Fr.shutter 2 M2
Fr.shutter 3 M1
Fr.shutter 3 M2
Fr.shutter 4 M1
Fr.shutter 4 M2
ðValue (000-255) for each function

9
RA2000PROFILEHB
Adjust ðPan
Tilt
Cyan
Magenta
Yellow
CTO
Color
Gobo
RGobo
Prism
Rot Prism
Eect
Focus
Zoom
Frost 1
Frost 2
Iris
Fr.shutters Rot.
Fr.shutter 1 M1
Fr.shutter 1 M2
Fr.shutter 2 M1
Fr.shutter 2 M2
Fr.shutter 3 M1
Fr.shutter 3 M2
Fr.shutter 4 M1
Fr.shutter 4 M2
ðValue (000-255) for each function
Factory Reload ðNO/YES ðValue (000-255)
4INFORMATION ðFixture Time ð0-9999
Temperature ð58 °C
Fans Speed ð**%
Software Version ðDISP- V1.0
NET-V1.0
CTR1-XY- V1.0
CTR2- MOTOR -V1.0
CTR3-MOTOR-V1.0
CTR4-MOTOR-V1.0
FPGA-------2.0
UID ð15D00237****
View DMX

RA2000PROFILEHB
10
3.4 LINKING
Several units may be interconnected in order to control all further slave units to the same eect of the
master unit.
1. Connect the DMX OUT of the master unit via 3/5-pole XLR cable to the DMX IN of the rst slave unit.
2. Connect the DMX OUT of the rst slave unit to the DMX IN of the second slave unit, etc. until all units
are connected in a chain.
3.5 DMX ADDRESSING CONFIGURATION
To enter the DMX mode, follow these steps:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select Connect, then press the ENTER button to enter the
next menu.
• Press the UP/DOWN button to scroll through the menu, select the Address and press the ENTER key.
• Press the arrow keys to select the desired value (001-512).
• Press the ENTER key to conrm the setting.
• Press the LEFT button repeatedly to exit the menu and save changes.
3.6 DMX MODE CONFIGURATION
RA2000PROFILEHB has 5 DMX channel congurations that can be accessed from the control panel.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Connect, then press the ENTER button to
enter the next DMX Mode menu.
• Press the ENTER button and select DMX Mode with the UP/ DOWN button, then conrm the selection with
the ENTER button.
• Use the UP/DOWN button to select the desired DMX channel conguration (Standard 38Ch, Standard 40Ch,
Extended 39Ch, Extended 41Ch, Extended 42Ch), then press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
The tables on page 19, 20, 21, 22, 23, 24 indicate the operating modes and related DMX values. As a DMX
interface, the unit has 5-pin XLR contacts.
3.7 DMX ADDRESSING
For operation via a light control unit with DMX512 protocol, simply connect RA2000PROFILEHB to the
controller. The projector has a DMX channel conguration that can be accessed from the control panel.
In order to control RA2000PROFILEHB with a light control unit, the DMX start address must be set for the
rst DMX channel.
If, for example, address 33 is provided on the control unit to control the function of the rst one DMX
channel, the start address 33 must be set on the RA2000PROFILEHB. The other panel functions will be
automatically assigned to the following addresses.

11
RA2000PROFILEHB
3.8 MOVEMENT
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button ac-
cess the next menu.
• Press the UP/DOWN button to select Movement and press the ENTER button to proceed.
• Select the proposed option with the UP/DOWN button and press the ENTER button to conrm.
-Pan Reverse - Rotation in the opposite direction of the moving head. NO to deactivate the function
(normal setting); YES to activate the function (Pan Reverse).
-Tilt Reverse - Inclination in the opposite direction of the moving head. NO to deactivate the function
(normal setting), YES to activate the function (Tilt Reverse).
-Pan/Tilt Feedbacks - Rearrange Pan/Tilt position after accidental shift. Select NO for deactivate the
function or YES to activate the function.
• Press the ENTER button to conrm the selection.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
Fig.5 - Example of a DMX 38-channel conguration
DMX Address: 147
DMX Address: 109
DMX Address: 33 DMX Address: 71
. . . . . . . . . . . .
DMX512 Controller
Number of
DMX channels
Start address
(example)
DMX Address
occupied
Next possible start
address for unit No. 1
Next possible start
address for unit No. 2
Next possible start
address for unit No. 3
38 33 33-70 71 109 147
39 33 33-71 72 111 150
40 33 33-72 73 113 153
41 33 33-73 74 115 156
42 33 33-74 75 117 159

