ProLite DIGI-Q User manual

User Manual
What’s in the box
Ticket Dispenser Installation
Ticket Roll Installation
LED Queuing Unit Installation
Operation / Troubleshooting
Contact Us

What’s in the box?
1. LED queuing unit
2. Power adaptor
3. Wireless transmitter
4. Ticket number dispenser
5. Ticket dispenser hardware
o“L”bracket
oSwivel with mounting screws (4 pcs)
6. Ticket roll holder
7. Ticket number roll
Note: Some accessory items are stored in the actual product.
Ticket Counter
Dimensions:
12.625” (L)
6” (H)
3.625” (W)
Ticket Dispenser
Dimensions:
Refer to following
page.

Ticket Dispenser Installation
1) Mount the “L” bracket on a flat sturdy surface.
Note: “L” bracket surface mounting screws are not included.
2) Using the included mounting screws, install the Swivel onto the “L” bracket.
3) Snap the swivel onto the Ticket Dispenser.
(1)
(2)
(3)
6”
3”
10.5”
11.75”

Ticket Roll Installation
1) Press the release buttons to open the Ticket Dispenser.
2) Remove the Ticket Roll Holder from dispenser
3) Insert the Ticket Roll Holder through the center of the Ticket Number Roll.
4) Insert the assembled roll back into the Ticket Dispenser.
5) Before closing dispenser, feed the ticket to the front of the dispenser mouth.
1
2

LED Queuing Unit
1) Sit LED Unit on a flat sturdy surface.
2) Make sure the power switch is off (down position).
3) Remove the back cover from unit.
4) Connect the power adaptor to a wall outlet.
5) Connect the power connector to the inner connection inside the unit.
5) Replace back cover onto unit.
Note: Feed the power cable through the notch on the right side of the back cover.
6) Turn power switch on (up position).
7) When powered on, the unit will display the number zero.
(2)
(5)
6
5

Operation
Simply press the button on the Wireless Transmitter to advance the number.
A beep will sound every time the button is pressed.
Troubleshooting
The LED Queuing Unit does not turn on.
Make sure the light on the power adaptor is on. If it is not on, please try
another outlet.
Unplug the power connection from the LED unit and reconnect firmly.
Make sure the LED unit on/off switch is set to the up position.
How do I reset to zero?
Turn the LED unit off, and back on.
The Wireless Transmitter will not advance the number.
Stand 5 feet from the LED unit and try again.
Replace battery on the Transmitter.
oUse only ALKALINE TYPE 27A (12 Volts).
Make sure the Dip Switches on LED unit and Transmitter match (see below).
What are the Switches on the back of the LED unit and bottom of transmitter for?
The Dip Switches set the operating frequency of the unit. Please do not
change unless absolutely necessary. Sometimes there are other wireless
devices nearby effecting the communication of the Queuing system. If this is
occurring, simply change the Dip Switches on the LED unit to a different
setting arrangement and make sure the Transmitter is set identically.
LED Unit Dip Switches
Transmitter Dip Switches
