Promate PM7500 ES User manual

Operator Manual
IMPORTANT –
Please make certain that persons who are to use this equipment thoroughly read
and understand these instructions and any additional instructions
provided prior to operation.
Record the model and serial numbers of your Generator below:
Model No. Serial No.

Introduction .............................................. 1
Section 1 — Safety Rules ...................... 1
Standards Index ...........................................1
Section 2 — General Information.......... 4
2.1 Unpacking ....................................................... 4
2.2
Assembly......................................................... 4
Section 3 —Features and Controls........ 5
Section 4 — Preparation
Before Operation............... 6
4.1 Adding Engine Oil ........................................ 6
4.2 Adding Fuel ............................................... 6
4.3 Grounding the Generator.....................................................6
Section 6 — Maintenance....................10
6.1 Maintenance Schedule ................................10
6.2 General Recommendations .......................... 10
6.2.1 Generator Maintenance... ......................... 10
6.2.2 To Clean the Generator..................................................10
6.2.3 Engine Maintenance ............................... 10
6.2.4 Changing the Oil .................................... 11
6.2.5 Replacing the Spark Plug ........................ 11
6.2.6 Spark Arrestor.........................................................................11
6.3 Service Air Filter...................................................................................11
6.4 Valve Clearance ...............................................12
6.5
General .............................................................. 12
6.6 Other Storage Tips.......................................... 12
Section 7 — Storage. ......................... 12
Section 8 — Warranty Policy ............. 13
Section 5 — Operation ..........................7
5.1 Starting the Engine .......................................7
5.2 Connecting Electrical Loads ...........................9
5.3 Stopping the Engine .................................... 9
5.4 Low Oil Level Shutdown System .................... 9
5.5 High Altitude ...............................................9

1
INTRODUCTION
Thank you for purchasing products from
Powertech, we appreciate your business. Our
generator is a compact, high performance,
air-cooled, engine driven generator designed to
supply electrical power to operate electrical loads
on job sites, or to run home appliances during
outage; or provide power to remote locations
where utility power is unavailable.
This manual contains of safety information to
make you aware of hazards and risks associated
with generator products and how to avoid them.
It
is important that you read and understand
these
instructions thoroughly before attempting
to start
or operate this equipment. Save this
original
instruction for future reference.
If any portion of this manual is not understood,
contact the nearest authorized dealer for starting,
operating and servicing procedures. We also
strongly recommend you to instruct any other
users who may operate the equipment in an
emergency needed.
Every effort has been made to ensure that
information in this manual is both accurate and
current. However, Powertech Asia Pacific Inc.
reserves the right to change, alter or otherwise
improve the generator and this documentation at
any time without prior notice.
SECTION 1 –
SAFETY RULES
Read this manual carefully and become
familiar with your generator. Know its
applications, its limitations and any
hazards involved.
Throughout this publication, and on tags and
decals affixed to the generator, DANGER,
WARNING, CAUTION and NOTICE blocks are
used to alert personnel with special instructions
about an operation that may be hazardous if
performed incorrectly or carelessly. Observe
them carefully. Their definitions are as follows:
DANGER indicates-a-hazard which, if not
avoided, will result in death or serious injury.
WARNING indicates a hazard which, if not
avoided, could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
could result in minor or moderate injury.
NOTICE covers some practices not related to
personal injury.
Safety Symbols and Meanings
Toxic Fumes Kickback Electrical Shock
Fire Explosion Operator’s Manual
Moving Parts Flying Objects Hot Surface
WARING A running engine gives off carbon
monoxide, an odorless, colorless,
poison gas. Breathing carbon
monoxide could result in death,
serious injury, headache, fatigue,
dizziness,
vomiting, confusion,
seizures, nausea or fainting.
•Operate this product ONLY outdoors.
•Install a battery-operated carbon monoxide
alarm near the bedrooms.
•Keep exhaust gas away from entering a
confined
area through windows, doors,
ventilation intakes,
or other openings.
•NEVER operate this product inside any
building, carport, porch, mobile
equipment,
marine applications, or
enclosure, even if
windows and doors are
open.

