Proline CAPTURE DMX512 User manual
Capture DMX512
USER
manual
USER MANUAL CAPTURE DMX512
Location
Don't installthedeviceatplaceswithmechanicalshakingsandvibrations,highdustiness
orhigh
temperature. Not keeping these conditions can lead to shorter lifetime or its damage.
DON´T exposethedevicetoinfluenceof water,rainormoisture.Itcouldleadtoelectric
shockorfire.
Ventilation
It is necessary to ensure fans against their covering and secure the devices to have
admissionofair.
Supplyvoltage
Don´t use any other supply voltage meant in technical specification and manufacture
label.Notkeepingpropersupplyvoltagecouldleadtodamagingthedevice,startingafire
oritswrongfunction.
Powercord
Check if power cord is not mechanical damaged and if it is connected properly. Check
also if the socket is designed sufficiently for needed loading. Otherwise there is a danger
of electric shock or a fire. Power cord must not be bent excessively, led through sharp
edgesor given tomechanical stress.Don´tpull the supplylead out bythe flex butonly by
theplug.The devicemustalwaysbeconnectedbehind the main switch.Do nottouchthe
supplyleadwithvethands,youarethreatenedbyelectricshock.
Otherimportantcautions
Don´t poke any objects into cooling fans and ventilator, it could lead to serious electric
shockordamagingthedevice.Becarefulofnowaterorotherliquidentering.
Maintenanceandcleaning
Don´t use any solvent and similar chemicals which could damage surface finish or some
parts of device. Use soft and smooth cloth for cleaning optical parts of device and its
surface. Never use washing powders or other cleaning agents with grinding effect.
Connectthedevicetopowersupplyaftercompletedrying.
Service
Never try to repair, dismantle or do some construction changes in case of any failure.
Always consult qualified employee or dealer. Not keeping this rule you can suffer
dangerouselectricshock.Disconnectthedevicefrommainsbeforereplacingthelampor
dismantling the housing. Not keeping this procedure you can suffer dangerous electric
shock.
Unplug mains lead before opening the housing and cleaning internal parts of device./
opticalsystem,dichroicfilters,etc/Youcansuffer electricshock.
Unpacking
Unpack the device and after acclimatisation take off the protective foil. Make sure that
therearenodamagescausedbytransportation.
Installation
The device can be installed in any position without alerting its operation. For mounting
use bracket of device, which is a mounting hole in. First make sure that the structure you
aregoingtoattachtheprojectorissecure.
Connection tothecontrol signal
Each function of device is addressed according to standard protocol DMX 512 /1990/4
us. It means, we can control this device by any other device, which provides signal
includedin protocol DMX512by serial line.Connectionis secured provided byscreened
double-lineendedbyconnectorJACK6,35/1/4"/.
Functionsof thedevice
CAPTUREDMX512
It is allow to save programs from whatever DMX controller. After saving programs you
chosen youcanthem transmittoyourdevices.Builtup 8memoryplaces,buttonchoice
for choice program /1-8/, AUDIO / mode of work according to coming sound impulses/,
Black Out, Potentiometer on speed setting saved program. Display screened number
working program, 2 modes of work sound, automat, STRING / setting program
sequence/.
DMX IN- input DMX signal. In condition of it is Jack connector in DMX IN, function of the
buttonAudio/WriteitissetonWRITE
DMXOUT-outputDMXsignal
MIC-microphonecapturingsound,signal
POWER- connectoronadapter
SPEED-settingofmakingprograms/leftfast,rightslow/
STRING - after pressing indicates on display point to the right. Programs, witch are
marked,willchain/programsequence/.Switchactiveanddeactive.
AUDIO/WRITE - when connector DMX IN is busy, button is for writing programs, when it
isnotbusyswitchmodeaudio/automat
PRGUP,PRGDOWN-Buttonsforgoingbetweenprograms
BLACKOUT-settingBlackOut
DMX systemisadigitalsystem,bywhich are moved all informations between
individual devices through one cable system IN/OUT. Abstractedly you can control by
DMX signal a lot of devices. The device connected to DMX signal have to be addressed
and this address determine , which informations from DMX , will be addressed exactly
toher.DMXsystem needs foritsactivityspecialcables /because frequencyoftransmitis
about 12 times higher then audio frequency has/, with characteristic impedance 120
ohm.
WorkwithCAPTUREDMX512
The controller is for saving programs, witch you chose from controllers DMX512, into
memory.
5Every pressingbybuttonsisindicated byLEDorbypointonadisplay
5LEDforpressingBlackOutindicatespermanentBLACKOUTforthedevices
5ProcessofthenotationisindicatedbyLEDonthebutton.Finishing of the notation is
possible by repeatedly pressing WRITE , by filling up of the program memory, or
when it is not DMX signal 5 sec. .After finishing of the notation LED don´t lights , set
BlackOut. The notation is possible only when BlackOut is switch off. The notation
startsafterreceiving2DMXpacketsofthecontroller..
5Theprograminsequenceisindicatedbypointonarightpositionofdisplay
5Set AUDIOmodeisindicatedbypointonaleftpositionofdisplay.
CAUTION: Theproducerdon´twarrantfunctionsofthedevicewitheveryDMXcontroller
inmarketing!
RESET-clearingdownthedevice
Press BlackOut and switch on the device. After 4.sec display screen "CC" and whole
memoryofthedevicecleardown.
Settingsizeofpacket
PressAUDIO/WRITEandswitchonthedevice.After4secdisplayhexadecimalvaluebig
asainput packet. By buttonsPRGUPand PRGDOWNyouadjust the value andconfirm
by BlackOut. Size of input packet determine way of CAPTURE regulation of notation
intomemory.For illustration: DMX controller USC-128 transmit inmaximal configuration
/16 scanners-8 channels/ 128 B packet /16x8/. It means that in case of setting packet on
size FF / can be 00/ is packed big 256 bytes and 128 bytes is idle and takes place in
memorywitchyoucanuseotherway.
Choiceofsomehexadecimalvalues:
hexa decimal hexa decimal
10 16 60 96
20 32 80 128
40 64 FF 255
Protectionofwrittenprograms
In case you want to save your data written in memory you can use program Lock. The
Lockisapplied byfollowingway:
5bybuttonPRGDOWNandPRGUPyouchoiceprogram
5by pressing BlackOUT, PRG DOWN, PRG UP together you lock or unlock an
actuallyprogram.Accordingtoconditiononadisplayis "CL"-closed/lock/, "oP"
-open/unlock/.
5Ifyouwanttorewritelockedprograms,onadisplayis"CL"anddon´tallowwrite.
Technicalspecification
Supplyvoltage adapter12V
Fuse T100mA5x20mm
Powerconsumption 10VA
Weight 1Kg
Dimensions 205x160x45
DMXinput/output DMX512/1990/4us,6,35stereoJack
/Data+,Data,-,OV/