RA2000PROFILEHB
12
3.9 SCREEN
• It is possible to modify the following parameters, related to the display, following the same procedure:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button ac-
cess the next menu.
• Press the UP/DOWN button to select Screen and press the ENTER button to proceed.
• Select the proposed option with the UP/DOWN button and press the ENTER button to conrm.
-Backlight - Auto O display backlight. This function allows you to switch o automatically
the backlighting of the display after a certain time which can be set using the directional keys. To have the
display always on select On or set a value between those shown (10s, 20s, 30s) to turn o the display once
the chosen time has elapsed, after exiting the menu.
-Flip Display - Display orientation. This feature allows you to rotate the display by 180 ° to get a better
view of the display when the unit is hanging upside down. Select YES to activate the function or NO
to deactivate it.
-Warn Cue - Warning of error. Use the arrow keys to select OFF or ON depending on whether or not the
display shows error warnings.
-Key lock - With this function, you can lock the keys on the control panel to prevent, for example, tam-
pering with the settings. If this function is activated, the keys are locked automatically. To disable or
temporarily disable or disable the key lock function, press the keys in the following order to regain
access to the menu commands:
• UP, DOWN, UP, DOWN, ENTER. Select YES to activate the function or NO to deactivate it.
• Press the ENTER button to conrm the selection.
• Press the LEFT key repeatedly to exit the menu and to save the changes made.
3.10 FIXTURE
-Dimmer mode - select this function to choose and simulate dierent dimming curves:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button ac-
cess the next menu.
• Press the UP/DOWN button to select Fixture and press the ENTER button to proceed.
• Press the UP/DOWN button to scroll through the menu, then select Dimmer mode and press the ENTER
button to conrm.
• Press the UP/DOWN button to select the mode (O - Dimmer1 - Dimmer2 - Dimmer3), then press the ENTER
button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
-Temperature - Select this function to set the unit of measurement of the temperature shown on the
display:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button to
access the next menu.
• Press the UP/DOWN button to select Fixture and press the ENTER button to proceed.
• Press the UP/DOWN button to scroll through the menu, then select Temperature °C/F and press the ENTER
button to conrm.
• Press the UP / DOWN button to select the Celsius / Fahrenheit measurement unit, then press the ENTER
button to conrm the selection.
• Press the LEFT buttton repeatedly to exit the menu and to save the changes made.

13
RA2000PROFILEHB
3. 11 FANS MODE
• Select this function to set the fan operating mode:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button ac-
cess the next menu.
• Press the UP/DOWN button to select Fixture and press the ENTER button to proceed.
• Press the UP/DOWN button to scroll through the menu, then select Fans Mode and press the ENTER but-
ton to conrm.
• Press the UP/DOWN button to select the Auto/Silent/High/O mode, then press the ENTER button to con-
rm your choice.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
3.12 AUTO E MANUAL TEST
Through these menus it is possible to test the functioning of all the functions of the moving head.
3.13 RESET OF THE FUNCTIONS
You can start a preset program to restore the selected function:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select Advanced, then press the ENTER button
to enter the next menu.
• Press the UP/DOWN button to select Reset and press the ENTER button to access the next menu.
• Press the UP/DOWN button to scroll through the menu, then select the function you want to reset
between those.
• Press the ENTER button to conrm the selection and wait for the selected function to be restored.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
3.14 ADJUST
• This function allows you to change all parameters. Press the UP/DOWN buttons to select one of the
parameters and press ENTER to change the value (000-999) using the UP/DOWN buttons.
• Press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and to save the changes made.
3.15 INFORMATION ON THE DEVICE
• To view all the information on the device, proceed as follows:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to select Information, then press the ENTER button to access the next
menu.
• Press the UP/DOWN button to scroll through the menu, then select one of the following information
and press the ENTER button to display it.
-Fixture Time - Through the Fixture Time function, the operating time of the projector can be shown on
the display.
-Temperature - Through the Temperature function it is possible to display on the display the temperature
inside the moving head, where the lamp is located. The temperature can be displayed in degrees
Celsius or Fahrenheit.
-Fans Speed - Through the Fans Speed function it is possible to display on the display the fan speed pre-
sent near the lamp. The speed measurement is expressed in RPM (revolutions per minute).
-Software Version - Through the Software Version function, the version of the installed software can be

RA2000PROFILEHB
14
viewed on the display.
-UID - Select the UID function to display the identication ID for the RDM control.
• Press the LEFT button repeatedly to exit the menu.
3.16 DMX VIEW
Select the View DMX to visualize the DMX values received by the xture for each channel during its opera-
tion.
NOTE: if the Motor fast mode is active, the speeds of all the engines increase to the maximum possible.
The RA2000PROFILEHB manages all the motors in a“smooth”mode by default, when the Motor fast mode
is activated the speeds increase to max and the smooth is lost.

15
RA2000PROFILEHB
3.17 CONNECTION OF THE DMX LINE
DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped-
ance and low capacity.
The following diagram shows the connection mode:
Fig.6
DMX - OUTPUT
XLR socket
DMX - INPUT
XLR plug
Pin1 : GND - Shield
Pin2 : - Negative
Pin3 : + Positive
Pin4 : N/C
Pin5 : N/C
ATTENTION
The screened parts of the cable (sleeve) must never be connected to the system’s earth, as this would
cause faulty xture and controller operation.
Over long runs can be necessary to insert a DMX level matching amplier.
For those connections the use of balanced microphone cable is not recommended because it cannot
transmit control DMX data reliably.
• Connect the controller DMX input to the DMX output of the rst unit.
• Connect the DMX output to the DMX input of the following unit. Connect again the output to the input
of the following unit until all the units are connected in chain.
• When the signal cable has to run longer distance is recommended to insert a DMX termination on the
last unit.
3.18 CONSTRUCTION OF THE DMX TERMINATION
The termination avoids the risk of DMX 512 signals being reected back along the cable when they reach-
es the end of the line: under certain conditions and with certain cable lengths, this could cause them to
cancel the original signals.
The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the 5-pin male XLR
connector, as shown in gure.
Fig.7
Example:
5 pin XLR connector
4