2
WARNING Starter cord kickback (rapid
retraction) will pull hand and arm
toward engine faster than you can
let go which could cause broken
bones,
fractures, bruises, or sprains resulting in serious
injury.
•When starting engine, pull cord slowly until
resistance is felt and then pull rapidly to
avoid kickback.
•NEVER start or stop engine with electrical
devices plugged in and turned on.
WARNING Fuel and its vapors are
extremely flammable and
explosive which could cause
burns, fire or explosion
resulting in death, serious injury and/or
property damage.
WHEN ADDING OR DRAINING FUEL
•Turn generator engine OFF and let it cool at
least 2 minutes before removing fuel cap.
Loosen cap slowly to relieve pressure in tank.
•Fill or drain fuel tank outdoors.
•DO NOT overfill tank, Allow space for fuel
expansion.
•If fuel spills, wait until it evaporates before
starting engine.
•Keep fuel away from sparks, open flames, pilot
light, heat, and other ignition sources.
•Check fuel lines, tank, cap and fittings
frequently for cracks or leaks. Replace
if necessary.
•DO NOT light a cigarette or smoke.
WHEN STARTING EQUIPMENT
•Ensure spark plug, muffler, fuel cap, and air
cleaner are in place.
•DO NOT crank engine with spark plug removed.
WHEN OPERATING EQUIPMENT
•DO NOT operate this product inside any
building, carport, porch, mobile
equipment, marine applications, or
enclosure.
•DO NOT tip engine or equipment at angle
which cause fuel to spill.
•DO NOT stop engine by moving choke control
to “OFF” position.
WHEN TRANSPORTING, OR REPAIRING
EQUIPMENT
• Transport/move/repair with fuel tank EMPTY or
with fuel valve OFF.
• DO NOT tip engine or equipment at angle which
cause fuel to spill.
• Disconnect spark plug wire.
WHEN STORING FUEL OR EQUIPMENT WITH
FUEL IN TANK
• Store away from furnaces, stoves, water
heaters, clothes dryers, or other appliances
that have light or other ignition source
because they could ignite fuel vapors.
WARNING Generator voltage could cause
electrical shock or burn
resulting in death or serious
injury.
Use approved transfer
equipment to prevent back
feed by isolating generator
from electric utility workers.
• When using generator for backup power, notify
utility company.
• Use a ground fault circuit interrupter in any
damp or highly conductive area, such as metal
decking or steel work.
• DO NOT touch bare wires or receptacles.
• DO NOT use generator with electrical cords
which are worn, frayed, bare or otherwise
damaged.
• DO NOT operate generator in the rain or wet
weather.
• DO NOT handle generator or electrical cords
while standing in water, while barefoot, or
while hands or feet are wet.
• DO NOT allow unqualified persons or children
to operate or service generator.
WARNING Exhaust heat/gases could ignite
combustibles, structures or
damage fuel tank causing a fire,
resulting in death, serious injury
and/or property damage. Contact with muffler
area could cause burns resulting in serious injury.
•DO NOT touch hot parts and AVOID hot
exhaust gases.
•Allow equipment to cool before touching.
•Keep at least 5 feet (1.5m) of clearance on
all sides of generator including overhead.

3
CAUTION Excessively high operating speeds
could result in minor injury and/or
generator
damage.
Excessively low speeds impose a heavy load.
•DO NOT tamper with governor spring, links or
other parts to increase engine speeds. Generator
supplies correct rated frequency and voltage
when running at governed speed.
WARNING Unintentional sparking could
cause fire or electric shock
resulting in death or serious
injury.
WHEN ADJUSTING OR MAKING REPAIRS TO
YOUR GENERATOR
•Disconnect the spark plug wire from the spark
plug and place the wire where it cannot contact
spark plug.
WHEN TESTING FOR ENGINE SPARK
•Use approved spark plug tester.
•DO NOT check for spark with spark removed.
NOTICE Improper treatment of generator
could damage it and shorten its life.
•Use generator only for intended uses.
•If you have questions about intended use,
ask dealer or contact local service center.
•Operate generator only on level surfaces.
•DO NOT expose generator to excessive
moisture, dust, dirt, or corrosive vapor.
•DO NOT insert any object through cooling
slots.
•If connected devices overheat
-or electrical output is lost.
-or equipment sparks, smokes, or emits flames.
-or unit vibrates excessively.
To turn them off and disconnect them from
generator
WARNING Starter and other rotating parts
could entangle hands, hair, clothing, or
accessories resulting in serious injury.
•NEVER operate generator without protective
housing or covers.
•DO NOT wear loose clothing, jewelry or
anything that could be caught in the starter
or other rotating parts.
•Tie up long hair and remove jewelry.
•DO NOT modify generator in any way.
NOTICE Exceeding generators wattage/
amperage capacity could damage generator
and/or electrical devices connected to it.
•DO NOT exceed the generator’s wattage/
amperage capacity. See Don’t Overload
Generator in the Operation section.
•Start generator and let engine stabilize
before
connecting electrical loads.
•Turn electrical loads OFF and disconnect
from generator before stopping generator.

