WARNINGS
Thisapplianceisintendedfordomestichouseholduseonlyandshouldnotbeused
foranyotherpurposeorinanyotherapplication,suchasfornonͲdomesticuseorin
acommercialenvironment.

Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersons
withreducedphysical,sensoryormentalcapabilitiesorlackofexperienceand
knowledgeiftheyhavebeengivensupervisionorinstructionconcerninguseofthe
applianceinasafewayandunderstandthehazardsinvolved.Childrenshallnotplay
withtheappliance.Cleaningandusermaintenanceshallnotbemadebychildren
withoutsupervision.

WARNING:Theapplianceanditsaccessiblepartsbecomehotduringuse.Care
shouldbetakentoavoidtouchingheatingelements.Childrenlessthan8yearsofage
shallbekeptawayunlesscontinuouslysupervised.

Ifthesupplycordisdamaged,itmustbereplacedbythemanufacturer,itsservice
agentorsimilarlyqualifiedpersonsinordertoavoidahazard.

Duringusetheappliancebecomeshot.Careshouldbetakentoavoidtouching
heatingelementsinsidetheoven.

WARNING:Accessiblepartsmaybecomehotduringuse.Youngchildrenshould
bekeptaway.

Donotuseharshabrasivecleanersorsharpmetalscraperstocleantheovendoor
glasssincetheycanscratchthesurfacewhichmayresultinshatteringoftheglass.

Donotuseasteamcleaner.

WARNING:Ensurethattheapplianceisswitchedoff(circuitbreakerisopen)
beforereplacingthelamptoavoidthepossibilityofelectricshock.

ExcessivespillagemustberemovedbeforeoperatingtheoveninselfͲcleaningmode.

Aftereachcookingcycle,thecoolingfanwillcontinuetorunforawhiletoensurea
coolingandsafeoperationoftheoven.

Downloaded from www.vandenborre.be
3


IMPORTANTSAFETYINSTRUCTIONS
Theovenmustbeproperlyinstalledandgroundedbyaqualifiedtechnician.
Donotwearlooseorhanginggarmentswhenusingtheoven.Theycouldigniteif
theytouchahotheatingelementandthismayleadtotheriskofburning
yourself.
Donotstoreflammablematerialsonorneartheoven.Thismaycauseafire
hazard.


DESCRIPTIONOFTHEOVEN

Controlpanel
TheovenisdesignedwithpushͲpullcontrolknobs.Theseknobscanbecompletely
sunkeninsidethecontrolpanelwhentheovenisnotworking.



Functioncontrolknob Thermostatcontrolknob
Timerbutton  Clocktimebutton  Startbutton  Pause/stopbutton


Thedoorshouldpreferablybeclosedinallcookingmodes.

Donothanganyclothorgarmenttothehandleoftheoven.

Donotlinetheoven’scavitywithaluminumfoilforeasiercleaning:Theovenmay
overheatandtheenamelcoatingofthecavitymaybedamaged.

Downloaded from www.vandenborre.be
4

Ovenlamp
Thefunctionallowstheovenlamptobeonwithoutany
cookingfunction.


Defrosting
Thisfunctioncirculatesroomtemperatureairaroundthe
food.

Bottomheat
Idealforcasseroles,curriesandanyslowcooking.The
temperaturecanbesetintherangeof60to120ćandthe
defaulttemperatureis60ć.
Conventional
Idealforsingleshelfcooking.Goodformeatandfruitpies.
Theovenneedstobepreheated.Thetemperaturecanbe
setintherangeof50to250ćandthedefaulttemperature
is220ć.
Conventionalwithfan
Thisfunctionusestopandbottomheatingelementswitha
fantocirculatetheair.Idealforgrillingorroastinglarge
piecesofmeat.Thetemperaturecanbesetintherangeof
50to250ćandthedefaulttemperatureis220ć.

Threestagevariablegrill
Thisfunctionprovidestheprecisetemperaturecontrolfora
fullwidthgrill.Thetemperaturecanbesetat180ć,210ć
or240ćandthedefaulttemperatureis210ć.

Dualgrill
Idealforgrillingflatfoodinlargequantitiesandfor
roasting.Thetemperaturecanbesetintherangeof180to
240ćandthedefaulttemperatureis210ć.

Dualgrillwithfan
Idealforroastinglargejointsofmeat.Thetemperaturecan
besetintherangeof180to240ćandthedefault
temperatureis210ć.

Convection
Inthisfunctionthefanautomaticallyturnsontoimprove
aircirculationandcreatesanevenheatforcooking.The
temperaturecanbesetintherangeof50to240ćandthe
defaulttemperatureis180ć.
Pyrolyticmode
Whenthisfunctionisselected,“PYA”willbeshownonthe
display.Thedefaulttemperatureis450ć.Thecleaning
timecanbesetfor1.5or2hours.



Display

Function
indicatorlights
Description

Downloaded from www.vandenborre.be
5


Ovenaccessories
 
WireshelfRoastingpan
Fordishes,caketinsanditemsfor
roastingandgrilling
Forbakingandroastingorfor
collectingfat





Pushthewireshelf/roastingpanbetweenthe
guidebarsintheoven.
Incasethattheovenshelfandtheroastingpan
areinsertedtogether,laythewireshelfonthe
roastingpan.


ELECTRICAL CONNECTION
Electrical connections must only be performed by a qualified and authorised
electrician.
The brown wire must be connected to the terminal marked L.
The blue wire must be
connected to the
terminal marked N.
The green and yellow wire must be connected to the letter E or the earth
symbol .