RA2000PROFILEHB
16
3.19 DMX CONTROL
38 Ch 39 Ch 40 Ch 41 Ch 42 Ch FUNCTION DMX
Value
11111PAN 8bit
0~100% 000 - 255
22222PAN 16bit
0~100% 000 - 255
33333TILT 8bit
0~100% 000 - 255
44444TILT 16bit
0~100% 000 - 255
55555
P/T SPEED
Fastest to slowest
Movement with Blackout
000 - 250
251 - 255
66666
SHUTTER
No function (shutter open)
Shutter eect slow to fast
No function (shutter open)
Pulse-eect in sequences
No function (shutter open)
Random Shutter eect slow to fast
No function (shutter open)
000 - 010
011 - 082
083 - 093
094 - 163
164 - 174
175 - 243
244 - 255
77777DIMMER 8bit
0~100% 000 - 255
88888DIMMER 16bit
0~100% 000 - 255
99999
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer speed mode o
Dimmer speed mode1 (fast speed)
Dimmer speed mode2 (middle speed)
Dimmer speed mode3 (slow speed)
000-051
052-101
102-152
153-203
204-255
10 10 10 10 10 CYAN
0~100% 000 - 255
11 11 11 11 11 MAGENTA
0~100% 000 - 255
12 12 12 12 12 YELLOW
0~100% 000 - 255
13 13 13 13 13 CTO
0~100% 000 - 255

17
RA2000PROFILEHB
38 Ch 39 Ch 40 Ch 41 Ch 42 Ch FUNCTION DMX
Value
14 14 14 14 14
COLOR
Open
Open+Color1
Color1
Color1+Color2
Color2
Color2+ Color3
Color3
Color3+ Color4
Color4
Color4+Color5
Color5
Color5+ Color6
Color6
Color6+ Open
Stop to fast(Forward Spin)
Fast to stop(Revers Spin)
Positioning from 0-360 degrees(Indexing)
000-004
005-009
010-013
014-018
019-022
023-027
028-031
032-036
037-040
041-045
046-049
050-054
055-058
059-063
064-095
096-127
128-255
15 15 15 15 15
ROTATING GOBO WHEEL
Open
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 1 (Position 1 Shake,from slow to fast)
Position 2 (Position 2 Shake,from slow to fast)
Position 3 (Position 3 Shake,from slow to fast)
Position 4 (Position 4 Shake,from slow to fast)
Position 5 (Position 5 Shake,from slow to fast)
Position 6 (Position 6 Shake,from slow to fast)
Position 7 (Position 7 Shake,from slow to fast)
Stop to fastest (Forward Wheel Spin)
Stop to fastest (Reverse Wheel Spin)
000 - 005
006 - 010
011 - 015
016 - 020
021 - 025
026 - 030
031 - 035
036 - 040
041 - 055
056 - 070
071 - 085
086 - 100
101 - 115
116 - 130
131 - 145
146 - 200
201 - 255
16 16 16 16 16
RGOBO
Positioning from 0-360 degrees(Indexing)
Slowest to fastest(Forward Spin)
Stop
Fastest to Slowest(Reverse Spin)
000 - 191
192 - 221
222 - 225
226 - 255

RA2000PROFILEHB
18
38 Ch 39 Ch 40 Ch 41 Ch 42 Ch FUNCTION DMX
Value
/ / 17 17 17 RGOBO FINE 000 - 255
17 17 18 18 18
PRISM ROT
Open
Insertion and Positioning from 0-360(Index)
Slowest to fastest (Forward Spin)
Fastest to Slowest (Reverse Spin)
000 - 005
006 - 191
192 - 223
224 - 255
19 19 19 PRISM ROT FINE 000 - 255
18 18 20 20 20 FROST 1
Frost1 0->100% 000 - 255
19 19 21 21 21 FROST 2
Frost1 0->100% 000 - 255
/ 20 / 22 22
AUTO FOCUS
Auto Focus O
Hole
4 metres
6 metres
8 metres
10 metres
12 metres
14 metres
16 metres
18 metres
Rotating gobo wheel
4 metres
6 metres
8 metres
10 metres
12 metres
14 metres
16 metres
18 metres
Reserved
000 - 000
001 - 007
008 - 015
016 - 023
024 - 031
032 - 039
040 - 047
048 - 055
056 - 063
064 - 071
072 - 079
080 - 087
088 - 095
096 - 103
104 - 111
112 - 119
120 - 127
128 - 255
20 21 22 23 23 FOCUS 8bit
Focus 000 - 255
21 22 23 24 24 FOCUS 16bit
Focus Fine 000 - 255
22 23 24 25 25 ZOOM 8bit
Zoom 000 - 255
23 24 25 26 26 ZOOM 16bit
Zoom Fine 000 - 255