4
SECTION 2 — GENERAL INFORMATION
2.1 UNPACKING
•Set the carton on a rigid flat surface.
•Remove everything from carton except
generator.
•Open carton completely by cutting each corner
from top to bottom.
•Leave generator on carton to install wheel kit.
2.1.1 PACKING CONTENTS
1-Owner’s Manual
2-Wheels
1-Handle Assembly
2-Wheel Axle
1-Hardware Bag
(including 1-Spark Plug Socket; 1-Extension
Housing)
The above contents in this manual are for
reference only and do not represent for any
specific model.
2.2 ASSEMBLY
The generator requires some assembly prior to
using it.
2.2.1 ASSEMBLING THE ACCESSORY
KIT
The wheels are designed to greatly
improve the portability of the generator.
NOTE The wheels are Not intended for
over-the-road use.
1. Refer to Figures to install wheels as shown.
•Slide the axle through the frame brackets.
•Slide on the hub, wheel and flat washer, then
insert
the cotter pin through the wheel axle hole.
•Bend the cotter pin tabs outward to lock the pin
in
place.
2. Refer to Figures to install foot as shown.
•Insert an M6 bolt through the rubber bumper
and
insert an M8 bolt through the bottom of the
bumper bracket. Secure the bolt with an M8
flange nut.

SECTION 3 — FEATURES AND CONTROLS
Read this Operator’s Manual and safety rules before operating your generator. Compare
the illustrations with your generator, to familiarize yourself with the locations of various
controls and adjustments. Save this manual for future reference.
14
16
15
10
6
17
12
13
11
1
ENGINE SWITCH
10
MUFFLER
2
VOLTMETER
11
AIR CLEANER
3
AC CIRCUIT BREAKER
12
FUEL VALVE
4
OIL DRAIN PLUG
13
CHOKE LEVER
5
OIL FILL CAP/ DIPSTICK SPARK
14
FUEL GAUGE
6
PLUG
15
FUEL TANK CAP
7
BATTERY
16
FUEL TANK
8
GROUND TERMINAL
17
RECOIL STARTER
9
230 VOLT AC RECEPTACLE
NOTICE
Pictures and drawings used in this manual are for reference only and do not represent any specific model.
5