Downloaded from www.vandenborre.be
6



Securingtheoventothefurniture
1. Fittheovenintothefurniturerecess.
2. Opentheovendoor.
3. Securetheoventothefurniturewith twoholders(A)which fit 
theholesintheovenframeandfitthetwoscrews(B).

Warning:Inordertoensureadequateventilation,ensurethat
thereareairinletsandoutletsforventilatingtheinteriorofthe
furnitureadequately.
OPERATION
Whentheovenisoperational(poweron),thedisplaywillshow“0:00”andabeep
soundwillbeheard.Theclockissetona24Ͳhourcycle.

SettingtheClock
1. Press ,thehourdigitswillflash.
2. Turnthethermostatcontrolknobtosetthecorrecthour.
3. Press toconfirmthentheminutesdigitswillflash.
4. Turnthethermostatcontrolknobtosetthecorrectminutes.
5. Press toconfirm.“:”willflashonthedisplay.


575
595
595
560
600
850
50
80
250
100
570
600
560

INSTALLATION

The figures below give the dimensions for installation to the furniture.

Downloaded from www.vandenborre.be
7
1. Turnthefunctioncontrolknobtoselectthedesiredfunction.
2. Thecorrespondingindicatorlightwillbeilluminatedonthedisplay.
3. Turnthethermostatcontrolknobtoselectthedesiredtemperature.
Thedefaultcookingtimeis9hours(9:00).
setthedesiredcookingtime,turnthefunctioncontrolknobandpress to
confirm.

thecookingisfinished,theovenbuzzerwillsoundfivetimes.
tochecktheclocktimeduringcooking.
topausecookingandtoresumecookingpress .
stopcookingpress twice.


Timer
1. Instandbymode,press .
“”willbeilluminatedonthedisplay
2. Turnthethermostatcontrolknobtosetthehour.
Thetimercanbesetupto9hours(9:00).
3. Press toconfirm.
4. Turnthethermostatcontrolknobtosettheminutes.
5. Press toconfirm.
“:”willflashonthedisplay.
6. Afterthesettimehaselapsed,theovenbuzzerwillsoundand“”willgooffon
thedisplay.
Tocancelthetimer,press twice.


ChildsafetyLockfunction
Toactivatethechildsafetylockfunction,press and atthesametimeuntila
longbeepisheardand“”willbeilluminated.
Allthecontrolknobsandbuttonsarelocked.
6. When
7. Press
8. Press
9. To
Cooking
4. To
5.

Downloaded from www.vandenborre.be
8

Tounlockthecontrolknobsandbuttons,press and atthesametimeagain
untilalongbeepisheardand“”willgooff.


Energysavingfunction
Instandbymodepressandhold for3secondstoenterenergysavingmode.The
displaywillbeswitchedoff.
Ifthereisnooperationin10minutesinstandbymode,thedisplaywillbeswitched
off.
Pressanybuttonorturnthecontrolknobtoexittheenergysavingmode.



CLEANINGANDMAINTENANCE

1. Switchofftheapplianceandallowittocoolcompletelybeforecleaning.
2. Cleantheoutsideoftheappliancewithadampcloth.Neverusemetalpolish.
3. Washalltheremovablepartsinmildsoapedwater.Rinseanddrythoroughly
beforeuse.





PyrolyticselfͲcleaningfunction

ATTENTION:
xBeforestartingthePyrolyticcycle,REMOVEALLTHEACCESSORIESFROMTHE
OVENtopreventthemfromgettingdamaged.
xRemoveallexcessivespillagebeforeoperatingtheoveninselfͲcleaningfunction.

1. Turnthefunctioncontrolknobuntil“PYA”isilluminatedonthedisplay.
2. Press tostartcleaning.Thedefaultcleaningtimeis2hours(2:00).
3. Tochangethecleaningtime,turnthefunctioncontrolknobtoselectthecleaning
time(1:30or2hours).
4. Press toconfirmthesetting.


Downloaded from www.vandenborre.be
9
xWhenthedisplayshows“DOOR”itsignifiesthattheovendoorisopen.Please
closetheovendoorproperly.

xDuringtheselfͲcleaning,theovendoorcannotbeopenedforsafetyreason.In
ordertoopenthedoortheovenmustcooldownfirst.
xWhenthetemperatureinthecentreoftheovenishigherthan200ć,press 
twicetoreturntothestandbymode.
xWhenthetemperatureinthecentreoftheovenishigherthan300ć,press 
tostartcoolingandthedisplaywillshow“COOL”.


Replacingtheovenlamp
1. Removetheglasslampcoverbyunscrewingit.
2. Replacethelampwithanewone.
3. Screwtheglasslampoverbackinplace.




NOTE:
SPECIFICATIONS

BrandProline
AppliancetypeBuilt‐inOven
Rating/SupplyVoltageandfrequency220‐240V50/60Hz
Maxpower 3.2KW
Ovenlamppower 25W
Topheatingelement(W) 950
Grillheatingelement(w) 2000
Bottomheatingelement(W)1100
Convectionheatingelement(W) 2000
Convectionmotor(w) 33
Coolingfan(w) 36
Cleaning(Enamel/catalytic/Pyrolytic)Pyrolytic
NetWeightkg37.8
Product dimension(W*D*H)595*575*595mm
Cabinet/furniturecut‐outsizes(W*D*H)560*570*600mm
EnergyClass(letterforthesticker)*A
EnergyconsumptionKwh
Heatingfunction
Conventional 0.95
Forcedairconvection 0.85
Usablevolume(litres)65
Size:(Small/Medium/Large)Large
NoiseDb(A)re1pw58
Madein PRC
*Energyclass:A……G(A=economicalG=lesseconomical)