6
Fuel gauge
Fuel tank cap
Max cap mark
Max oil
Full
Empty
Fuel gauge
SECTION 4 — PREPARATION BEFORE OPERATION
4.1 ADDING ENGINE OIL
Please add properly oil before starting the
generator.Use nonspecial additives. Select
the oil’s Viscosity grade according to the
expected operating temperature (also see
chart).
•Use regular UNLEADED gasoline with the
generator engine. Do not use any fuel with more
than 10% added ethanol, and never use E85 fuel.
•Do not mix oil with gasoline.
•Install fuel cap and wipe up any spilled
gasoline.
Above 40 F, use SAE 30
Below 40 F and down to 10 F, use 10W-30 CAUTION Do not overfill the fuel tank.
Below, 10 F use synthetic 5W-30
Allow space for fuel expansion.
IF the fuel tank is overfilled, fuel
can overflow onto a HOT engine and cause FIRE or
EXPLOSION. If fuel spills, wait until it
evaporates
before starting engine. Check fuel
lines, tank, cap and
fittings frequently for cracks
or leaks. Replace if
necessary.
NOTICE Improper treatment of generator could
damage it and shorten its life. DO NOT attempt crank
or start the engine before it has been properly serviced
with the recommended oil. This could result in an
engine failure.
•Place generator on a flat, level surface.
•Clean area around oil fill and remove oil fill cap /
dipstick. Wipe dipstick clean.
•Slowly fill engine with oil through the oil fill
opening until it reaches the full mark on the
dipstick. Stop filling occasionally to check oil level.
Be careful do not over fill.
•Install oil fill cap and finger tighten securely
•Check engine oil level before starting each time
thereafter.
4.2 ADDING FUEL
DANGER Never fill tank indoors. Never fill
fuel
tank when engine is running
or hot.
Turn generator engine
OFF and allow engine to cool entirely before filling fuel
tank. Avoid spilling gasoline on HOT engine. Keep fuel
away from sparks, open flames, pilot lights, heat, and
other ignition sources. DO NOT light a cigarette or
smoke when filling the
fuel tank. Fuel is highly
FLAMMABLE, and its vapors are EXPLOSIVE.
IMPORTANT: It is important to prevent gum
deposits from forming in fuel system parts such
as the carburetor, fuel hose or tank during storage.
Alcohol-blended fuels (called gasohol), ethanol
or
methanol) can attract moisture, which leads to
separation and formation of acids during storage.
Acidic gas can damage the fuel system. The fuel
should
be emptied before storage of 30 days or longer. See the
“Storage” section. Never use engine or carburetor
cleaner products in the fuel tank as permanent damage
may occur.
4.3 GROUNDING THE GENERATOR
The national Electrical Code requires that the frame
and external electrically conductive part of this
generator be properly connected to an
approved
earth ground.
Dipstick

7
Amps
0 in
Proper grounding of the generator will help
prevent electrical shock in the event of ground
fault condition in the generator or in
connected
SECTION 5— OPERATION
electrical devices. Proper grounding also helps
dissipate static electricity, which often builds up
5.1 STARTING THE ENGINE
In ungrounded devices. WARNING Never start or stop the engine with
WATTAGE REFERENCE GUIDE
electrical devices plugged into the
receptacles AND devices turned on.
Unplug all electrical loads from the unit’s
receptacles before starting the engine.
Make sure the unit is in a level position.
Turn the Engine Switch to “ON” position.
Turn Fuel Switch to ON position
ON
OFF
ON
OFF
Wattage Reference Guide
Tool or Appliance
Running
(Rated)
Watts
Additional
Starting
(Surge)
Watts
Essentials
Light Bulb - 75 watt
75
—
Furnace Fan Blower - 1/2 HP
800
2350
Sump Pump - 1/3 HP
800
1300
Refrigerator/Freezer
700
2200
Water Well Pump - 1/2 HP
1000
2100
Heating/Cooling
Window AC - 10,000 BTU
1200
3600
Humidifier - 13 Gal
175
—
Central AC - 24,000 BTU
3800
11400
Kitchen
Microwave Oven - 1000 Watt
1000
—
Coffee Maker
1000
—
Electric Stove - 8”
2100
—
Toaster
850
—
Family Room
DVD/CD Player
100
—
VCR
100
—
Stereo Receiver
450
—
Color Television - 27 in
500
—
Personal Computer w/17
in monitor
800
—
Other
Security System
500
—
AM/FM Clock Radio
100
—
Garage Door Opener - 1/2 HP
875
2350
Electric Water Heater
4700
11700
DIY/Job Site
Quartz Halogen Work Light
1000
—
Airless Sprayer - 1/3 HP
600
1200
Reciprocating Saw
960
—
Electric Drill - 1/2 HP, 5.
600
900
Circular Saw - 7-1/4 in
1400
2300
Miter Saw - 10 in
1800
1800
Table Planer - 6 in
1800
1800
Table Saw/Radial Arm Saw -
2000
2000
Air Compressor - 1 HP
1600
4500
Start
ON/OFF
Engine
Switch
Fuel Switch
Choker Lever
Recoll
Starter

8
Move engine choke lever to the OFF position.
ON OFF
For Recoil start, firmly grasp the recoil handle and
pull slowly until increased resistance is felt. Pull
rapidly up and away.
Recoil Starter
For electric start, turn and hold key in start
switch
to “start” position until generator starts.
To prolong the life of starter components, DO
NOT hold key in “start” position for more than 15
seconds, and pause for at least 1 minute
between
starting attempts.
When engine starts, move choke lever to 1/2-
CHOKE position until engine runs smoothly and
then fully into ON position. If engine falters,
move choke back out to 1/2- CHOKE position
until engine runs smoothly and then fully into ON
position.
NOTICE If battery is discharged, use manual
starting instructions.
NOTICE If engine fires, but does not continue
to run, move choke lever to the OFF position and
repeat starting instructions.
WARNING Starter cord kickback (rapid
retraction) will pull hand and arm toward engine
faster than you can let go which could cause
broken bones, fractures, bruises, or sprains
resulting in serious injury.
When starting engine, pull cord slowly until
resistance is felt and then pull rapidly to avoid
kickback.
Never start or stop engine with electrical devices
plugged in and turned on.
NOTICE If engine fails to start 3 pulls,
or
if unit shut down during operation,
make sure unit is on a level surface and check for
proper oil level in crankcase. This unit may be
equipped with a low oil protection device. If so,
oil must be checked at proper level for engine
to start and run.
WARNING Exhaust heat/ gases could
ignite combustible, structures or damage
fuel tank causing a fire, resulting in
death,
serious injury and/or property damage.
Contact
with muffler area could cause burn
resulting in
serious injury.
DO NOT touch hot part and AVOID hot exhaust
gases.
Allow equipment to cool before touching.
Keep at least 5 feet (152 cm) of clearance on all
sides of generator including overhead.
Contact the original equipment manufacturer,
retailer, or dealer to obtain a spark arrester
designed for the exhaust system installed on this
engine.
Replacement parts must be the same and installed
in the same position as the original parts.
Start
ON
OFF

9
IMPORTANT Do not overload the generator.
Also, do not overload individual panel
receptacles. These outlets are protected against
overload with push-to-reset-type circuit breakers.
If amperage rating of any circuit breaker is
exceeded, that breaker opens and electrical
output
to that receptacle is lost.
5.2 CONNECTING ELECTRICAL
LOADS
•Let engine runs stable and warm up for a
few minutes after starting.
•Plug in and turn on the electrical loads.
•Add up the rated watts (or amps) of all loads
to be connected at one time. This total should
not be
greater than (a) the rated
wattage/amperage
capacity of the generator or
(b) circuit breaker
rating of the receptacle
supplying the power.
NOTICE Start generator and let engine
stabilize before connecting electrical loads.
Connect electrical loads in OFF position then turn
ON for operation.
Turn electrical loads OFF and disconnect from
generator before stopping generator.
NOTICE Exceeding generators wattage/
amperage capacity could damage generator
and/or electrical devices connected to it. DO
NOT exceed the generator’s
wattage/amperage
capacity.
•Overloading a generator in excess of it
rated
wattage capacity can result in damage
to the
damage to the generator and to
connected
electrical devices. Observe the
following to
prevent overloading the unit:
•Add up the total wattage of all electrical devices
to be connected at one time. This total should
NOT be greater than the generator’s wattage
capacity.
The rated wattage of lights can be taken from
light bulbs. The rated wattage of tools,
appliances
and motors can usually be found on
a data label
or decal affixed to be the device.
If the appliance, tool or motor does not give
wattage, multiply volts times ampere rating to
determine watts (volts× amps = watts).
Some electric motors, such as induction types,
require about three times more watts of power
for starting than for running. This surge of
power lasts only a few seconds when starting
such motors. Make sure to allow for high
starting
wattage when selecting electrical
devices to connect to the generator:
•Figure the watts needed to start the
largest
motor.
•Add to that figure the running watts of all
other
connected loads.
The wattage reference guide is provided to assist
in determining how many items the generator
can operate at one time.
5.3 STOPPING THE ENGINE
Shut off all loads then unplug the electrical loads
from generator panel receptacles. Never start or
stop the engine with electrical devices plugged in
and turned on.
Let engine run at no-load for several minutes
to
stabilize the internal temperatures of engine
and generator.
Move ON/OFF switch to OFF position. Close
fuel valve.
5.4 LOW OIL LEVEL SHUTDOWN
SYSTEM
The engine is equipped with a low oil level
sensor that shuts down the engine automatically
when the oil level drops below a specified level.
If the engine shuts down by itself and the fuel
tank has enough gasoline, check engine oil
level.
5.5 HIGH ALTITUDE
At altitudes over 5,000 feet (1524 meters), a
minimum 85 octane / 85 (89 RON) gasoline is
acceptable. To remain emissions compliant, high
altitude adjustment is required. Operation
without
this adjustment will cause decreased
performance, increased fuel consumption, and
increased emissions. See an authorized dealer
for high altitude adjustment information.
Operation
of the engine at altitudes below 2,500
feet (762 meters) with the high-altitude kit is not
recommended.

10
SECTION 6 — MAINTENANCE
6.1 MAINTENANCE SCHEDULE
Follow the calendar intervals shown below.
More frequent service is required when
operating in adverse conditions.
6.2.1 GENERATOR MAINTENANCE
Generator maintenance consists of keeping the
unit clean and dry. Operate and store the unit in
a
clean dry environment where it will not be
exposed to excessive dust, dirt, moisture or any
corrosive vapors. Cooling air slots in the
generator must not become clogged with snow,
leaves, or any other foreign material.
Check the cleanliness of the generator frequently
and clean when dust, dirt, oil, moisture or other
foreign substances are visible on its exterior
surface.
CAUTION Never insert any object or tool
though the air cooling slots, even if the engine
is
not running.
6.2 GENERAL RECOMMENDATIONS
The warranty of the generator does not cover
items that have been subjected to operator
abuse
or negligence. To receive full value from
the
warranty, the operator must maintain the
generator as instructed in this manual.
Some adjustments will need to be made
periodically to properly maintain the generator.
All adjustments in the Maintenance section of
this manual should be made at least once each
season. Follow the requirements in the
“Maintenance Schedule”.
NOTE Once a year replace the spark plug
and replace the air filter. A new spark plug and
clean air filter assure proper fuel-air mixture and
help the engine run better and last longer.
NOTE DO NOT use a garden hose to clean
generator. Water can enter the engine fuel
system
and cause problems. In addition, if water
enters
the generator though cooling air slots,
some water
will be retained in voids and crevices
of the rotor and stator winding insulation. Water
and dirt
buildup on the generator internal
windings will
eventually decrease the insulation
resistance of these windings.
6.2.2 TO CLEAN THE GENERATOR
•Use a damp cloth to wipe exterior surfaces
clean.
•A soft, bristle brush may be used to
loosen
caked on dirt, oil etc.
•A vacuum cleaner may be used to pick up loose
dirt and debris.
•Low pressure air (not to exceed 25 psi) may
be
used to blow away dirt. Inspect cooling air
slots
and openings on the generator. These
openings
must be kept clean and unobstructed.
6.2.3 ENGINE MAINTENANCE
DANGER When working on the generator,
always disconnect spark plug wire from spark
plug and keep wire away from spark plug.
First 5 Hours
•Change engine oil
Every 8 Hours or Daily
•Clean debris
•Check engine oil level
Every 25 Hours or Yearly
•Clean engine air filter
Every 50 Hours or Yearly
•Change engine oi1 l
Yearly
•Replace engine air filter
•Service fuel valve
•Service spark plug
•Inspect muffler and spark arrester
•Clean cooling system
1

11
Soak Squeeze Engine oil Squeeze
6.2.4 CHANGING THE OIL
Change the oil after the first eight hours of
operation, then every 50 hours thereafter. If
running this unit under dirty or dusty conditions,
or in extremely hot weather, to change the oil
more often.
Dipstick
Sealing ring
Max level
Drain plug
6.2.6 SPARK ARRESTOR
•Shut off generator and allow the engine and
muffler to cool down completely before servicing
spark arrestor (located on the back of the
muffler).
•Remove the clamp and spark arrestor screen.
•Clean the spark arrestor screen with a
small
wire brush.
•Replace the spark arrestor if it is damaged.
•Installation of the spark arrestor screen is
the
reverse of the removal.
6.3 SERVICE AIR FILTER
CAUTION Hot oil may cause burns.
Allow engine to cool before draining oil. Avoid
prolonged or repeated skin exposure with used
oil. Thoroughly wash exposed areas with soap.
Use the following instructions to change the oil
while the engine is still warm:
•Clean area around oil drain plug.
•Remove oil drain plug from engine and oil fill
plug to drain oil completely into a suitable
container.
•When oil has completely drained, install oil
drain plug and tighten securely.
•Fill engine with recommended oil. (See “Before
Starting the Generator” for oil recommendations).
•Wipe up any spilled oil.
•Dispose of used oil at a proper collection
center.
The engine will not run properly and may be
damaged if using a dirty air filter. Replace the air
filter once a year. Clean or replace more often if
operating under dusty conditions.
•Remove air filter cover.
•Wash in soapy water. Squeeze filter dry in clean
cloth (DO NOT TWIST).
•May drop a bit of engine-oil to avoid ice blocked
during winter season.
•Clean air filter cover before re-installing it.
6.2.5 REPLACING THE SPARK PLUG
Use spark plug F6TC, BPR4ES or Champion
RN14YC.Replace the plug once each year. This
will help the engine start easier and run better.
•Stop the engine and pull the spark plug wire
off of the spark plug.
•Clean the area around the spark plug
and
remove it from the cylinder head.
•Set the spark plug’s gap to 0.70-0.80 mm
(0.028-0.031 in.). Install the correctly gapped
spark plug into the cylinder head and torque to
15 ft/lbs.
Bolt Cover of air cleaner
Cartridge of air cleaner

12
6.4 VALVE CLEARANCE
After the first 50 hours of operation, check the
valve clearance in the engine and adjust
if
necessary.
Important: If feeling uncomfortable about doing
this procedure or the proper tools are not
available, please take the generator to the
nearest
service center to have the valve
clearance
adjusted. This is a very important step
to ensure
longest life for the engine.
6.5 GENERAL
The generator should be started at least once
every seven days and be allowed to run at least
30 minutes. If this cannot be done and the unit
must
be stored for more than 30 days, use the
following
information as a guide to prepare it for
storage.
DANGER NEVER store engine with fuel in
tank indoors or in enclosed, poorly ventilated
areas where fumes may reach an open flame,
spark or pilot light as on a furnace, water heater,
clothes dryer or other gas appliance.
SECTION 7 — STORAGE
It is important to avoid gum deposits from forming
in essential fuel system parts such as the
carburetor,
fuel hose or tank during storage. Also,
experience
indicates that alcohol-blended fuels
(called gasohol, ethanol or methanol) can attract
moisture, which leads to separation and formation
of acids storage. Acidic gas can damage the fuel
system of an engine while in storage.
To avoid engine problems, the fuel system should
be emptied before storage of 30 days or longer,
as follows:
•Remove all gasoline from the fuel tank.
•Start and run engine until engine stops
from
lack of fuel.
•While engine is still warm, drain oil from
crankcase. Refill with recommended grade.
•Remove spark plugs and pour about 1/2 ounce
(15 ml) of engine oil the cylinders. Cover the
spark plug hole with rag. Pull the recoil starter a
couple
times to lubricate the piston rings and
cylinder
bore.
CAUTION Avoid spray from spark plug
holes when cranking engine.
DANGER Drain fuel into approved container
outdoors, away from open flame. Be sure
engine
is cool. Do not smoke.
6.6 OTHER STORAGE TIPS
•Do not store gasoline from one season
to
another.
•Replace the gasoline can if it starts to rust.
Rust
and/or dirt in the gasoline will cause
problems with the carburetor and fuel system.
•If possible, store the unit indoors and cover it
to
give protection from dust and dirt. BE SURE
TO EMPTY THE FUEL TANK.
•If it is not practical to empty the fuel tank
and
the unit is to be stored for some time, use
a
commercially available fuel stabilizer added
to
the gasoline to increase the life of the
gasoline.
•Cover the unit with a suitable protective cover
that does not retain moisture.
DANGER NEVER cover the generator while
engine and exhaust area are warm.
•Install and tighten spark plugs. Do not
connect
spark plug wires.
•Clean the generator outer surfaces. Check
that
cooling air slots and openings on
generator are
open and unobstructed.
•Store the unit in clean, dry place.
•Do not store gasoline from one season
to
another.
•Replace the gasoline can if it starts to rust.
Rust
and/or dirt in the gasoline will cause
problems with the carburetor and fuel system.
•If possible, store the unit indoors and cover it
to
give protection from dust and dirt. BE SURE
TO EMPTY THE FUEL TANK.
•If it is not practical to empty the fuel tank
and
the unit is to be stored for some time, use
a
commercially available fuel stabilizer added
to
the gasoline to increase the life of the
gasoline.
•Cover the unit with a suitable protective cover
that does not retain moisture.
Drain screw

13
CONTACT THE POWERTECH Asia Pacific Inc.,
PRODUCT SERVICE DEPARTMENT AT ([phone] | 09228741679
[email protected]
www.facebook.com/PromateServicePH/
(MAIN) #420 Diamond Warehouse Compound, F Legaspi St., Maybunga Pasig City 1607
(DAVAO) Space 10 & 11 Jin-Long Complex R. Castillo St., Agdao District, Davao City 8000
SERVICE INFORMATION
HOW TO ORDER REPLACEMENT PARTS
Even quality-built equipment such as the
generator you have purchased will need
occasional replacement parts to maintain its
good condition over the years.
To order replacement parts and
consumable parts, please contact Promate
Service (details below) and be ready with
the following information:
1. Model No., Serial No. and all
specifications that are shown on the Model
No./Serial No. plate.
2. Part number or numbers as shown in the
Parts List section.
3. A brief description of the trouble with the
generator.
LIMITED WARRANTY
Warranty Coverage: Powertech Asia Pacific
Inc., (the Company) warrants to the original
retail customer that it will repair or replace,
free of charge, any parts found by the
Company or its authorized service
representative to be defective in material or
workmanship. This warranty covers the cost
of replacement parts and labor for defects in
material or workmanship.
Not Covered:
• Shipping/Handling charges for sending the
product to the Company or its authorized
service representative for warranty service.
Shipping/Handling repaired or replaced
products back to the customer; these
charges must be borne by the customer.
• If a separate operator's manual and
engine warranty from the engine
manufacturer is included with this product,
only that warranty will apply to the engine.
• Damage caused by abuse, accident, the
effects of corrosion, erosion and normal
wear and tear.
• Warranty is void if the customer fails to
install, maintain and operate the product in
accordance with the instructions and
recommendations of the Company set forth
in the owner's manual, or if the product is
used as rental equipment.
• The Company will not pay for repairs or
adjustments to the product, or for any costs
of labor performed without the Company's
prior authorization.
• Consumable parts such as battery, spark
plugs, and air cleaner.
Warranty Period: One (1) year from the date
of purchase on products used solely for
consumer applications, if a product is used
for business or commercial applications,
the warranty period will be limited to ninety
(90) days from the date of purchase.
For warranty service, the customer must
provide dated proof of purchase and must
notify the Company within the warranty
period.
EXCLUSIONS AND LIMITATIONS: THE
COMPANY MAKES NO OTHER
WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED. IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF
MERCHANTABILITY AND OF FITNESS
FOR A PARTICULAR PURPOSE, ARE
HEREBY DISCLAIMED. THE WARRANTY
SERVICE DESCRIBED ABOVE IS THE
EXCLUSIVE REMEDY UNDER THIS
WARRANTY; LIABILITY FOR INCIDENTAL
AND CONSEQUENTIAL DAMAGES IS
EXCLUDED TO THE EXTENT
PERMITTED BY LAW.
This warranty gives you specific legal rights,
and you may also have other rights which
vary from state to state. Some states do not
allow a disclaimer of implied warranties or
the exclusion or limitation of incidental and
consequential damages, so the above
disclaimers and exclusions may not apply to
you.

32082-00167-01
